BMW Z3(E36/7) Electrical Troubleshooting Manual page 29

POWER DISTRIBUTION
BMW BMW BMW BM
Z3
5
4 RT/WS
2.5 RT/WS
1
15 15
S54
F201 F202
30A 30A
2 4
2.5 RT/WS
2.5 RT/WS/GE 4 RT/WS/GE 2.5 RT/WS
2
4 RT
X6300
6
K6300
30
ENGINE CONTROL
MODULE RELAY
87
2 X6300
4 RT/WS
5
15 15
F203 F204
20A 30A
6 8
4 RT/WS
X6961
1.5 RT/WS X6962 S54 1.5 RT/WS
2 X6021
1.5 RT/WS
5 X10016
P90
15
FRONT POWER
F13
DISTRIBUTION BOX
5A
X10016
6
.75 RT/WS
FUSE DETAILS
0670.3
G7512
B+ JUNCTION
POINT
F108
80A
X10422
6 RT
1
X64192
1
X64102
2.5 RT
9 X8680
P98
FUSE HOLDER IN
30
E–BOX
F205
30A
10 X8680
2.5 RT
2.5 RT/GE
S54
6 X6327
K6327
INJECTION VALVES
RELAY
1210.26
1210.27
1 2
X64101
1.5 RT 1 RT
Z3 VERSIONS
7 X60001 7 X70001
A6000
ENGINE CONTROL
MODULE (DME)
1210.26 2460.14
G6400
B+ JUNCTION
POINT E–BOX
A7000
TRANSMISSION
CONTROL MODULE
(EGS)
