QUICK REFERENCE GUIDE

QUICK REFERENCE GUIDE
P O R T A B L E M E D I A P L A Y E R
Features include the following: This PDF was downloaded from SatelliteGuys.US
Video Player: DISH Network content and MPEG-4
Music Player & Recorder: DISH Network content, MP3, WMA, WAV
Photo Viewer/Slideshow: JPG, JPEG, BMP
Game Console: Mophun 2D/3D Games
Additional on-screen information
Built-in Help:
Browser: Built-in Hard Drive: USB Mass Storage
Device for any file type.
USB-A (Host): connect USB (mass storage device)
compatible equipment, like a camcorder, digital photo
camera or a USB flash drive
USB-B (Device): connect to a compatible
DISH Network DVR or computer
Power (DC IN): connect to the AC/DC power
adapter that came with the PocketDISH
Charge the Battery
Your PocketDISH has a rechargeable Li-Ion battery. The Li-Ion battery is a
high capacity power source. Do not use another battery charger or AC/DC
adapter. For your safety, charge the Li-Ion battery only with the AC/DC
adapter that came with the PocketDISH. Failing to do so can cause
permanent damage to equipment and can result in serious personal injury.
CHARGE BATTERY
Flip down the pins ON
4 Hours
Flashing
110Vac/60Hz
DC-IN
Connect to power
Headphones/AV
Multi-connection: install
the multi-connector for
use with other multimedia
devices
ON: press and hold to turn on
PocketDISH
Play: starts playback
Pause: pauses playback
Enter: acknowledges a selection
OFF: press and hold to turn off
PocketDISH
Stop: stops playback
Escape: quits a selection
Exit: pauses or exits a game
Previous/Next: selects previous/next file
Fast Forward/Fast Reverse: advances or reverses quickly.
Vol +/-: increases or decreases volume
CHANGE VOLUME
Charging
Increase
Up to 4 hours
Ready
Decrease
Microphone: for digital audio (voice) recordings
: moves the cursor left/right
: moves the cursor up/down
00 ... 99
Press and hold to increase
the volume
99 ... 00
Press and hold to decrease
the volume
HDD: the hard drive is active when lit
ON: shows that the PocketDISH is turned on
CHG: a solid light indicates that PocketDISH is
connected to the battery charger. If charging is
complete, the light flashes
Function key 3: Access the selection menus,
when displayed
Function key 2: Access the selection menus,
when displayed
TV/LCD - Press and hold to select PocketDISH or
TV for viewing
Function key 1: Access the selection menus,
when displayed
Key lock - Press and hold to activate or deactivate
CONNECT HEADSET
Control 1: Play,
Pause, Enter or
Game Control key
Control 2: Stop,
Escape, Exit or
Game Control key
Min Volume control:
The volume level of
PocketDISH will effect the
range on the headphone's
Max volume control.
