Rainbow Technologies KX-87 Installation Instruction

RAC GmbH & Co. KG – P.O. Box 12 25 – 74899 Bad Rappenau
Please read carefully the installation instructions before you start with the installation!
KX-87 (VW Golf II and Seat Toledo)
KX-87 Installer 2-way-coaxial loudspeaker
KX-9x15
The factory location for the installation of the loudspeakers is provided and partly wired in the
dashboard and in the rear.
...to avoid fire and risk of accident.
Our products are only suitable for users with the necessary professional installation
knowledge. The relevant safety regulations for bearing car body parts, instructions on the
vehicle safety inside, as well as the regulations of the competent vehicle manufacturer are
necessary to be observed.
Attention: Important operational notice, please take in consideration before installation.
• The loudspeakers should only be operated with the indicated rated power.
• The mix up of the connections woofer/tweeter will lead to the immediate distortion of
the tweeter.
• The operation without crossover or with an active crossover would result in a
damage of the loudspeakers.
• Make sure that the same polarity in loudspeakers, crossover and amplifier is
guaranteed. If the speakers were wired out of phase, an unnatural sound without bass
would be the result.
Phone + 49-7066-9006-0 Fax +49-7066-9006-50
Installation instruction
KX-9x15
2-way-coaxial loudspeaker

Safety regulations for the user...

45 watt art.no. 231551
60 watt art.no. 231552
