Summary of Contents for ENHANCE TECHNOLOGY TS800 IP
- Page 1 TS800 IP v.1.1 EnhanceRAID Desktop Series TS800 IP 8 disks iSCSI for Energy E cient Desktop Productivity RAID Quick start guide Linux www.enhance-tech.com © Copyright 2009. Enhance Technology, Inc. Proudly Assembled in the U.S.A.
-
Page 2: Quick Start Guide
Learn and identify each component of TS800 Thank you for choosing Enhance Technology Thank you for buying Enhance Technology TS800 Series, a compact dual GbE iSCSI RAID storage system with a slick T shaped tray design, built in next generation hardware RAID controller, and a standard 300 watts 80+ green power supply. -
Page 3: Disk Installation
TS800 IP Quick start guide Disk Installation Connecting Your TS800 - Cable Connections If your system was purchased with capacity, please skip this section and - Option 1 immediately go to next section. If your system was purchased without disks, install each disk into the provided disk trays and fasten using the supplied Direct connect to the host computer with iSCSI cables. - Page 4 TS800 IP Quick start guide Connecting Your TS800 - Cable Connections - Option 2 Connect to the host computer via Ethernet Switch with iSCSI cables. Ensure that all of the connectors are properly secured & fastned. Most commom issues are related to poor cable connection. Do not force connector into place.
-
Page 5: Create A Raid Array
TS800 IP Quick start guide Preparing TS800 for Con guration Create a RAID Array After power-on, the power LED and hard disks LEDs will light up and your TS800 You will be using the Quick Install function in the Web GUI to create a RAID and will display a message showing the system is booting then change to Initializing User Data Volume for your TS800. -
Page 6: Troubleshooting
8. Select Mac OS extended under the format options. 9. Click on Partition in the Partition dialog box. 3. Check your TS800 IP’s drive presence LEDs, located on the front 10. The drive will be formatted and mounted on the desktop. - Page 7 Enhance Technology's property. Parts provided by Enhance Technology in ful llment of its warranty obligation must be used in products for which warranty service is claimed. When a refund is given, the product for which the refund is provided must be returned to Enhance Technology and becomes Enhance Technology’s...
