0670.4 GROUND DISTRIBUTION

BMW BMW BMW BM

GROUND X165

Z3
E51
LEFT WASHER JET
HEATER
E52
1 X105
RIGHT WASHER
JET HEATER
1 X106
.75 BR .75 BR
X1091
2 X127
.75 BR
2 X10088
.75 BR .5 BR
1
B9508
PRESSURE
SWITCH
E22
RIGHT FRONT
MARKER LIGHT
2 X767
S36
TEMPERATURE
SWITCH
.5 BR
2 X87
.5 BR 1 BR
X1610
1 BR
H3
RIGHT HORN
X133
E19 H4
RIGHT PARK LIGHT RIGHT FRONT
TURN LIGHT
H4
RIGHT FRONT
TURN LIGHT
1 X137
E27
RIGHT FOG LIGHT
1 X769
.75 BR .75 BR
2.5 BR
X216
A51
WIPER/WASHER
MODULE
15 X285
2.5 SW/BR
E8
2 X123
RIGHT HEADLIGHT
2.5 SW
WITHOUT HEAD- 1 X123
LIGHT WASHER
E12
RIGHT HIGH BEAM
LIGHT
1 X134
E14
RIGHT LOW BEAM
LIGHT
1 X135
1.5 BR 1.5 BR 2.5 BR
X11337
4 BR
X165
M7
HEADLIGHT/FOG
LIGHT WASHER
PUMP
WITH HEADLIGHT
WASHER
M VERSIONS
M9
AUXILIARY FAN
MOTOR
1 X19022
4 BR
