BMW Z3(E36/7) Electrical Troubleshooting Manual page 95

ENGINE CONTROL SYSTEM MS43 (6–CYLINDER M54)
BMW BMW BMW BM
Z3
.5 RT/WS
3 X6207
B6207
HOT FILM AIR
MASS METER
+ –
2 1 X6207
.5 GE .5 SW
1 17
.5 RT/WS
3 X6203
B6203
CRANKSHAFT
POSITION/RPM
SENSOR
2 1 X6203
.5 GE
.5 BR
8 21
P98
FUSE HOLDER IN
F203 E–BOX
20A
6 X8680
FUSE DETAILS
0670.3
.5 RT/WS
1 X6214
B6214
CAMSHAFT
POSITION SENSOR
1 (INLET)
2 3 X6214
.5 GE
.5 BR
5 18
Z3 VERSIONS
.5 RT/WS .5 RT/WS
1 X6224
B6224
CAMSHAFT
POSITION SENSOR
2 (OUTLET)
2 3 X6224
.5 GE
.5 BR .5 GR/BR
2 15
1 X6279
B6279
THERMOSTAT,
CHARACTERISTIC
MAP COOLING
2 X6279
X60003
45
A6000
ENGINE CONTROL
MODULE (DME)
