Pin Assignments (M Versions) - BMW Z3(E36/7) Electrical Troubleshooting Manual

BMW BMW BMW BMW
01/01
Z3

Pin Assignments (M Versions)

F = X60001 9 Pins, black
G = X60002 24 Pins, black
H = X60003 52 Pins, black
I = X60004 40 Pins, black
J = X60005 9 Pins, black
X60001
Pin Type Signal
1 A 15
2 A P_DKSM+
3
4 M 31E
5 M 31L
6 M 31L
7 E 30
8 E U_HR<2
9 M P_DKSM–
X60002
Pin Type Signal
1 M T_LHV1
2
3
4
5 M M_CAN
6
7 M T_LHH1
8
E = Input, A = Output, M = Ground
1210.27 a
Description/Function
Activate relay
Voltage supply
Not used
Ground
Ground
Ground
Voltage supply
Voltage supply
Ground
Description/Function
Oxygen sensor heating ground
Not used
Not used
Not used
Ground
Not used
Oxygen sensor heating ground
Not used
Connection
Relay, injection valves
Electric throttle motor
Ground point
Ground point
Ground point
B+ junction point E-box
Fuse holder in E-box, fuse F202
Electric throttle motor
Connection
Oxygen sensor 1 (in front of
catalytic converter)
Oxygen sensors, exhaust
temperature sensor
Oxygen sensor 1 (behind catalytic
converter)
2001
