Bull DPS7000/XTA NOVASCALE 7000 CDA 7 5630 Maintenance Manual

Integrated cache disk array
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CDA 7 5630
Maintenance Manual
Hardware: CDA
REFERENCE
77 A7 48UU 03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPS7000/XTA NOVASCALE 7000 CDA 7 5630 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bull DPS7000/XTA NOVASCALE 7000 CDA 7 5630

  • Page 1 CDA 7 5630 Maintenance Manual Hardware: CDA REFERENCE 77 A7 48UU 03...
  • Page 3 DPS7000/XTA NOVASCALE 7000 CDA 7 5630 Maintenance Manual Hardware: CDA December 1999 BULL CEDOC 357 AVENUE PATTON B.P.20845 49008 ANGERS CEDEX 01 FRANCE REFERENCE 77 A7 48UU 03...
  • Page 4 The following copyright notice protects this book under Copyright laws which prohibit such actions as, but not limited to, copying, distributing, modifying, and making derivative works. 4, 1999 Copyright Bull SAS 199 Printed in France Suggestions and criticisms concerning the form, content, and presentation of this book are invited.
  • Page 5 Preface This manual is part of the documentation set for the CDA 7 family of products. Scope and Objectives The CDA 7 is a very reliable high performance Integrated Cached Disk Array (ICDA) designed for online data storage. This manual describes CDA 7 maintenance and ORU replacement procedures. This manual is intended for personnel involved in maintaining and repairing the Intended CDA 7 5330.
  • Page 6 CDA 7 Maintenance Manual This manual is structured as follows: Structure Chapter 1 Introduction, provides a overview of the CDA 7 system. Chapter 2 About the Lap-Top shows the place and connections of the Lap-Top in the CDA 7 5330 subsystem. Chapter 3 System Repairs, contains instructions for replacing CDA 7 components.
  • Page 7 Preface The following manuals discuss related subjects: Bibliography Bull DPS 7000 User’s Guide Firmware Release Bulletin ......77 A7 67US Bull DPS 7000 - System Repair Manual ...........77 A7 72US CDA/x Product Manual ................96 A1 70EC CDA 7 Maintenance Manual..............77 A7 48UU CDA 7 5330 Site Preparation..............77 A1 97UU CDA 7 5330 Product Manual (9 GB)............
  • Page 8 CDA 7 Maintenance Manual 77 A7 48UU Rev03...

  • Page 9: Table Of Contents

    Table of Contents Introduction....................1-1 System Performance ....................1-1 Logical Architecture....................1-5 POWER Subsystem ....................1-22 1.3.1 Fan Assemblies....................1-23 1.3.2 Operator Panel .....................1-24 CDA 7 System Connection Example................1-26 1.4.1 External Cable Requirements ...............1-27 1.4.2 LABEL Command..................1-28 1.4.3 Cable Requirements (View From MNCONF)..........1-29 Installation Conditions ....................1-29 About the Lap-Top ..................
  • Page 10 CDA 7 Maintenance Manual 3.3.2 Replacing the Director and Communication Card..........3-11 3.3.3 Replacing the DA#1 from the Lap-Top Access Change.........3-13 3.3.4 Replacing the Memory Board................3-15 3.3.5 Replacing the Battery ...................3-16 3.3.6 Replacing a Fan Module ................3-17 3.3.7 Replacing the Power Supply .................3-19 3.3.8 Replacing the Lap-Top .................3-21 Disruptive Replacement Procedures................3-22...
  • Page 11 Software Release and CDA 7 Configurations (9 GB Disks)......A-1 Software Level ......................A-1 Bin Files ........................A-2 CDA 7 5330 Disk Configurations ................A-3 Basic Models......................A-4 A.4.1 MSPD038-0000: 4 Mirror ................A-4 A.4.2 MSPD039-0000: 8 Mirror ................A-5 A.4.3 MSPD040-0000: 12 Mirror ................
  • Page 12 CDA 7 Maintenance Manual Software Release and CDA 7 Configurations (18 GB Disks)....D-1 Software Level ......................D-1 BIN Files ........................D-2 CDA 7 5330 Disk Configurations ................D-3 Basic Models......................D-4 D.4.1 Binary File S01-200.BIN ................D-4 D.4.2 Binary File S02-200.BIN ................D-5 D.4.3 Binary File S03-200.BIN ................
  • Page 13 F.3.6 Setting the Modem Parameters ..............F-16 F.3.7 Verifying the CDA 7 Configuration ............... F-18 F.3.8 Declaring the CDA 7 Subsystem under GCOS 7.......... F-30 Glossary ......................g-1 Index ........................i-1 77 A7 48UU Rev03...
  • Page 14 CDA 7 Maintenance Manual Table of Graphics Figures 1-1. CDA 7 Subsystem ..................... 1-1 1-2. CDA 7 (Rear View - 9 GB)..................1-2 1-3. CDA 7 (Rear View - 18 GB and 36 GB) ..............1-3 1-4. CDA 7 Main Components (Exploded View)..............1-4 1-5.
  • Page 15 3-6. Battery With Extension ....................3-19 3-7. Power Supply (Rear View)..................3-20 3-8. Lap-Top in the Front Door ..................3-21 3-9. Power Distribution Module..................3-22 3-10. Alarm Codes ......................3-23 3-11. Environment Fault Display..................3-26 5-1. Add-On Procedure Overview ..................5-2 C-1. CDA 7 5330, Removing the Shipping Brackets ............C-4 C-2.
  • Page 16 CDA 7 Maintenance Manual F-6. Site Information - 3 ....................F-10 F-7. Site Information - 4 ....................F-11 F-8. Site Information - 5 ....................F-11 F-9. Customer Name ....................... F-13 F-10. Cabinet Serial Number ..................... F-15 F-11. Modem Parameter Setting..................F-16 F-13.

  • Page 17: Introduction

    1. Introduction This chapter provides an overview of the CDA 7 Integrated Cache Disk Array (ICDA) highlighting its performance and reliability features. System Performance The CDA 7 is a reliable high performance Integrated Cached Disk Array designed for on-line data storage. CDA 7 (front view) Figure 1-1 provides a front view of the exterior of the CDA 7.
  • Page 18 CDA 7 Maintenance Manual CDA 7 (rear view) - 9 GB Figure 1-2 provides a rear view of the exterior of the CDA 7 (9 GB). Figure 1-2. CDA 7 (Rear View - 9 GB) 77 A7 48UU Rev03...
  • Page 19 Introduction CDA 7 (rear view) - 18 GB and 36 GB Figure 1-3 provides a rear view of the exterior of the CDA 7 (18 GB and 36 GB). AC IN Figure 1-3. CDA 7 (Rear View - 18 GB and 36 GB) 77 A7 48UU Rev03...

  • Page 20: Cda 7 Main Components (Exploded View)

    CDA 7 Maintenance Manual CDA 7 Main Components Figure 1-4 shows the location of the main components in the CDA 7 chassis. DISK DEVICES ASSEMBLIES SERVICE PROCESSOR ADAPTER Open Position CARDS REAR BATTERY SUBSYSTEM DIRECTOR AND CACHE CARDS FRONT Closed POWER Position SUBSYSTEM...

  • Page 21: Logical Architecture

    Introduction Logical Architecture Links to the system are established with a Fast-Wide / Ultra SCSI type interface. Director channels and adapter channels are specific to the SCSI interface of the DPS 7000. MPORTANT The abbreviations used in this document are: Channel Director = SD (SCSI Director) Channel Adapter = SA (SCSI Adapter for the link with the WSP board).

  • Page 22: Interconnection Of Main Components

    CDA 7 Maintenance Manual Interconnection of Main Components Figure 1-5 shows the interconnection of the main components of the CDA 7. Main AC Power Dist. Main switches Module Modem POWER Distribution Power MODEM ETHERNET Module (PDM) Supply FANS 50 V PC Power LAPTOP PC Supply...

  • Page 23: Cda 7 Front View (Covers Off)

    Introduction CDA 7 Front View (covers off) Top Cover is removable to allow access to fan assemblies DIR-2b DIR-2b DIR-2b DIR-2b DIR-2b DIR-2b DIR-2b DIR-2b DIR-2a DIR-2a DIR-2a DIR-2a DIR-2b DIR-2b DIR-2b DIR-2b JL1 5V blue JL2 5V red JL3 12V blue JL4 12V red 1 2 3 4 5 6 JL5 24V blue...
  • Page 24 CDA 7 Maintenance Manual Disk Director Device Figures 1-7 and 1-8 provide a front and rear view of the disk director device. Front View DIR 02, slot 1 # 0 # 1 SCSI C Bus C SCSI D Processor B Bus D SCSI C Bus C...

  • Page 25: Disk Device Director (Rear View)

    Introduction Rear View DIR 01, slot 0 (Rear view) SCSI C Example: SCSI D, Address #3 SCSI D Processor B SCSI C Processor A SCSI D Figure 1-8. Disk Device Director (Rear View) 77 A7 48UU Rev03...
  • Page 26 CDA 7 Maintenance Manual Front Card Cage - Channel Director Location Figure 1-9 shows the location of the channel directors in the CDA 7. SCSI Channel Directors SCSI Disk Directors Channel Directors Memory Slot Figure 1-9. Front Card Cage (Location of Channel Director) 1-10 77 A7 48UU Rev03...

  • Page 27: Dual Processor Directors

    Introduction Dual Processor Director Figure 1-10 provides a close-up view of a dual processor director. Right side view (Floor) Screw Ejector tab Hard Reset Push button Display (OF = Off Line) Rotary switches Power for external tests RS232 (Engineering) Yellow led Green led Attention button...
  • Page 28 CDA 7 Maintenance Manual Front Card Cage - Memory Board Location Refer to the Front Card Cage figure above to locate the memory boards in the CDA 7. Memory Board Figure 1-11 provides a close-up view of a memory board. Ejector tab Hardware Reset Yellow LED...

  • Page 29: Cda 7 Rear View (Covers Off) - 9 Gb Disks

    Introduction CDA 7 Rear View (covers off) - 9 GB Disks Figure 1-12 provides a rear view of the CDA 7 (9 GB disks). Top Cover is removable to allow access to fan assemblies 2 1 0 DIR-1b DIR-1b DIR-1b DIR-1b DIR-1b DIR-1b...

  • Page 30: Cda 7 Rear View (Covers Off) - 18 Gb Disks

    CDA 7 Maintenance Manual CDA 7 Rear View (covers off) - 18 GB Disks and 36GB Figure 1-13 provides a rear view of the CDA 7 (18 GB Disks). Top Cover is removable to allow access to fan assemblies DIR-1b DIR-1b DIR-1b DIR-1b...
  • Page 31 Introduction Rear Card Cage -SCSI Adapter Location Figures 1-14 shows the location of the SCSI Adapters in the rear card cage. COM0 COM1 Channel A Processor b Channel B Processor b Channel A Processor a Channel B Processor a Slot Slot Slot Slot...

  • Page 32: Scsi Adapter Switch Positions

    CDA 7 Maintenance Manual Rear Card Cage - SCSI Adapter Switch Positions Figures 1-14 shows the SCSI Adapter switch positions in the rear card cage. FUSES TERMPOWER SCSI C SWC2 ENABLE SWC1 DISABLE TERMPOWER SCSI D SWD2 ENABLE SWD1 DISABLE TERMPOWER SWE2 SCSI E...
  • Page 33 Introduction Special cables are required to ensure conformity of the grounding link between the host and the CDA 7. The bare part of the cable must be installed in the clamp grounding of the CDA 7 as shown in Figure 1-16. These cables are specific to CDA 7 and will be available for refurbished 5100 models.

  • Page 34: Scsi Adapter Locations And Port Assignments

    CDA 7 Maintenance Manual Rear Card Cage - SCSI Adapter Locations and Port Assignments Optional SCSI Locations COM0 COM1 Channel A Processor b Channel B Processor b Channel A Processor a Channel B Processor a Figure 1-17. SCSI Adapter Locations and Port Assignments 1-18 77 A7 48UU Rev03...
  • Page 35 Introduction Rear Card Cage - COM Card Location COM0COM1 Figure 1-18. Location of COM Card 77 A7 48UU Rev03 1-19...

  • Page 36: Com Card - 2 Types

    CDA 7 Maintenance Manual COM Card Figure 1-19, below, provides a close-up view of two types of COM cards. 3 positions slider switch (Must be in low position) Jumper J1 RS232 connector, (Engeenering) Remote power connector CR19 SW5 Attention switch CR15 CR17 CR19...

  • Page 37: 3.5 Inch. Disk-Drives

    Introduction 3.5 inch. Disk-Drives The CDA 7 uses 3.5" disk-drives with a formatted capacity of 9 or 18 GBytes. 18 Gbyte devices are split into two logical 9 Gbyte drives. Figure 1-20. 3.5 inch. Disk-Drives 77 A7 48UU Rev03 1-21...

  • Page 38: Power Subsystem

    CDA 7 Maintenance Manual POWER Subsystem The CDA 7 power subsystem provides a redundant source of DC power to the major components in the CDA 7 cabinet. Figure 1-21 provides an overview of the EPO assembly and power supplies above it. POWER BUSS 3.5 DISK CAGE...

  • Page 39: Fan Assemblies

    Introduction 1.3.1 Fan Assemblies There are four fan assemblies located under the top cover of the CDA 7. To remove the top cover, loosen the two captive screws in the back of the CDA 7 and push the top back one to two inches and lift it up. The Fan Tachs are numbered 1, 2 ,3 and 4 starting from the rear left: •...

  • Page 40: Operator Panel

    CDA 7 Maintenance Manual 1.3.2 Operator Panel Figure 1-23 shows the operator panel which is located in the upper part of the front door of the CDA 7 5330 unit (9 GB). Active/Ready LEDS Re a dy Active DIR3 DIR15 DIR16 DIR14 POWER...

  • Page 41: Operator Panel - 18 Gb

    Introduction Figure 1-24 shows the operator panel which is located in the upper part of the front door of the CDA 7 5330 unit (18 GB). Active/Ready LEDS Ready Active DIR3 DIR16 DIR14 DIR15 POWER DA 1 DA 2 DIR 15 DIR 14 DIR 16 ENABLE...

  • Page 42: Cda 7 System Connection Example

    CDA 7 Maintenance Manual CDA 7 System Connection Example Figure 1-25 shows the configurations possible for CDA 7 system connection. MB2-05 MB2-04 (DPS 7000) GRP 0-0 GRP 0-3 GRP 0-1 GRP 0-2 ESDS CHANNEL CHANNEL DIRECTOR DIRECTOR DIRECTORY DIRECTORY CACHE CACHE DISK DISK...

  • Page 43: External Cable Requirements

    Introduction 1.4.1 External Cable Requirements Figure 1-26 shows the external cable requirements for the CDA 7. HOST#1 CDA 7 Disks SCSI cable Port 0 SCSI cable "built-in" terminator Terminator Port 1 (Never used !) Figure 1-26. CDA 7 External Cable Requirements 77 A7 48UU Rev03 1-27...

  • Page 44: Label Command

    CDA 7 Maintenance Manual 1.4.2 LABEL Command Entering the LABEL command displays the connections file as shown in the figure below. For more information, refer to the Bull DPS 7000 User’s Guide Firmware Release Bulletin. *** LABELs and CDA7 connections: MYCDA Iom WSP-R slot 15 PX43 port 0 connected to Scsi Adaptor slot f port A cda #01 Controller name...

  • Page 45: Cable Requirements (View From Mnconf)

    Introduction 1.4.3 Cable Requirements (View From MNCONF) Figure 1-28 shows the cable requirements for the CDA 7. SCSI’s SA-03A 20 21 22 23 24 25 26 27 20 21 22 23 24 25 26 27 SA-14A 20 21 22 23 24 25 26 27 20 21 22 23 24 25 26 27 Half Channel Director with B Processor Half Channel Director with A Processor...
  • Page 46 CDA 7 Maintenance Manual 1-30 77 A7 48UU Rev03...

  • Page 47: About The Lap-Top

    2. About the Lap-Top Location of the Lap-Top The Lap-Top for the CDA 7 is a TwinHead PC model used as a Service Processor. It is located in the front door of the subsystem. The following figure shows the position of the Lap-Top in the front door of the CDA 7. Figure 2-1.

  • Page 48: Types Of Lap-Top

    CDA 7 Maintenance Manual Types of Lap-Top There are two types of Lap-Top: • the TwinHead 5 (090-000-039) • the TwinHead 9 (090-000-040) Verifying the Lap-Top Connections The CDA 7 is delivered with an integral Lap-Top. The following figure shows the connection that must be in place.
  • Page 49 About the Lap-Top When you define the setup parameters of your Lap-Top, you need to enter the type of the interface board. To find out the type, proceed as follows: Unplug the Modem and Ethernet cables. To extract the board, press on the lock and remove the board. Read the socket identifier on the board.

  • Page 50: Connecting The Modem

    CDA 7 Maintenance Manual Connecting the Modem Use a modem in the standard of the country where the CDA 7 is to be installed. The COM card connector dedicated to the modem is at the end of a cable and is accessible at the Bus &...

  • Page 51: System Repairs

    3. System Repairs This chapter contains only a broad outline of the procedures for removing and replacing CDA 7 components. The replacement procedure used depends on the category to which the component in question belongs. For full details of the procedures, refer to the SYMMETRIX Maintenance Manual Part Number PN-200-858-551, and in all cases contact your Bull Competence Center.

  • Page 52: Oru Classes

    CDA 7 Maintenance Manual ORU Classes There are two classes for ORU replacement: • Class A, "non-disruptive procedure": Those that can be removed and replaced while the system remains on-line. • Class B, "disruptive procedure": Those that must be removed and replaced off-line.

  • Page 53: Power Down/Power Up Procedure

    System Repairs Power Down/power up Procedure This procedure describes the steps for powering down and powering up the CDA 7. There are two procedures for powering down: • routine • emergency 3.2.1 Routine Power Down To power down your CDA 7 subsystem: From your GCOS console, set the channels off-line.

  • Page 54: Power On

    CDA 7 Maintenance Manual 3.2.3 Power On To power ON your CDA 7 subsystem: Turn the battery ON. Verify that the EPO switch is in the up position. Set the AC power switch on the Power Distribution Module to the up position and wait for the end of IML operations.

  • Page 55: Replacing A Disk-Drive

    System Repairs 3.3.1 Replacing a Disk-Drive To replace a disk-drive, follow the procedure described hereafter: • Identify the disk-drive. • Replace the identified disk-drive. 3.3.1.1 Identifying the Disk-Drive To identify a disk-drive in the cluster: Using the deplacement arrows, go to the Disk Utilities Menu or enter P. A window is displayed.
  • Page 56 CDA 7 Maintenance Manual Select the Mark a Volume option or enter A. CDA7 5330 version CDA7 5630 version A window is displayed. Highlight the Turn LED ON option and press Enter to select it. A window is displayed. Highlight the Single Device option and press Enter to select it. A dialog box displays the following message: Enter Entire Device Number to Mark.

  • Page 57: Marking The Mirror Disk-Drive 1000

    System Repairs Disk Cage Rear View LED ON Mirror 1 Disk 000 Figure 3-1. Marking the Mirror Disk-Drive 1000 The information of the mirror Disk-drive 1000 is as follows: 77 A7 48UU Rev03...
  • Page 58 CDA 7 Maintenance Manual 3.3.1.2 Replacing the Identified Disk-Drive To replace the disk-drive you just identified: From the main window, select the Hot Replacement Menu or enter Q. A window is displayed. CDA7 5330 version CDA7 5630 version 77 A7 48UU Rev03...
  • Page 59 System Repairs Select the Replace Disk Drive option or press A. CDA7 5330 version CDA7 5630 version A window displays the following information. Non Mirror Mirror 1 Mirror 2 Mirror 3 RAID DATA RAID Parity RDF R1 RDF R2 RDF R3 Mirror For RDF R3 Mirror For BCV Volume An R1...
  • Page 60 CDA 7 Maintenance Manual Extract the disk-drive. Several messages are displayed, then you are prompted to place the new disk-drive. Place the new disk-drive. The data is rebuilt from the mirror disk-drive. 3-10 77 A7 48UU Rev03...

  • Page 61: Replacing The Director And Communication Card

    System Repairs 3.3.2 Replacing the Director and Communication Card This procedure is valid for all DIRECTORS except DA#1: • switch Disk Director to ENABLE, Channel DIRECTORS to DISABLE on the operator panel. • display the Hot replacement menu, then select the card type. The figure below illustrates schematically the steps involved in this procedure: DIRECTOR Number Choice Confirmation ?
  • Page 62 CDA 7 Maintenance Manual The details of the procedure are as follows: Enter the number of directors to be replaced. Transfer the data load from DIR 1 to DIR 2. Change the DIR 1. A message box is displayed and, it prompts you to enter the LAN Number.

  • Page 63: Replacing The Da#1 From The Lap-Top Access Change

    System Repairs 3.3.3 Replacing the DA#1 from the Lap-Top Access Change Before replacing the DA#1 from the Lap-Top access change, call the Bull Competence Center. To define the default access on DA#1: Using the deplacement arrows, highlight the PC Configuration option or press L.
  • Page 64 CDA 7 Maintenance Manual Highlight the RS-232 MUX option and press Enter. The default value of the MUX ’Local’ director is 02. Enter the number of the DIRECTOR to MUX ’Local’ director. At the end of the operation, highlight the Parallel port option: Not in use and press Enter.

  • Page 65: Replacing The Memory Board

    System Repairs 3.3.4 Replacing the Memory Board To replace the memory board: Highlight the Hot Replacement Menu and press Enter. Select the type of board. The procedure is as follows: Replace memory board ..Memory MAP: HEX Slot 0000 0008 0010 0028 0020...

  • Page 66: Replacing The Battery

    CDA 7 Maintenance Manual 3.3.5 Replacing the Battery The procedure for replacing the battery is as follows: Turn the battery OFF. Remove the two screws from the left of the battery. Remove the PS1/PS2 Power/Battery cables. Use the handle to pull the battery backwards (be careful, it is very heavy) Position the new battery in the cabinet.

  • Page 67: Replacing A Fan Module

    System Repairs 3.3.6 Replacing a Fan Module Figure 3-4 shows you the location of fan modules: Fan Tach #1 Fan Tach #2 Fan Tach #4 Fan Tach #3 Figure 3-4. Location of Fan Modules 77 A7 48UU Rev03 3-17...

  • Page 68: Unmounting Fan Modules

    CDA 7 Maintenance Manual Unmount the upper cover of the cabinet, and remove the two fan fixing screws which are accessible from behind, then slide backward and lift slowly as shown in figure 3-5. REAR FRONT 1. Remove the 2. Slide backward 3.

  • Page 69: Replacing The Power Supply

    System Repairs 3.3.7 Replacing the Power Supply Figure 3-6 shows the battery with an extension cable: Bat. Figure 3-6. Battery With Extension Remove the battery and attach it if necessary to an extension cable. Turn the power supply being replaced OFF at the Power Distribution Module (PDM).
  • Page 70 CDA 7 Maintenance Manual Figure 3-7 shows a rear view of the power supplies: PS1 & PS2 Rear View Power Supply Control Cable AC Power Cable Fan Power Battery Assembling Bolts Cable Connection to Busbar Figure 3-7. Power Supply (Rear View) On the rear of the power supply, remove the four connectors: −...

  • Page 71: Replacing The Lap-Top

    System Repairs 3.3.8 Replacing the Lap-Top The Lap-Top in the CDA 7 subsystem is a TwinHead PC. Figure 3-8 shows the Lap-Top in place in the front door of the CDA 7 subsystem. Plate Figure 3-8. Lap-Top in the Front Door To replace the Lap-Top follow the procedure described hereafter: Make sure the Lap-Top is off.

  • Page 72: Disruptive Replacement Procedures

    CDA 7 Maintenance Manual Disruptive Replacement Procedures 3.4.1 Replacing the Power Distribution Module The Power Distribution Model replacement procedure is as follows: Power down the system, including PS1 and PS2. Disconnect the AC main cable. Remove the PDM fixing screw. Remove the Module carefully.

  • Page 73: Alarm Codes And Errors

    System Repairs Alarm Codes and Errors 3.5.1 COM Card Alarm Code Figure 3-10, below, shows the hexadecimal display on the two COM card types. 3 positions slider switch (Must be in low position) Jumper J1 RS232 connector, (Engeenering) Remote power connector CR19 SW5 Attention switch CR15...

  • Page 74: Environment Faults

    CDA 7 Maintenance Manual 3.5.3 Environment Faults To display the environmental faults: From the main window, select the Statistics Menu or enter O. A window is displayed. CDA7 5330 version CDA7 5630 version 3-24 77 A7 48UU Rev03...
  • Page 75 System Repairs Select Display Environment Faults or enter F. CDA7 5330 version CDA7 5630 version 77 A7 48UU Rev03 3-25...
  • Page 76 CDA 7 Maintenance Manual XAMPLE Figure 3-11 shows a typical environment fault display. Type N to update Type Q to quit, A to toggle scanning all directors 33: POWER FAIL ALMPS1 35: CHG STATE ALMPS2 Bit 35 Bit 33 Quit, return to menu Figure 3-11.

  • Page 77: Displaying The Memory Error Map

    System Repairs 3.5.4 Displaying the Memory Error Map To display the memory error map: Select Display Memory Errors option in the Statistics menu or enter E. CDA7 5330 version CDA7 5630 version 77 A7 48UU Rev03 3-27...
  • Page 78 CDA 7 Maintenance Manual The scan start date is displayed as follows: DISPLAY MEMORY ERRORS MAP Use data Since M/DD/YY HH/MM/SS DISPLAY MEMORY ERRORS MAP Use data Since MM/DD/YY HH/MM/SS Symp Address Slot Bank Date Time Count Pipe 3-28 77 A7 48UU Rev03...

  • Page 79: Displaying The Hardware Status Revision

    System Repairs 3.5.5 Displaying the Hardware Status Revision To display the hardware status revision: Select Display Hardware Revision option in the Statistics menu or enter D. CDA7 5330 version CDA7 5630 version 77 A7 48UU Rev03 3-29...
  • Page 80 CDA 7 Maintenance Manual The following screen is an example of the information you can display. Hardware Revision DA-01 200-811-909 B1052421362 DA-02 ..SA-15 200-881-902 05914409818 SA-16 ..MEMORY BOARDS 200-828-903 10591420096 200-828-903 **** 3-30 77 A7 48UU Rev03...

  • Page 81: Log Files

    System Repairs Log Files You can consult and copy log files from your Lap-Top. For more information, refer to the appropriate CDA 7 5330 Product Manual or CDA 7 5630 Product Manual. There are two product manuals one for 9 GB disks and one for 18 GB disks.

  • Page 82: Displaying The Log Files

    CDA 7 Maintenance Manual 3.6.2 Displaying the Log Files To display the main log files: Display the list of log files: highlight the List Log Files option in the main menu or enter H. CDA7 5330 version CDA7 5630 version In the following window, select the specific file you want to display.
  • Page 83 System Repairs Press <ENTER>. 77 A7 48UU Rev03 3-33...

  • Page 84: Copying A Log File

    CDA 7 Maintenance Manual 3.6.3 Copying a Log File If the files are too large, first use the PKZIP utility which is on the PC disk. For example (with an empty and formatted diskette): C:\SYMM4\>PKZIP A:<target-file>.ZIP <log-file>.LOG For PKZIP/PKUNZIP help: C:\SYMM4>PKZIP<Enter>...

  • Page 85: Parts Catalog

    4. Parts Catalog Overview This chapter provides a list of part numbers for use in ordering replacement parts for the CDA 7. Spare Parts List 5330 (9 GB and 18 GB Disks) Except for part numbers of the disk modules themselves, these part numbers are common to systems with 9 GB disks and 18 GB disks.

  • Page 86: Spare Parts List 5630 (18 Gb And 36 Gb Disks)

    CDA 7 Maintenance Manual Spare Parts List 5630 (18 GB and 36 GB Disks) Except for part numbers of the disk modules themselves, these part numbers are common to systems with 18 GB disks and 36 GB disks. Description EMC Part number Ultra SCSI Director Board 201-277-977 Ultra SCSI Adapter Board...

  • Page 87: Add-On/Microcode Upgrade

    5. Add-On/Microcode Upgrade The Add-On procedures are those provided by the BICC (Bull International Intervention Center). The following paragraphs should be treated as guidelines. Add-Ons or Microcode upgarades are to be performed either by BICC personnel or by accredited persons. 77 A7 48UU Rev03...

  • Page 88: Dps 7000 Add-On Hardware

    CDA 7 Maintenance Manual DPS 7000 Add-on Hardware The introduction of standard configuration files has greatly simplified Add-Ons. This chapter describes how to perform such an add-on to a CDA 7 cabinet already installed in the configuration. Perform the required operations in the order shown in Figure 5-1.
  • Page 89 Add-On/Microcode Upgrade 5.1.1 Step 1 To estimate the installation time, perform the following operation: Build a new configuration file under MNCONF as follows: S:FGF ..F:MNCONF ..N:MD <OLDCONF> <NEWCONF> CDA7 MPORTANT There are a certain number of standard configurations. In an add-on operation, the rule is as follows: Config standard XX+Add-On=Config standard YY Whatever the type of add-on, you will encounter a known configuration.
  • Page 90 CDA 7 Maintenance Manual Perform the following two commands: − FIRMGEN, − BLOAD on a media intended for the next initialization of the new configuration. For more information, refer to Basic Models in Appendix A, Software Release and CDA 7 Configurations (9 GB Disks), or in Appendix D, Software Release and CDA 7 Configurations (18 GB Disks).

  • Page 91: Microcode Upgrade/Modification

    Add-On/Microcode Upgrade 5.1.4 Step 4 The step 4 procedure is as follows: Reinitialize the entire system with the new BLOAD. Any new disk-modules are in NSTD state. Enter a VOLPREP [short] command to assign them the label chosen by your client. Terminate with BLOAD (final)/BLOAD-BACKUP if not already done.
  • Page 92 CDA 7 Maintenance Manual 77 A7 48UU Rev03...

  • Page 93: Software Level

    A. Software Release and CDA 7 Configurations (9 GB Disks) This Appendix concerns the CDA 7 with 9 GB disks only. For the equivalent information for a system with 18 GB disks, see Appendix D. Software Level The software release level is identified according to the following format: XXXX.yy.zz where: XXXX...

  • Page 94: Bin Files

    CDA 7 Maintenance Manual Bin Files For the 9 GB disks, the following BIN files are available: 5300-9M: D0100-20.BIN 8 HDAs Mirrored (4 M1 + 4 M2) D0200-20.BIN 16 HDAs Mirrored (8 M1 + 8 M2) D0300-20.BIN 24 HDAs Mirrored (12 M1 + 12 M2) D0400-20.BIN 32 HDAs Mirrored (16 M1 + 16 M2) 5300-9S...

  • Page 95: Cda 7 5330 Disk Configurations

    Software Release and CDA 7 Configurations (9 GB Disks) CDA 7 5330 Disk Configurations A CDA 7 5330 cabinet is organized into from one to four physical groups (0 to 3) of eight physical disks each. Each physical group may be: •...

  • Page 96: Basic Models

    CDA 7 Maintenance Manual Basic Models A.4.1 MSPD038-0000: 4 Mirror 8 physical disk drives 4 logical disks Cache: 2*512 MBytes Binary file: D0100-20 00 01 02 DA-01 DA-02 21 22 SA-15A 21 22 SA-16A Mirror-1 Mirror-2 77 A7 48UU Rev03...

  • Page 97: Mspd039-0000: 8 Mirror

    Software Release and CDA 7 Configurations (9 GB Disks) A.4.2 MSPD039-0000: 8 Mirror 16 physical disk drives 8 logical disks Cache: 2*512 MBytes Binary file: D0200-20 00 01 02 03 04 05 06 07 DA-01 DA-02 21 22 23 24 26 27 SA-15A 21 22 23 24...

  • Page 98: Mspd040-0000: 12 Mirror

    CDA 7 Maintenance Manual A.4.3 MSPD040-0000: 12 Mirror 24 physical disk drives 12 logical disks Cache: 2*512 MBytes Binary file: D0300-20 00 01 02 03 04 05 06 07 08 09 0A 0B DA-01 DA-02 20 21 22 23 24 25 26 27 SA-15A 20 21 22 23 20 21 22 23 24 25 26 27...

  • Page 99: Mspd041-0000: 16 Mirror

    Software Release and CDA 7 Configurations (9 GB Disks) A.4.4 MSPD041-0000: 16 Mirror 32 physical disk drives 16 logical disks Cache: 2*512 MBytes Binary file: D0400-20 77 A7 48UU Rev03...

  • Page 100: Mspd042-0000: 6 Raid-S

    CDA 7 Maintenance Manual A.4.5 MSPD042-0000: 6 RAID-S 8 physical disk drives 6 logical disks Cache: 2*512 MBytes Binary file: D2000-20 77 A7 48UU Rev03...

  • Page 101: Mspd039-0000: 9 Raid-S

    Software Release and CDA 7 Configurations (9 GB Disks) A.4.6 MSPD039-0000: 9 RAID-S 12 physical disk drives 9 logical disks Cache: 2*512 MBytes Binary file: D3000-20 77 A7 48UU Rev03...

  • Page 102: Mspd040-0000: 12 Raid-S

    CDA 7 Maintenance Manual A.4.7 MSPD040-0000: 12 RAID-S 16 physical disk drives 12 logical disks Cache: 2*512 MBytes Binary file: D4000-20 A-10 77 A7 48UU Rev03...

  • Page 103: Mspd041-0000: 15 Raid-S

    Software Release and CDA 7 Configurations (9 GB Disks) A.4.8 MSPD041-0000: 15 RAID-S 20 physical disk drives 15 logical disks Cache: 2*512 MBytes Binary file: D5000-20 77 A7 48UU Rev03 A-11...

  • Page 104: Mspd042-0000: 18 Raid-S

    CDA 7 Maintenance Manual A.4.9 MSPD042-0000: 18 RAID-S 24 physical disk drives 18 logical disks Cache: (1*1024 + 1*512) MBytes Binary file: D6000-20 A-12 77 A7 48UU Rev03...

  • Page 105: Mspd043-0000: 21 Raid-S

    Software Release and CDA 7 Configurations (9 GB Disks) A.4.10 MSPD043-0000: 21 RAID-S 28 physical disk drives 21 logical disks Cache: (1*1024 + 1*512) MBytes Binary file: D7000-20 77 A7 48UU Rev03 A-13...

  • Page 106: Mspd044-0000: 24 Raid-S

    CDA 7 Maintenance Manual A.4.11 MSPD044-0000: 24 RAID-S 32 physical disk drives 24 logical disks Cache: (1*1024 + 1*512) MBytes Binary file: D8000-20 A-14 77 A7 48UU Rev03...

  • Page 107: Error Report (Gcos 7 Prlog

    B. Error Report (GCOS 7 PRLOG) This Appendix concerns the CDA 7 with either 9 GB disks or 18 GB disks. Channel Exceptions At the top of the PRLOG you find an area called History report for Channel Exception. The channel exception logging allows you to define the channel exception reasons and at the same time information on the cause of this state.
  • Page 108 CDA 7 Maintenance Manual The "Reason" list of Termp code on abnormal execution of GPOS primitive are: 0x01 RC_RQTM Request timer 0x02 RC_DELRQT Delete timer 0x03 RC_SEPM P operation 0x04 RC_SEPMTST P operation test 0x05 RC_SEVM V operation 0x06 RC_NOTIFY Notify (attention) 0x07 RC_GETDATA...
  • Page 109 Error Report (GCOS 7 PRLOG) 0x60 TIMERQUEUE_EXPECTED 0x61 TIMERBUSY_EXPECTED 0x62 ILLEGAL_PAGE_SELECTED Internal error, mode select page not foreseen. 0x63 ERR_DRIVER_UNKNOWN This driver error is unexpected 0x64 RC_GPOS_UNKNOWN Return code GPOS unknown or unexpected. 0x65 SENDER_UNKNOWN Message from sender unknown 0x66 SENDER_NOT_EXPECTED This message is not expected from this sender...
  • Page 110 CDA 7 Maintenance Manual 0x82 NO_SYC_PARAMETER No SYC parameter in the table. 0x83 LUN_NOT_PRESENT ID2, LUN # 0 mandatory, is not present 0x84 UNKNOWN_CONFIG Configuration is neither RAID-1 nor RAID-5 0x85 UNKNOWN_MESSAGE Monitoring Process Message received is unknown 0x86 UNKNOWN_SP No reply from SP during test switch LUN 0x87...

  • Page 111: I/O Errors

    Error Report (GCOS 7 PRLOG) I/O Errors The PRLOG contains an area dedicated to each logical device named History report for MSxx FSA. This area reports all types of I/O errors such as: NT with marginal conditions, ASR, ANR, AMR) and the Attentions. Some I/O errors and attentions, reported by WSP-A, are filtered by GCOS 7 (AVAIL &...
  • Page 112 CDA 7 Maintenance Manual STANDARDIZED DETAILED STATUS DSB0 bit 0 Illegal command bit 1 Illegal count bit 2 Invalid data bit 3 Illegal sequence bit 4 Resume error bit 5 bit 6 bit 7 Programmed release DSB1 bit 0 Underrun/Overrun (for WSP the meaning is: device busy longer than expected) bit 1 Device not initialized...
  • Page 113 Error Report (GCOS 7 PRLOG) DSB9 bit 0-1 bit 2 Device Explicitly Seized bit 3 Device Implicitly Seized bit 4 Device Was Reserved bit 5-7 DSB10 to DSB12: Current Operating Mode Type of Device: DSB13 0x00=Illegal Value (Device unknown) 0x01=ST42400N; 2,1Gbytes 0x02=ST41600N;...
  • Page 114 CDA 7 Maintenance Manual CONTROLLER/DEVICE STATUS Last failed SCSI command. These bytes report the last DSB16-DSB27 failed command descriptor block as described in SCSI specification (ANSI X3T9.2/86). Valid field. This byte reports the first byte of extended sense DSB28 table as described in SCSI specification (ANSI X3T9.2/86) DSB29 bit 0 tape mark detected bit 1 EOM...
  • Page 115 Error Report (GCOS 7 PRLOG) SCSI Controller Type: DSB40 0x00: MSP 0x10: WSP 0x11: WSP-R 0x12: WSP-B DSB41-DSB44 Complementary device type revision level If Device Type= 06 IBM disks -->FW Disks DSB45 Degraded Mode Information byte: If Device type = 80 or 81 (EMC) . 0x00 : Normal Mode.
  • Page 116 CDA 7 Maintenance Manual Vendor Identification DSB46 0x00 illegal code. 0x01 SEAGATE 0x03 MAXTOR 0x04 IBM 0x06 BULL 0x08 QUANTUM DSB47 0x00 illegal code 0x01=ST42400N; 2,1Gbytes 0x02=ST41600N; 1,4Gbytes 0x03=XT-4380S; 320Mbytes 0x04=XT-8760S; 680Mbytes 0x06=DFHSS2E ; 2,1Gbytes 0x07=XP32150W ;2,1Gbytes 0x08=XP34300WD;4,2Gbytes 0x80= EMC5130, 4,3 Gbytes 0x81= EMC5330, 9 Gbytes 0x8A= Disk Array 7000, 4 Gbytes 0x8B= Disk Array 7000, 5 Gbytes...
  • Page 117 Error Report (GCOS 7 PRLOG) Message out. DSB67 Last message out on SCSI bus 0x01 Extended message 0x05 Initiator detected error 0x06 Abort 0x07 Message reject 0x08 No operation 0x09 Message parity error 0x0C Bus device reset 0x8x Identify 0xCx Identify DSB68-DSB71 Last event on SCSI bus File termp code.
  • Page 118 CDA 7 Maintenance Manual DSB80-DSB95 DEFINE EXTENT/LOCATE DATA DSB96-DSB103 Drive serial number DSB104-DSB107 If (DSB104 = 0xFF) DSB105 = 0x00 DSB106 = 0x00 ou 0x01( Fuse SCSI port0 blown) DSB107 = 0x00 ou 0x01( Fuse SCSI port1 blown) Else if ( Device type = 80 or 81(EMC) and DSB[45] not equal to 00) The information bytes contains a value which represents a complementary Degraded mode information.
  • Page 119 Error Report (GCOS 7 PRLOG) If DSB116 different 0 and different 1: err_driver. DSB117 DSB118 device status DSB119 DSB120 DSB121 ASCQ If DSB116 equal 1 (AIR error): err_driver DSB122 device status DSB123 DSB124 DSB125 DSB126 ASCQ DSB127 If (Device type= 8A or 8B or 8C or 8D and DSB[127] = zyyy yyyy;...
  • Page 120 CDA 7 Maintenance Manual B-14 77 A7 48UU Rev03...

  • Page 121: Installing The Cda 7 5330 With Microcode Release 5263

    C. Installing the CDA 7 5330 with Microcode Release 5263 This Appendix concerns Release 5263 of the Microcode only. This release runs on the CDA 7 with 9 GB disks only. The following table shows the relationship Microcode Release <-> Disk Size. Disks Release 5263 Release 5264...

  • Page 122: Installation Conditions/Auxiliaries

    CDA 7 Maintenance Manual Installation Conditions/Auxiliaries These characteristics are mentioned as a reminder, and are given in the CDA 7 5330 Site Preparation Guide. Electrical environment: • 220 V - 20 A single phase, output by an electric box (International). •...

  • Page 123: Installing The Cda 7 On A Host System

    Installing the CDA 7 5330 with Microcode Release 5263 Installing the CDA 7 on a Host System Two ways are possible: • Installation of a CDA 7 subsystem in an existing configuration. This case is described hereafter. • Installation of a CDA 7 subsystem delivered with a new system. For more information, refer to the On-Line Help of the BUILD P2 command of FGF.
  • Page 124 CDA 7 Maintenance Manual De-palletizing the subsystem Check the "TIP-N-TELL" indicator on one side of the main package. Unpack the box, and cut the protection film to access the cabinet on its pallet. Open the front and rear doors. Release the cabinet by removing the shipping brackets, you will need to remove six screws and six bolts, see the figure below.

  • Page 125: Powering Up The Cda 7

    Installing the CDA 7 5330 with Microcode Release 5263 C.3.2 Powering Up the CDA 7 C.3.2.1 Electrical Connection of Subsystem After opening the back door, check that the PDM breakers (EPO and AC), the PS1 and PS2 breakers and the BATTERY switch are OFF. Check that the circuit breaker, (customer panel), for the AC power connection box is OFF.

  • Page 126: Setting The Cda 7 Internal Clocks

    CDA 7 Maintenance Manual A faulty DIRECTOR or a DIRECTOR which has been badly initialized displays the value DD. In this case, restart the operation or contact support. In this case, "loading" includes initialization of the hardware and loading the MICROCODE (IML = Initial MICROCODE Loading).
  • Page 127 Installing the CDA 7 5330 with Microcode Release 5263 C.3.3.2 Loading the Defined Parameter Values to the CDA 7 Clock To set the SYMMETRIX clock of the CDA 7 subsystem: Set All directors OFF line. In the main window, select the Maintenance Menu or press M. INLINES AUTOMATIC INSTALL ANALYZE...

  • Page 128: Setting The Site Information

    CDA 7 Maintenance Manual C.3.4 Setting the Site Information To enter the site information: In the Symm4 Main Window, select Site information option or enter J. INLINES AUTOMATIC INSTALL ANALYZE SUBSYSTEM IML VTOC ALL DRIVES IN SYSTM ON LINE Configuration Change Start logging List Log files Display Code revision...
  • Page 129 Installing the CDA 7 5330 with Microcode Release 5263 During the CDA 7 installation procedure, set Enable Automatic Calls to FieldWatch? to N. After the installation, verify the connection by changing Enable Automatic Calls to FieldWatch? to Y. Enter the following parameters: Enter site name: This name begins G7 followed by the four last digits of the serial number of the tag located on the rear side...
  • Page 130 CDA 7 Maintenance Manual Note some redundancies between the two first Site information screens. Site information Modem port: Modem Baud rate: 9600 Parity: N Stop bits: 1 Data bits: 8 Parrallel port: "Not in use" RS-232 MUX Use only black and white? N Return to default colors? N Modify screen colors? N Reboot after calling home? N...
  • Page 131 Installing the CDA 7 5330 with Microcode Release 5263 Press F10 to go back to the Symm4 Main Window and save modifications. When press ESCape generally displays the following message: All changes will be abandoned. Quit anyway? Enter Y for YES. The default option is N for NO. Pressing ESCape displays the following message: Do you really want to quit? Press Enter to return to MS-DOS.

  • Page 132: Verifying The Site Information

    CDA 7 Maintenance Manual C.3.5 Verifying the Site Information C.3.5.1 Verifying the Customer Name The Customer name is in the header of the main menu in the miscellaneous information area: Figure C-8. Customer Name For the DPS 7000 line, the customer name will be identified as follows: G7 + last 4 digits of the serial number + (Blank) + Customer Name + (Blank ) + Town This allows the AUTOCALL reception center to sort DPS 7000 systems, and to...
  • Page 133 Installing the CDA 7 5330 with Microcode Release 5263 C.3.5.2 Verifying the CDA 7 Serial Number The cabinet serial number is located on the label glued at the top back of the rack. Top cover EMC CORPORATION 50/60 Hz 208/240 Rear view 10 A MODEL NO...

  • Page 134: Setting The Modem Parameters

    CDA 7 Maintenance Manual C.3.6 Setting the Modem Parameters To set the Modem parameters: Under the SYMM4 prompt, enter the following command: C:\SYMM4> scsetup The following dialog box is displayed. SymmCom Target Configuration Modem Multitech MULTIMODEM Comm Port COM (3F8 hex- IRQ4) Port Rate 19200 Connectivity...

  • Page 135: Verifying The Cda 7 Configuration

    Installing the CDA 7 5330 with Microcode Release 5263 To enter the values of the parameters displayed in the above table, answer to these dialog boxes as follows: Modem Multitech MULTIMODEM Comm Port COM2 (2F8 hex.) Port Rate 9600 Connectivity Allowed Password Change Enter G7xxx.
  • Page 136 CDA 7 Maintenance Manual C.3.7.2 Standard Configuration The standard configuration of a basic CDA 7 contains: • 2 to 4 SCSI Channel DIRECTORS • 2 Disk DIRECTORS • 2 Memory boards • 8 physical disk-modules For more information about CDA 7 subsystems with 9 GB disks, refer to the Appendix A Software Release and CDA 7 Configurations (9 GB Disks) earlier in this document.
  • Page 137 Installing the CDA 7 5330 with Microcode Release 5263 INLINES AUTOMATIC INSTALL ANALYZE SUBSYSTEM IML VTOC ALL DRIVES IN SYSTEM ON LINE Configuration Change Start logging List Log files Display Code revision Site Information MII Parameters PC Configuration *** Maintenance Menu *** *** RDF Utilities Menu ***...
  • Page 138 CDA 7 Maintenance Manual And an example of the final result: IMPL File: C:\SYMM4\IMPL.BI1 08/29/97 15:14:04 aced: ACED version: 4220 internal date: 08/29/1997 ================== IMPL HEADER ================== Host: Server/Bull Emulation: Disk size: :Mix Physical drives: Volumes: Mirrors: Memory (MB): 1024 Hot Spare: Disable Mirroring:...
  • Page 139 Installing the CDA 7 5330 with Microcode Release 5263 ================== Detailed Director list ================== DA-01 Target | Dev. | Int. | Cyl. | Label Flags ====== | ==== | ======== | ====== | ========== | ============== | | 00 | C0 | 18414 | SYM000 | M1 | 04...
  • Page 140 CDA 7 Maintenance Manual SA-16: (4 Channels) Channel: A 1st dev | last dev | 1st chn | last dev | count | ======== | ======== | ======== | ======== | ======== | | 07 | 20 | 27 Channel: B 1st dev | last dev | 1st chn | last dev | count | ======== | ======== | ======== | ======== | ======== |...
  • Page 141 Installing the CDA 7 5330 with Microcode Release 5263 C.3.7.5 Running Automatic Installation To run the Automatic Installation: Highlight the AUTOMATIC INSTALL option in the Main menu or enter B. INLINES AUTOMATIC INSTALL ANALYZE SUBSYSTEM IML VTOC ALL DRIVES IN SYSTEM ON LINE Configuration Change Start logging List Log files...
  • Page 142 CDA 7 Maintenance Manual The following screens are displayed in turn. • In each screen, press the up/down/right/left keys to highlight your choice. • Press Enter to validate the highlighted parameter and go to the next line or next screen. WARNING: USE OF CERTAIN FEATURES IN THIS MICROCODE REQUIRE SEPARATE SOFTWARE LICENCE NOT AUTOMATICALLY INCLUDED WITH THE SYMMETRIX.
  • Page 143 Installing the CDA 7 5330 with Microcode Release 5263 The next screen gives a warning concerning a format operation on disks. The following dialog box asks if the PC is connected to a CDA 7 cabinet ("box"), which is usually the case. First installation only Current procedure Upgrade/modification operations...
  • Page 144 CDA 7 Maintenance Manual C.3.7.6 Running the Change Command To change (or check) the configuration or some parameters, proceed as follows: If you modify an existing configuration in the case of an Add-on, select Change to make any changes to the configuration, or to check the configuration.
  • Page 145 Installing the CDA 7 5330 with Microcode Release 5263 Pressing "Enter" on this selection causes the map to be displayed SYMMETRIX III Configuration Information Enter Total System memory (MB): 1024 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Enable Mirroring? Enable Dynamic Spare? Number of PHYSICAL drives: 16 Drive type: Cuda-9X...
  • Page 146 CDA 7 Maintenance Manual Internal device number Mirrored pair = SCSI Address #2 for CDA subsystem One logical disk [CTRL] Arrow, PgUp, PgDn move. F10 exit. <R>estore. <O>riginal. Space Bar Add/Del. "M" to toggle No-Mirror ( ) -> Mirror-1 ( ) -> Mirror-2 ( ) "S": Rearrange.
  • Page 147 Installing the CDA 7 5330 with Microcode Release 5263 The lower part of the screen shows the distribution of logical units per channel. SCSI Adaptor for SCSI DIRECTOR #3 SCSI’s SA-03A SA-14A Figure C-19. Distribution of Logical Units The final part of the screen shows the wiring of the 16 logical units in the subsystem.
  • Page 148 CDA 7 Maintenance Manual SYMMETRIX III Configuration Information Enter Total System memory (MB): 2048 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Are you updating a live system? N Number of PHYSICAL drives: 02 Drive type: Cuda-9X 16 Logical Volumes in the system. "Edit Directors/Volumes/Channels map"...
  • Page 149 Installing the CDA 7 5330 with Microcode Release 5263 Remember that the MNCONF "LABEL" command will give almost the same layout showing the distribution of disks on each SCSI channel, for cabling the subsystem and the name of the binfile. Press F10.
  • Page 150 CDA 7 Maintenance Manual C.3.8 Declaring the CDA 7 Subsystem under GCOS 7 The version of FGF supporting CDA 7 subsystem does not have any new commands for management of these subassemblies. C.3.8.1 Global Method Firstly, you should be aware that if MSC4 subsystems are present in the configuration, MNCONF will assign slots occupied by the PxM cards to WSP cards, and that substitution will be compulsory.
  • Page 151 Installing the CDA 7 5330 with Microcode Release 5263 C.3.8.2 Declaring the CDA 7 Subsystems Non-coupled system Definition: a "physical group" of disks always contains 8 disks. The following is a standard declaration of a configuration containing 8 physical disks. (1) N: MD OLD NEWCDA CDA7 CDA7 CDA7 present?
  • Page 152 CDA 7 Maintenance Manual Coupling refers to both of the following possibilities: Your system Your system Inst # 0 Inst # 1 Inst # 0 Inst # 1 From inst # 1 to "myinstall" From "myinstall" to install # 1 Cabinets that are accessed by two installations are incorrectly called "4 path"...
  • Page 153 Installing the CDA 7 5330 with Microcode Release 5263 Second case: your system accesses installation #1 : N: MD TEMPCDA REMPCDA1 CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled? With AURIGA? Instal # <0 or 1>...
  • Page 154 CDA 7 Maintenance Manual C.3.8.3 Running the LABEL Command The LABEL command has been modified to support CDA 7 subsystems. It clearly and unambiguously gives From/To information for SCSI cables between IOSS and the CDA 7 cabinet. XAMPLE ITHOUT OUPLING Configuration: 8 mirrored disks = 4 logical volumes *** LABELS and CDA7 connections: MYCDA *** Iom WSP-R slot 15 PX43...
  • Page 155 Installing the CDA 7 5330 with Microcode Release 5263 XAMPLE ONFIGURATION ON **Lap top configuration for cda #01 ---> Name of the bin file is: Cxxxx-xx i.e. corresponds to file Dxxxx-xx.BIN on the hard disk External identifier MSxx 01 02 03 04 00 01 02 03 Device number for CDA sub-system SA-15A...
  • Page 156 CDA 7 Maintenance Manual XAMPLE OUPLING This is a configuration of 16 mirrored disks belonging to a cabinet in another installation. Iom WSP-R slot 19 PX47 port 0 connected to Scsi Adaptor slot 0 port D cda #01 other instal Iom WSP-R slot 08 PX10 port 0 connected to Scsi Adaptor slot 2 port D cda #01 other instal From...

  • Page 157: Software Level

    D. Software Release and CDA 7 Configurations (18 GB Disks) This Appendix concerns the CDA 7 with 18 GB disks. For the equivalent information for a system with 9 GB disks, see Appendix A. Software Level The software release level is identified according to the following format: XXXX.yy.zz where: XXXX...

  • Page 158: Bin Files

    CDA 7 Maintenance Manual BIN Files The 18 GB configuration implies sharing with UNIX. In this case, the BIN files described below are just the base from which you create the real BIN files. The BIN files supplied describe just the disks accessed by GCOS 7. In the case of sharing between the CDA 7 and UNIX, the ESP option is implemented.

  • Page 159: Cda 7 5330 Disk Configurations

    Software Release and CDA 7 Configurations (18 GB Disks) CDA 7 5330 Disk Configurations A CDA 7 5330 cabinet is organized into from one to four physical groups (0 to 3) of eight physical disks each. Each physical group is four MIRROR devices (8 physical disks).

  • Page 160: Basic Models

    CDA 7 Maintenance Manual Basic Models D.4.1 Binary File S01-200.BIN 4 physical disks (and 4 logical disks) configured in RAID1: 4 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 161: Binary File S02-200.Bin

    Software Release and CDA 7 Configurations (18 GB Disks) D.4.2 Binary File S02-200.BIN 8 physical disks (and 8 logical disks) configured in RAID 1: 8 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 162: Binary File S03-200.Bin

    CDA 7 Maintenance Manual D.4.3 Binary File S03-200.BIN 12 physical disks (and 12 logical disks) configured in RAID 1: 12 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 163: Binary File S04-200.Bin

    Software Release and CDA 7 Configurations (18 GB Disks) D.4.4 Binary File S04-200.BIN 16 physical disks (and 16 logical disks) configured in RAID 1: 16 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 164: Binary File S05-200.Bin

    CDA 7 Maintenance Manual D.4.5 Binary File S05-200.BIN 20 physical disks configured in RAID 1: 20 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 165: Binary File S06-200.Bin

    Software Release and CDA 7 Configurations (18 GB Disks) D.4.6 Binary File S06-200.BIN 24 physical disks configured in RAID 1: 24 Mirror. Cache: 2*512 MBytes. 77 A7 48UU Rev03...

  • Page 166: Binary File S07-200.Bin

    CDA 7 Maintenance Manual D.4.7 Binary File S07-200.BIN 28 physical disks configured in RAID 1: 28 Mirror. Cache: 2*512 MBytes. MI: For example, MSPD054-0000. D-10 77 A7 48UU Rev03...

  • Page 167: Binary File S08-200.Bin

    Software Release and CDA 7 Configurations (18 GB Disks) D.4.8 Binary File S08-200.BIN 32 physical disks configured in RAID 1: 32 Mirror. Cache: 2*512 MBytes. The first figure shows the left hand side, the second shows the right hand side. 77 A7 48UU Rev03 D-11...
  • Page 168 CDA 7 Maintenance Manual D-12 77 A7 48UU Rev03...

  • Page 169: Installing The Cda 7 5330 With Microcode Release 5264

    E. Installing the CDA 7 5330 with Microcode Release 5264 This Appendix concerns the CDA 7 with Microcode Release 5264. This release of the Microcode can run on systems with 9 GB or with 18 GB disks. The following table shows the relationship Microcode Release <-> Disk Size. Disks Release 5263 Release 5264...

  • Page 170: Installation Conditions/Auxiliaries

    CDA 7 Maintenance Manual Installation Conditions/auxiliaries These characteristics are mentioned as a reminder, and are given in the CDA 7 5330 Site Preparation Guide. Electrical environment: • 220 V - 20 A single phase, output by an electric box (International). •...

  • Page 171: Installing The Cda 7 On A Host System

    Installing the CDA 7 5330 with Microcode Release 5264 Installing the CDA 7 on a Host System Two ways are possible: • Installation of a CDA 7 subsystem in an existing configuration. This case is described hereafter. • Installation of a CDA 7 subsystem delivered with a new system. For more information, refer to the On-Line Help of the BUILD P2 command of FGF.
  • Page 172 CDA 7 Maintenance Manual Depalletizing the subsystem Check the "TIP-N-TELL" indicator on one side of the main package. Unpack the box, and cut the protection film to access the cabinet on its pallet. Open the front and rear doors. Release the cabinet by removing the shipping brackets, you will need to remove six screws and six bolts, see the figure below.

  • Page 173: Powering Up The Cda 7

    Installing the CDA 7 5330 with Microcode Release 5264 E.3.2 Powering Up the CDA 7 E.3.2.1 Electrical Connection of Subsystem After opening the back door, check that the PDM breakers (EPO and AC), the PS1 and PS2 breakers and the BATTERY switch are OFF. Check that the circuit breaker, (customer panel), for the AC power connection box is OFF.

  • Page 174: Setting The Pc Parameters

    CDA 7 Maintenance Manual A faulty DIRECTOR or a DIRECTOR which has been badly initialized displays the value DD. In this case, restart the operation or contact support. In this case, "loading" includes initialization of the hardware and loading the MICROCODE (IML = Initial MICROCODE Loading).
  • Page 175 Installing the CDA 7 5330 with Microcode Release 5264 The following screen is displayed: Figure E-3. PC Configuration - 2 This screen displays the standard values of the parameters. If you select the Parallel port: • RS-232 MUX, the following line displays: MUX "local" director: 1 and the cursor goes automatically to this line.

  • Page 176: Setting The Site Information

    CDA 7 Maintenance Manual E.3.4 Setting the Site Information To enter the site information: In the Symm4 Main Window, select Site information option or enter J. Figure E-4. Site Information - 1 77 A7 48UU Rev03...
  • Page 177 Installing the CDA 7 5330 with Microcode Release 5264 The following screen is displayed: Figure E-5. Site Information - 2 To enter the three phone numbers, call the Bull Competence Center. Enter the following parameters: Enter site name: This name begins G7 followed by the four last digits of the serial number on the label located on the rear side of the cabinet.
  • Page 178 CDA 7 Maintenance Manual During the CDA 7 installation procedure, set Enable Automatic Calls Home? to N. After the installation, verify the connection by changing both Enable Automatic Calls Home? and Enable Machine Initiated Interrupts to Y. Click on to proceed from screen to screen. More Figure E-6.
  • Page 179 Installing the CDA 7 5330 with Microcode Release 5264 Figure E-7. Site Information - 4 Figure E-8. Site Information - 5 The values of some of these parameters may change in different versions, please refer to the Bull Competence Center to obtain up-to-date parameters. 77 A7 48UU Rev03 E-11...
  • Page 180 CDA 7 Maintenance Manual MPORTANT Remember that the function of the ESCape key is to exit without modification. Press F10 to go back to the Symm4 Main Window and save modifications. If you press ESCape the following message is displayed: All changes will be abandoned.

  • Page 181: Verifying The Site Information

    Installing the CDA 7 5330 with Microcode Release 5264 E.3.5 Verifying the Site Information E.3.5.1 Verifying the Customer Name The Customer name is in the header of the main menu in the miscellaneous information area: Figure E-9. Customer Name For the DPS 7000 line, the customer name is made up as follows: G7 + last 4 digits of the serial number + (Blank) + Customer Name + (Blank ) + Town This allows the AUTOCALL reception center to sort DPS 7000 systems, and to...
  • Page 182 CDA 7 Maintenance Manual E.3.5.2 Verifying the CDA 7 Serial Number The cabinet serial number is located on the label glued at the top back of the rack. Top cover EMC CORPORATION 50/60 Hz 208/240 Rear view 10 A MODEL NO EMCFRA5330 5330-9M08 SERIAL NO CRK 81800557 Figure E-10.

  • Page 183: Setting The Modem Parameters

    Installing the CDA 7 5330 with Microcode Release 5264 E.3.6 Setting the Modem Parameters To set the Modem parameters: Under the SYMM4 prompt, enter the following command: C:\SYMM4> scsetup The following dialog box is displayed. SymmCom Target Configuration Modem Multitech MULTIMODEM Comm Port COM (3F8 hex- IRQ4) Port Rate...
  • Page 184 CDA 7 Maintenance Manual To enter the values of the parameters displayed in the above table, answer to these dialog boxes as follows: Modem Multitech MULTIMODEM Comm Port COM2 (2F8 hex.) Port Rate 9600 Connectivity Allowed Password Change Enter G7xxx. Encryption Call Back disabled Press Enter.

  • Page 185: Verifying The Cda 7 Configuration

    Installing the CDA 7 5330 with Microcode Release 5264 E.3.7 Verifying the CDA 7 Configuration Bull has defined a number of standard models, for which the configuration (number of disks, number of DIRECTORS, etc.) is precisely determined. In order to initialize the subsystem correctly, the PC must contain a file describing the installed configuration;...
  • Page 186 CDA 7 Maintenance Manual E.3.7.3 Checking the Configuration To check the configuration on the laptop, use the following procedure: From the main menu, using the Up/Down arrows select the Maintenance menu or press M. E-18 77 A7 48UU Rev03...
  • Page 187 Installing the CDA 7 5330 with Microcode Release 5264 Using the Up/Down arrows, select Display Current Configuration or press I. Figure E-12. Checking the Configuration 77 A7 48UU Rev03 E-19...
  • Page 188 CDA 7 Maintenance Manual XAMPLE ESULT IMPL File: C:\SYMM4\IMPL.BI1 08/29/97 15:14:04 aced: ACED version: 4220 internal date: 08/29/1997 ================== IMPL HEADER ================== Host: Server/Bull Emulation: Disk size: :Mix Physical drives: Volumes: Mirrors: Memory (MB): 1024 Hot Spare: Disable Mirroring: Enable RDF: Disable False disconnect:...
  • Page 189 Installing the CDA 7 5330 with Microcode Release 5264 ================== Detailed Director list ================== DA-01 Target | Dev. | Int. | Cyl. | Label Flags ====== | ==== | ======== | ====== | ========== | ============== | | 00 | C0 | 18414 | SYM000 | M1 | 04...
  • Page 190 CDA 7 Maintenance Manual SA-16: (4 Channels) Channel: A 1st dev | last dev | 1st chn | last dev | count | ======== | ======== | ======== | ======== | ======== | | 07 | 20 | 27 Channel: B 1st dev | last dev | 1st chn | last dev | count | ======== | ======== | ======== | ======== | ======== |...
  • Page 191 Installing the CDA 7 5330 with Microcode Release 5264 E.3.7.5 Running Automatic Installation To run the Automatic Installation: Highlight the AUTOMATIC INSTALL option in the Main menu or enter B. Figure E-13. The Automatic Install Command A sequence of screens is displayed. •...
  • Page 192 CDA 7 Maintenance Manual The following automatic installation screens are displayed: Figure E-14. Automatic Install Screens E-24 77 A7 48UU Rev03...
  • Page 193 Installing the CDA 7 5330 with Microcode Release 5264 Select Impl.bin and, after the Warning screen, press the space bar, then select Standard. The PC reads the IMPL.BIN file from disk. − If you choose System, the configuration is read from the installed hardware.
  • Page 194 CDA 7 Maintenance Manual Figure E-16. Installation Dialog (1/3) Figure E-16. Installation Dialog (2/3) E-26 77 A7 48UU Rev03...
  • Page 195 Installing the CDA 7 5330 with Microcode Release 5264 Figure E-16. Installation Dialog (3/3) When the configuration details are correct, press F10 to return to the Current Configuration screen. Type S for Save and press Enter. Now that the IMPL.BIN file is correct , you can go on and select the "LOAD" command (option C "Load &...
  • Page 196 CDA 7 Maintenance Manual Fixed Block Architecture Bull DPS 7000 SYMMETRIX III Configuration Information SYSTEM ------ System Serial Number: 0008116000177 Emulation code: "FBA " 3300-OLD 3390 3300-NEW MIX-CKD Host system: UNISYS Server "Server/Bull" Server/UOD SERIES-A AS/400-240 AS/400-480 AS/400-480R Drive Capacity: 1.2 GB 1.6 GB 2.2 GB...
  • Page 197 Installing the CDA 7 5330 with Microcode Release 5264 Pressing "Enter" on this selection causes the map to be displayed SYMMETRIX III Configuration Information Enter Total System memory (MB): 1024 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Enable Mirroring? Enable Dynamic Spare? Number of PHYSICAL drives: 16 Drive type: Cuda-9X...
  • Page 198 CDA 7 Maintenance Manual Internal device number Mirrored pair for CDA subsystem One logical disk = SCSI Address #2 [CTRL] Arrow, PgUp, PgDn move. F10 exit. <R>estore. <O>riginal. Space Bar Add/Del. "M" to toggle No-Mirror -> Mirror-1 -> Mirror-2 "S": Rearrange. "P": Pack in physical drives. "+ -" Add/Remove volumes. F5: Zoom.
  • Page 199 Installing the CDA 7 5330 with Microcode Release 5264 The lower part of the screen shows the distribution of logical units per channel. SCSI Adaptor for SCSI DIRECTOR #3 SCSI’s SA-03A SA-14A Figure E-20. Distribution of Logical Units The final part of the screen shows the wiring of the 16 logical units in the subsystem.
  • Page 200 CDA 7 Maintenance Manual SYMMETRIX III Configuration Information Enter Total System memory (MB): 2048 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Are you updating a live system? N Number of PHYSICAL drives: 02 Drive type: Cuda-9X 16 Logical Volumes in the system. "Edit Directors/Volumes/Channels map"...
  • Page 201 Installing the CDA 7 5330 with Microcode Release 5264 OTES Parameters have a black or green square to show whether they are validated or not. Use the space bar to toggle the selections. The correct parameters are validated by loading the binary file but you need to check in the event of replacement of SCSI directors.

  • Page 202: Declaring The Cda 7 Subsystem Under Gcos 7

    CDA 7 Maintenance Manual To do this: Press Escape to exit the main menu. Confirm your request. The C:\SYMM4 prompt is displayed. Insert the diskette. Enter the following command: C:\SYMM4 > COPY C:\SYMM4\IMPL.BIN A:\<goodfile.bin> Return to the main menu with the command: C:\SYMM4 >...
  • Page 203 Installing the CDA 7 5330 with Microcode Release 5264 In CONFIG_TEMPRY, execute a MODIFY command to insert WSP cards supporting CDA subsystems. This creates the final configuration, for example named CONFIG_MYCDA. E.3.8.2 Declaring the CDA 7 Subsystems Non-coupled system Definition: a "physical group" of disks always contains 8 mirror disks or 4 RAID-S disks.
  • Page 204 CDA 7 Maintenance Manual Coupled systems For a coupled system, answer "1" to the second question in the following sequence: N: MD OLD NEWCDA CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled?
  • Page 205 Installing the CDA 7 5330 with Microcode Release 5264 First case: your system is accessed by installation #1 N: MD OLD NEWCDA CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled? With AURIGA?
  • Page 206 CDA 7 Maintenance Manual Second case: your system accesses installation #1 : N: MD TEMPCDA REMPCDA1 CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled? With AURIGA? Instal # <0 or 1>...
  • Page 207 Installing the CDA 7 5330 with Microcode Release 5264 E.3.8.3 Running the LABEL Command See the figure in chapter 1 for the location of SCSI adapters and port assignments. The LABEL command has been modified to support CDA 7 subsystems. It clearly and unambiguously gives From/To information for SCSI cables between IOSS and the CDA 7 cabinet.
  • Page 208 CDA 7 Maintenance Manual XAMPLE ONFIGURATION ON **Lap top configuration for cda #01 ---> Name of the bin file is: Cxxxx-xx i.e. corresponds to file Dxxxx-xx.BIN on the hard disk External identifier MSxx 01 02 03 04 Device number for CDA sub-system 00 01 02 03 SA-15A 20 21 22 23...
  • Page 209 Installing the CDA 7 5330 with Microcode Release 5264 XAMPLE OUPLING This is a configuration of 16 mirrored disks belonging to a cabinet in another installation. The connection of the coupled disks is shown in the label of System 0. Iom WSP-R slot 19 PX47 port 0 connected to Scsi Adaptor slot 0 port D cda #01 other instal Iom WSP-R slot 08 PX10...
  • Page 210 CDA 7 Maintenance Manual E-42 77 A7 48UU Rev03...

  • Page 211: Installing The Cda 7 5630 With Microcode Release 5265

    F. Installing the CDA 7 5630 with Microcode Release 5265 This Appendix concerns the CDA 7 with Microcode Release 5265. This release of the Microcode can run on systems with 18 GB or with 36 GB disks. The following table shows the relationship Microcode Release <-> Disk Size. Disks Release 5265 18 GB...

  • Page 212: Installation Conditions/Auxiliaries

    CDA 7 Maintenance Manual Installation Conditions/auxiliaries These characteristics are mentioned as a reminder, and are given in the CDA 7 5630 Site Preparation Guide. Electrical environment: • 220 V - 20 A single phase, output by an electric box (International). •...

  • Page 213: Installing The Cda 7 On A Host System

    Installing the CDA 7 5630 with Microcode Release 5265 Installing the CDA 7 on a Host System Two ways are possible: • Installation of a CDA 7 subsystem in an existing configuration. This case is described hereafter. • Installation of a CDA 7 subsystem delivered with a new system. For more information, refer to the On-Line Help of the BUILD P2 command of FGF.
  • Page 214 CDA 7 Maintenance Manual Depalletizing the subsystem Check the "TIP-N-TELL" indicator on one side of the main package. Unpack the box, and cut the protection film to access the cabinet on its pallet. Open the front and rear doors. Release the cabinet by removing the shipping brackets, you will need to remove six screws and six bolts, see the figure below.

  • Page 215: Powering Up The Cda 7

    Installing the CDA 7 5630 with Microcode Release 5265 F.3.2 Powering Up the CDA 7 F.3.2.1 Electrical Connection of Subsystem After opening the back door, check that the PDM breakers (EPO and AC), the PS1 and PS2 breakers and the BATTERY switch are OFF. Check that the circuit breaker, (customer panel), for the AC power connection box is OFF.

  • Page 216: Setting The Pc Parameters

    CDA 7 Maintenance Manual A faulty DIRECTOR or a DIRECTOR which has been badly initialized displays the value DD. In this case, restart the operation or contact support. In this case, "loading" includes initialization of the hardware and loading the MICROCODE (IML = Initial MICROCODE Loading).
  • Page 217 Installing the CDA 7 5630 with Microcode Release 5265 The following screen is displayed: Figure F-3. PC Configuration - 2 This screen displays the standard values of the parameters. If you select the Parallel port: • RS-232 MUX, the following line displays: MUX "local" director: 1 and the cursor goes automatically to this line.

  • Page 218: Setting The Site Information

    CDA 7 Maintenance Manual F.3.4 Setting the Site Information To enter the site information: In the Symm4 Main Window, select Site information option or enter J. Figure F-4. Site Information - 1 77 A7 48UU Rev03...
  • Page 219 Installing the CDA 7 5630 with Microcode Release 5265 The following screen is displayed: Figure F-5. Site Information - 2 To enter the three phone numbers, call the Bull Competence Center. Enter the following parameters: Enter site name: This name begins G7 followed by the four last digits of the serial number on the label located on the rear side of the cabinet.
  • Page 220 CDA 7 Maintenance Manual During the CDA 7 installation procedure, set Enable Automatic Calls Home? to N. After the installation, verify the connection by changing both Enable Automatic Calls Home? and Enable Machine Initiated Interrupts to Y. Click on to proceed from screen to screen. More Figure F-6.
  • Page 221 Installing the CDA 7 5630 with Microcode Release 5265 Figure F-7. Site Information - 4 Figure F-8. Site Information - 5 The values of some of these parameters may change in different versions, please refer to the Bull Competence Center to obtain up-to-date parameters. 77 A7 48UU Rev03 F-11...
  • Page 222 CDA 7 Maintenance Manual MPORTANT Remember that the function of the ESCape key is to exit without modification. Press F10 to go back to the Symm4 Main Window and save modifications. If you press ESCape the following message is displayed: All changes will be abandoned.

  • Page 223: Verifying The Site Information

    Installing the CDA 7 5630 with Microcode Release 5265 F.3.5 Verifying the Site Information F.3.5.1 Verifying the Customer Name The Customer name is in the header of the main menu in the miscellaneous information area: Figure F-9. Customer Name For the DPS 7000 line, the customer name is made up as follows: G7 + last 4 digits of the serial number + (Blank) + Customer Name + (Blank ) + Town This allows the AUTOCALL reception center to sort DPS 7000 systems, and to...
  • Page 224 CDA 7 Maintenance Manual The remote station contains a file in the form of a table defining the correspondence between the system serial number and the type of maintenance contract. F-14 77 A7 48UU Rev03...
  • Page 225 Installing the CDA 7 5630 with Microcode Release 5265 F.3.5.2 Verifying the CDA 7 Serial Number The cabinet serial number is located on the label glued at the top back of the rack. Top cover EMC CORPORATION 50/60 Hz 208/240 Rear view 10 A MODEL NO...
  • Page 226 CDA 7 Maintenance Manual F.3.6 Setting the Modem Parameters To set the Modem parameters: Under the SYMM4 prompt, enter the following command: C:\SYMM4> scsetup The following dialog box is displayed. SymmCom Target Configuration Modem Multitech MULTIMODEM Comm Port COM (3F8 hex- IRQ4) Port Rate 19200 Connectivity...
  • Page 227 Installing the CDA 7 5630 with Microcode Release 5265 To enter the values of the parameters displayed in the above table, answer to these dialog boxes as follows: Modem Multitech MULTIMODEM Comm Port COM2 (2F8 hex.) Port Rate 9600 Connectivity Allowed Password Change Enter G7xxx.
  • Page 228 CDA 7 Maintenance Manual F.3.7 Verifying the CDA 7 Configuration Bull has defined a number of standard models, for which the configuration (number of disks, number of DIRECTORS, etc.) is precisely determined. In order to initialize the subsystem correctly, the PC must contain a file describing the installed configuration;...
  • Page 229 Installing the CDA 7 5630 with Microcode Release 5265 F.3.7.3 Running Automatic Installation To run the Automatic Installation: Highlight the AUTOMATIC INSTALL option in the Main menu or enter B. Figure F-12. The Automatic Install Command A sequence of screens is displayed. •...
  • Page 230 CDA 7 Maintenance Manual The following automatic installation screens are displayed: Figure F-13. Automatic Install Screens F-20 77 A7 48UU Rev03...
  • Page 231 Installing the CDA 7 5630 with Microcode Release 5265 Select Impl.bin and, after the Warning screen, press the space bar, then select Standard. The PC reads the IMPL.BIN file from disk. − If you choose System, the configuration is read from the installed hardware.
  • Page 232 CDA 7 Maintenance Manual Figure F-15. Installation Dialog (1/3) Figure F-15. Installation Dialog (2/3) F-22 77 A7 48UU Rev03...
  • Page 233 Installing the CDA 7 5630 with Microcode Release 5265 Figure F-15. Installation Dialog (3/3) When the configuration details are correct, press F10 to return to the Current Configuration screen. Type S for Save and press Enter. Now that the IMPL.BIN file is correct , you can go on and select the "LOAD" command (option C "Load &...
  • Page 234 CDA 7 Maintenance Manual Fixed Block Architecture Bull DPS 7000 SYMMETRIX III Configuration Information SYSTEM ------ System Serial Number: 0008116000177 Emulation code: "FBA " 3300-OLD 3390 3300-NEW MIX-CKD Host system: UNISYS Server "Server/Bull" Server/UOD SERIES-A AS/400-240 AS/400-480 AS/400-480R Drive Capacity: 1.2 GB 1.6 GB 2.2 GB...
  • Page 235 Installing the CDA 7 5630 with Microcode Release 5265 Pressing "Enter" on this selection causes the map to be displayed SYMMETRIX III Configuration Information Enter Total System memory (MB): 1024 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Enable Mirroring? Enable Dynamic Spare? Number of PHYSICAL drives: 16 Drive type: Cuda-9X...
  • Page 236 CDA 7 Maintenance Manual Internal device number Mirrored pair for CDA subsystem One logical disk = SCSI Address #2 [CTRL] Arrow, PgUp, PgDn move. F10 exit. <R>estore. <O>riginal. Space Bar Add/Del. "M" to toggle No-Mirror -> Mirror-1 -> Mirror-2 "S": Rearrange. "P": Pack in physical drives. "+ -" Add/Remove volumes. F5: Zoom.
  • Page 237 Installing the CDA 7 5630 with Microcode Release 5265 The lower part of the screen shows the distribution of logical units per channel. SCSI Adaptor for SCSI DIRECTOR #3 SCSI’s SA-03A SA-14A Figure F-19. Distribution of Logical Units The final part of the screen shows the wiring of the 16 logical units in the subsystem.
  • Page 238 CDA 7 Maintenance Manual SYMMETRIX III Configuration Information Enter Total System memory (MB): 2048 Enter SCU-ID number: E0 Enter CTRL-ID number: 30 Are you updating a live system? N Number of PHYSICAL drives: 02 Drive type: Cuda-9X 16 Logical Volumes in the system. "Edit Directors/Volumes/Channels map"...
  • Page 239 Installing the CDA 7 5630 with Microcode Release 5265 OTES Parameters have a black or green square to show whether they are validated or not. Use the space bar to toggle the selections. The correct parameters are validated by loading the binary file but you need to check in the event of replacement of SCSI directors.
  • Page 240 CDA 7 Maintenance Manual To do this: Press Escape to exit the main menu. Confirm your request. The C:\SYMM4 prompt is displayed. Insert the diskette. Enter the following command: C:\SYMM4 > COPY C:\SYMM4\IMPL.BIN A:\<goodfile.bin> Return to the main menu with the command: C:\SYMM4 >...
  • Page 241 Installing the CDA 7 5630 with Microcode Release 5265 In CONFIG_TEMPRY, execute a MODIFY command to insert WSP cards supporting CDA subsystems. This creates the final configuration, for example named CONFIG_MYCDA. F.3.8.2 Declaring the CDA 7 Subsystems Non-coupled system Definition: a "physical group" of disks always contains 8 mirror disks or 4 RAID-S disks.
  • Page 242 CDA 7 Maintenance Manual Coupled systems For a coupled system, answer "1" to the second question in the following sequence: N: MD OLD NEWCDA CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled?
  • Page 243 Installing the CDA 7 5630 with Microcode Release 5265 First case: your system is accessed by installation #1 N: MD OLD NEWCDA CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled? With AURIGA?
  • Page 244 CDA 7 Maintenance Manual Second case: your system accesses installation #1 : N: MD TEMPCDA REMPCDA1 CDA7 CDA7 CDA7 present? Some Grx will be defined in function of its nb of 8-disk physical groups One Gr correlates with CDA Scsi Adaptator Coupled? With AURIGA? Instal # <0 or 1>...
  • Page 245 Installing the CDA 7 5630 with Microcode Release 5265 F.3.8.3 Running the LABEL Command See the figure in chapter 1 for the location of SCSI adapters and port assignments. The LABEL command has been modified to support CDA 7 subsystems. It clearly and unambiguously gives From/To information for SCSI cables between IOSS and the CDA 7 cabinet.
  • Page 246 CDA 7 Maintenance Manual XAMPLE ONFIGURATION ON **Lap top configuration for cda #01 ---> Name of the bin file is: Cxxxx-xx i.e . co rresponds to file S xxxx-xx . B IN on the hard d isk Ex terna l iden tifier M Sxx 01 02 03 04 D evice num ber fo r CDA sub -system 00 01 02 03...
  • Page 247 Installing the CDA 7 5630 with Microcode Release 5265 XAMPLE OUPLING This is a configuration of 16 mirrored disks belonging to a cabinet in another installation. The connection of the coupled disks is shown in the label of System 0. Iom WSP-R slot 19 PX47 port 0 connected to Scsi Adaptor slot 0 port D cda #01 other instal Iom WSP-R slot 08 PX10...
  • Page 248 CDA 7 Maintenance Manual F-38 77 A7 48UU Rev03...
