0670.0 POWER DISTRIBUTION CHART

BMW BMW BMW BM

FRONT POWER DISTRIBUTION BOX

Z3
K6325 ** X6325
REVERSING LIGHT
RELAY
WITH EGS
1
46
45
44
11 12
43
42
41
40 K2
HORN RELAY
39
38
37
36
35
34
K9
33
UNLOADER RELAY,
32
TERMINAL 15
31
FUSES
2 3 4 5 6 7 8 9 10
13 14 15 16 17 18 19 20
X56 K47 ** X44
FRONT FOG LIGHT
RELAY
K33a * X50
AIR CONDITIONING
RELAY, MOTRONIC
X63 K104 * X1602
AIR CONDITIONING
RELAY/AUXILIARY
WATER PUMP
LATE PRODUCTION
EARLY
PRODUCTION
K25 X509
RIGHT PARK LIGHT/
LICENSE PLATE
LIGHT RELAY
K48 X45
LOW BEAM LIGHT
RELAY
K22 X53
HIGH SPEED
54
RELAY
53
52
51
FUSES
* M VERSIONS
** Z3 VERSIONS
K26 X510 K70 X1376
LEFT PARK LIGHT CENTRAL LOCKING
RELAY LUGGAGE
COMPARTMENT LID
MOTOR RELAY (ZV)
M COUPE
K16 X64 K4 X58
HAZARD FLASHER BLOWER RELAY
RELAY
K19 X51 K21 X52
COMPRESSOR NORMAL SPEED
CONTROL RELAY RELAY
21 22 23 24 25 26 27 28 29 30
