Parts List - FAFCO Drainback 200 Series Installation Manual

Major Components
COMPONENT IMAGE
Solar collectors
Controller
PN 08238
Circulation Module
PN 08303 (HH)
PN 08302 (MD)
Drainback Tank
PN 08209
Roof Kit: Two 2' x 12' Collectors
Mounting bases
PN 06918
Mounting caps
PN 06919
Collet clips
PN 08819
Support liner
PN 08520
Collector connectors
3-1/2" L, PN 08883
* Quantities in upper left denote 2'x12' collectors and lower right denote 2'x8' collectors
Ground Kit
PN XXXXX
Teflon tape roll
PN 07581
Flexible hoses
3' - PN 08834
Plastic tubing,
80 ft.
PN 08613
Tube support
clips
PN 08609
Drain valve
PN XXXXX
Sensor
PN 08380
Sensor cable,
50'
PN 08208
QTY.
DESCRIPTION / FUNCTION
-
Qty. (2) 2' x 12' (PN 08842) or qty. (3) 2' x 8' (PN 08891) polymer unglazed
solar collectors transfers solar energy to the heat transfer fluid.
1
Controls the Solar Water Heating System.
Circulates the potable water and the solar loop fluid. Transfers solar heat
1
to solar storage tank. Includes:
- Heat exchanger, copper brazed stainless steel, P/N 08782
- Potable loop pump, direct current (DC), P/N 08795
- Solar loop pump, direct current (DC), P/N 08795
Accommodates heat transfer fluid expansion, fluid contraction, vents air, and
1
relieves pressure.
or Three 2' x 8' Collectors
PN 08881
13
Mounting Strap,
40' roll, PN 08907
18*
Elbow fittings
13
PN 08441
18*
Panel plug
20
PN 08837
28*
20
Roof Sensor
PN 08380
24*
2
Coltector lag screw, st/st,
1/4" x 2", PN XXXXX
4*
Tee, brass, 3/4"
1
PN 08872
2
Drainback screws,
1/4" x 2", PN XXXXX
Nipple, brass, hex,
1/2"
1
PN 08854
Nipple, brass, hex,
3/4"
PN 08869
20
Reducer, brass,
3/4" x 1/2"
2
PN 08862
Nipple, brass,
2
3/4" x 3"
PN 08863
1
Escutcheon
PN 08462
PN 08911
Wire connector
1
PN 08359
Roof jack
6
PN 08211
Rubber grommet
2
Roof Jack, PN 08190
Roof sealant,
1
10 oz. tube
PN 08229
1
2
Support liner
PN 08520
Fender washer, Drain-
18
back Tank, PN 08884
2
Roofing nails, 1"
1
Circulation module
screws, 1/4" x 1-1/2"
2
Dip tube with filter
PN XXXXX
1
Screw, self tapping,
2-1/2", PN 08830
2
Collet clips
PN 08819

Parts list

2
1
2
1
8
2
8
2
1
2
8
4
