- Page 1 AE202 All-in-One (AIO) PC MS-AA87 System G52-AA871X1...
-
Page 2: Table Of Contents
Preface Contents Copyright Notice ������������������������������������������������������������������������������������������������������iii Trademarks �������������������������������������������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Upgrade and Warranty ��������������������������������������������������������������������������������������������iv Acquisition of Replaceable Parts ����������������������������������������������������������������������������iv Technical Support ���������������������������������������������������������������������������������������������������iv Green Product Features ������������������������������������������������������������������������������������������iv Environmental Policy �������������������������������������������������������������������������������������������� v Chemical Substances Information �������������������������������������������������������������������������� v Battery Information �������������������������������������������������������������������������������������������������� v Safety Instructions ���������������������������������������������������������������������������������������������������vi CE Conformity �������������������������������������������������������������������������������������������������������... -
Page 3: Copyright Notice
All-in-One PC Copyright Notice The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL� We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents� Our products are under continual improvement and we reserve the right to make changes without notice�... -
Page 4: Upgrade And Warranty
Preface Upgrade and Warranty Please note that certain components preinstalled in the product may be upgradable or replaceable by user’s request� For any further information about the product users purchased, please contact the local dealer� Do not attempt to upgrade or replace any component of the product if you are not an authorized dealer or service center, since it may cause the warranty void�... -
Page 5: Environmental Policy
All-in-One PC Environmental Policy ◙ The product has been designed to enable proper reuse of parts and recycling and should not be thrown away at its end of life� ◙ Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products�... -
Page 6: Safety Instructions
Preface Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the equipment or user’s manual should be noted� Keep the User’s Guide that comes with the package for future reference� Keep this equipment away from humidity and high temperature� Lay this equipment on a reliable flat surface before setting it up�... - Page 7 All-in-One PC Never pour any liquid into the opening that could damage or cause electrical shock� Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord� ◙ When installing the coaxial cable to the TV Tuner, it is necessary to ensure that the metal shield is reliably connected to protective earthing system of the building�...
-
Page 8: Ce Conformity
Preface CE Conformity Hereby, Micro-Star International CO�, LTD declares that this device is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive� FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules�... -
Page 9: Overview
Chapter 1 Overview This system is integrated in design, selecting a stylish appearance with a mirror screen, which displays the simplicity of modern individualism and the comfort of home� With a touchscreen display, flawless audio/ video capabilities and intuitive user interface, it blends technology with life, making computers easier and more fun to use —... -
Page 10: Packing Contents
Overview Packing Contents All-in-One PC AC/DC Adapter AC Power Cord User Manual Display Wiper Driver/ Utility Disc & Quick Guide Keyboard (Optional) Mouse (Optional) Stylus (Optional) * Please contact us immediately if any of the items is damaged or missing� * The illustrations are for reference only and your packing contents may slightly vary depending on the model you purchased�... -
Page 11: System Overview
All-in-One PC System Overview Front View Microphone The built-in microphone can be used for video chatting online� Webcam The built-in webcam with the microphone can be used for picture taking, video recoding, online conferencing and any other interactive applications� LED Indicator (Optional) The LED indicator indicates when it is recording�... -
Page 12: Rear View
Overview Rear View Important We suggest that you connect the AC/DC adapter to your AIO PC first and then connect the AC power cord to the socket-outlet for safety concerns�... - Page 13 All-in-One PC Ventilator The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating� Do not cover the ventilator� Kensington Lock Port This AIO PC provides a Kensington lock port, which allows users to secure the AIO PC in place with a key or some mechanical PIN device and attached through a rubberised metal cable�...
-
Page 14: Important 1
Overview RJ-45 LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN)� You can connect a network cable to it� Yellow Green/ Orange Color LED State Condition Left Yellow LAN link is not established� On (steady state) LAN link is established�... -
Page 15: Side View
All-in-One PC Side View System Power LED The power LED glows when the system is turned on and goes off when the system is shut down� In terms of power saving, the LED blinks in S3 (Suspend to RAM) mode and goes off in S4 (Suspend to Disk) mode�... - Page 16 Overview Brightness Up / Volume Up Button Press this button to tune the brightness/volume up� Brightness Down / Volume Down Button Press this button to tune the brightness/volume down� USB 3�0 Port The USB 3�0 port is backward-compatible with USB 2�0 devices� It supports up to 5 Gbit/s (SuperSpeed) data transfer rate�...
-
Page 17: Component Replacement & Upgrade
All-in-One PC Component Replacement & Upgrade Please note that certain components preinstalled in the product may be upgradable or replaceable by user’s request depending on the models users purchased� For any further information on the product users purchased, please contact the local dealer�... -
Page 19: Getting Started
Chapter 2 Getting Started This chapter provides you with the information on hardware setup procedures� While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity�... -
Page 20: Safety & Comfort Tips
Getting Started Safety & Comfort Tips The AIO PC is a portable platform that allows you to work anywhere� However, choosing a good workspace is important if you have to work with your PC for a long period of time� 1�... -
Page 21: Hardware Setup
All-in-One PC Hardware Setup Positioning Your System 1� Place your system on a flat and steady surface such as a table or desk� 2� Pull the stand open and tilt the monitor� To stabilize the system, make sure that the stand has been pulled until the mark on its hinge aligns to the edge of the hinge cover�... -
Page 22: Powering On The System
Getting Started Connecting the AC Power 1� Assemble the AC/DC adapter and the AC power cord� 2� Plug the DC end of the adapter to the AIO PC� 3� Plug the male end of the AC power cord to the electrical outlet� Important We suggest that you connect the AC/DC adapter to your AIO PC first and then connect the AC power cord to the socket-outlet for safety concerns�... -
Page 23: System Operations
Chapter 3 System Operations This chapter provides you with essential information on system operations� Important All information is subject to change without prior notice�... -
Page 24: Power Management
System Operations Power Management Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits� To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity�... - Page 25 All-in-One PC Waking the System Up The computer shall be able to wake up from power saving mode in response to a command from any of the following: ■ the power button, ■ the network (Wake On LAN), ■ the mouse, ■...
-
Page 26: Network Connection (Windows 7)
System Operations Network Connection (Windows 7) Wired LAN 1� Go to [Start] > [Control Panel]� 2� Select [Connect to the Internet] under [Network and Internet]� 3� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password�... -
Page 27: Wireless Lan
All-in-One PC Wireless LAN 1� Go to [Start] > [Control Panel]� 2� Select [Connect to the Internet] under [Network and Internet]� 3� Select [Wireless] to connect using a wireless router or a wireless network� 4� A list of available WLAN connections pops up� Choose a connection from the list or click [Open Network and Sharing Center] to establish a new connection�... - Page 28 System Operations 5� To establish a new WLAN connection, select [Set up a new connection or network] in [Network and Sharing Center]� 6� Followingly, choose [Manually connect to a wireless network] and click [Next] to continue� 7� Enter information for the wireless network you intend to add and click [Next] to proceed�...
-
Page 29: System Recovery (Windows 7)
All-in-One PC System Recovery (Windows 7) Important The Recovery Tool is only available on systems bundled with Windows OS and MSI utilities by default� The purposes for using the Recovery Tool may include: ■ Restore the system back to the initial status of original manufacturer’s default settings�... -
Page 30: System Backup
System Operations 3� Enter the Recovery Tool� This tool contains three features: Backup System, Restore System and Recover to factory default� System Backup It is highly recommended that users back up the system as the solution in the event of a catastrophic disk failure or other accidents�... - Page 31 All-in-One PC 2� Select [BACKUP] to start the system backup immediately� The Initial Backup The initial backup may take a while� Please let it complete without interruption� Subsequent Backups Subsequent backups will replace the previous backup files�...
- Page 32 System Operations 3� The system backup is in progress� Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system� 4� Alternatively, select [CANCEL] to stop the system backup immediately� Please do not switch off the power while the system backup cancellation is in progress�...
-
Page 33: System Restore
All-in-One PC 5� The following message indicates a successful system backup� Press [OK] to finish� System Restore This tool helps to return the system to a previous state with the backup files that users created and saved in the hard disk drive beforehand� If no backup files are available, the system will be restored to the default setup�... - Page 34 System Operations 2� Select [OK] or [NE�T] so that the system can recover to the previous backup or default setup� Alternatively, select [CANCEL] to stop the system restore immediately� With backup files: restoring the system to the previous backup Without backup files: restoring the system to the default setup ...
- Page 35 All-in-One PC 3� The system restore is in progress� Please note that it may take a while� Do not switch system restore is in progress� Please note that it may take a while� Do not switch � Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system�...
- Page 36 System Operations System Recovery This tool helps to recover the system back to factory default settings� All data on the default settings� All data on the HDD will be erased while all settings will be restored to factory default� Follow the instructions below to continue: 1�...
- Page 37 All-in-One PC 3� Please select [OK] so that the system can recover its default setup� 4� The system recovery is in progress� Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system� 3-15...
- Page 38 System Operations 5� The following message indicates a successful system recovery� Press [OK] to finish� Restart the system and access the Windows operating system as usual� If the recovery process fails or is interrupted, please start the whole procedure all over again�...
-
Page 39: Troubleshooting
Appendix A Troubleshooting... - Page 40 Troubleshooting My system does not start� 1� Check if the system is connected to an electrical outlet and it is turned on� 2� Check if the power cord and all cables are connected firmly� When I turn on my computer, the message “Operating System not found” appears or Windows does not start�...
- Page 41 All-in-One PC System speakers do not work� 1� Check the master volume setting in the Audio Mixer� 2� If you are using an application that has its own volume control, check if the volume is muted� 3� If you have connected an audio cable to the Headphone jack, disconnect it� 4�...
