Summary of Contents for Shanghai Kingstronic K-BD5106
- Page 1 Blu-Ray Disc Player Instruction Manual Read all of the instructions before using this bluray player and keep the instruction manual in a safe place for future reference. Model No.: K-BD5106...
-
Page 3: Table Of Contents
Contents Contents Settings 11-13 Important Notes Safety and important notice Basic operation for the menu Disposal of your old product and batteries General Setting Trademark notice Display Setting Audio Setting Product Introduction System Information Feature highlights Region codes Additional Information Update software Accessories Care... -
Page 4: Important Notes
Important Notes Safety and important notice Trademark notice 'DVD Video' is a trademark of DVD Warning Format/Logo Licensing Corporation. • Risk of overheating! Never install the product in a confined 'Blu-ray Disc' and 'Blu-ray Disc' logo space. Always leave a space of at least 4 inches around the are trademarks. -
Page 5: Product Introduction
Product Introduction Feature highlights Australia, New Note Zealand • The product does not guarantee 100% interoperability with all HDMI CEC devices. Russia, India High-Definition entertainment Watch high-definition content disc with HDTV (High Definition Television). Connect it through a high speed HDMI cable (1.3 or category 2). You can enjoy excellent picture quality up to 1080p resolution with the frame rate of 24 frames per China... -
Page 6: Product Overview
Product Introduction Product Overview Main unit 1. Disc compartment 2. IR sensor • Point the remote control at the IR sensor. Front panel Description 3. Display panel display 4. USB jack LOAD Loading a disc. • Connect to USB device. UNK DISC The disc is not supported. -
Page 7: Remote Control
Product Introduction Remote control 8. RETURN • Return to a previous display menu. 9. SETUP • Access the SETUP menu. 10. POP-MENU/TITLE • BD: Display the top menu. • DVD: Display the title menu. 11. Menu Navigation Keys • Navigate through the menus. 12. -
Page 8: Connection
Connection 33. TOP MENU Option 1: Connect to the HDMI jack • To open the Top menu of BD/DVD-Video disc. 34. BONUS VIEW • Turn on or off the secondary video in a small screen window during play (applicable only to BD-video that supports the BONUSVIEW or Picture-In-Picture feature). -
Page 9: Route Audio To Other Devices
Connection Option 3: Connect to the composite video jack. Connect the audio cables to: • the AUDIO L/R-AV OUTPUT jacks on this product. • the AUDIO input jacks on the device. VIDEO IN Connect network AUDIO IN Connect this product to the network to enjoy software updates and BD-Live bonus content. -
Page 10: Getting Started
Getting Started Navigate the menu Caution When a menu is displayed, press the buttons on the remote • Use of controls or adjustments or performance of control to navigate. procedures other than herein may result in hazardous radiation exposure or other unsafe operation. Move up or down. -
Page 11: Play
Play Play a disc Buttons Action Pause play. Caution Start or resume play. • Do not place any objects other than discs into the disc Stop play. compartment. Skip to a previous/next title or chapter. • Do not touch the disc optical lens inside the disc compartment. -
Page 12: Play Music
Play Button Action When a disk is playing, pressing this button once will save a “start point” for repeating playback. Pressing this button again will save an “end point” for repeating playback. Playback will repeat from the start point to the end point. •... -
Page 13: Play Photo
Play Play musical slideshow Note Create a musical slideshow to play simultaneously MP3/WMA music files and JPEG photo files. • Press MEDIA CENTER to display the file list. Note Note • To create a musical slideshow, you must store the MP3/ WMA and JPEG files on the same disc. -
Page 14: Settings
Settings General Setting Note • If the setup option is grayed out, it means the setting cannot be changed at the current state. Basic operation for the menu 1 Press SETUP. 2 Select a mains menu by SETUP System SETUP 3 Select the menu you want to setting by , and press •... -
Page 15: Display Setting
Settings Playback 1 Internet Connection: Display the internet connection state. 2 Information: Display the informations of the Network. 3 Connection Test: Test the internet connection state. 4 IP Setting: Setting the IP for the product. 5 Host Name Setting: Setting the name for the product. 6 BD-Live Connection: Connection situation of BD-Live. -
Page 16: Audio Setting
Settings Video Process Speaker Setting SETUP SETUP 1 Video Adjust: Enter the submenu to adjust the video display. Configuration: Select configuration mode. System Information Adjust the Brightness, Contrast, Hue, Saturation of the screen for yourself. 2 Sharpness: Select the sharpness mode. Audio Setting SETUP Display the system information(The information on the picture... -
Page 17: Additional Information
Additional Information Accessories supplied Update software • Remote control and batteries For software updates to enhance performance, check the • Audio/Video cables current software version of this product to compare with the • User manual latest software (if available) . 1 Press SETUP. -
Page 18: Troubleshooting
Troubleshooting Data files (JPEG, MP3, WMA) cannot be played or read. Warning • Ensure that the data file was recorded in the UDF, ISO9660 or JOLIET format. • Risk of electric shock. Never remove the casing of the • Ensure that the selected group (folder) does not contain more product. -
Page 19: Glossary
Glossary Aspect ratio JPEG Aspect ratio refers to the length to height ratio of TV screens. A very common digital still picture format. A still-picture data The ratio of a standard TV is 4:3, while the ratio of a high- compression system proposed by the joint Photographic definition or wide TV is 16:9.
