Touch Sensitive Remote Control
THIS WARRANTY IS NOT TRANSFERABLE, AND,
TO THE MAXIMUM EXTENT PERMITTED BY
Model LZ6220
APPLICABLE LAW, IS IN LIEU OF ALL OTHER
WA R R A N T I E S , R E P R E S E N T AT I O N S A N D
16 Function Universal Remote Control
C O N D I T I O N S , E X P R E S S O R I M P L I E D ,
With Touch Sensitive Keypad
STATUTORY OR OTHERWISE, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF
M E R C H A N T A B I L I T Y A N D F I T N E S S F O R A
Installation Guide
PARTICULAR PURPOSE. NO OTHER PERSON OR
REPRESENTATIVE IS AUTHORIZED TO MAKE
ANY OTHER WARRANTY ON BEHALF OF ECP OR
ASSUME FOR ECP ANY OTHER LIABILITY IN
C O N N E C T I O N W I T H T H E S A L E O F T H I S
PRODUCT. IN NO EVENT WILL ECP BE LIABLE
FOR ANY DAMAGES, INCLUDING BUT NOT
L I M I T E D T O I N C I D E N TA L , S P E C I A L O R
CONSEQUENTIAL DAMAGES ARISING OUT OF
THE USE OR INABILITY TO USE THE PRODUCT,
I N C L U D I N G D A M A G E S D U E T O E C P ' S
NEGLIGENCE.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE
AND COUNTRY TO COUNTRY .
La-Z-Boy is a Trademark of La-Z-Boy Incorporated and
is used under license to
Elexa Consumer Products, Inc.
©
2008
6200 N. Hiawatha Ave, 8th Floor Chicago, IL 60646
31
95 x 190mm

Advertisement

loading
Need help?

Need help?

Do you have a question about the LZ6220 and is the answer not in the manual?

Questions and answers

Summary of Contents for LAZBOY LZ6220

  • Page 1 THIS WARRANTY IS NOT TRANSFERABLE, AND, TO THE MAXIMUM EXTENT PERMITTED BY Model LZ6220 APPLICABLE LAW, IS IN LIEU OF ALL OTHER WA R R A N T I E S , R E P R E S E N T AT I O N S A N D...
  • Page 2 This device complies with Part 15 of the FCC Rules. PRODUCT DIAGRAM Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 -Fast forward when in VCR mode. Scan KEY FUNCTION DESCRIPTIONS forward when in VCR, DVD, CD & DVR mode. -Programs your TV. Also programs one -Access the play feature when in VCR, DVD, auxiliary device using the shift key. DVR or CD mode. -Programs your DVD Player.
  • Page 4 -Scrolls right thru menus and guides. This package contains the following: -Scrolls left thru menus and guides. One LZ6220 Touch Sensitive Remote Control. One Installation Guide. One Quick Reference Guide. One Infra-red Device Code List.
  • Page 5: Table Of Contents

    Table of Contents GETTING STARTED Product Diagram/Key Function Descriptions Page 2 A few helpful hints on terms used in this manual. Introduction/Package Contents Page 6 LR: La-Z-Boy Universal Remote Control Table of Contents Page 7 Backlighting: The blue backlighting on the touch sensitive inlay/keypad of your La-z-boy remote.
  • Page 6 HOW TO INSTALL BATTERIES 1.1. HOW TO CHARGE BATTERIES When it is first unpacked, the supplied battery pack is not - Take off the battery case cover, fully charged. Be sure to fully charge it before usage for a then connect the battery into the minimum of 12 hours.
  • Page 7: How To Find The Remote

    1.2. HOW TO FIND THE REMOTE KEYPAD SENSITIVITY LEVEL SET - Press find key on the charging cradle. The red LED indicator will flash 4 times. Set up - Your LR will emit a continous series of beep tones. Keypad sensitivity- Your LR features a touch sensitive - Press any key on the LR once it is located to turn off keypad.
  • Page 8: How To Set Up Your La-Z-Boy Remote

    HOW TO SET UP YOUR LA-Z-BOY Note: When programming AUX 1-8 devices, the device mode REMOTE (LR) key backlight will be green. 3.1. By entering Device Code Suggestion: You may setup your La-Z-Boy Remote (LR) by the - If you cannot find a correct Device Code for your following code entering instructions.
  • Page 9 3.2.5. Press the same desired device mode key again as Important: in step 2 above. (e.g. TV) During set up mode, the upper 4 red device mode 3.2.6. Hold down "CHANNEL+" and "VOLUME-" indicators will blink six times and the set up procedure together simultaneously again for 2 seconds until will be terminated if any of the following conditions the upper 4 red device mode indicators light up...
  • Page 10 4.8. Repeat from step 4.5 to learn other key functions, HOW TO SET UP YOUR LA-Z-BOY or press the same device mode key on step 4.1 (e.g. REMOTE (LR)(Learning Commands) TV) to terminate the learning mode. The upper 4 red device mode indicators will flash twice and Your LR is equipped with learning capability.
  • Page 11 HOW TO SET UP YOUR LA-Z-BOY HOW TO SET UP YOUR LA-Z-BOY REMOTE (LR) (Teaching a dual signal) REMOTE (LR) (By PC SETUP) If you found a learned programmed key only works - Visit www.lazyboyremotes.com . occasionally, your device remote may contain dual - Select "support", then "code download".
  • Page 12 O P E R A T I N G T H E L A - Z - B O Y PUNCH THROUGH REMOTE (LR) You can activate certain functions like TV volume to be operated in other modes such as SAT. This is referred to Normal Operation as punch through.
  • Page 13 8.2.4. Press "CHANNEL-" 8.4. To deactivate the Punch through Volume 8.2.5. The upper 4 red device mode indicators will flash setting: twice and setting punch through mode will exit if 8.4.1. Hold down "CHANNEL+" and "VOLUME-" the setting is deactivated. The lower clear function keys on the remote simultaneously for 2 seconds keys will also be lit.
  • Page 14 MACRO POWER 9.2. To deactivate the Macro Power setting: 9.2.1. Hold down "CHANNEL+" and "VOLUME-" keys on the remote simultaneously for 2 seconds The Macro Power allows you to turn a second device on until the upper 4 red device mode indicators light or off at the same time.
  • Page 15: Maintenance

    - On step 10.4, if no key is selected for more than 8 10. PROGRAM SMART KEYS seconds, the upper 4 red device mode indicators will You can program a sequence of steps into your LR such flash six times then all device mode indicators turn as turn on your TV, turn on your DVD player, turn on off except the selected device mode key and the smart your home theater receiver and press play on your DVD...
  • Page 16: Troubleshooting

    Home Theater Touch sensitive Remote control charged for 12 hours.. For details, please refer to section 1. LZ6220 (the "Product") will be free of defects in A. Check whether you have pressed the corresponding device mode materials or workmanship under normal use for one (1) key for your device.
