CB-1 CHATTERBOX VOICE RECORDER FEATURES
• LED display for mode and address
• Up to five separate four second addresses can be accessed
• Easy to use microprocessor control
• Seven modes available:
Mode 1: Play selected message once.
Mode 2: Play through messages until button is released.
Mode 3: Play selected message over and over while start button is
depressed.
Mode 4: Play through all of memory starting at selected address.
Mode 5: Play one message upon release of the button.
Mode 6: Record until the button is released.
Mode 7: Disable mode.
• 12VDC operation
• Loud 2 Watt audio output
• Designed to operate with a radio transceiver or stand alone
• Will even appropriately key your radio to output a message after each
transmission
• Ideal for contests, repeaters, CB radio or any other application that
requires repetitive speech or sounds
INTRODUCTION TO THE RAMSEY CB-1 VOICE RECORDER
We're sure you've found that it gets tiring repeating what you have just said
over and over again, whether you are contesting, or just simply using your
radio a lot. This kit can take care of the tiresome tasks such as saying "Over
and out", a call sign, CQ, your QTH or whatever. Not only is this kit useful for
repeating messages, but it is very easy to record with also. You simply select
the record mode, press a button, and it instantly records sound through the
built-in microphone. If desired, you may connect up an external microphone
of your choice. Since this circuit records electronically, there is no rewinding
or resetting to wait for, everything is near instantaneous. Since the audio
quality of this kit is very good, your listeners will hardly be able to tell the
difference between your original voice and the recorded voice.
Not only will you find this kit very useful, you'll also find it enjoyable to build,
whether you are a beginner or an experienced kit builder.
NOTE TO NEWCOMERS: If you are a first time kit builder you may find this
manual easier to understand than you may have expected. Each part in the
kit is checked off as you go, while a detailed description of each part is given.
If you are to follow each step in the manual in order, and practice good
soldering and kit building skills, the kit is next to fail-safe. If a problem does
CB-1 • 4
