BMW Z3(E36/7) Electrical Troubleshooting Manual page 94

ENGINE CONTROL SYSTEM MS43 (6–CYLINDER M54)
BMW BMW BMW BM
Z3
F46
15A
32 X10018 6
FUSE DETAILS
0670.3
1 4
2 1 3
2 3 X78
1.5 BL/RT
BRAKE LIGHTS
X181
6325.0
.5 BL/RT
.35 RT/GE
24 28
P90
FRONT POWER
F13 DISTRIBUTION BOX
5A
X10016
FUSE DETAILS
0670.3
X78
3 X1714
S30
BRAKE LIGHT
SWITCH
1) BRAKE PEDAL
4
RELEASED
2) BRAKE PEDAL
2
DEPRESSED
3) BRAKE PEDAL
DEPRESSED
(TEST)
4) BRAKE PEDAL
RELEASED
(NORMAL)
.75 BR/BL .5 SW/GN
30
31
F204
30A
8 X8680
FUSE DETAILS
0670.3
8
4
M119
LEAKAGE DIAGNO-
SIS PUMP
.5 BR/WS
1 X1714
8 X6053
.5 BR/WS
8 X2499
.35 BR/BL/GE
20 3 X60004
Z3 VERSIONS
G7512
P98
B+ JUNCTION
FUSE HOLDER IN
POINT
E–BOX
F107
50A
X1982
POWER
DISTRIBUTION
0670.2
2 X6304
6
4 RT/GE
2 X6133
Y6133
AIR PUMP
1 X6133
GROUND
A6000
DISTRIBUTION
ENGINE CONTROL
0670.4
MODULE (DME)
X6455
K6304
SECONDARY AIR
PUMP RELAY
5 X6304
GROUND
DISTRIBUTION
0670.4
