0670.3 FUSE DETAILS

BMW BMW BMW BM

FUSES 1, 2, 3, AND 4

Z3
F1
30A
2
ROADSTER
4 RT/GE
X10014
2.5 RT/GE 2.5 RT/GE 2.5 RT/BR/GE
1 6 X13146
2.5 RT/GE 2.5 RT/GE
2 X18364
K18364
CONVERTIBLE TOP
RELAY II (OPEN)
5430.2
2 X18363
K18363
CONVERTIBLE TOP
RELAY I (CLOSE)
5430.2
F2
15A
4
COUPE
.75 RT/WS
18 X10182
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
6100.0
6330.3
2 X13057
6575.0
A36
REAR WIPER/
WASHER INTERVAL
CONTROL MODULE
6160.1
F3
30A
6
2.5 RT/BR/GE .5 GN/GE .5 GN/GE
2
5203.0
14 X285
A51
WIPER/WASHER
MODULE
6160.1
6167.1
P90
FRONT POWER
F4
DISTRIBUTION
15A
BOX
8 X10015
1.5 GN/GE
X9454
.5 GN/GE .5 GN/GE
3 X651
S53
DRIVER'S SEAT,
SEAT HEATER
SWITCH
2 3 X658
5203.0
S54
PASSENGER'S
SEAT, SEAT
HEATER SWITCH
