HTTP://WWW.SUNCTI.CO.TH
1. Welcome
Congratulations on becoming an owner of S06 telephone adapter! You made an excellent
choice and we hope you will enjoy all its capabilities.
S06 offers a rich set of functionality and superb sound quality at ultra affordable price. It
is fully compatible with SIP industry standard and can interoperate with many other SIP
compliant devices and software on the market.
2. Product brief
2.1. Key Features
• Support SIP 2.0, TCP/UDP/IP, RTP/RTCP, HTTP, HTTPS, ICMP, ARP, DHCP,
NTP/SNTP, TFTP protocols.
• Support STUN and symmetric RTP for NAT.
• Interoperable with various 3
and gateway products.
• Advanced 32bit embed MCU + DSP technology to ensure superior audio quality.
• Advanced adaptive jitter buffer control, packet delay and loss concealment
technology.
• Support popular vocoders including G.723, G.729A, G.711 (a-law and u-law),
G.726(40K/32K/24K/16K).
• Support standard voice feature such as Caller ID Display, Call Waiting, Hold,
Transfer, in-band and out-of-band DTMF, three way conference.
• Support Silence Suppression, VAD(Voice Activity Detection), CNG(Comfort
Noise Generation), Line Echo Cancellation(G.168), and AGC(Automatic Gain
Control)
2.2. Hardware Overview
IPP 200analog phone adapter is a small CPE. It is easy to install. See picture 2.1.
S06

User manual

rd
party SIP end user device, Proxy/Registrar Server,
Ver 1.0 2006-11-12
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S06 and is the answer not in the manual?

Questions and answers

Summary of Contents for Suncti S06

  • Page 1: User Manual

    S06 offers a rich set of functionality and superb sound quality at ultra affordable price. It is fully compatible with SIP industry standard and can interoperate with many other SIP compliant devices and software on the market.

  • Page 2: Installation

    3. Two Cat-5 Ethernet cables 4. An Ethernet port connecting to IP networks Please follow the instruction below for S06 setup: 1. Insert one end of Cat-5 Ethernet cable to one “LAN” port on the back of ATA and the other end to Ethernet port connecting to IP networks.
  • Page 3 • User information such as user ID and password. 4.1 Setup with Keypad Connecting telephone to I-06’s “Phone” port, press “**00”to enter into S06 setup menu. You can use keypad referencing following menu to do basic network setup. Please use web browser to do more advance setup.

  • Page 4: Setup With Web Browser

    =============================================================== 4.2 Setup with Web Browser Connecting S06’s “LAN” port to a router. The procedure in 4.2.1 shows you how to setup your ATA and the menu in 4.2.2 for your reference. 4.2.1 Use Web Browser for system setup 1.
  • Page 5 HTTP://WWW.SUNCTI.CO.TH USER MANUAL Under Proxy Server Setup • Set “Proxy” to the SIP proxy server IP address or domain name. In FWD case, it is “fwd.pulver.com”. • Set “Use Outbound Proxy” to “yes”. • Set “Outbound Proxy” to be the outbound proxy server IP address or domain name.
  • Page 6 HTTP://WWW.SUNCTI.CO.TH USER MANUAL At bottom of the pager: • Click “Save Changes” button to apply all the changes. 4.2.2 Setup Menu Network Information Under this tab, the current network information of ATA is presented. Product Information Under this tab, the current product information of ATA is presented.
  • Page 7 HTTP://WWW.SUNCTI.CO.TH USER MANUAL Gateway The default gateway used by ATA when 0.0.0.0 DHCP is disable Primary DNS DNS server used by ATA in addition to DHCP supplied DNS servers if DHCP is enable; when DHCP is disable, this will be...
  • Page 8 HTTP://WWW.SUNCTI.CO.TH USER MANUAL in SIP responses if received from IP and VIA sent-by IP differ Insert VIA rport Insert rport parameter in VIA header in SIP responses if received-from port and VIA sent-by port differ Substitute VIA addr Use nat-mapped IP: port value in VIA...

  • Page 9: Call Features

    HTTP://WWW.SUNCTI.CO.TH USER MANUAL Auth ID Subscriber’s authentication ID Use Auth ID If it is set to “yes”, the pair “Auth ID> and no “Password” are used for SIP authentication. Else the pair “User ID” and “Password” are used Audio Setup...

  • Page 10: Product Use Environment

    3)After A(or B)heard a dial tone, A(or B) dial C’s number. 4)After C answered, A(or B)click hang up hook again, Three way conference is on. ------------------------------------------------------------------------------------------------------------ ------------------------------------------------------------------------------------------------------------ 5. Product Use Environment S06 is recommended to work as in-door equipment. Ver 1.0 2006-11-12...
