Fuses 24 And 25 - BMW Z3(E36/7) Electrical Troubleshooting Manual

FUSE DETAILS
BMW BMW BMW BM

FUSES 24 AND 25

Z3
F24
10A
8
.75 GN/SW
X10020
Z3 VERSIONS
.75 GN/SW .5 GN/SW .75 GN/SW
8 X58
K4
BLOWER RELAY
6450.6 .75 GN/SW
1 X1148
S198
JET HEATER
THERMOSWITCH
6169.0
.5 GN/RT
18 X257
3 X65
N17
CRASH CONTROL
MODULE
6312.0
6350.0
4 X625
S17
MIRROR CONTROL
SWITCH
5116.0
F25
5A
X10017
10
.5 GN/RT
X11264
.5 GN/RT .5 GN/RT
1 X1530
V10
UNCOUPLING
DIODE (LIGHTS)
6314.0
6320.0
4 X510
K26
LEFT PARK LIGHT
RELAY
6314.0
CANADA
P90
FRONT POWER
DISTRIBUTION BOX
USA
.5 GN/RT .5 GN/RT
4 X503
6300.0
6312.0
5 X10262 6350.0
K46
HIGH BEAM LIGHT
RELAY
6312.0
S8
LIGHT SWITCH
