SnowDogg 16071120 Installation Instructions

SnowDogg

installation instRUCtions

SWITCHED GROUND
NOTE: The 16071120 Headlight Adapter is only for use with HB5 headlights. HB1 headlights use the
same connector, but require a 16071130 adapter. Always check the application guide and your bulb
marking before installation.
INSTRUCTIONS
Always verify that all truck lights are functioning correctly before beginning any installation.
FOR DODGE SPORT APPLICATION – use the OUTBOARD headlamps
1. Disconnect both PS and DS side truck headlights from the truck headlight harnesses.
2. Connect the 16071120 adapters to the truck headlights and truck headlight harnesses.
3. Connect the 16071120 adapters to the 8-pin RELAY HARNESS connectors.
4. Use an included Tap connector to tap the PURPLE wire into the TURN light circuits on the passenger and
driver sides of the truck.
If the truck is a SWITCHED GROUND INSTALL – skip step 5 and go to the special instructions (on back
of this page).
5. Use an included Tap connector to tap the BROWN wire into the PARK light circuits on passenger and driver
sides of the truck.
6. Check all light functionality before operating the plow.
Snowplow Headlight Adapter
®
16071120
HB5/9007 DODGE
FORD
JEEP
NISSAN
DODGE
HB5/9007
If your application is not shown here, contact your dealer for further assistance
Toll-Free Fax 800-841-8003 • snowdoggplows.com
HB5
2000-2004 Dakota
2002-2005 RAM 1500
2003-2005 RAM 2500/3500
1998-2011 Ranger
1995-2001 Explorer
2001-2003 Explorer Sport
2001-2006 Explorer Sport Trac
1997-2002 Ford Expedition
1997-2003 F150
1997-1999 F250LD
1992-1997 F250HD/F350/SD
1999-2004 F250SD/F350/F450/F550
2003-2007 Liberty
2005-2012 Frontier/Pathfinder
1999-2001 RAM 1500 - QUAD/SPORT
1999-2002 RAM 2500/3500 - QUAD/SPORT
9049 Tyler Blvd. • Mentor, Ohio 44060
Phone (440) 974-8888 • Fax (440) 974-0165
—continued on back
