SoundGate LEXPD2 User Manual

Apple ipod directly from the controls on your factory lexus radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LEXPD2
Purpose
The SoundGate LEXPD2 lets you connect and control an Apple
iPod directly from the controls on your factory Lexus radio.
Features
The LEXPD2 uses a simple "Y" harness for installation using
factory connectors. There is no need to cut or splice any wires,
including power and ground!
The LEXPD2 works in the following vehicles:
LEXUS ES300/330*
LEXUS ES350
LEXUS GS300/430**
LEXUS GS300/350/430/450H
LEXUS GX470
LEXUS IS300**
LEXUS IS250/350
LEXUS LS430
LEXUS LS460
LEXUS LX470**
LEXUS LX470
LEXUS LX570
LEXUS RX300*
LEXUS RX330/350/400H
LEXUS SC430*
*audio systems without navigation do not display text
**does not display text
NOTE: MP3 emulation mode is available only for 2006-2009 models with mp3 playback supported 5th Gen Navigation
Check www.soundgate.com for the most
current compatibility information.
Copyright© 2004-2008 SoundGate®. All Rights Reserved.
SoundGate® is a registered trademark of Stillwater Designs, Inc.
All other trademarks are the property of their respective owners.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
If you experience problems, call SoundGate Technical Support
at 800-256-0808, or email us at sgtech@soundgate.com.
7 < S B D A D E = a d g j j u > 9
2002–2006
All
2007–2008
All
2001–2005
All
2006–2009
All
2003–2008
All
2001–2005
All
2006–2008
All
2001–2006
All
2007–2008
with Navigation
2001–2003
All
2004–2007
All
2008
All
2001–2003
with Navigation
2004–2008
All
2005–2008
All
www.soundgate.com
Rev 20081216
