BMW Z3(E36/7) Electrical Troubleshooting Manual page 104

BMW BMW BMW BMW
01/01
Z3
Pin Assignments (M Versions)
Pin Type Signal
37 A P_EVZ5
38 A P_EVZ6
39 E F_OLN
40
41
42 A T_TEV
43 A T_NWA_S1
44 A T_NWA_F1
45 A S_DMTL–LED Tire pressure warning lamp control
46 A T_LLFSS
47 A T_LLFSO
48
49
50 A T_NWE_S1
51 A S_SSP
52
X60004
Pin Type Signal
1 A 61
2
3 A S_SLP
4 E ELUE
5
6 E S_50
7 M M_FW1
8 E A_FW1
9 A U_FW1
10
E = Input, A = Output, M = Ground
1210.27 d
Description/Function
Activate valve
Activate valve
Oil level/temperature signal
Not used
Not used
Activate valve
Activate valve
Activate valve
CLOSE signal
OPEN signal
Not used
Not used
Activate valve
Activate valve
Not used
Description/Function
Battery charge indicator
Not used
Activate relay
Signal, auxiliary fan ON
Not used
Signal start
Ground
Signal, pedal position 1
Voltage supply
Not used
Connection
Cyl. 5 fuel injection valve
Cyl. 6 fuel injection valve
Thermal oil level switch
Evaporative emission valve
Variable camshaft control valve
(outlet) – retard
Variable camshaft control valve
(outlet) – advance
Instrument cluster
Idle speed control valve
Idle speed control valve
Variable camshaft control valve
(inlet) – retard
Solenoid valve, sucking jet pump
Connection
Instrument cluster
Secondary air pump relay
High speed relay
Fuse 15
Pedal position sensor
Pedal position sensor
Pedal position sensor
2001
