BMW Z3(E36/7) Electrical Troubleshooting Manual page 105

BMW BMW BMW BMW
01/01
Z3
Pin Assignments (M Versions)
Pin Type Signal
11 A OELD
12 M M_FW2
13 E A_FW2
14 A U_FW2
15
16
17 A TD
18
19 E RFL
20 A TOG
21
22 E DFAHR
23
24 E KL 54 ON
25
26 E 15A26
27 E MFL
28 E A_S_LDPV
29 A KOREL
30 E A_T_LDP
31
32 E/A TXDII
33 E S_DWA
34 E S_BLTS
35 M 31
36 E/A CAN+
37 E/A CAN–
38
39
40
E = Input, A = Output, M = Ground
1210.27 e
Description/Function
Signal, oil pressure
Ground
Signal, pedal position 2
Voltage supply
Not used
Not used
Crankshaft RPM speed signal (TD)
Not used
Reversing light signal
Signal oil level
Not used
Speed signal right rear
Not used
Brake signal
Not used
Terminal 15
Cruise control signal
Leakage diagnosis
Activate relay
Leakage diagnosis
Not used
TXD diagnosis data link
Drive-away protection signal (code)
Signal test
Ground
CAN-bus High
CAN-bus Low
Not used
Not used
Not used
Connection
Instrument cluster
Pedal position sensor
Pedal position sensor
Pedal position sensor
Electronic immobilizer control
module (EWS III)
Reversing light switch
Thermal oil level switch
Dynamic stability control unit
Brake light switch
Fuse 26
Cruise control interface
Leakage diagnosis pump
Compressor control relay
Leakage diagnosis pump
Data link connector
Electronic immobilizer control
module (EWS III)
Brake light switch
Cruise control interface
Splice, CAN-bus High
Splice, CAN-bus Low
2001
