56” utility blade for garden tractors

Advertisement

Quick Links

* ASSEMBLY
* OPERATION
READ & FOLLOW ALL SAFETY RULES & INSTRUCTIONS
104327
BERCO
56" Utility Blade
GARDEN TRACTORS
CAUTION:
BEFORE OPERATING THIS EQUIPMENT
OWNER'S MANUAL
Model Number
700416
for
* REPAIR PARTS
* MAINTENANCE
1
G-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700416 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bercomac 700416

  • Page 1 OWNER’S MANUAL Model Number 700416 BERCO 56” Utility Blade GARDEN TRACTORS * ASSEMBLY * REPAIR PARTS * OPERATION * MAINTENANCE CAUTION: READ & FOLLOW ALL SAFETY RULES & INSTRUCTIONS BEFORE OPERATING THIS EQUIPMENT 104327 G-05...
  • Page 2: Limited Warranty

    NOTE: All warranty work must be performed by an authorized dealer using original (manufacturer) replacement parts. Note: Bercomac reserves the right to change or improve the design of any part or accessory without assuming any obligation to modify any product previously manufactured. Instructions for Obtaining Warranty Services: Contact dealer where equipment was purchased or any other BERCOMAC Service Dealer to arrange service at their dealership.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS PAGE INTRODUCTION ..............................SAFETY PRECAUTIONS ............................. SAFETY DECALS ..............................ASSEMBLY Step 1: Blade Preparation ........................Step 2: Blade Installation ......................... OPERATION Adjusting the Angle of the Blade Manually ..................... Anti-Trip Protection ..........................MAINTENANCE & DISMOUNTING Maintenance ............................. Blade Dismounting ...........................
  • Page 4: Introduction

    INTRODUCTION TO THE PURCHASER This new attachment was carefully designed to give years of dependable service. This manual has been provided to assist in the safe operation and servicing of your attachment. NOTE: All photographs and illustrations in the manual may not necessarily depict the actual models or attachment, but are intended for reference only and are based on the latest product information available at the time of publication.
  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Careful operation is your best insurance against an accident. Read this section carefully before operating the tractor and attachment. All operators, no matter how experienced they may be, should read this and other manuals related to the tractor and utility blade before operating. It is the owner's legal obligation to instruct all operators in safe operation of the utility blade TRAINING e) When...
  • Page 6 SAFETY PRECAUTIONS 4. Stop the engine (motor) whenever you leave the MAINTENANCE AND STORAGE operating position and when making repairs, adjustments or inspections. 1. Check mounting bolts and other bolts at frequent intervals for proper tightness to be sure they are tight 5.
  • Page 7: Safety Decals

    SAFETY DECALS REPLACE IF DECALS ARE DAMAGED SEE PARTS BREAKDOWN FOR DECAL LOCATION #103165...
  • Page 8: Assembly

    ASSEMBLY STEP 1 BLADE PREPARATION: IMPORTANT: TORQUE ALL BOLTS ACCORDING TO TORQUE SPECIFICATION TABLE (SEE TABLE OF CONTENTS) WHEN STATED: TIGHTEN FIRMLY. REFER TO PARTS BREAKDOWN SECTION FOR THEIR IDENTIFICATION. Install the push frame (item 1) to the attaching frame (item 2) with a 5/8 x 4’’...
  • Page 9: Step 2: Blade Installation

    ASSEMBLY STEP 2 BLADE INSTALLATION: WARNING TO PREVENT INJURIES: Stop the motor. Apply parking brake. Remove the ignition key. Attach the blade to the subframe as shown. Make sure the blade’s push frame is pushed in until locked into place by the springs (item 1). Attach the blade NOTE: If the blade is equipped with a hydraulic angling kit, do not do this step and connect the...
  • Page 10: Operation

    OPERATION ADJUSTING THE ANGLE OF THE BLADE MANUALLY: To adjust the angle, turn the handle counter-clockwise to unlock the latch. Push or pull the handle to adjust the blade to the desired angle. ANTI-TRIP LOCK PROTECTION: The blade was designed to topple forward when striking solid objects.
  • Page 11: Maintenance & Dismounting

    MAINTENANCE & DISMOUNTING WARNING TO PREVENT INJURIES: Stop the motor. Apply parking brake. Remove the ignition key. MAINTENANCE: a) Verify the mounting bolts at frequent intervals for proper tightness in order to prevent costly repairs. Make sure that your equipment is in safe working condition.
  • Page 12: Utility Blade

    PARTS BREAKDOWN / NOMENCLATURE DES PIÈCES 56" UTILITY BLADE / LAME UTILITAIRE 56"...
  • Page 13 PARTS LIST / LISTE DES PIÈCES Ref. English description Description française Qty. Part # Réf. Qté. Pièce # 1 Blade Lame 104326 2 Cutting edge 56" Racloir 56" 104325 3 Carriage bolt 5/16" n.c. x 3/4" Boulon à carrosserie 5/16" n.c. x 3/4" 4 Flange nut 5/16"...
  • Page 14: Torque Specification Table

    TORQUE SPECIFICATION TABLE GENERAL TORQUE SPECIFICATION TABLE USE THE FOLLOWING TORQUES WHEN SPECIAL TORQUES ARE NOT GIVEN NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal oil. They do not apply if special graphited or moly disulphide greases or other extreme pressure lubricants are used. This applies to both UNF and UNC threads.
  • Page 15: Attachments

    ATTACHMENTS SNOWBLOWER ROTARY TILLER #700312 #700210 40" #700211 44" Mounts to the rear of lawn & garden UTILITY BLADE #700266 #700255 40’’ tractors 14 to 25 HP. Comes complete #700400 48’’ with drive & manual lift mechanisms Mounts on the same subframe as the Fits on same subframe as rotary &...
  • Page 16 NOTES...
