AdventistSat Installation Guide

GEOSATpro

DVR1000ci

Digital Video Recorder System

Reception of Satellite AMC4

Dish Aiming Information for Zip Code ____________

Dish Elevation

Compass Azimuth

LNBF Rotation

_______

_______°

_______

_______°

_______

45+ Hours Record Capacity

+ / -

_______°

Table of Contents

Need help?

Do you have a question about the GEOSATpro DVR1000ci and is the answer not in the manual?

Questions and answers

Summary of Contents for AdventistSat GEOSATpro DVR1000ci

Page 1 AdventistSat Installation Guide GEOSATpro DVR1000ci Digital Video Recorder System 45+ Hours Record Capacity Reception of Satellite AMC4 Dish Aiming Information for Zip Code ____________ Dish Elevation _______ _______° Compass Azimuth _______ _______° + / - LNBF Rotation _______ _______°...
Page 2 Important Installation Notice: The Federal Communications Commission (FCC) has ruled that local government zoning or homeowner’s associations may not prevent the installation of satellite antennas one meter (39”) or smaller in diameter, unless legitimate safety restrictions such as fire codes are in effect. For more information: www.fcc.gov/cgb/satellite.html...
Page 3: Table Of Contents
33 of this manual. Please call 866-552-6882 with any questions. Materials contained in this installation manual are the property of: AdventistSat 8801 Washington Blvd., Suite 101 Roseville, CA 95678 www.adventistsat.com ©2006 Adventistsat.com www.adventistsat.com Toll Free 866-552-6882...
Page 5: Serial Number
Grounding the system as recommended in the National Electric Code. NOTE: If you don’t feel completely comfortable with these tasks, please contact AdventistSat toll free at 866-552-6882 or local 916- 677-6228 for information on having your system installed by a local installer.
Page 6: Parts List
AdventistSat System Parts Reflector (1) Tripod Support Leg (2) LNBF ARM (1) Post (1) Installation Kit (1) Satellite DVR Receiver (1) Dish Accessory Kit (1) LNBF (1) Tools Required Phillips Screwdriver 10, 11mm Socket Drill and Bits Measuring Tape Hammer...
Page 7: Important Safeguards
Please refer servicing to qualified service personnel only. Note: Hardware / software modifications not expressly authorized by AdventistSat will void any system warranty. CAUTION: To prevent electric shock, do not use your receiver’s (polarized) plug with an extension cord receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
Page 8 Water and Moisture Do not use this product near water. For example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement, near a swimming pool, etc. ©2006 Adventistsat.com...
Page 9 Toll Free 866-552-6882...
Page 10 Never spill liquid of any kind on the product. Heat The product should be placed away from heat sources such as radiators, heat registers, stoves, or any product that produces heat. ©2006 Adventistsat.com...
Page 11 Refer all servicing to qualified service personnel. Modification to the hardware or software without authorization by AdventistSat the will result in voiding any warranty. Service assistance may be arranged by contacting AdventistSat technical support at 866-552-6882.
Page 12: Site Survey
US and Canada. In Mexico call 800-727-1080. Will a AdventistSat System work at your home? Before assembling any equipment it is important to verify that the installation location has a suitable area to safely and securely mount the satellite dish and have a clear line of site to receive the satellite signal.
Page 13 That means if you live in Miami, you must have a clear line of sight to the Southwest; if you live in San Francisco, you must have a clear line to the Southeast. Compass Azimuth Reading: _______________ www.adventistsat.com Toll Free 866-552-6882...
Page 14 Please note that the Elevation Angle Finder is only used for the site check and cannot be used to set the elevation angle of the dish. The elevation scale on the back of the dish is used for setting the correct elevation angle. ©2006 Adventistsat.com...
Page 15: Dish Mounting Options
Wall Mount Roof Mount The AdventistSat system includes a heavy duty universal wall / roof post mount. This mount can be attached at almost any angle and provides a stable secure mount even in high wind regions if properly attached.
Page 16: Dish Assembly
If any area of the edge is raised by even an 1/8th of an inch reception of the satellite signal could be affected! It is important to check the reflector for warping before assembly of the satellite dish. ©2006 Adventistsat.com...
Page 17 Hex Nut 10mm Hex Tap Bolt M6 - 90mm Fastener Insert Please contact AdventistSat at 866-552-6882 if any of these parts are missing or damaged. Most replacement or damaged hardware items can be found at a local hardware supply store. www.adventistsat.com...
Page 18 Post Clamp. If an upside down letter A is visible on the Post Clamp, the dish has been assembled to use Scale B for measuring the Elevation Angle. After verifying the reflector is not warped, mount to the Elevation Bracket. ©2006 Adventistsat.com...
Page 19 Example: If the Aiming Coordinates specify a LNBF Rotation of -30, estimate and add an additional 10° (two additional marks) and set the center pointer to a -30° clockwise position. www.adventistsat.com Toll Free 866-552-6882...
Page 20: Universal Post Mount Assembly And Install
Center the bubble in the level then tighten the 4 flange bolts to secure the post. It is very important to make sure that the post is perfectly plumb (level on all sides). ©2006 Adventistsat.com...
Page 21 The post is not designed to solely support the dish. If you hire a local installer, please be sure that the legs are installed. AdventistSat will chargeback contracted professional installers if the Tripod Support Legs are not installed.
Page 22: Dish Aiming Angles
(leveled on all sides). The dish elevation angle cannot be set using an angle finder on the LNBF arm or on the face of the dish. ©2006 Adventistsat.com...
Page 23 Semi-tighten the post clamp nuts, but allow the dish to be just loose enough to be moved left or right by gripping the elevation bracket with applying light pressure. www.adventistsat.com Toll Free 866-552-6882...
Page 24: Connect Receiver And Television
Remove the satellite receiver and remote control from the packaging. Inspect the unit before operation. If any equipment is damaged or if you have any questions, please immediately contact AdventistSat at 866-552-6882. Install the two included AAA batteries into the remote control.
Page 25: Locate And Peak Satellite Signals
Select satellite AMC4 KU by pressing the VOL/LEFT or VOL/RIGHT arrow. Press the CH/DOWN arrow to select the 2nd line, frequency. Select 11822 by pressing VOL/LEFT or VOL/RIGHT. (This is 3ABN, the strongest transponder on the satellite). www.adventistsat.com Toll Free 866-552-6882...
Page 26 Signal Quality must be at least 90% + on this channel. Note: Setting the LNBF Rotation is extremely important! If the LNBF Rotation is not set to the approximate angle , the satellite signal might not be found. ©2006 Adventistsat.com...
Page 27 Congratulations! The dish is now aimed for optimum reception of the Adventist channels. Press the EXIT button 3 times to exit the menu screens and view the TV and listen to the Radio channels. www.adventistsat.com Toll Free 866-552-6882...
Page 28: Setting Time
Press VOL ◄ until satellite name Press ENTER AMC4/KU is displayed. Select Local Time/Timers Press EXIT to view or listen to Press ENTER available channels. Select Local Time/Timers Enter Month/Day/Year and the hour and minutes (24 hour) Press EXIT 2 times ©2006 Adventistsat.com...
Page 29: Grounding The System
Often these cables are not rated for satellite applications or have splitters and other devices that are not compatible with a AdventistSat satellite system. Always connect the RG-6 type coax cable directly from the satellite dish LNBF through the grounding block and attach to the LNBF IN Digital connection on the rear of the Satellite Receiver.
Page 30: Basic Operation
Note: Volume is also controlled by the TV. AdventistSat suggests that the satellite receiver volume be set at mid-level and use the TV to adjust the sound level.
Page 31: Frequently Asked Questions
Mount the dish where snow can be gently brushed off. Dish covers and heaters are available for locations with regular ice and snow accumulations. DVR will not record. Local Time is not set. Hard disk is full. Overlapping timers. www.adventistsat.com Toll Free 866-552-6882...
Page 32 TV and Radio services. Many free national and international services are available. Do this at your own risk, as AdventistSat will only provide the warranty free technical support for the reception of the AdventistSat programming.
Page 33: Connection Examples
VCR or DVD Recorder Please consult the owners manual provided with TV, VCR or other device that will be connected to the AdventistSat satellite receiver. The manual will include important connection and operational information. Please contact AdventistSat technical support for assistance in connecting the receiver to a television.
Page 34: Accessories
Accessories * prices in US Dollar AdventistSat carries a large selection of satellite accessories and replacement items. Please call 866-552-6882 or www.adventistsat. com for additional items or to place an order. Glorystar Satellite System Satellite Receiver with PVR Non-Penetrating Roof Mount Over 32 Christian Channels 45+ Hour Record time.
Page 35: Limited Warranty
Invoice by the original purchaser. Annual warranty extension and telephone technical support is available for a $19.95 fee. AdventistSat agrees to repair or replace the unit at no charge within the warranty period, provided that the item is delivered to an AdventistSat service center in the original packaging and appropriately protected and packaged for shipment.
Page 36: Quick Install Guide For Professional Installers
Quick Guide for Professional Installers This section is an overview of the installation information contained in this booklet designed for the experienced professional installer. AdventistSat equipment is preprogrammed to receive Adventist Television and Radio Services on satellite AMC4. No activation is necessary.
Page 37 Press the CH/DOWN arrow to select the 2nd line. This line selects the frequency that the receiver is tuning. The Signal Strength Level and Signal Quality is displayed in the lower left corner of the screen. www.adventistsat.com Toll Free 866-552-6882...
Page 38 Installer Tip: If you are having trouble locating the satellite, remove the AdventistSat LNBF from the clamp and install a DirecTV LNBF into the LNBF position. Locate the DirecTV 101w satellite with a meter or DirecTV receiver. Replace the AdventistSat LNBFs into the clamp.
Page 39: Site Check: Satellite Elevation Finder Tool
Cut Here www.adventistsat.com Toll Free 866-552-6882...
