BM‐3000 User Manual Welcome, Thank you for purchasing the BM‐3000 from Best Media. With years of experience in musical entertainment, Best Media is the leading brand of Karaoke machine. Currently, Best Media is one of the major brand of Alright Media LLC, which is manufacturing bass in Taiwan. Our mission is to providing excellent customer service, high product quality, and completive price to our customers. Our technical support professional and customer service are ready to assist you with your need. Below is our contact information: Alright Media LLC 20746 Carrey Road, Walnut California 91789 Tel: 909‐348‐5555 Fax: 909‐230‐9789 Website: www.bestmediausa.com Email: info@bestmediausa.com ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Warranty Statement BEST MEDIA warrants this product to the original purchaser ONLY, to be free from defects in materials for One Year under normal use from the date of original purchase. BEST MEDIA warrants free labor for at its option under the warranty period, to replace product if it is determined to be defective at "No Charge." This limited warranty does not cover any loss or damages that occur as a result of: Cosmetic damage. Shipping or improper installation or maintenance. Misuse. Neglect. Any cause other than ordinary commercial or industrial application. Adjustment by non‐authorized source or any of the products firmware or hardware that you or any third party have modified or altered ...
BM‐3000 User Manual 1. Product Safety WARNING: To reduce the risk of electric shock, do not remove the cover or the back. Opening or removing the covers may expose you to the risk of voltages and electric shocks. Please only refer servicing to qualified service personnel Caution: To reduce the risk of fire or electric shocks, do not expose this unit to rain or moisture. Read Instruction Retain Instruction Heed Warning Follow Instruction ‐ Please install according to manufacture’s instruction Heat prevention – Keep the device away from heat source such as radiators, heaters, stoves and other appliances that produce heat. Lighting prevention ‐ Do not touch the power cord during lightning to avoid electric shock ‐ Do not overload power strips or extension cords ‐ Do not touch power connector with wet hands Power Cord Protection ...
BM‐3000 User Man nual 2. Product Overview This BM3000 is s an ultra‐compact, h high definition (HD) U USB 2.0 media player r. It supports high‐ definition vide o playback of up to F Full HD 1080p throug gh an HDMI connecti on or standard definition for T TVs with lower capab bilities. In addition, th his KOD allow you to store your favorite movie and son ngs into the hard driv ve through USB conne ection, so you can en njoy all your favorites s in one machine e. 2a. P Package’s Accesso ries: 1 x BM3000 HD D Karaoke Media Play yer (with internal har rd drive built‐in) ...
BM‐3000 User Manual Fig 3.3 Connection Diagram for Karaoke 3b. HDMI Connection BM‐3000 can identify ONLY plug‐in TV input or HTMI input automatically. If both HTMI and AV connect to TV and KOD, please follow these steps: Press “System” button on remote control to direct you to System/Setting Enter Password: (default PW: 347437) Use “Left/Right” button move to page 4/5 Use “Up/Down” Key to navigate to “HDMI&AV” Select 480i, 720p, 1080i, or 1080p for HDMI quality. If set “HDMI &AV AUTO”, it will use HTMI as priority. After any changes, just simply exit the system and the new setting will automatically saved. 3c. Quick Starting Guide After connect all the cables (figure 3.3), please connect the AC adapter Insert 2xAAA batteries to remote control Click the “Power” button on the front panel of the device to turn on It will direct you to the welcome screen, then you are all set. Enjoy!!!! 5 ...
BM‐3000 User Manual 4. Remote Control 4a. Remote Control Fig 4.1 Remote Control ...
Page 9
BM‐3000 User Man nual 6 C Delete/ /Clear input character o or delete a queue song in “List” menu INPUT T When playing song, use input function to add selecte ed song into 7 the “Lis st” menu NEXT Stop th he current song, and pla ay the first selected son ng on the 8 “List” MENU U Display y the menu on the uppe er left corner of TV fram 9 Direct tional keys Up/Do wn/Left/Right keys 10 11 VOL + +/‐ ...
Page 10
BM‐3000 User Man nual 5. General Operation and Navigation Sear rch by Artist/ Lang guage/ Feature/ D ance/ Stroke Press “Artist” bu utton on remote cont trol Choose Artist’s c categories/ Language e (figure 5.1) Follow on‐screen n instruction Fig 5.1 Sort by Artist’s Type ...
BM‐3000 User Man nual Fig 5.3 Pinyin Chart 6. System/ / Setting Fig 6.1: ...
Page 12
BM‐3000 User Man nual Fig 6.2 System Setup Menu 6a. Change S System’s Password (figure 6.3) 1. Cho oose “System Passw word Setting” on Sy ystem Setup 2. Ent er old PW and new ...
Page 13
BM‐3000 User Man nual 6c. Change S ongs for Public Pla ay Frame (aka Pub blic Performance Fr rame) Songs for P Public Play Fame will randomly play from the list when no son g is selected. 1. In Syste m set up menu, select “Pub blic Performance Frame” 2. Choose “ON” for Multi 3. Press “L eft/Right” key to ‐‐‐ active: allo ow playing multiple songs; inactive: n ot allow playing multiple so ongs 4. Add up t to 100 songs for Public Play y Frame Fig 6.5 5. Select vo ocal of each songs: by press number pad (1) or (2) on remote e control Fig 6.1 ...
BM‐3000 User Manual To save Customized BBE Sound effect: In System Setup Menu, choose “Basic Setting” Choose “ON” for BBE save on page 2/5 Short cut for TV play frame: On BBE Org: Choose “Custom” and change BBE as user customized value. After exiting, in the TV play frame, enter “0000” and “002” to set everything to BBE custom value On BBE Org: Choose “Ori” to set to factory value. After exiting, in the TV play frame, enter “0000” and “002” to set everything back to factory value. On BBE Org: Choose “BBE OFF” to change BBE as initial factory setup. After exiting, in the TV play frame, enter “0000” and “002” will display BBE OFF 6e. Personal Message Setup 1. On “System Setup Menu,” select Basic Setting 2. Choose “Per. Message” on page 1/5 (figure 6.8) 3. Enter up to 5 lines of Welcome message or information of karaoke room. Fig 6.8 Personal Message (These message will appear when the machine starts) 6f. Song Limit Setup This function is to limit the songs to be played. When the song limit expires, no songs can be ordered. You cannot order songs until it is unlocked with the required password. 1. Press “System” on remote control 2. Choose “Limit Setting” to limit song order. (figure 6.9) *Note: This function is used only by the registration of agent or dealer. ...
BM‐3000 User Manual Press “1” for “Quick Recording” to quickly add song into the Hard Drive *Note: Using this function, the system will automatically number the song, so you should write down the song number for reference (starting from: 80001‐84999) **BM‐3000 support AVI, MPG, VOB, WMV, MKV, and DAT files 7b. Detailed Recording USB songs to Hard Drive 1. Follow 7a (1‐6) 2. Press “2” for detailed recording 3. Enter Artist and Song’s information. Fig 7.1 Add/Del 7c. Add Song Disc Guide We do sell Add song list for every quarter (4 Quarter/Year), 150 songs/Quarter Please visit "Download" Section on our website for songlist. To use Add Song Disc: Place Add Song Disc into computer's DVD tray Plug in your empty USB drive (suggest 8GB or 16GB) Choose "Start" > "Computer" > locate your USB drive and Add Song Disc Copy all the files from Add Song Disc to USB drive If there are more than 1 DVDs, please place 2nd DVD into the Tray and copy all the files into your USB drive For Example: Mandarin (2 DVD), then copy all files from these 2 DVD into USB Cantonese (1 DVD), then only copy this DVD into USB drive Unplug USB from computer and plug USB to BM‐3000 Go to System Setup > "Add/Del Song" > Data Disc Add Wait for BM‐3000 completely copy all songs Check your songs by entering the number on the list 7d. Smart Delete Function 1 Follow 7a (1‐3), Choose “Smart Delete” 2 Select options that fit your need 3 Press “Play/Pause” to start deleting ...
BM‐3000 User Manual 8. Connect to net work (LAN) (WIFI required) **Note: You need to have WIFI router in order Fig 8.1 to connect to Iphone/ Ipad/ Android wirelessly Prepare: Connect an Internet Cable from your WIFI Router to the back of BM‐3000. (figure 8.1) If your Router is located far away from your karaoke machine, we suggest you to use Method 2: using a WIFI Extender to hook up internet to BM‐3000 9. iPhone/Android Method 1: Hook up an Internet cable to BM‐3000 Required: ‐ WIFI Router ‐ iPad / Android Tablet ‐ Long Internet Cable (connect from WIFI Router to BM‐3000) ‐ Download "KOD App" on our website (www.bestmediausa.com) Step 1 ‐ IP Address ...
Page 17
BM‐3000 User Manual Step 2 ‐ New IP Address ‐ Press "System" > "Basic System Setting" > Go to Page 5/5 Fig 8.5 What is New IP address? ‐ Set your IP to 192.168.x.XXX (please note on the 4 group (underlined), choose a number that is greater than the number showing on your smart phone or tablet) See example below: For Example: IP Address showed on iPad is 192.169.10.100 <‐‐(8. 3) Input IP Address into BM‐3000 as: 192.169.10.118 <‐‐(8. 4) *Press #: for number. Press "Input" button for (.) dot* **Make sure the number of the 4 group is greater than the number showing on your iPad** Step 3 ‐ Download "KOD" App ‐ Visit our website: www.bestmediausa.com ‐ Select "Karaoke Player" on the left column ‐ Choose "BM‐3000" (with Chinese Character, not Vietnamese Version) ‐ Scroll down and choose iPad/Android App. ‐ iPad will directly link you to the App Store Download Page. (see App Icon on Fig 8.5) *For Android, Please first download Android App into Computer ‐ Simply Copy / Drag that App into your Android device. ...
Page 18
BM‐3000 User Man nual Step 4 ‐ Input New IP Address on "KOD" app ‐ Install and open "KOD" App (Fi ig 8.5) ‐ Tap on the "Service" Icon which h Located on Top Rig ht Corner (Fig 8.6) ‐ Tap on "Ma anually Connect the Private Room", and I Input New IP Addres s. (Fig 8.7) Step 5 ‐ Verific cation Code ‐ The app will start to search, and when it finds the ma achine, it will ask for r "5 Digit Code". ‐ At the same e time there will be a 5 digit code showing g on ...
Page 19
B. Connect WIFI Extender to BM‐3000 1. Plug WIFI Extender to the Power Plug near BM‐3000 Machine. 2. Connect a short Internet Cable from WIFI Extender (on the back) to the back of BM‐3000. (Fig 8.1) 3. Turn On WIFI Extender and Turn on BM‐3000. 4. You will notice the light on WIFI Extender is stable on Green light 5. On BM‐3000, Press "System" button on Remote Control 6. Choose " Basic Setting", use "Up and Down" arrow to navigate to the last page IP Address (5/5) ‐‐> (Fig 8. 4) 7. Insert a random IP Address such as (192.68.11.XXX or 192.68.11.234) ‐‐‐‐‐‐ Or follow Method 1 (Step 1 ‐ 2) to get an IP Address ‐‐‐‐‐‐‐‐‐ 8. Follow Method 1 (Step 3 ‐ 5) 9. Well Done and Enjoy Singing! ‐ For quick connection, please Tap on "Automatically connect to Private Room" first. (sometimes, app recognize machine automatically ‐ When it can't find room, then continue Method 1 step 4‐5 Additional Info: Forum (Guideline and Video Tutorial): bestmedia.forumotion.com Check out our FB for news: facebook.com/alrightmedia.llc 17 ...
Page 20
BM‐3000 User Man nual al) 19 吋立地式 式觸摸屏 10. Touch S Screen (Optiona 10a. Touch sc creen navigation BM3000 19” T ouch Screen is the o nly one that compati ible with BM3000 KO OD a. Touch Screen Conn nection 1. Plug in Touch Scree en Power and VGA cable 2. Press “System” on remote control 3. Enter Password (De efault Password: 347437) 4. Choose “Basic Sett ing,” then navigate o page 3/5 5. Choose “PS2 Pic ‐> Screen” for Touch Screen Option (Fig 10 0.1) b. Mouse Fig 10.1 1. Plug in wireless mo ouse USB on the USB B Port ...
Page 21
BM‐3000 User Man nual Fig 10.4 O Order by Artist, Pinyin i nput Fig 10.5 Order by Song Title, ha and writing input 换肤 10c. Change T Touch’s Appearan BM3000 Touch h has 3 different Scre een Appearance: Clas ssic, Dragon, and Fan ncy Style Click k on “Other” Icon, it w will pull up another r ow Click k on the “Service” Ico on of the pop‐up row Choo ose “Brush” Icon to c change appearance (f figure 10.6) Fig 10.6 Click on “Brush” Icon to cha nge Skin Appearance ...
Page 22
BM‐3000 User Manual 11. Stands (Optional) There are 3 different stands to choose for this touch screen: Stand‐C: curve style, the most common KTV style Stand‐L: clean and tall style Stand‐S: short, suitable for placing on table 12. WIFI Extender (Optional) If connecting Ethernet cable and setting IP address sound complicated to you, WIFI Extender is here to help. WIFI Extender is used to expand the WIFI connection in area of low WIFI signal. *For BM‐3000, we use WIFI Extender not only to expand WIFI connection, but also to customize your own IP Address. So you won't have to spend time to figure out what is the IP Address need to be enter into the System Setup. 不但可以用來寬大 的範圍,還可以用來自設定一個 WIFI Extender IP Address IP Address 所以它可以幫客人們省下去尋找正確 的時間 IP Address With WIFI Extender, you can hook up BM‐3000 and iPad/Android easily. 1. Setup your WIFI Extender to connect with WIFI router* 2. After WIFI Extender was assigned an IP Address, connect it to BM‐3000 with an Ethernet cable (not included in the package, you can use a short Ethernet cable) 3. Go into the "System Setup"(see pg 9) ...
BM‐3000 User Man nual 3. Press on the e "WPS" on both WIF FI Extender and Rout ter at the same e time for 3‐5 second s 4. Notice the li ight of WIFI Extender r turns from Red > Orange > Gr reen (successfully co onnected) 5. Unplug the W WIFI Extender and pl lug into the power closer to BM M‐3000 6. Connect Eth hernet cable (not incl uded in the package )between Extender a and BM‐3000's Ethernet po rt 7. Follow Step 3‐9 on the section a bove (How to Hook u up BM‐3000 to iPad/ /Android) 13. Codec S Support ...
BM‐3000 User Manual KOD/DVD button These buttons are NOT Applied to BM‐3000 ONLY For machine with DVD and KTV Service Microphone has no Please check if microphone cable is connected correctly sound Please check if microphone has battery or not **Please note that the HDMI video and audio's content are digital, while audio information (L/R) of AV component are analog. The audio from your microphone is also analog and therefore cannot be ported to the HDMI output. Therefore, please plug both HDMI and AV component cable (Red and White) to view high definition video and still able to hear sound from microphone 15. Specification Measurement Width: 283mm, Length: 430mm, Height: 68mm Weight 3.7 Kg Power 100V‐240V Video output NTSC, 75Ω, 1 VP‐P Analog sound output STEREO L/R, 1KΩ, 20HZ~20KHZ Fiber digital output Fiber output Terminal Digital coaxial output PCM, 91Ω, 0.5 VP‐P, 0.15~1MHZ Static noise ‐105db IR reception INFR, 38KHZ PS/2 device input MOUSE VGA output RGB, 75Ω, Monitor ...
Page 25
Thank You for Using Best Media's Product! Please visit our site for more details Homepage: bestmediausa.com Updated news and events facebook: facebook.com/alrightmedia.llc For Tech guideline and Video Tutorial Forum: bestmedia.forumotion.com If you still have any question, please do not hesitate to contact us at 909‐348‐5555 or info@bestmediausa.com. Thank You Alright Media LLC ...
