Summary of Contents for Wren V5BT
- Page 1 V5BT Setup Guide...
-
Page 2: Box Contents
Box Contents AC Power Cord Mini USB Micro USB Charging Cable Charging Cable Power Supply V5BT Safety Instructions & Warranty Wren V5 Safety Instructions & Warranty V5BT Setup Guide Wren V5BT Speaker Wren V5BT Setup Guide... -
Page 3: Before You Begin Setup
Your source device is equipped with Bluetooth® 2.0 or higher. • • You have your source device within range (32 ft. or less) of your V5BT. The Bluetooth wireless feature on your source device is turned on. • Please Note: A comprehensive user manual is available for download from... - Page 4 Powering On Your Wren V5BT Connect AC power cord Connect power supply to power to power supply. input on rear of speaker. The power indicator in the center of the power button will flash white for about 10 seconds, then turn off.
- Page 5 Connections Setup Button Used to pair the V5BT with Bluetooth devices 3.5mm Aux Input Connects any audio source to your Wren V5BT via a 3.5mm audio cable Power Supply Input Connects to the power supply USB Charging Port Charges most smartphones...
- Page 6 For best results, have your Bluetooth source device near your V5BT. Note: Your V5BT will automatically enter pairing mode the first time you plug it in. The following directions are for all subsequent pairings. If you are setting up the speaker for the first time, start with step 3 below.
- Page 7 (Figure 3) A message will appear on your source device to indicate when pairing is complete, In addition, the Bluetooth indicator on the V5BT will go blinking solid from blinking amber to solid amber white white .
- Page 8 • Play music that you are familiar with. • Raise the volume control on the V5BT in small steps until it is as loud as you think you will want it to play. • Turn the volume down on your source device. You will find that it goes from the peak loudness you established all the way down through medium to soft to inaudible.
- Page 9 How Does Bluetooth Work? Bluetooth wireless technology is a small-area networking protocol that removes the need for user intervention and keeps transmission power extremely low to save battery power. Because it is efficient and easy to use, Bluetooth wireless technology has been widely adopted as the most popular (and familiar) way to enable devices like smartphones, tablets, and computers to connect to and communicate with other popular devices like audio headsets and speakers—all without cumbersome wires.
- Page 10 Using multiple devices on your V5BT Many households (and many individuals) have multiple Bluetooth-equipped devices that they use for music. The Wren V5BT can “remember” pairings with up to six different Bluetooth devices, eliminating the need to go through the initial pairing process every time you switch devices.
- Page 11 To clear the V5BT’s memory of all paired devices, press and hold the Setup button on the rear of your V5BT and, while holding the Setup button, press the Power button on the front control panel. The Volume indicator will blink amber two times to indicate that the memory has been cleared.
- Page 12 Bluetooth connection. To determine if a Bluetooth-enabled device supports aptX, just look for the aptX logo on the product’s packaging: For an up-to-date list of devices equipped with aptX, go to the “Support” page on the Wren website (www.wrensound.com/support), select “V5BT for Bluetooth” from the drop-down...
-
Page 13: Speaker Controls
Speaker Controls Volume Adjustment Indicator Indicates volume being adjusted. Source Selector Selects the desired audio input source. Bluetooth Indicator Indicates Bluetooth audio source is selected. Aux (3.5mm) Source Indicator Indicates aux audio source is selected. * See the full user manual at wrensound.com/support for details. -
Page 14: Troubleshooting Tips
You may need to play an audio track to make the connection. • Your Bluetooth device may be out of range. Try moving it closer to the V5BT. Poor sound • Make sure your Bluetooth device and/or you V5BT are not positioned near quality from a Bluetooth®... - Page 15 • Make sure your Wren V5BT is not muted, and the volume is up. • Make sure your Bluetooth®-enabled device is playing audio. • Make sure your Bluetooth device and/or your V5BT are not positioned near...
-
Page 16: Contact Information
La palabra, marca y logos Bluetooth® son marcas comerciales registradas pertenecientes a Bluetooth SIG, Inc. y todo uso de ellos por parte de Wren Sound Systems, LLC se hace bajo licencia. Otras marcas comerciales y nombres comerciales pertenecen a sus respectivos dueños. - Page 17 V5 Safety Instructions & Warranty...
-
Page 18: Consumer Product Safety Guide
7. Heat • Service methods not covered in the User • The unit should be situated away from heat Manual should be referred to Wren. sources such as radiators, heat registers, The unit should be serviced by stoves or other appliances (including amplifiers) qualified service personnel when:... -
Page 19: Fcc Radiation Exposure Statement
Canada Rules. Operation is subject to the following FCC ID: R48-V5PF IC:7190A-V5PF two conditions: FCC ID: R48-V5BT IC:7190A-V5BT 1. This device may not cause harmful interference, and This device complies with Part 15 of the FCC Rules. 2. This device must accept any interference... - Page 20 Note: This mark applies only to countries within the European Union (EU) and Norway. This appliance is labeled in accordance with European Directive 2002/96/EC concerning waste electrical and electronic equipment (WEEE). This lebel indicates that this product should not be disposed of with household waste.
- Page 21 (1) year anniversary Wren or any such other party knew or should have known but before the three (3) year anniversary of the date of the possibility of such damages. Notwithstanding...
- Page 22 W R E N S O U N D . C O M V5.SIW.V1.R0.01.10.13.US...
