X60004 - BMW Z3(E36/7) Electrical Troubleshooting Manual

BMW BMW BMW BMW
01/01
Z3
Pin Assignments (Z3 Versions)
Pin Type Signal
37 A P_EVZ5
38 A P_EVZ6
39
40 A T_NWE1
41 A T_NWA1
42 A T_TEV
43 A T_MDK1
44 A T_MDK2
45 A S_KFK
46 A T_LLFSS
47 A T_LLFSO
48 M W_KS
49 A S_DISA
50
51
52 A S_SLPV

X60004

Pin Type Signal
1
2
3 A S_SLP
4
5
6
7 M M_FWG1
8 E A_FWG1
9 A U_FWG1
E = Input, A = Output, M = Ground
1210.26 d
Description/Function
Activate valve
Activate valve
Not used
Activate valve
Activate valve
Activate valve
Activate motor
Activate motor
Cooling signal
CLOSE signal
OPEN signal
Ground
Activate valve
Not used
Not used
Activate valve
Description/Function
Not used
Not used
Activate relay
Not used
Not used
Not used
Ground
Signal, pedal position 1
Voltage supply
Connection
Cyl. 5 fuel injection valve
Cyl. 6 fuel injection valve
Variable camshaft control valve 1
(inlet)
Variable camshaft control valve 2
(outlet)
Evaporative emission valve
Throttle position actuator
Throttle position actuator
Thermostat, characteristic map
cooling
Idle speed control valve
Idle speed control valve
Shield knock sensor
Valve, individual control intake
system
Secondary air pump valve
Connection
Secondary air pump relay
Pedal position sensor
Pedal position sensor
Pedal position sensor
2001
