BMW Z3(E36/7) Electrical Troubleshooting Manual page 17

SYMBOLS
BMW BMW BMW BM
Z3
P90
F18
FRONT POWER
15A
DISTRIBUTION BOX
FUSE DETAILS
0670.3
THE COMPLETE WIRE
PROGRESSION AND
FURTHER CIRCUITS
CONNECTED TO FUSE
17 X252
18 ARE SHOWN IN CELL
N1
"0670.3 FUSE DETAILS"
ANTI–THEFT
AT FUSE 18
CONTROL MODULE
(DWA)
A2
INSTRUMENT
CLUSTER
RXD
11 X16
.5 WS/GE
DATA LINK
0670.5
N9
RADIO
15 X18126
1.5 BR
CURRENT PATH IS CON-
TINUED AS LABELED
0670.0-03
CIRCUIT REFERENCE–A
WIRE WHICH CON-
NECTS TO ANOTHER
CIRCUIT
0670.0-02
1.5 BR
X491
A1
GENERAL MODULE
2 X332
GROUND
DISTRIBUTION
0670.4
X497
THE COMPLETE WIRE
PROGRESSION AND
FURTHER CIRCUITS
CONNECTED TO
GROUND X497 ARE
SHOWN IN CELL
"0670.4 GROUND
DISTRIBUTION" AT
GROUND X497
ARROW SHOWS DIRECTION
OF CURRENT FLOW AND IS
REPEATED WHERE CURRENT
PATH CONTINUES
