  • Page 1 OMNIScanner featuring OMNI Fiber t h e f u t u r e o f n e t w o r k t e s t i n g...
  • Page 2 OMNI Scanner LT OMNI Fiber 7IAH /KE@A ENGLISH A Guide to using the Microtest OMNI Scanner to install, manage, and troubleshoot high performance cabling systems as well as multi- and single-mode fiber. OMNI Scanner verifies installed links against all common cabling and network standards including Category 6/Class E and Gigabit Ethernet.

  • Page 3: Table Of Contents

    OMNIFiber MM LED Indicators ..............1 - 10 OMNIFiber SM LED Indicators ..............1 - 10 Attaching the OMNIScanner Fiber Adapters ..........1 - 11 Attaching the Microtest Connector Adapter ........... 1 - 11 Editing With OMNIScanner ................1 - 12 Predefined Lists ..................1 - 12 Editing Numeric Fields with the Spin Control .........
  • Page 4 OMNIScanner User Guide Chapter 3 - Getting Started Fiber Optic Networks .......... 3 - 1 Charging OMNIScanner’s Battery ..............3 - 1 OMNIScanner’s Project Screen ............... 3 - 1 Certification of Fiber Installations ..............3 - 2 Preparation ....................3 - 2 Certification ....................
  • Page 5 OMNIScanner User Guide General Information ..................5 - 3 Twisted Pair Measurements with OMNIScanner ........5 - 5 Wiremap ...................... 5 - 5 Length/Delay ....................5 - 5 NEXT ......................5 - 6 Attenuation ....................5 - 7 Return Loss ....................5 - 8 ELFEXT ......................
  • Page 6 Chapter 12 - Universal Serial Bus Port ............12 - 1 Installing the USB Driver ................12 - 1 Uploading OMNIScanner2 Test Results to the PC ........12 - 3 Downloading Configurations to OMNIScanner2 .......... 12 - 4 Remote Controlling OMNIScanner2 ............12 - 5 Appendix A - Technical Specifications ............

  • Page 7: Chapter 1 - Introduction

    OMNIScanner User Guide Chapter 1 - Introduction The Digital Solution for Fiber and Copper OMNI Scanner is the most advanced hand-held certification and diagnostic tool for the verification of copper links. The Category 7, 6, 5E (Enhanced), 5 and ISO Class F, E, D, and C tester has an extended frequency range of 300 MHz.

  • Page 8: Omnifibertm

    OMNIScanner User Guide OMNIFiber OMNI Fiber transforms OMNI Scanner and OMNIScanner2 into a fiber optic tool for testing and certification of multimode and single-mode fiber premise networks. OMNI Fiber consists of two test heads that attach directly onto OMNI Scanner and OMNI Remote to become a part of each unit. Using the 1-Button Autotest feature, OMNI Fiber measures loss and length over two fibers simultaneously.

  • Page 9: Omniscanner's Display

    OMNIScanner User Guide OMNIScanner’s Display Scanner Display Function 1-2 or 12/36: The paired numbers in the display indicate wire pairs. For example, 1-2 indicates the wire pair of pins 1 and 2. 12/36 indicates two wire pairs tested, the first pair of pins 1 and 2, and the second pair of pins 3 and 6.

  • Page 10: Omniscanner's Keypad

    SWITCH KEY AC ADAPTER USB PORT DB-9 SERIAL MMC CARD CONNECTOR SOCKET (OMNISCANNER2) (OMNISCANNER2) OMNIScanner’s Keypad ON/OFF When turned on OMNI Scanner will display the project screen. Backlight Press the Backlight key to toggle the backlight between its two levels of brightness.
  • Page 11 OMNIScanner User Guide screen. Use the é and ê keys on the keypad to adjust the display con- trast. In addition to contrast adjustments, the screen displays hardware version, software version, serial number information, and the date and time when the unit was last Factory Calibrated. AUTOTEST Autotest Press the Autotest key to run a custom or predefined Autotest.

  • Page 12: Function Keys

    OMNIScanner User Guide Function Keys The functions of the 4 keys vary depending on the current display. The assigned functions are: Setup Measurements Diagnostics Results Edit Delete Save Options Save Save with Graphs Save to MMC Save with Graphs to MMC Copy Project to MMC Copy Results to MMC Erase a letter Clear a field...

  • Page 13: Omniremote's Led Indicators

    OMNIScanner User Guide OMNIRemote’s LED Indicators Color Description PASS Green Overall Autotest Result is PASS Status Green (flashing) OMNIRemote is ready for testing Green (consistent) OMNIRemote is active FAIL Overall Autotest Result is FAIL Circuit Orange Hazard condition is Guard detected.

  • Page 14: When To Use Omniremote

    OMNIScanner User Guide When To Use OMNIRemote Most measurements require the use of OMNI Remote at the far end of the cable. For other measurements, OMNI Remote can be connected, but its use is optional. OMNI Scanner detects the presence of the remote unit and automatically configures it for the measurement to be performed.
  • Page 15 OMNIScanner User Guide OMNI Scanner displays test results for both ends of the link. Press to toggle the display between Scanner and Remote test results. Note: Refer to the graphics in Chapter 2 - Getting Started: Typical Test Configurations for instructions on connecting OMNIScanner and OMNI- Remote for basic link and full channel tests.

  • Page 16: Omnifiber Mm Led Indicators

    OMNIScanner User Guide OMNIFiber MM LED Indicators Color Description 850nm Green OMNIFiber is transmitting at 850 nm 850nm Green (flashing) OMNIFiber is transmitting modulated light at 850 nm 850nm Orange Part 1 of Two Way test completed, switch fibers 1300/ Green OMNIFiber is transmitting 1310nm...

  • Page 17: Attaching The Omniscanner Fiber Adapters

    Attaching the Microtest Connector Adapter OMNI Fiber has one ST-style connector port (TX) and one threaded optical receiver port (RX) which accepts different Microtest connector adapters. Attach the included ST connector adapters to the OMNIFiber RX receiver ports before connecting jumpers.

  • Page 18: Editing With Omniscanner

    OMNIScanner User Guide Editing With OMNIScanner OMNI Scanner includes sophisticated easy-to-use editing methods to accommodate a variety of user-definable items. Different fields have different editing procedures. Please follow the described procedures to make editing with the OMNI Scanner effortless. Note: All editable fields can be easily recognized by their dotted borders. Predefined Lists To quickly and easily select Projects, Autotests, Cables, etc.

  • Page 19: Editing Alphanumeric Fields

    OMNIScanner User Guide Editing Alphanumeric Fields To start the editing procedure for fields that contain alphabetic and numeric characters use the alphanumeric keypad. 1. Use the é or ê arrow keys to move the cursor to the field to be edited. The entire field will be high- lighted in black.

  • Page 20: Technical Support

    OMNIScanner User Guide Technical Support If you have technical questions, you may contact Microtest Technical Support by phone, fax, or e-mail. Note: Before calling Technical Support, please have your Serial number, and the Hardware and Software Version numbers available. See Product Versions section below.

  • Page 21: Product Versions

    OMNIScanner User Guide Product Versions To display the software version #, the hardware version #, the serial #, and the factory calibration data for OMNI Scanner, press and hold the Backlight key. The CONTRAST screen will be displayed, which contains information that you may need to provide when calling Technical Support.
  • Page 22 OMNIScanner User Guide 1 - 16...

  • Page 23: Chapter 2 - Getting Started Twisted Pair Networks

    OMNIScanner User Guide Chapter 2 - Getting Started Twisted Pair Networks Charging OMNIScanner’s Battery In order to operate the OMNI Scanner and OMNI Remote with battery power, the battery must first be charged. Until the charging cycle is com- plete, the units can run with the AC adapter plugged in. (See Appendix B - Batteries for more information about the batteries.) OMNIScanner’s Project Screen OMNI Scanner ’s project screen is designed to allow you to perform all...

  • Page 24: Certification Of Network Installations

    OMNIScanner User Guide Certification of Network Installations OMNI Scanner is designed to efficiently certify cabling installations through its Autotest feature. Test results, test specifications, and cable types are organized into Projects. The Project, its test specifications and cable types are selectable from the OMNI Scanner Project screen. OMNI Scanner contains a number of predefined projects, grouped by test standards, to allow easy and fast operation.

  • Page 25: Setting The Reference

    OMNIScanner User Guide The following sections provide detail on the certification process. Setting the Reference A reference must be set when OMNI Scanner and OMNI Remote are used as a set for the first time. After the initial reference setting, the process should be repeated periodically to ensure unit verification.

  • Page 26: Project Selection

    OMNIScanner User Guide Project Selection A project name must be selected for test result management. Autotests and Cables were previously assigned to a specific project through the use of the OMNI Scanner Configuration utility. (See Chapter 9 - Uploading and Printing for further information about OMNIScanner Configuration.) The Project feature is very useful for grouping test results and eases uploading and sorting of...

  • Page 27: Running An Autotest For Twisted Pair Cabling

    OMNIScanner User Guide Running an Autotest for Twisted Pair Cabling 1. Connect OMNI Scanner to the near end of the twisted pair cable you are testing and connect OMNI Remote to the far end. (See the Typical Test Configurations for Twisted Pair Cabling section in this chapter for more information.) AUTOTEST 2.

  • Page 28: Saving Twisted Pair Autotest Results

    OMNIScanner User Guide Saving Twisted Pair Autotest Results 1. Press (Save) from the AUTOTEST screen to open the SAVE AUTOTEST screen, where the Autotests can be stored into OMNI Scanner ’s memory. 2. The Project: field contains the name of the project.

  • Page 29: Viewing Twisted Pair Autotest Results

    OMNIScanner User Guide selected Save Option. Press (Save) to save the test results to OMNI Scanner’s internal memory. Press (Save with Graphs) to save the test results with their graphs to OMNI Scanner’s internal memory. Note: Saving graphs will reduce the number of Autotests that can be stored.
  • Page 30 OMNIScanner User Guide 2 - 8...
  • Page 31 OMNIScanner User Guide Most Autotest result screens have a retest feature for diagnostic purposes. Press (Retest) to run continuous tests for the same cable. The arrow located on the Retest button will be turning for the duration of the test. Press (Retest) once more to stop the continuous measurement.
  • Page 32 OMNIScanner User Guide The RETURN LOSS and NEXT screens have (Diagnostic) function keys to help you with the interpretation of failed test results. (See Chapter 6 - TDRL and TDNXT for detailed information.) 2 - 10...

  • Page 33: Typical Test Configurations For Twisted Pair Cabling

    Scanner and OMNI Remote with IDC 110 A Link Adapter (110) punch-down blocks. Use the MICROTEST 110 A or B Link Adapter to attach OMNI- Scanner to the 110 Punch Down block. At the other end of the link, use the MICROTEST Link Adapter to attach OMNI Remote to the Modular 8 jack.

  • Page 34: Full Channel With Modular 8 Jacks

    110 Block Modular 8 Jack For cables terminated with a modu- lar 8 plug, use the supplied modular User Cable 8 MICROTEST Channel Adapter* Cat 5/5E/6 Channel Adapter and attach OMNI Scanner and OMNI Remote to the channel patch cords.

  • Page 35: Chapter 3 - Getting Started Fiber Optic Networks

    OMNIScanner User Guide Chapter 3 - Getting Started Fiber Optic Networks Charging OMNIScanner’s Battery In order to operate the OMNI Scanner and OMNI Remote with battery power, the battery must first be charged. Until the charging cycle is complete, the units can run with the AC adapter plugged in.

  • Page 36: Certification Of Fiber Installations

    OMNIScanner User Guide Certification of Fiber Installations OMNI Scanner and OMNI Fiber are designed to efficiently certify fiber optic cabling installations through the Autotest feature. Test results, test specifi- cations, and cable types are organized into Projects. The Project, its test specifications and cable types are selectable from the OMNI Scanner Project screen.

  • Page 37: Setting The Reference For Fiber Optic Cabling

    Since the reference value expires each day at midnight, a refer- ence must be established least once each calendar day that the OMNI- Fiber is used. 1. Attach the Microtest connector adapters to each of the OMNIFiber RX ports. 2. To set the reference value, connect the OMNI- Fiber Main and OMNI Fiber Remote using launch cables (jumpers) and couplers.

  • Page 38: Project Selection

    OMNIScanner User Guide cables remain attached to the fiber adapters’ TX (transmit) ports so that the connections are not disturbed. 6. Once the reference value has been set, OMNI- Scanner will display the FIBER INFO screen. 7. Press ESC to return to the SETUP screen. Project Selection A project name must be selected for test result management.

  • Page 39: Running An Autotest For Fiber Optic Cabling

    OMNIScanner User Guide The Adapter: field will automatically change to reflect that OMNI Fiber is currently attached. OMNI Scanner auto-senses the adapter. If the adapter is changed, OMNI Scanner will automati- cally adjust the content in the fields Autotest: and Cable: to reflect the new setup. Every Project has certain Autotests and cables assigned already.

  • Page 40: Jumper Method Autotest

    OMNIScanner User Guide 4. Press 1 JUMPER METHOD AUTOTEST To run an Autotest when the 1-Jumper Method was used to set the Refer- ence proceed as follows: 2 m Launch Cable Cable under Test 2 m Launch Cable Wall Plate Patch Panel 1.

  • Page 41: Loopback Autotest Using Omnifiber Main

    OMNIScanner User Guide 2 m Launch Cable 2 m Launch Cable Cable under Test Wall Plate Patch Panel 4. Press Loopback Autotest using OMNI Fiber Main This configuration is used to test single fibers, reels and short cables when both ends of the fiber under test are accessible from the same location. Note: The loopback Autotest assumes that the 2-Jumper Method was used to make the reference measurement.

  • Page 42: Running A Fiber Autotest

    OMNIScanner User Guide Running a Fiber Autotest Some Autotests do not have a fixed loss limit. The Optical Link Budget (OLB) is calculated based on the wavelength, the length of the cable, and the number of connectors and splices. OMNI Scanner will automatically display the CONNECTIONS screen if you are running an equation based Autotest (TIA 568A, ISO 11801, or 1000 Base F).

  • Page 43: Fiber Autotest Results

    OMNIScanner User Guide Fiber Autotest Results Once the Autotest is completed the Autotest screen will be displayed. The arrows at the top of the screen indicate the direction of the light. points to the result measured from OMNIRemote to OMNI Scanner. points out the result measured from OMNI Scanner to OMNI Remote.
  • Page 44 OMNIScanner User Guide 3 - 10...

  • Page 45: Chapter 4 - Setup

    OMNIScanner User Guide Chapter 4 - Setup Configuring OMNIScanner OMNI Scanner’s easy-to-use setup feature allows you to define, edit and preset many items. They are conveniently organized and can be easily accessed by pressing the assigned number on your alphanumeric keypad, or by highlighting the item and then pressing ENTER.

  • Page 46: Set Reference

    OMNIScanner User Guide Set Reference Connect OMNI Scanner and OMNI Remote through their test connector ports using the Link Adapter and the Channel Adapter*. Select Set Refer- ence to display the SET REFERENCE screen. OMNI Scanner will immedi- ately start to communicate with OMNI Remote . *Use the Set Reference Adapter with OMNIScanner LT.

  • Page 47: Autotests

    Select Autotests to display the AUTOTESTS screen. It contains a list of standard Autotest specifications supported by OMNI Scanner . Standards are grouped by TIA, ISO, VENDOR, MICROTEST, IEEE, ATM, and AS/NZ. If there are Autotest specifications in a folder, it will...
  • Page 48 OMNIScanner User Guide The second page shows limits for Resistance, NEXT, Attenuation, and Return Loss. The third page lists limits for ELFEXT, ACR, and Power Sum NEXT measurements. The fourth page shows limits for Power Sum ELFEXT and Power Sum ACR. This screen also informs you whether or not OMNI Remote is required to perform the selected Autotest.

  • Page 49: Cables

    OMNIScanner User Guide µ m fibers. When running an Autotest, OMNIScanner will choose the appropriate Autotest limits based on the selected fiber. Use the function key to view the limits for single-mode fibers. When viewing limits for equation-based Autotests like TIA 568B, ISO 11801, and 100Base-F, the Loss per km (kilometer) will be displayed.
  • Page 50 OMNIScanner User Guide If you cannot find or do not know the name of your cable manufacturer, simply select a cable from the Generic folder, or create a new cable. Press (Delete) to permanently remove a custom cable. Note: Default cables cannot be removed. With a twisted pair or a coaxial cable highlighted, press...

  • Page 51: Projects

    Select Projects to display the PROJECTS screen. It contains a list of all projects that are currently stored in OMNI Scanner . Predefined default projects are: TIA, ISO/IEC, VENDOR, Microtest, IEEE, ATM, AS/NZ, ANSI. OMNI Scanner ’s project feature allows you to organize test specifications, cables types, and test results into Projects.

  • Page 52: Editing A Circuit Id

    Circuit IDs. Each character can be incremented. The example shows how to quickly create an incremental Circuit ID. Enter MT-F01 (MICROTEST - Floor 01) -PP01 (- Patch Panel 01) -P01 (- Position 01) in the First Circuit ID: field.
  • Page 53 Press ENTER to terminate the edit mode. Use the ê to highlight the Last Circuit ID: field and press ENTER. Enter MT-F12 (MICROTEST - Floor 12) -PP02 (- Patch Panel 02) -P48 (- Position 48) in the Last Circuit ID: field. Press ENTER to terminate the edit mode.

  • Page 54: Configurations

    It contains the following projects: TIA, ISO/IEC, VENDOR, Microtest, IEEE, ATM, AS/NZ, ANSI. OMNIScanner2 only: Use the é or ê arrow key to highlight a specific Configuration. Press (Set Default) to select it as the Configuration to be used and to return to the SETUP screen.

  • Page 55: Autotest Save Options

    Select Autotest Save Options to display the SAVE OPTIONS screen. This screen contains several options that allow you to customize the way OMNIScanner will save Autotests. OMNIScanner2 only: Press ENTER to change the Destination: from MMC ) to Internal. Use the éê keys to highlight the desired (MultiMediaCard destination and press ENTER to select it as the default destination.

  • Page 56: User Options

    OMNIScanner User Guide Depending on the performed Autotest, NEXT/PSNEXT, ELFEXT/PSELF- EXT, Return Loss, and Attenuation graphs can be saved. Use the éê to highlight the Save Graph Option checkboxes. Press to select the graph to be saved. Press (Save) your changes and return to the SETUP screen. to save Press ESC to discard the changes and return to the SETUP screen.

  • Page 57: Adapter Usage

    Technical Support. Press ESC to return to the SETUP screen. *OMNI Scanner and OMNI Remote should be calibrated annually with specialized Microtest equipment. Contact Microtest Technical Support for information on calibration and service requirements. 4 - 13...

  • Page 58: Fiber Adapter Info

    OMNIScanner2 only: When using the MultiMediaCard for the first time, it may require formatting. Insert the MMC into OMNIScanner2’s MMC slot. Select Format MMC to open the FORMAT MMC screen. Formatting will start immediately. The formatting time is dependent on the capacity of the MultiMediaCard, 8MB will require 2 minutes.
  • Page 59 OMNIScanner User Guide Use the è to advance to the Date: field. Press ENTER to change the date format. DD is the day setting, MM is the month setting, YY is the year setting. Use the éê keys to highlight the desired format and press ENTER to select it as the default date format.
  • Page 60 OMNIScanner User Guide 4 - 16...

  • Page 61: Chapter 5 - Measurements

    OMNIScanner User Guide Chapter 5 - Measurements Note: The list of tests in the Measurement screen changes depending on the adapter that is currently attached to OMNIScanner. Performing Individual Measurements with OMNIScanner OMNI Scanner allows you to perform tests on twisted pair, fiber optic and coaxial cabling.

  • Page 62: Measuring Fiber Optic Cabling

    OMNIScanner User Guide Measuring Fiber Optic Cabling With the OMNI Fiber adapter attached, press the (Measurements) function key to display the MEASUREMENTS screen for fiber optic cabling. Measuring Coaxial Cabling With the coax adapter attached, press the (Measurements) function key to display the MEASUREMENTS screen for coaxial cabling. Selecting an individual Test Highlight the test you want to perform using the é...

  • Page 63: General Information

    OMNIScanner User Guide General Information Most test result screens have a retest feature for diagnostic purposes. Press (Retest) to run continuous tests for the same cable. Press (Retest) once more to stop the continuous measurement. OMNI Scanner will display the last measured data. Tests that require the use of OMNI Remote will have small icons in the upper right corner of the titlebar indicating whether the information on the screen is OMNI Scanner or...
  • Page 64 OMNIScanner User Guide Use the ç or è keys to move the cursor within the graph. Use the cursor to display values for the desired frequency. 5 - 4...

  • Page 65: Twisted Pair Measurements With Omniscanner

    OMNIScanner User Guide Twisted Pair Measurements with OMNIScanner Wiremap The Wiremap function tests twisted-pair cabling for proper wiring. Your cabling configuration is checked for shield continuity, opens, shorts, crossed pairs, split pairs, and reversed pairs. For each pair, Wiremap displays the length.

  • Page 66: Next

    OMNIScanner User Guide Delay is a measure of the time required for a pulse to travel from one end of the link to the other. OMNI Scanner measures the delay from when the pulse was sent to when the reflection was received. Knowing the speed that the pulse propagates down the cable (NVP), OMNI Scanner then calculates the length of the cable.

  • Page 67: Attenuation

    OMNIScanner User Guide compared to the transmitted signal and the difference is reported as the NEXT value in dB. When measuring the NEXT for the OMNI Remote end, the roles of the two units are reversed. OMNI Scanner provides the termination; OMNI Remote transmits and measures the signal.

  • Page 68: Return Loss

    OMNIScanner User Guide The pairs are displayed in the column on the left side, followed by the Attenuation in decibels (dB), the Attenuation margin/limit values, and the frequency. The result for each pair is tagged with a PASS , Marginal PASS , Marginal FAIL , or FAIL...

  • Page 69: Elfext

    OMNIScanner User Guide displayed for the frequency indicated by the cursor position. Press (Pairs) to view Return Loss graphs for other pairs. Press (Diagnostics) to display the TDRL screen, where cabling and/or connection faults can be identified. (See Chapter 6 - Diagnostics: Using TDRL to diagnose a Link for further information.) Press ESC to exit the RETURN LOSS screen.

  • Page 70: Acr/Bandwidth

    OMNIScanner User Guide Press (Pairs) to view ELFEXT graphs for other pair combinations. Press ESC to exit the ELFEXT screen. ACR/Bandwidth Attenuation to Crosstalk Ratio (ACR) is an indication of how much larger the received signal is compared to the Near End Crosstalk (NEXT) on the same pair.

  • Page 71: Resistance

    OMNIScanner User Guide Resistance Resistance is measured in a loop through each pair in the cable. In a twisted pair cable, Resistance is measured by using OMNI Remote to short the far end of the pair under test. The RESISTANCE screen displays the Resistance Limit and the test results in Ohms for each pair.

  • Page 72: Power Sum Elfext

    OMNIScanner User Guide Press (Pairs) to view PSNEXT graphs for other pairs. Press ESC to exit the POWER SUM NEXT screen. Power Sum ELFEXT Power Sum ELFEXT is calculated from the summation of the individual ELFEXT effects on each pair by the other three pairs. In the POWER SUM ELFEXT screen, the worst case margin for all near and far pairs is shown at the top of the screen.

  • Page 73: Power Sum Acr

    OMNIScanner User Guide Power Sum ACR Power Sum ACR is calculated from the Attenuation of the disturbing pair subtracted from the Power Sum NEXT for the pair. The worst case Power Sum ACR is reported for each pair. The POWER SUM ACR screen displays the pairs in the column on the left side, followed by the PSACR in decibels (dB), the margin/limit, and the frequency.

  • Page 74: Fiber Optic Measurements With Omnifiber

    OMNIScanner User Guide Fiber Optic Measurements with OMNIFiber Length/Delay The Length/Delay function measures a fiber’s length and propagation delay. Length measurements are derived from the propagation delay results using the GRI (Graded Refractive Index) at the appropriate wavelength. Propagation Delay is the measure of the time required for a signal to ad- vance from one end of the link to the other.

  • Page 75: Power Meter

    OMNIScanner User Guide Power Meter The Power Meter function reports the overall received power. Use it to quickly verify and correct cabling and equipment problems. The POWER METER screen shows the currently selected wavelength and light source mode. The overall power is displayed. OMNI Fiber main is designed to provide a consis- tent, calibrated light source for effectively measuring signal loss in fiber optic cables.

  • Page 76: Coaxial Measurements With Omniscanner

    Tracer/Toner is a cable tracing function that assists in tracking cables hidden in walls, ceilings, floors, or patch panels by generating a signal that can be converted into an audible tone by Microtest’s Cable Tracer II (sold separately) or any other equivalent tracing device.
  • Page 77 OMNIScanner User Guide weaken the signal. A multi-tone trace signal will begin transmitting. To enhance the signal, insert a grounding plug into the ground jack located left of the DB-9 Serial Connector. A grounding plug is included in the optional Cable Tracer II kit;...
  • Page 78 OMNIScanner User Guide 5 - 18...

  • Page 79: Chapter 6 - Diagnostics

    OMNIScanner User Guide Chapter 6 - Diagnostics OMNIScanner’s Diagnostic Functions OMNI Scanner has several advanced diagnostic test functions to help you with the identification of network cabling faults. Diagnostics allows you to locate opens, breaks, and short circuits as well as NEXT and Return Loss cabling faults in twisted pair cabling.

  • Page 80: Wiremap Displays

    OMNIScanner User Guide For each of the 8 conductors and the Shield, Wiremap can indicate proper pin termination on each end, continuity to OMNI Remote , shorts between any two or more conductors, crossed pairs, reversed pairs, split pairs, and any other miswiring.

  • Page 81: Tdnxt

    OMNIScanner User Guide SPLIT PAIRS: If a cable is wired correctly, pin-to-pin, but there is a split pair, Wiremap displays Split Pairs and highlights the pins in error. In our example, one wire from the 4-5 pair is twisted with one wire in the 7-8 pair. The Split Pair will be highlighted with reversed numbers.

  • Page 82: Using Tdnxt To Diagnose A Link

    OMNIScanner User Guide to select which end, OMNI Scanner or OMNI Remote, you want to view the results for. Press to open the TDNXT screen. The screen displays the TDNXT (Time Domain NEXT) graph. The funnel- like lines are the upper and lower S-Bands. S-Bands are limit lines for connections as a function of distance from the cable end.

  • Page 83: Tdnxt Examples

    OMNIScanner User Guide If failures occur at both ends of the link, use to diagnose each end. Failures at both ends of the link can interact. TDNXT Examples The following examples show the diagnostics process that is performed to identify failures on typical links with 2 meter test cables. GOOD CABLE, BAD CONNECTION: The cursor in the NEXT graph is located at the worst NEXT at 144.0 MHz, which is outside the...

  • Page 84: Tdrl

    OMNIScanner User Guide NEXT in the cable is the source of the failure even though the cable’s NEXT response peaks are less than those of the connection. By knowing that the connection meets its perfor- mance requirement, the cable is easily identi- fied as the non-compliant component of the link.
  • Page 85 OMNIScanner User Guide S-Bands™ provide a time domain limit to verify that the connections are within the desired category of performance. In a typical link, failures are a result of either a non-compliant connection or a faulty cable. The ability to determine if a connection meets the expected performance requirement significantly simplifies the diagnosis of a failure.

  • Page 86: Using Tdrl To Diagnose A Link

    OMNIScanner User Guide Using TDRL to Diagnose a Link S-Bands provide an easy method to pinpoint if the fault is located at the connection or at the cable. The S-Bands allow you to determine if the connections in a link meet the desired performance level. They are de- signed to match the standard category of the selected Autotest.
  • Page 87 OMNIScanner User Guide BAD CABLE, GOOD CONNECTION: The cursor in the Return Loss graph is located at the worst Return Loss at 110.4 MHz, which is outside the limit line. The Link failed. Why? Press to open the TDRL screen to further review and diagnose the graph.

  • Page 88: Impulse Noise

    OMNIScanner User Guide Impulse Noise Noise is undesirable electrical energy that falls within the typical network frequency bands of operation (generally 1-20 Mhz). It interferes with a network’s ability to transmit data reliably. Noise sources may include AC transmission lines, fluorescent light fixtures, industrial equipment, eleva- tors, etc.

  • Page 89: Cable Trace

    Tracer/Toner is a cable tracing function that assists in tracking cables hidden in walls, ceilings, floors, or patch panels by generating a signal that can be converted into an audible tone by Microtest’s Cable Tracer II (sold separately) or any other equivalent tracing device.
  • Page 90 OMNIScanner User Guide OMNI Scanner will identify office locations and display the ID of the Office Locator adapter found at the far end of the attached cable. If you are testing a cable that does not have an Office Locator attached at the other end, OMNI- Scanner will display a question mark.

  • Page 91: Chapter 7 - Results

    OMNIScanner User Guide Chapter 7 - Results Autotest Results To view previously saved Autotests, press the (Results) function key. The RESULTS screen displays Project names together with the number of Autotests that are stored within each project. In the bottom row you will find the total number of Autotests currently stored in OMNI Scanner ’s memory.

  • Page 92: Viewing Autotest Results

    OMNIScanner User Guide another project or to change the Circuit ID. Press ENTER with the Project: highlighted to reveal a list of all projects that are currently stored. Use the éê to highlight the project you want to store the Autotest within, and press ENTER to select it.
  • Page 93 OMNIScanner User Guide For Twisted Pair Cabling: The Autotest Results screen will be displayed. The name of the Autotest, the cable that was used to run the test, and the overall test result (PASS or FAIL) are shown. All measurements that were performed during the Autotest are listed in the left column.

  • Page 94: Results Stored On A Multimediacard

    OMNIScanner User Guide indicate the Method used to set the reference. (See Chapter 8 - Fiber Optic Reference for further information.) When dual fiber is measured, arrows at the top of the screen point out the direction of the light. The arrows also indicate the fiber that the (PASS) or (FAIL) result is for.

  • Page 95: Chapter 8 - Fiber Optic Reference Methods

    OMNIScanner User Guide Chapter 8 – Fiber Optic Reference Methods Establishing the Reference Different methods can be used when making a reference measurement with OMNI Fiber. The reference measurement to use depends on how the standard defines the link, and how the network is interconnected. There are three basic link definitions and three corresponding reference methods.

  • Page 96: The Launch/Jumper Cable

    The Reference Methods For testing of networks with different connector styles, please consult the Microtest web site (http://www.microtest.com/support/techbulletins/). It is very important that the transmitter (TX port) connections are not dis- turbed after the reference value is established. Note: When a connector is removed and then reattached, it is unlikely to go back into the exact same position.

  • Page 97: One Jumper Reference Method

    OMNIScanner User Guide One Jumper Reference Method This method is used when the link includes: • the loss of one connection at the near end cross connect • the loss of one connection at the far end cross connect/outlet • the loss of the cable plant TIA/EIA -568-A, ISO 11801, and IEEE 802.3 (100 Base-X, 1000Base-X) specify the one jumper method.

  • Page 98: Two Jumper Reference Method

    OMNIScanner User Guide Two Jumper Reference Method This method is used when the link includes: • the loss of one connection at the near or far end cross connect • the loss of the cable plant TIA/EIA -455-171and IEEE 10 Base-X specify the two jumper method. Note: This method is called ‘Method A’...

  • Page 99: Three Jumper Reference Method

    OMNIScanner User Guide Three Jumper Reference Method This method is used when the link includes: • the loss of the cable plant Note: This method is called ‘Method C’ in TIA-526-14A and ‘Method A.3’ in TIA-526-7. 2 m Launch Cable 2 m Launch Cable 2 m Launch Cable Couplers...

  • Page 100: Two Jumper Reference Method In Loopback Mode

    OMNIScanner User Guide Two Jumper Reference Method in Loopback Mode The OMNI Fiber Main can be used without the remote to make measure- ments on a single fiber. In this state the TX fiber is looped back to the RX port of the same OMNI Fiber adapter.

  • Page 101: Chapter 9 - Uploading And Printing

    The Getting Started Guide together with the software is part of the Scanlink Tools CD that is included with OMNI Scanner. Scanlink Tools are also available for download from the Microtest web site at www.microtest.com. 9 - 1...
  • Page 102 OMNIScanner User Guide 9 - 2...

  • Page 103: Chapter 10 - Updating Scanner Software

    Downloading Software from the Microtest WWW site Software updates can be easily downloaded from the Microtest World Wide Web site. If you are connected to the Internet, you can access our web site by entering http://support.microtest.com in the URL address field.
  • Page 104 OMNIScanner User Guide 2. Plug the AC adapter into OMNI Scanner . Test Cable 3. Connect OMNI- Scanner and OMNI- Remote using the provided test cable AC Adapter AC Adapter Com 1 and adapter. or Com 2 4. Plug the AC adapter into OMNI- Remote .

  • Page 105: Chapter 11 - Multimediacard

    OMNIScanner User Guide Chapter 11 - MultiMediaCard The MultiMediaCard is the world’s smallest solid state storage device. It weighs less than two grams and is the size of a postage stamp (32mm high by 24mm wide and 1.4mm thick). The card is available in 8MB, 16MB, and 32MB capacities.

  • Page 106: Multimediacard Maintenance

    OMNIScanner User Guide MultiMediaCard Maintenance Multi Media Flash memory cards store data just like a PC stores data on the hard disk. Saved files are broken into segments and stored in any free segment of the multi media flash memory card. Prior to the initial use, the MMC may require formatting.

  • Page 107: Chapter 12 - Universal Serial Bus Port

    Configuration and OMNIScanner Remote Control. (See Chapter 9 - Uploading and Printing for more information.) Installing the USB Driver Note: OMNIScanner2 supports high speed USB connections. Please use only high-speed USB cables. Make sure the length of the cable does not exceed 5 meters (1m recommended).
  • Page 108 Rom drive to start the search for the USB driver. Click Next > to continue. Next, Windows will detect the location of the file OMNIScanner2 USB. Click Next > to install the driver file. Once windows has finished installing the driver, OMNI- Scanner2 USB will appear in your PC’s driver list.

  • Page 109: Uploading Omniscanner2 Test Results To The Pc

    Uploading OMNIScanner2 Test Results to the PC 1. To send test results from OMNI Scanner2(s) to a PC, first turn your PC on. 2. Connect the PC with OMNIScanner2 via the high-speed USB cable. 3. Turn on OMNI Scanner2 4. Run the Scanlink software and click on the (Upload) button in the toolbar, or select Upload in the File menu.

  • Page 110: Downloading Configurations To Omniscanner2

    To review collected Autotest data, select the items to be viewed, then select View Autotest from the View menu. (Consult the Scanlink on-line help for further information.) Downloading Configurations to OMNIScanner2 1. To download Configurations from OMNIScanner Configuration software to one or several OMNI Scanner2s, first turn your PC on.

  • Page 111: Remote Controlling Omniscanner2

    Project screen. (Consult the OMNIScanner Configuration on-line help for further information.) Remote Controlling OMNIScanner2 1. To remote control OMNI Scanner2 , first turn your PC on. 2. Connect OMNIS canner2 and OMNI Remote via the link to be tested.
  • Page 112 OMNIScanner User Guide 12 - 6...

  • Page 113: Appendix A - Technical Specifications

    OMNIScanner User Guide Appendix A - Technical Specifica- tions Specifications apply to both OMNI Scanner and OMNI Remote unless otherwise noted. Physical Characteristics OMNI Scanner • Dimensions: 8.75” x 4.50” x 2.12” (22.25 cm x 11.4 cm x 5.4 cm) •...

  • Page 114: Serial Port

    OMNIScanner User Guide OMNI Fiber MM LED Displays • 850 nm Indicator (GREEN) for transmitting at 850 nm • 1300 nm Indicator (GREEN) for transmitting at 1300 nm • 850 nm Indicator (ORANGE) for switching fibers • 1300 nm Indicator (ORANGE) for switching fibers OMNI Fiber SM LED Displays •...
  • Page 115 OMNIScanner User Guide Universal Serial Bus • Type Self Powered Device • Link 12 MB/s Full Speed Bulk Transfer with two 128 byte FIFOs and Automatic Retry • Connector Type ‘B’ Receptacle • Recommended Cable Full Speed Shielded Twisted Pair with A-B Plugs (USB V1.1 Complaint) MultiMediaCard Interface •...
  • Page 116 OMNIScanner User Guide • Attenuation • ELFEXT (Equal Level FEXT) • ACR (Attenuation to Crosstalk Ratio) • Bandwidth • Length/Delay • Resistance • Power Sum NEXT, ACR and ELFEXT • Coax Tests: Length, Delay, Impedance, Resistance OMNI Fiber Test Functions •...
  • Page 117 OMNIScanner User Guide NEXT • Test all six pair combinations from both directions using OMNI Remote • Frequency Range: 1 to 300 MHz • Dynamic Range: >100dB • Measurement Accuracy: Calculated per TIA error model • Accuracy: Significantly exceeds Level III requirements •...
  • Page 118 OMNIScanner User Guide Length • Range: 0 to maximum distance, where max. distance = 457 m (1500 ft.) for twisted pair cable • Accuracy: ± K ± Length resolution ± NVP uncertainly, where K = ± 4% of length or 0.6 m (2ft.), whichever is greater. Length resolution: 0.3 m (1ft.) Resistance •...
  • Page 119 OMNIScanner User Guide High Voltage Input Protection • The test interface withstands input hazard conditions that arise from normal telephone interfaces (48 VDC at less than 80 mA) or 24 VAC power used to power many telephone keysets. The unit detects when a voltage of greater than ±15 volts is applied on the inputs and sounds a warning to alert the user to remove the hazard condition immediately to prevent possible damage to the input circuits.
  • Page 120 OMNIScanner User Guide A - 8...

  • Page 121: Appendix B - Batteries

    OMNIScanner User Guide Appendix B - Batteries Battery Packs OMNI Scanner and OMNI Remote are powered by rechargeable, recyclable battery packs. Under various state and local laws, it may be illegal to dispose of this battery pack into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

  • Page 122: Battery Charging

    (See Chapter 1 - Introduction: OMNIScanners Keypad: Backlight) • Average daily life of the battery pack is about ten hours. • An external charger is also available. Contact your Microtest distributor for details on the external charger, Microtest Part Number 8003-01. B - 2...

  • Page 123: Appendix C - Omnifiber Pass/Fail Criteria

    OmniScanner User Guide Appendix C - OMNIFiber PASS/FAIL Criteria For the latest cable installation, international standards, and conformance techniques: http://cabletesting.com/Fiber_Standards.html Formula 1: 568A Equation for 850nm fiber: (# of mated connections x 0.75) + (# of splices x 0.3) + (length x 3.75dB/1000m) = OLB* Formula 2: 568A Equation for 1300nm fiber: (# of mated connections x 0.75) + (# of splices x 0.3) + (length x 1.5dB/1000m) = OLB* Formula 3: 11801 Equation for 850nm fiber:...
  • Page 124 OmniScanner User Guide C - 2...

  • Page 125: Appendix D - Cable Pin-Outs

    OmniScanner User Guide Appendix D - Cable Pin-Outs Described below are the functions of the electronic signals transmitted through each pin in a connector. Serial Cable DB-9 Male to DB-9 Female Pin-outs DB-9 Male DB-9 Female Serial Cable DB-9 Male to DB-25 Female Pin-outs DB-9 Male DB-25 Female D - 1...

  • Page 126: Cable Pin-Out Signals

    OmniScanner User Guide Cable Pin-Out Signals The signals for the cable pin-outs are as follows: DB-9 DB-25 DB-9 Male Female Female Signal Signal Description Protective Ground Transmitted Data Received Data Request to Send Clear to Send DataTerm Ready Data Set Ready Received Line Signal Detector Ring Indicator D - 2...
  • Page 127 OMNIScanner User Guide Index Symbols Date format 4 - 15 2KHz Modulated Mode 5 - 15 Decimal Separator 4 - 15 Delay 5 - 5 Delete Test Results 7 - 1 Abort on Fail 4 - 10, 4 - 11 Detail 2 - 9, 6 - 10 ACR 5 - 10 Diagnostic Functions 6 - 1...
  • Page 128 OMNIScanner User Guide Hardware 4 - 13 Office Locator 6 - 11 OLB C - 1 OMNIFiber MM 1 - 10 OMNIFiber SM 1 - 10 IDC (110) block 2 - 11 OMNIRemote 1 - 8 Impedance 4 - 6, 5 - 8 Opens 5 - 5 Impulse Noise 6 - 10 Optical Link Budget C - 1...
  • Page 129 OMNIScanner User Guide S-Band 6 - 3 View Autotest Detail 4 - 4 S-Band techology 6 - 6 View fiber optic cable results 7 - 3 SAVE AUTOTEST 2 - 6 View twisted pair cable results 7 - 3 Save Graph Options 4 - 11 Viewing Autotest Results 2 - 7, 7 - 2 Save Graphs 7 - 3 Save Graphs to MMC 7 - 3...
  • Page 130 OMNIScanner User Guide Index - 4...
  • Page 131 Microtest, Inc. Microtest, Inc. makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Microtest, Inc. shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance or use of this material.
  • Page 132 OMNI Scanner, OMNI Remote and OMNIFiber are registered trademarks of Microtest, Inc., PentaScanner is a registered trademark of Microtest, Inc., CertiFiber is a registered trademarrk of Microtest, Inc., Microtest is a registered trademark of Microtest, Inc., ScanLink is a registered trademark of Microtest, Inc., Windows and MS-DOS are trademarks of Microsoft Corporation.
  • Page 133 t h e f u t u r e o f n e t w o r k t e s t i n g...

This manual is also suitable for:

Omniscanner ltOmnifiber

Table of Contents

Save PDF
