Anthem Statement D2 Operating Manual

Hide thumbs Also See for Statement D2:
Table of Contents

Advertisement

Quick Links

STATEMENT D2
OPERATING MANUAL
™
UPDATES: www.anthemAV.com
S O F T W A R E V E R S I O N 1 . 3 x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Statement D2 and is the answer not in the manual?

Questions and answers

Related Manuals for Anthem Statement D2

Summary of Contents for Anthem Statement D2

  • Page 1 STATEMENT D2 OPERATING MANUAL UPDATES: www.anthemAV.com S O F T W A R E V E R S I O N 1 . 3 x ™...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS READ THIS SECTION CAREFULLY BEFORE PROCEEDING! WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowpoint within an equilateral triangle warns of the presence of uninsulated “dangerous voltage”...
  • Page 3 8. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
  • Page 4 16. Object and Liquid Entry – Never push objects of any kind through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Do not expose this product to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the product.

  • Page 5: Table Of Contents

    TABLE of CONTENTS SECTION PAGE 1. INTRODUCTION 1.1 Before Making Connections............. 1 1.2 In-Use Notices .
  • Page 6 4. OPERATION 4.1 Power On and Off ..............50 4.2 Path Selection .
  • Page 7 6. SOFTWARE UPDATING 6.1 Software Version Identification ............78 6.2 Software Updating Via Your Dealer.

  • Page 9: Introduction

    1. INTRODUCTION Thank you for purchasing the Anthem Statement D2 processor. The Statement D2 is a cutting-edge home theater audio processor with HDMI switching and video upconversion, multizone capabilities, and FM/AM tuner, along with state of the art video processing which includes deinterlacing, scaling, aspect ratio control, and picture adjustment.

  • Page 10: Front Panel

    1. INTRODUCTION continued … FRONT PANEL 1 – Path selection 9 – Mute 2 – Mode and decoder indicators 10 – Status review / setup menu access 3 – Display 11 – Balance setting 4 – FM•AM preset selection 12 – Bass / treble settings 5 –...

  • Page 11: Front Panel Display

    1. INTRODUCTION continued … FRONT PANEL DISPLAY MAIN Display Example: DVD1 Dolby D 1080p 5.1+PLIIx Movie -7.5 1 – Source selection. 2 – Audio input format or sleep timer if engaged. 3 – Video input resolution. 4 – Volume. 5 – Number of input channels + surround mode.

  • Page 12: Rear Panel

    1. INTRODUCTION continued … REAR PANEL SHOCK HAZARD E X PA N S I O N P O R T DO NOT OPE N. RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR SUB 2 W MAX M A I N A U D I O - O U T M A I N A U D I O - O U T ( B A L A N C E D )

  • Page 13: Remote Control

    1. INTRODUCTION continued … REMOTE CONTROL 1 – IR transmitter (front face) 2 – LED 3 – Power on for MAIN, ZONE2, and ZONE3 Power on/off for other control modes This key does not turn off the processor (see #31) 4 –...

  • Page 14: Speaker Placement

    1. INTRODUCTION continued … SPEAKER PLACEMENT These illustrations show typical speaker placement for a 7.1-channel surround system. The surround and rear speakers are normally positioned 2-3 feet above ear level. The subwoofer can be placed in any location where severe resonances are prevented – see section 3.3. 5 and 6 are not used in a 5.1 system Front-Left Front-Right...

  • Page 15: Interconnects

    1. INTRODUCTION continued … INTERCONNECTS These illustrations show audio, video, IR, and trigger connectors used between source components, the processor, displays, and power amplifiers. Note that when RCA cables have coaxial construction and their impedance is 75 ohms, they are equally suitable for analog video and digital audio. RCA Black or RCA Red RCA Yellow...

  • Page 16: Connections

    2. CONNECTIONS VIDEO CONNECTIONS To configure inputs, see section 3.6 and to configure video outputs see section 3.1. HDMI: Video is sent with audio from source components to the processor. Maximum video resolution is 1080p/60. Connect MAIN HDMI output to a display with HDMI or DVI input – one with High-bandwidth Digital Content Protection (HDCP) is required to display copy-protected material.

  • Page 17: Audio

    2. CONNECTIONS continued … AUDIO CONNECTIONS There are two methods of transmitting audio signals: Analog and digital. Analog is an electrical waveform representation of sound and requires one cable for each channel. Digital represents sound using a sequence of numbers and requires only one cable for all channels. Digital Audio Inputs and Outputs: Digital audio source components can be connected with a coaxial, optical, balanced, or HDMI cable.
  • Page 18 2. CONNECTIONS continued … Analog Audio Outputs: Balanced connection offers the highest transmission quality over long cable lengths, because it rejects noise pickup. In the processor, XLR output voltage is twice that of RCA (6 dB higher). The RCA outputs and the XLR outputs are always active –...

  • Page 19: Fm•Am Antennas

    2. CONNECTIONS continued … FM•AM ANTENNAS To connect the AM loop antenna, press the spring-loaded tabs of the AM ANTENNA connector and insert the bare ends of the two wires. Move the antenna until best reception is found. To connect the FM antenna, connect the two wires to the screw terminals of the 75-ohm to 300-ohm adapter, then connect the adapter to the FM ANTENNA connector.
  • Page 20 2. CONNECTIONS continued … Example 1: DVD Player to processor to main display HDTV receivers are connected the same way as DVD players. HDMI IN SHOCK HAZARD E X PA N S I O N P O R T DO NOT OPE N. RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR SUB 2...
  • Page 21 2. CONNECTIONS continued … Example 2: Video recorder to processor EJECT SHOCK HAZARD E X PA N S I O N P O R T DO NOT OPEN. RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR SUB 2 W MAX M A I N A U D I O - O U T M A I N A U D I O - O U T...
  • Page 22 2. CONNECTIONS continued … Example 3: Processor to amplifiers and subwoofer (Balanced connection shown, single-ended is similar) Trigger Setup Suggestion: If it is not necessary to have both amplifiers turned on when stereo To powered SHOCK HAZARD sources are playing, set triggers E X PA N S I O N P O R T DO NOT OPEN.

  • Page 23: Setup

    3. SETUP For optimum performance and enjoyment, your processor should be properly set up. This may appear like a lot of work but keep in mind that most settings do not need to be changed from the factory ones. The most important things are entering information about your display and speakers if the defaults do not apply, the distance from each speaker to the listening area, balancing output levels to one another, and input connections.

  • Page 24: Video Output

    On-screen display is available from the following video outputs: MAIN – HDMI, Component (processed) and S-Video ZONE2 – S-Video STATEMENT D2 SETUP 1. VIDEO OUTPUT 2. SET TIME / TIMERS 3. SPEAKER CONFIG 4.
  • Page 25 Video Output Configurations: The Statement D2 allows you to set four video output configurations – only Configuration 1 is needed in most cases. The rest can be used to match the output refresh rate to source material refresh rates, i.e. 1080p/24, 1080p/50, and 1080p/60 if your display accepts these rates, or with a secondary display that needs different settings –...
  • Page 26 For standard-def DVD, set the player’s output to 480i/576i because if output is progressive-scan you will be looking at the player’s deinterlacing, not the Statement D2’s. If the player does not allow 480i/576i HDMI output, using 480i/576i component video output may be best. If the player can be set to put out both 480i (NTSC) and 576i (PAL) according to source material, you can use that setting since the Statement D2 accepts both formats.
  • Page 27 3. SETUP continued … Output Resolution: Input from S-Video, Component, and HDMI is scaled to this resolution for Component and HDMI output. If interlaced to progressive scan conversion is in effect, it is uncompromisingly pixel-adaptive even with 1080i, and the same robust film mode detection applies as with standard-definition interlaced input. Resolution is expressed as follows: number of pixels across the screen frames per second (Hz)
  • Page 28 3. SETUP continued … Letterbox: When the source material’s aspect ratio (the proportion of image width to height) does not match the display’s aspect ratio and you want to preserve the original image’s proportions, the unused areas of the screen will be blank. You can select the shade of these areas from ten levels between light gray and black. If you do not want letterbox (bars on top/bottom) or pillarbox (sidebars) on your screen, see section 4.11.

  • Page 29: Set Time And Timers

    3. SETUP continued … SET TIME / TIMERS The time and day, plus 6 different timers are set in this menu. The timers in the processor are like an alarm clock, but allow two different timer settings for each of MAIN, ZONE2, and ZONE3. 2.
  • Page 30 3. SETUP continued … Timer Options: There are two Timers for Main and each Zone to allow greater flexibility. You can set week and weekend on/off times twice – once for the morning and again for the evening, for example. Using the buttons, TIMER 1 and TIMER 2 choices are: •...
  • Page 31 3. SETUP continued … Example 1: Select a source for the ZONE2 Timer: • Enter the setup menu. Go to SET TIME / TIMERS and press SELECT. • Press the button until you reach SET ZONE2 TIMERS. • Press SELECT. The SET ZONE2 TIMERS submenu will appear. •...

  • Page 32: Speaker Configuration

    3. SETUP continued … SPEAKER CONFIGURATION The Speaker Configuration Setup allows you to enter information about your speakers so that sounds from source materials are not lost or distorted. 3. SPEAKER CONFIGURATION a. BASS MANAGEMENT-MOVIE b. BASS MANAGEMENT-MUSIC c. SURROUNDS: Dipole REARS: Dipole-7.1 UNITS: ft f.
  • Page 33 3. SETUP continued … Highlighting BASS MANAGEMENT-MOVIE then pressing SELECT displays this menu: 3a.BASS MANAGEMENT-MOVIE a. ADV SETTINGS: Off FRONTS: Small CENTER: Small SURROUNDS: Small REARS: Small SUBS: 1 Sub g. XOVER FREQ: 80 THX h. FRONTS XOVER: -- Hz i.
  • Page 34 3. SETUP continued … Bass response highly depends on room acoustics and experimentation with subwoofer placement is recommended. Start by temporarily placing the subwoofer in the listening area, play some music with a range of bass and walk around the room. Positions where the bass range sounds smooth are suitable for permanent subwoofer placement as long as decor allows.
  • Page 35 3. SETUP continued … Highlighting ROOM RESONANCE FILTER then pressing SELECT displays this menu: 3h.ROOM RESONANCE FILTER ROOM RESONANCE TEST TONE: Off TEST LEVEL: +0.0dB TEST FREQ: 21 Hz d. APPLY FILTER: No RESONANCE FILTER CENTER FREQ: 60 Hz f. FILTER DEPTH: 1 dB g.
  • Page 36 3. SETUP continued … Procedure for adjusting Room Resonance Filter: • Enter the setup menu. Go to SPEAKER CONFIGURATION and press SELECT. • Press the button until you reach ROOM RESONANCE FILTER and press SELECT. • Use the buttons to set TEST TONE to Auto. Press SELECT to start automatic sweeping of the test tones.

  • Page 37: Listener Position

    3. SETUP continued … LISTENER POSITION The Listener Position menu lets you enter the distance between each speaker and the listening area. Ideally, speakers should be placed at an equal distance so that their sound arrives at the listening area at the same time, but since this is rarely practical, the processor can delay the sound coming from speakers that are closer to the listener.

  • Page 38: Level Calibration

    3. SETUP continued … LEVEL CALIBRATION Level Calibration uses internal test noises to match the relative level of each speaker at the listening position. Use of noises from home theater setup discs is not recommended – some use incorrect methods. Use of a Sound Pressure Level meter is recommended if not using ARC.
  • Page 39 3. SETUP continued … Procedure for Manual Test Sequence: • Enter the setup menu. Go to LEVEL CALIBRATION and press SELECT. • Use the buttons to set NOISE SEQUENCE to Manual. • Press the buttons to go from speaker to speaker. •...

  • Page 40: Source Setup

    3. SETUP continued … SOURCE SETUP This is where you set up each source and path according to how you want them to be used. SOURCE SETUP a. CD b. 2-Ch c. 6-Ch d. TAPE e. FM/AM f. DVD1 g. DVD2 h.
  • Page 41 3. SETUP continued … Highlighting DVD1 then pressing SELECT displays this menu – the other submenus are similar: 6f. DVD1 SOURCE SETUP RENAME: DVD1 b. VID OUT CNFG: 1 c. SCALER INPUT: HDMI1 d. COMPONENT IN: 1 S-VIDEO IN: DVD f.
  • Page 42 3. SETUP continued … Scaler Input (MAIN only): Assign which input is used by the video processor when the source is selected – any HDMI, Component video, S-Video input, or “None”. Before setting this, be sure that you have read section 2.1. Note that if S-Video is selected, the input connection is the one specified in S-VIDEO IN.
  • Page 43 Lip-Sync (MAIN only): Video can fall out of synchronization with audio for a variety of reasons. The Statement D2’s video processing causes video to be delayed by 24 milliseconds, which is less than the duration of one frame, thus considered synchronized.

  • Page 44: Mode Presets

    3. SETUP continued … MODE PRESETS When you or another member of your family uses the processor, the mode and THX presets that are set here are recalled, ensuring trouble-free operation. The presets are applied when a source is selected or MAIN power is turned on.

  • Page 45: Analog Input Levels

    3. SETUP continued … ANALOG INPUT LEVELS For sources set to Anlg-DSP or Anlg-Dir in under Source Setup, you can match input levels in MAIN to each other so there are no large changes in volume as you change sources. This is also where recording level is set when using the processor as an analog-to-digital converter (see sections 3.6, 3.9, and 4.3).

  • Page 46: Adc And Audio Output

    3. SETUP continued … ADC / AUDIO OUTPUT In the ADC / Audio Output menu you can configure the surround and rear channels, set analog to digital conversion parameters for the digital Record output, and configure the balanced analog outputs. 9.

  • Page 47: Volumes And Path Names

    3. SETUP continued … 3.10 VOLUMES / PATH NAMES This menu allows you to define the power-on volume settings, set whether or not MAIN outputs shut off when headphones are used, and to rename ZONE2, ZONE3, and RECORD. 10. VOLUMES / PATH NAMES MUTE LEVEL: Silent b.

  • Page 48: Triggers, Ir, And Rs-232

    3. SETUP continued … 3.11 TRIGGERS / IR / RS232 When a trigger output on the processor is connected to the trigger input of another component, such as an amplifier or projector, the processor can turn it on or off according to the trigger’s Setup. For components that do not have trigger inputs, a triggerable power bar may work (see your dealer).
  • Page 49 3. SETUP continued … After highlighting Power or a source, press SELECT and use the buttons to move from one path to another. To set the condition, use the buttons to change the “–” to a “*”. Don’t forget: In the root menu you have to set ALL TRIGGERS to Enabled for the triggers to work.

  • Page 50: Displays And Timeout

    3. SETUP continued … 3.12 DISPLAYS / TIMEOUT This menu allows you to configure on-screen display, front panel display, and selection time. 12. DISPLAYS / TIMEOUT a. MAIN OS OUT: S-V + HD b.MAIN OS INFO:All Zones c.MAIN OS POS'N: Bottom d.MAIN OS COLOR: Blue e.MAIN VID MUTE: Gray Z2 OS OUT: S-V Only...
  • Page 51 3. SETUP continued … Front Panel Wake-Up: If Display is set to Medium, Low, or Off, it can be made to change to a brighter level while you make any adjustment – choose None, Up 1 brightness level, or Hi. When None is chosen and the Display is Off, it will behave as if set to Up 1 to prevent confusion as to whether the power is on or off.

  • Page 52: Save And Load Settings

    3. SETUP continued … 3.13 SAVE / LOAD SETTINGS Two memories are provided: User and Installer. If your system is set up by your dealer, the settings can be saved in the Installer file by the dealer and you can then make further adjustments – save those settings in your User file.

  • Page 53: Lockout And Passwords

    3. SETUP continued … 3.14 LOCKOUT / PASSWORDS Passwords are used to protect the saved User and Installer settings. Once you have set a password, it can also be used as a Lockout to prevent settings from being changed by anyone without one of the passwords. 14.

  • Page 54: Anthem Room Correction

    3. SETUP continued … 3.15 ARC-1 ANTHEM ROOM CORRECTION ARC-1 corrects the effects of reflective surfaces and room boundaries on sound quality by measuring the response of each speaker relative to the listening area and equalizing it. ARC equalizes response without stressing the amplifier or speakers and does not downsample the source material to process it.
  • Page 55 3. SETUP continued … Before starting: • Ensure that the processor software and ARC software that you will be using are compatible with one another – check www.anthemAV.com for latest versions. Processor software installation instructions are in section 6. • Your ARC-1 microphone, its support files, and your processor are a system with matching serial numbers –...
  • Page 56 3. SETUP continued … Microphone stand assembly: Screw the telescoping tube into its base and the microphone clip onto the tube. Position the clip vertically. Connect the USB microphone cable to the microphone and slide the microphone into the clip. Microphone positioning: During measurement the microphone must point straight up.
  • Page 57 3. SETUP continued … Updating ARC: Check www.anthemAV.com periodically for ARC software updates. The download contains revision history, which may also indicate that the processor requires an update for the ARC version to work correctly. If a newer version is posted and you would like to use it, check your current version: •...

  • Page 58: Operation

    4. OPERATION POWER ON/OFF The processor comes on at the volume setting in the Volumes setup menu. The power amplifier should be turned on last and off first to prevent “popping” when upstream components are turned on and off. Front Panel – Main on •...

  • Page 59: Manually Copying The Main Path To Zone2/3 And Record

    4. OPERATION continued … MANUALLY COPYING THE MAIN PATH TO ZONE2, ZONE3, OR RECORD When Main is copied to another path, the source selected in MAIN is directed to the other path. If a source component’s audio is connected to the processor using digital connection only, the Copy function is the only way to deliver the sound to another path.

  • Page 60: Fm•Am Tuner

    4. OPERATION continued … 4.4.1 FM•AM TUNER The processor has an FM•AM tuner. The selected station is common to all paths. Manual Tuning: After selecting the desired band by pressing FM•AM, use the buttons (remote control) or press TUNE and rotate the Master Control Knob (front panel). Automatic Tuning: TUNE To find the next station, press...

  • Page 61: Volume Control

    4. OPERATION continued … VOLUME CONTROL Front Panel: MAIN – Adjust using the Master Control Knob. If levels have been calibrated according to setup instructions, set volume to 0 dB for the MASTER playback level at which the film was presented in theaters. CONTROL KNOB ZONE2 or ZONE3 –...

  • Page 62: Bass, Treble, And Balance

    4. OPERATION continued … BASS / TREBLE / BALANCE To change the Bass, Treble, or Balance of: • MAIN – All Speakers Simultaneously: Press BASS, TREBLE, or BALANCE, then adjust. • MAIN – Fronts Only: Press FRONTS, press BASS, TREBLE, or BALANCE, then adjust.

  • Page 63: Anthemlogic

    4. OPERATION continued … LOGIC LOGIC 4.8.1 AnthemLogic ™ These are proprietary surround modes developed by Anthem that offer outstanding surround performance and can be applied to any 2-channel source material: AnthemLogic-Music ™ AnthemLogic-Music enhances the stereo listening experience without detracting from the ™...

  • Page 64: Surround Modes For 2.0-Channel Source Material

    4. OPERATION continued … 4.8.3 SURROUND MODES FOR 2.0-CHANNEL SOURCE MATERIAL Number of output channels for each mode is indicated below in bold type. THX must be Off for all modes to be available. Press MODE then use the Master Control Knob or (up/down) on the remote control to cycle through selections: Stereo...

  • Page 65: Dolby Digital Ex And Pro Logic Iix For 5.1-Channel Source Material

    4. OPERATION continued … Why can’t I select a surround mode when playing a 5.1-channel source? If you are using 5.1 speakers, with rears correctly set to None in the speaker configuration, modes that require 6.1 or 7.1 speakers cannot be selected. 4.8.4 DOLBY DIGITAL EX / PRO LOGIC IIx FOR 5.1 SOURCES Dolby Digital EX and Pro Logic IIx can be used to decode DVDs encoded in Dolby Digital Surround EX by extracting rear channel information from the surround channels.
  • Page 66 4. OPERATION continued … • Timbre Matching – The human ear changes our perception of a sound depending on the direction from which the sound is coming. In a movie theatre, there is an array of surround speakers so that the surround information is all around you.
  • Page 67 4. OPERATION continued … THX Surround EX: 6.1 output with Dolby Digital Surround EX Processing: Re-Equalization,Timbre Matching THX Surround EX – Dolby Digital Surround EX is a joint development of Dolby Laboratories and the THX division of Lucasfilm Ltd. In a movie theater, film soundtracks that have been encoded with Dolby Digital Surround EX technology are able to reproduce an extra channel which has been added during the mixing of the program.
  • Page 68 4. OPERATION continued … THX Ultra2 Overview Key: Re-EQ – De-emphasizes treble. May be turned on or off at any time after pressing THX twice. Timbre – Matches the sound character, or timbre, of the surround channels to the front channels. Adp-Decor –...

  • Page 69: Mode And Thx Operation For 2.0-Channel Source Material

    4. OPERATION continued … 4.8.7 Mode and THX Operation for 2.0-Channel Source Material – To make all modes available, turn THX Off. Cycle through modes and THX using Master Control Knob or keys on remote control. Stereo (2-Ch) Press MODE presets are in AnthemLogic-Music (6.1) setup menu...

  • Page 70: Mode And Thx Operation For Dolby Digital 5.1 And 6-Ch S/E

    4. OPERATION continued … 4.8.8 Mode and THX Operation for Dolby Digital 5.1 and 6-Ch S/E – To make all modes available, turn THX Off. Cycle through modes and THX using Master Control Knob or keys on remote control. THX Options Press THX None (5.1) THX Cinema...

  • Page 71: Mode And Thx Operation For Dts Source Material

    4. OPERATION continued … 4.8.9 Mode and THX Operation for DTS Source Material – To make all modes available, turn THX Off. Cycle through modes and THX using Master Control Knob or keys on remote control. THX Options None (5.1) Press THX THX Cinema Press MODE...

  • Page 72: Dynamics

    4. OPERATION continued … 4.8.10 DYNAMICS This allows you to control the difference between the softest and loudest passages on 5.1/6.1-channel soundtracks, as long as the soundtrack contains dynamic scaling information and at least 5.1 speakers are used. Press DYNAMICS and use the Master Control Knob or keys on the remote control to select: Reduced: Allows the quieter parts to be heard more easily, and works by raising the level of quieter...

  • Page 73: Picture

    4. OPERATION continued … Entering the video processing menu: For three seconds, press and hold DISPLAY on the front panel or ON SCREEN on the Remote. Navigating through menus and items: Use the keys. Selecting an item: Press SELECT. Menu items with a right-arrow beside them lead to further TUNE SEEK...
  • Page 74 4. OPERATION continued … Input Color Space For YCbCr input, the default is Auto, which switches between HD and SD color space according to whether input has HD or SD resolution. In case the source material contains the wrong color space for its resolution, for example, a cable box that converts 480i channels to 1080i output without converting SD color space to HD causing some unnatural hues, the color space can be corrected by forcing the setting to SD or HD.

  • Page 75: Crop Input

    4. OPERATION continued … CROP INPUT The Crop Input menu is where the image’s frame is set. If there’s anything outside of the image that you want to remove, this is the best place to do it, i.e. before the image is scaled, preventing unnecessary artifacts. PICTURE CROP INPUT SCALE OUT...

  • Page 76: Scale Output

    4. OPERATION continued … SCALE OUTPUT The Scale Output menu provides options for making non-16:9 inputs fit on a 16:9 screen. PICTURE CROP INPUT SCALE OUT OUTPUT PATTERNS INFO Panoramic Stretch Anamorphic Stretch Letter/Pillar Box Zoom No Scaling Panoramic Stretch Fills the screen by stretching only the sides of the picture while the middle portion stays undistorted.

  • Page 77: Aspect Ratio Control Examples

    4. OPERATION continued … Aspect Ratio Control Examples – how to crop and scale various sources for display on 16:9 and 2.4:1 screens: Display as original Standard-definition 4:3 source CROP INPUT: Auto Detect SCALE OUTPUT: Letter / Pillar Box Stretch sideways to fill screen Standard-definition 4:3 source CROP INPUT: Auto Detect SCALE OUTPUT: Anamorphic Stretch...
  • Page 78 4. OPERATION continued … Aspect Ratio Control Examples continued Crop and/or stretch to fill screen Anamorphic SD-DVD, 2.4:1 source CROP INPUT: Custom, adjust to taste SCALE OUTPUT: Anamorphic Stretch Display as original using anamorphic lens Anamorphic SD-DVD, 2.4:1 source CROP INPUT: Custom, Vertical Size 810 SCALE OUTPUT: Anamorphic Stretch Display as original Hi-definition 16:9 source...

  • Page 79: Output

    4. OPERATION continued … OUTPUT The Output menu is used to select gamma correction and to turn frame lock on/off. PICTURE CROP INPUT SCALE OUT OUTPUT PATTERNS INFO Gamma Corr Exponential Gamma Corr Custom Singl Gamma Corr Custom RGB Gamma Corr Off Frame Lock Gamma Correction (normally for use only by calibration specialists) The default is Off.

  • Page 80: Test Patterns

    4. OPERATION continued … TEST PATTERNS This section is a primer on display calibration and although the procedure is no match for a professional setup, the result will almost always be better than using the display with its factory settings. The only tool needed to adjust color this way is a blue filter that comes with test discs or the glasses from www.thx.com.

  • Page 81: Info Panel

    4. OPERATION continued … Color Bars is the SMPTE test pattern, with bars at 75% saturation: Setting your display’s brightness and contrast Increase brightness (black level) so that areas A can be seen as two areas with different brightness, then reduce the level until these areas match each other, or in other words, when the A on the left disappears by blending into the background.

  • Page 82: Sleep Timer

    4. OPERATION continued … 4.12 SLEEP TIMER (remote control only) If you would like to go sleep while listening to a program or music, the Sleep Timer will turn the SLEEP processor power off after the selected amount of time: •...

  • Page 83: Codes For Other Brands

    5. REMOTE CONTROL CUSTOMIZATION CODES FOR OTHER BRANDS The processor remote can control other components – brands and setup instructions are in Appendix B. If the brand for your component is not listed, try searching for a code as follows: 1.

  • Page 84: Copying Commands

    5. REMOTE CONTROL CUSTOMIZATION continued … COPYING COMMANDS The command from one key can be copied to another key (not applicable to Power, Record, and Learn keys). To copy a command to another key in the same control mode: 1. Press the control mode key. 2.

  • Page 85: Programming Macros

    5. REMOTE CONTROL CUSTOMIZATION continued … PROGRAMMING MACROS Macros are used to execute multiple functions with one key press, such as powering the processor, cable box, and display On at the same time. Up to 32 commands can be programmed. Programming a Macro that works regardless of control mode setting: 1.

  • Page 86: Software Version Identification

    6. SOFTWARE UPDATING The operational characteristics of the processor are controlled by software installed through the RS-232 port on the rear panel. Updates can be downloaded from our web site and installed afterwards. SOFTWARE VERSION IDENTIFICATION To find out which software version is in your processor, press STATUS and the display will show it. The latest software and manual are available from our web site.
  • Page 88 APPENDIX A – IR MACROS Using the factory remote control’s IR codes for MAIN path, the following 3-key sequences can be programmed into macro-capable aftermarket remotes to create a separate button for each mode, source, and tuner bank: For Stereo sources: For Dolby Digital 5.1 sources: For DTS sources: MODE, 0, 1 –...
  • Page 89 APPENDIX B – PRESET MEMORY CODES The following codes are for setting operation of other components with the processor’s remote control. If codes for your components are not in this library, see sections 5.1 and 5.2. To enter a 5-digit code: 1.
  • Page 90 APPENDIX B – PRESET MEMORY CODES continued … Regal 00279, 00273, 00259, 00020 30072, 31294, 30655 Cable Converters: Regency 00002 Kenwood 30681, 30826, 30626, 30028, 00003, 00008, 00014, 00001, Rembrandt 00011 30037, 30036, 30190 00007, 00013, 00011, 00017 Runco 00000 31318 Allegro 00315, 00153...
  • Page 91 APPENDIX B – PRESET MEMORY CODES continued … Microsoft 20522 DVD Players: Satellite Receivers: Mintek 20839, 20717 Adcom 21094 AlphaStar 00772 Mitsubishi 21521, 20521 Advent 21016 Chaparral 00216 Momitsu 21082 Aiwa 20641, 21912 Crossdigital 01109 20785 Akai 20899, 20770, 21975, 21089 DirecTV 00392, 00566, 00639, 01639, Nesa...
  • Page 92 APPENDIX B – PRESET MEMORY CODES continued … Curtis Mathes 10047, 10054, 10154, 10451, Huafa 10145 TVs: 10093, 10060, 10702, 10030, Huanghe 10817 10264 10145, 10166, 10466, 11347, Huangshan 10264, 10817 A-Mark 10003 10039, 10056, 11147, 10016, Huanyu 11910, 10817, 10264 Abex 10032 11919...
  • Page 93 APPENDIX B – PRESET MEMORY CODES continued … 11447, 10047, 11454, 10000, 10381, 11944, 10020, 10096 TVs continued: 10030, 10178, 10679, 11247, Symphonic 10180, 10171, 11913, 11904 Minutz 10021 11917, 10090, 11948, 11147, Synco 10000, 10451, 10093, 10060, Mitsubishi 10154, 10250, 10093, 10236, 10019, 11907, 11922, 10135, 10178, 10092, 10036, 10474 10180, 11250, 10150, 10030,...
  • Page 94 APPENDIX B – PRESET MEMORY CODES continued … 20166, 20105, 20089 21060, 20761 VCRs: Howard Computers 21972 Protec 20072 21972 21972 Pulsar 20039 Admiral 20048, 20209 21944 Qisheng 20060 Adventura 20000 Hughes Network Sys 20042, 21949, 20739 Quarter 20046 Aiko 20278 Hyundai 21951...
  • Page 95 APPENDIX B – PRESET MEMORY CODES continued … MyHD 01383 VCRs continued: Video Accessories: Northgate 01272 Villain 20000 01272 Panasonic 01120 Wards 20060, 20035, 20048, 20047, Alienware 01272 Pinnacle Systems 01268 20081, 20240, 20000, 20042, CyberPower 01272 Pioneer 01010 20072, 20062, 20212, 20760 Gateway 01272 Princeton...

  • Page 96: Specifications

    SPECIFICATIONS ANALOG VIDEO SWITCHING Bandwidth from input jack to output jack (bypass mode for component video) Composite & S-Video ............70 MHz Component: Y.
  • Page 97 SPECIFICATIONS continued … MAIN Path (RCA & XLR output) Frequency Response and Bandwidth Analog-Direct Inputs....10 Hz to 20 kHz (+0, -0.2 dB), 1 Hz to 130 kHz (+0, -3 dB) Analog-DSP Inputs at 24/96 .
  • Page 98 Pinout (Statement D2 side) ......

  • Page 99: Warranty

    CANADA & USA Anthem Electronics warrants to the original purchaser that each Anthem Statement D2 processor is free from defects in workmanship and materials, during normal use, for a period starting from the date of sale of three (3) years, except for video circuitry, which is covered for two (2) years, and remote controls which are covered for one (1) year.
  • Page 102 D E S I G N E D A N D M A N U F A C T U R E D I N N O R T H A M E R I C A t e l . ( + 1 ) 9 0 5 - 3 6 2 - 0 9 5 8 M - F 9 : 0 0 a m - 5 : 3 0 p m ( E T ) w w w .
