X60005 - BMW Z3(E36/7) Electrical Troubleshooting Manual

BMW BMW BMW BMW
01/01
Z3
Pin Assignments (Z3 Versions)
Pin Type Signal
37 E/A CAN–
38
39
40

X60005

Pin Type Signal
1 A P_ZSZ3
2 A P_ZSZ2
3 A P_ZSZ1
4
5 M 31L
6 M A_ZSR
7 A P_ZSZ6
8 A P_ZSZ5
9 A P_ZSZ4
E = Input, A = Output, M = Ground
1210.26 f
Description/Function
CAN bus low
Not used
Not used
Not used
Description/Function
Ignition coil signal
Ignition coil signal
Ignition coil signal
Not used
Ground
Ground
Ignition coil signal
Ignition coil signal
Ignition coil signal
Connection
Instrument cluster, ABS/ASC/DSC
control module, steering angle
sensor
Connection
Cyl. 3 ignition coil
Cyl. 2 ignition coil
Cyl. 1 ignition coil
Ground point
Ground point
Cyl. 6 ignition coil
Cyl. 5 ignition coil
Cyl. 4 ignition coil
2001
