user guide
Phone Clip+
400227000-GB-12.08-Rev.A.indd 1
28-09-2012 11:48:57

Advertisement

Table of Contents
loading

Related Manuals for ReSound Unite Phone Clip+

Summary of Contents for ReSound Unite Phone Clip+

  • Page 1 user guide Phone Clip+ 400227000-GB-12.08-Rev.A.indd 1 28-09-2012 11:48:57...
  • Page 2 Welcome Congratulations on your purchase of a Phone Clip+. Phone Clip+ will allow you to connect your wireless resound hearing instruments to Bluetooth-enabled mobile phones. This enables clear and hassle-free phone connectivity, whether you are at home, in the office or on the move.
  • Page 3 Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this de- vice may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 Changes or modifications can void the user’s authority to oper- ate the equipment. Intended use Phone Clip+ is intended to enable wireless resound hearing instrument users to better follow phone conversations. The essential performance of the Phone Clip+ is to transfer signals between a phone with Bluetooth capabilities and wireless re- sound hearing instrument.
  • Page 5 - Annex i of Council directive 93/42/eeC for medical devices (Mdd) and essential requirements and other relevant provisions of directive 1999/5/eC (r&TTe). The declaration of conformity may be consulted at www.resound.com in us: FCC CFr 47 Part 15, subpart C, section 15.247 and 15.249.
  • Page 6 Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. in JP: This device has been granted a designation number by Ministry of internal Affairs and Communications under „Ordinance con- cerning Technical regulations Conformity Certification etc.

  • Page 7: Table Of Contents

    Contents description ........8 getting started .

  • Page 8: Description

    Description 1. ON/OFF switch 2. Call pick-up/hang-up button 3. Hearing instrument program toggle 4. Hearing instrument microphone mute button 5. Micro-usB for charging 400227000-GB-12.08-Rev.A.indd 8 28-09-2012 11:48:59...
  • Page 9 6. Volume control 7. Microphone inlet 8. Mounting clip 9. Hearing instrument pairing button 10. Bluetooth pairing button 400227000-GB-12.08-Rev.A.indd 9 28-09-2012 11:48:59...

  • Page 10: Getting Started

    3 hours, even if the battery indicator shows that the unit is fully charged (see section about “Light indicators”). • For safety reasons, recharge the battery only with chargers supplied by resound. 400227000-GB-12.08-Rev.A.indd 10 28-09-2012 11:49:00...

  • Page 11: Turning Your Phone Clip+ On And Off

    Phone Clip+ while it is on your body. Turning your Phone Clip+ ON and OFF To turn ON your Phone Clip+ slide the ON/ OFF switch (1 on page 8) down to the ON position. A white ”i” icon will be visible on the base of the switch and the Led indicator will now blink green every 2,5 seconds.
  • Page 12 1. Make sure Phone Clip+ is turned on. Your hearing instru- ments must be OFF – this is done by opening the battery door on the hearing instrument(s). 2. remove the silver cap from the Phone Clip+. With the tip of a pen or similar object, press the small white pairing but- ton one time on the back of your Phone Clip+ (see picture to...

  • Page 13: Bluetooth Pairing

    Bluetooth Pairing if your mobile phone is Bluetooth-enabled and supports the ap- propriate profiles, it can communicate with the Phone Clip+ only after completing two simple procedures: pairing and connecting. The pairing procedure allows you to control which Bluetooth devices are permitted to communicate with each other. it needs to be completed only once for each device you wish to use with your Phone Clip+.
  • Page 14 here. 1. Turn you Phone Clip+ ON and remove the silver cap. Place your mobile phone next to the Phone Clip+, and make sure your phone is ON. 2. Find the connectivity settings on your phone. Look for the “Bluetooth” feature in the main menu or one of the sub menus, such as “Connectivity”.
  • Page 15 Your Phone Clip+ should now be paired to your mobile phone. some mobile phones may ask which Bluetooth service you wish to enable. select “Headset”. Connecting Once your mobile phone and Phone Clip+ are paired, the mobile phone may need to be connected before it will actually send the appropriate audio signals.

  • Page 16: Phone Operation

    Phone operation in the below table you will find an overview of how you operate the Phone Clip+ when using it in connection with phone calls. Answering and end- Push the call pick-up/hang-up button if ano ing a call once incom if ano instea...
  • Page 17 Note: except for the answer and end call operations one or more of the below described operations may be phone depen- dent, i.e. they may either differ slightly or be absent altogether. if another call is already active it will be terminated and the new incoming call - indicated by knocking tones - will become active if another call is currently on hold it will become the active call instead...
  • Page 18 Voice dialling Press and hold the call pick-up/hang- if two up button for 2 seconds last p This f availa Increase or decrease Push the + sign on the side of the the volume of the Phone Clip+ to increase the volume speaker at the other Push the - sign on the side of the end of the phone call...
  • Page 19 if two mobile phones are connected this operation applies to the last paired mobile phone This functionality requires that the Voice dialling functionality is available and activated on your Bluetooth phone This functionality is only available for the wireless Verso hearing instrument family 400227000-GB-12.08-Rev.A.indd 19 28-09-2012 11:49:03...

  • Page 20: Volume Control

    * For the family of wireless Alera hearing instruments only: The Alera hearing instrument(s) must be initially paired once with a resound unite remote Control (either a customer or dispenser remote control) to enable the remote control functionality in the Phone Clip+.

  • Page 21: Operating Time

    To mute your hearing instrument microphones push the micro- phone mute/unmute button (4 on page 8) once on the front of the Phone Clip+ To unmute your hearing instrument microphones push the microphone mute/unmute button (4 on page 8) once on the front of the Phone Clip+ Toggle through hearing instrument programs Push the program button (3 on page 8) to toggle through avail-...

  • Page 22: Light Indicators

    The Phone Clip+ has a swivel clip to ensure that you can always place it so that the microphone inlet faces upwards towards the mouth. For optimal voice pickup keep the device within a range of 10- 30cm from your mouth. Light indicators (LED) The Light indicator at the top of your Phone Clip+ serves as a multipurpose user interface, providing information on the status...

  • Page 23: Introduction To Bluetooth

    Introduction to Bluetooth What is Bluetooth? Bluetooth provides a way for devices like mobile phones to com- municate wirelessly. First, check whether the phone you wish to use offers Bluetooth connectivity. Look for the following symbol on the device or its user guide.
  • Page 24 to a range of approximately 10 meters. Line-of-sight between the devices is not required. However, the following factors may affect the maximum range: • interference in the environment • The mobile phone which you are connecting to may support a more limited range than the 10 meters supported by the Phone Clip+ if your mobile phone moves out of range, the connection will be terminated.

  • Page 25: Important Information

    Never use household cleaning products (washing powder, soap etc…) or alcohol to clean the device • When resound unite Phone Clip+ is not in use, turn it OFF and store it safely • Protect resound unite Phone Clip+ from excessive moisture (bathing, swimming) and heat (radiator, car dashboard).
  • Page 26 • Avoid exposing your product to rain, moisture or other liquids to protect against damage to the product or injury to you. • Keep the product and any cords and cables away from operating machinery. • if the product overheats, if the product has been dropped or damaged, if the product has a damaged cord or plug, or if the product has been dropped in a liquid, discontinue use and contact your hearing care professional.
  • Page 27 • Opening the resound unite Phone Clip+ might damage it. if problems occur which cannot be resolved, consult your hearing care professional. • resound unite Phone Clip+ may only be repaired by an authorized service center. 400227000-GB-12.08-Rev.A.indd 27 28-09-2012 11:49:04...
  • Page 28 • do not use Phone Clip+ in areas where rF transmission is prohibited, e.g. air planes etc. • do only connect Phone Clip+ to connections which it is explicitly intended for. BUILT-IN BATTERY CARE: Please observe the following if the product contains a battery • Your product is powered by a rechargeable battery.
  • Page 29 Any attempt to do so is risky and may result in damage of the product. • Only recharge the resound unite Phone Clip+ only with a power supply unit that has been supplied together with the product.
  • Page 30 CHARGER CARE: Please observe the following if the product is supplied with a charger • do not attempt to charge your product with anything other than the AC adapter provided. The use of any other types may damage or destroy the product and could be danger- ous.
  • Page 31 • do not charge the resound unite Phone Clip+ while it is on your body. 400227000-GB-12.08-Rev.A.indd 31 28-09-2012 11:49:04...

  • Page 32: Technical Specifications

    Technical specifications Operating range: up to 3 m Wireless: 2.4 gHz Operating temperature: 0 to 45 °C Charging temperature: 0 to 45 °C storage temperature: -20 to 45 °C Temperature test, transport and storage information The product is subject to various tests in temperature and damp heating cycling between -25 °C and +70 °C according to internal and industry standards.

  • Page 33: Warranty

    Warranty The resound unite Phone Clip+ is covered by a limited war- ranty issued by the manufacturer for a period of 12 months from the day of the original purchase. Please notice that extended warranties may apply in your country. Please contact your local Hearing Care Professional for more information.
  • Page 34 What is not covered by this warranty? Problems arising from improper handling or care, excessive use, accidents, repairs made by an unauthorized party, exposure to corrosive conditions or damage due to foreign objects entering the device are NOT covered by the limited warranty and may void it.
  • Page 35 400227000-GB-12.08-Rev.A.indd 35 28-09-2012 11:49:04...

  • Page 36: Troubleshooting Guide

    TROUBLESHOOTING GUIDE SYMPTOM CAuSE The Phone Clip+ does not The battery in the Phone respond to any (long or short) Clip+ is depleted presses on the call pick-up/ hang-up button The pairing button on the The Phone Clip+ and hearing Phone Clip+ is pressed but instrument are not within wire...
  • Page 37 POSSIBLE REMEDY Charge the battery Assure that Phone Clip+ and hearing instruments are within wireless range, and repeat pairing process repeat pairing process, and assure that the battery doors on both hearing instruments are closed within 20 seconds after the pairing button has been pressed on the Phone Clip+ Assure that Phone Clip+ and mobile phone are within wire- less range, and repeat Bluetooth pairing process The Phone Clip+ is only in Bluetooth pairing mode for 120...
  • Page 38 TROUBLESHOOTING GUIDE SYMPTOM CAuSE The Bluetooth pairing failed The Phone Clip+ left Blue- tooth pairing mode before mobile phone completed the acti pairing session The wrong 4-digit PiN code has been entered The Phone Clip+ is powered The mobile phone is ringing but the light indicator on the Phone Clip+ does not flash, The Phone Clip+ and mobile...
  • Page 39 POSSIBLE REMEDY repeat the Bluetooth pairing process, and assure that the process is completed within 120 seconds after having been activated in the Phone Clip+ repeat the Bluetooth pairing process and if a PiN code is requested, enter 0000 (four zeros) Power on the Phone Clip+ Perform the Bluetooth pairing process and make a Bluetooth connection between the Phone Clip+ and the mobile phone...
  • Page 40 TROUBLESHOOTING GUIDE SYMPTOM CAuSE The mobile phone is ringing The Phone Clip+ and hearing and the light indicator on the instruments are not within wire Phone Clip+ does flash, but wireless range no ringing tones will sound in The battery in the hearing in- one or both hearing instru- struments is so depleted that ments...
  • Page 41 POSSIBLE REMEDY Assure that Phone Clip+ and hearing instruments are within wireless range replace the battery in the hearing instrument with a new one Assure that the Phone Clip+ microphone is kept close to your mouth, and that the Phone Clip+ does not rub against any clothing during the call Adjust the volume on the mobile phone until the sound is suitable, or adjust the volume using the ”+”...
  • Page 42 WARNING points out a situation that could lead to seri- ous injuries, CAUTION indicates a situation that could lead to minor and moderate injuries Advice and tips on how to handle your resound unite accessory better. equipment includes rF transmitter Product is a Type B applied part 400227000-GB-12.08-Rev.A.indd 42...
  • Page 43 Please ask your local hearing care professional con- cerning disposal of your resound unite accessory Any issues relating to the eu Medical device directive 93/42/eeC and r&TTe directive 1999/5/eeC should be directed to gN Hearing A/s, Lautrupbjerg 7, dK 2750 Ballerup, denmark 400227000-GB-12.08-Rev.A.indd 43...
  • Page 44 Worldwide Headquarters Australia resound A/s gN resound Pty. Ltd. Lautrupbjerg 7 unit r1 regents Park estate dK-2750 Ballerup, denmark 391 Park road Tel.: +45 45 75 11 11 regents Park NsW 2143 Fax: +45 45 75 11 19 Tel.: (free) 1800 658 955 www.resound.com...
