Summary of Contents for IK Multimedia 5 STOMP effects
- Page 3 Guitar Amp & FX modeling plug-in User Manual...
- Page 5 P LE A S E N OT E : AMPLITUBE™ IS A TRADEMARK OF IK MULTIMEDIA. ALL OTHER PRODUCT NAMES AND TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS, WHICH ARE IN NO WAY ASSOCIATED OR AFFILIATED WITH IK MULTIMEDIA.
-
Page 6: Table Of Contents
Using AmpliTube™ pag. 14 2.1 Connecting your Guitar to your computer pag. 14 2.2 Input Level – optimal setting pag. 14 2.3 AmpliTube™ signal path and effects chaining pag. 15 2.4 Stomp Module pag. 16 2.5 Amp Module pag. 16 2.6 Post FX Module... - Page 7 28 5.1 Parametric EQ pag. 28 5.2 Stereo Delay pag. 28 5.3 Stereo Reverb pag. 29 Chapter 6 General AmpliTube™ controls/display pag. 30 6.1 Input Level pag. 30 6.2 Gate pag. 30 6.3 Output Level pag. 31 6.4 Module Bypass pag.
-
Page 8: Ii - Interface
Guitar Amp and FX modeling Plug-In 5 STOMP effects models: - Wah-Wah - Chorus Stomp Module - Delay - Flanger - Overdrive 3 STEREO POST effects: - 3 band parametric stereo EQ Post FX module - Stereo Delay - Stereo Reverb... - Page 9 7 PRE-AMP models: - solid state clean - vintage clean - tube clean - british crunch - modern hi-gain - solid state lead - fuzz 5 EQ models: - tube american - tube american 2 - british class A - tube british - tube british 2 4 POWER AMP models: - solid state 30W...
- Page 10 "EULA” means this end user license agreement "AmpliTube™ plug-in software" means the software program included in the enclosed package, and all related updates supplied by IK Multimedia. "IK Multimedia Product" means the AmpliTube™ plug-in software and the related documentation and models and multimedia content (such as anima- tion, sound and graphics) and all related updates supplied by IK Multimedia.
- Page 11 All questions concerning this Agreement shall be directed to: IK Multimedia Production srl Via Dell’Industria 46 41100 Modena Italy e-mail: ikm@ikmultimedia.com © 2003 IK Multimedia. All rights reserved. AmpliTube™ is a trademark property of IK Multimedia Production. III License Agreement...
-
Page 12: Chapter 1 What Is Amplitube
What is AmpliTube™ Description AmpliTube™ is an amp modelling and effects plug-in. It gives you the abi- lity to model the complete guitar chain - including stomp boxes, amp model- ling, mic modelling and post effects. Thanks to its separate pre, eq, amp and cabinet models, 1,260 amp combinations can be generated to craft your favourite guitar sound modelled on top vintage and modern gear. - Page 13 2 Amp effects - Tremolo - Spring Reverb The Stomp Module (fig2) includes: 5 Stomp effects models: - Wah-Wah - Chorus - Delay fig. 2 - Flanger - Overdrive The Post FX Module (fig3) includes: 3 Stereo Post effects: - 3 band parametric stereo EQ...
-
Page 14: Chapter 2 Using Amplitube
Chapter 2 Using AmpliTube™ Connect your guitar to your computer To achieve the best input signal when using AmpliTube™ be sure you have an "instruments input" on your audio card (or a guitar dedicated input - fig. 6). The “instrument input” needs a gain control and commonly is an high impedance input, this means that the pickups of your guitar will find an input that matches that found in guitar amplifiers. -
Page 15: Amplitube™ Signal Path And Effects Chaining
The output signal is always stereo, so it is not possible to open AmpliTube™ as a ‘mono to mono’ plug-in, while it can be opened as a ‘mono to stereo’ or ‘stereo to ste- reo’. -
Page 16: Stomp Module
The sound of the effects is very different if they are applied before or after the Amplifier. In AmpliTube™ you have choice of both the options and the units are spe- fig. 8 cially designed for the “pre” or “post” operation. This “pre” section recrea- tes the sound of some of the classic pedal stomp boxes and it is patched, as for a real guitar setup, before the amplifier. -
Page 17: Post Fx Module
Speakers cabs need to be miked to capture their magical sound both in the studio or onstage. Some miking techniques with different microphones deli- ver various tonal results, that’s why AmpliTube™ has its own internal fig. 15 microphone type and placement section. Thanks to different Mic types and positions (fig. -
Page 18: Presets
AmpliTube™, as these are high precision digital processors used to create exactly the sound the user is searching for, and sometimes this goes beyond the stomps > amp > cabinet system. While the first two sections are entirely modeled after real gear which... -
Page 20: Chapter 3 Stomp Module
This is useful for instantaneously check the sound without all the Stomp boxes in the signal path. Wah-Wah The first stomp box in AmpliTube™ is the wah pedal (fig. 19). It carefully recreates that typical mid-rangey funky sweep of the best vinta- ge units. -
Page 21: Chorus
Chorus After the Delay the signal goes into the analog chorus / vibrato unit. This recreates the deep and articulated tone that only analog chorus boxes can deliver (fig. 21). Click on the “Chorus” big button to engage the effect. The red led shows that the unit is active. - Page 22 Level: sets the output level of the overdrive pedal. By turning this up the amplifier that follows will be overdriven. To get a more amp driven sound use low distortion settings with an high output level. Tone: Controls the timbre of the overdrive pedal. From extra warm at the full counterclockwise position to extra bright and sharp at the fully clockwise position.
-
Page 23: Chapter 4 Amp Module
This is useful for instantaneously checking the sound without the Amplifier emulation inserted into the signal path. The Amplifier module is the heart of AmpliTube™. Here is where the tone is actually modeled and shaped to be impressively similar to those obtained with very well miked high end amplifiers. - Page 24 Here are some suggestions for making the right choice of preamp type: Solid State Clean: This is the most linear preamplifier of AmpliTube™. Very good for jazz sounds, similar to Fender® combos and the Roland® Jazz Chorus. The frequency response is only slightly shaped.
-
Page 25: Eq Model
Try anyway to experiment all the other combinations because the sounds you get will always be very interesting. The Preamp and Eq stage has been kept separated in AmpliTube™ just to give much more flexibility to the user, it’s like being able to connect part of fig. -
Page 26: Amp Match
Amp Match AmpliTube™ offers the choice of a number of options for the single stages that an amplifier comprises of, so that you can try to experiment on your own with a huge number of combinations. Even so you have the capability of making things much simpler. -
Page 27: Cabinet Match
Microphone Modeling A good cabinet must be very well miked to get the right sound in the studio or onstage. AmpliTube™ even provides accurate miking that’s not fixed (fig. 33)- you can select some different configurations and placement of the microphone in front of the speakers. -
Page 28: Chapter 5 Post Fx Module
Chapter 5 Post FX Module Parametric Eq This parametric Stereo digital equalizer is the first of the Post FX (fig. 36) modules encountered by the signal. This is a precision stereo digital equa- lizer that it’s used to finely tune the modeled sound after all of the Amplifier simulations. -
Page 29: Stereo Reverb
This is a classic high quality hall reverb that can be found in high quality professional effects units. Very useful for adding space and dimension to the sound, it’s completely different in terms of timbre from the Spring emulation in the AmpliTube™ fig. 42 amplifier stage. -
Page 30: Chapter 6 General Amplitube™ Controls/Display
(fig. 45). It is an ultra fast noise gate that is able to cut the input of AmpliTube™ when the signal is lower than a certain threshold. This eliminates the noise back- ground typical of the guitar pickups / preamp system when the instrument is not playing. -
Page 31: Output Level
(fig. 46), it has a very wide range and has to be used to set the output level of the various AmpliTube™ presets. Depending on how AmpliTube™ is set the level can be quite different at the Post Effect outputs, that’s why this control is very useful. -
Page 32: Chapter 7 Support
User Area Together with your authorization code you've also have received a user id and password to access your personal user area on AmpliTube™' website. The personal user area is an advanced online service provided to you by IK Multimedia. It allows you to download patches and updates or to generate new authorization codes in the event that you accidentally lose the previous ones. - Page 33 In the personal user area you can: 1) Request a new authorization code This is useful for users who need to reinstall their applications with a new authorization code. The codes are supplied immediately with no need to wait before receiving them. 2) Submit a support request Support requests received using this form will follow a preferential line and will be answered first within our standard 24 hours lead time (busi...
- Page 36 AmpliTube™ is a trademark of IK Multimedia www.ikmultimedia.com www.amplitube.com IK Multimedia Production Via dell’Industria 46 - 41100 Modena Italy tel +39 059 285496 fax +39 059 2861671 info@ikmultimedia.com All specifications are subject to change without further notice. ©2003 IK Multimedia Production All other trademarks are property of their respective owners.
