FUSE DETAILS
BMW BMW BMW BM

FUSES 201 AND 202

Z3
1 RT/WS 1 RT/WS 1 RT/WS
3 X6153
T6153
CYL. 3 IGNITION
COIL
1210.26
3 X6152
T6152
CYL. 2 IGNITION
COIL
1210.26
3 X6151
T6151
CYL. 1 IGNITION
COIL
1210.26
F201
30A
2
2.5 RT/WS/GE
1 X6054
2.5 RT/WS
X6969
1 RT/WS 1 RT/WS 1 RT/WS
3 X6156
1210.26
3 X6155
T6155
CYL. 5 IGNITION
COIL
1210.26
3 X6154
T6154
CYL. 4 IGNITION
COIL
1210.26
1 RT/WS/GE .5 RT/WS/ 1 RT/
GE WS/GE
2
T6156
CYL. 6 IGNITION
COIL
1210.26
1
1 X6120
Y6120
EVAPORATIVE
EMISSION VALVE
1210.26
8 X60001
A6000
ENGINE CONTROL
MODULE (DME)
1210.26
Z3 VERSIONS
F202
30A
4 X8680
4 RT/WS/GE
X6960
2.5 RT/WS/GE
2 X6053
2.5 RT/WS/GE
X6964
.5 RT/WS/ .5 RT/WS/GE .5 RT/
GE WS/GE
2 X6163
Y6163
SECONDARY AIR
PUMP VALVE
1210.26
X6130
Y6130
IDLE SPEED
CONTROL VALVE
1
1210.26
2 X6167
1210.26
P98
FUSE HOLDER IN
E–BOX
.5 RT/
WS
1 X6276
Y6276
VARIABLE CAM-
SHAFT CONTROL
VALVE 2 (OUTLET)
1210.26
X6275
Y6275z
VARIABLE CAM-
SHAFT CONTROL
VALVE 1 (INLET)
Y6167
VALVE, INDIVIDUAL
CONTROL INTAKE
SYSTEM
