Unicont SPb PCH-205 Operating Manual

Power supply/automatic battery charger

Advertisement

Quick Links

Unicont SPb Ltd
Power Supply/Automatic Battery Charger
PCH-205
Technical Documentation
(205-1-27062012)
St. Petersburg
2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCH-205 and is the answer not in the manual?

Questions and answers

Summary of Contents for Unicont SPb PCH-205

  • Page 1 Unicont SPb Ltd Power Supply/Automatic Battery Charger PCH-205 Technical Documentation (205-1-27062012) St. Petersburg 2012...
  • Page 2: Table Of Contents

        OPERATION PRINCIPLE .....................8     CONTROLS AND INDICATORS ..................9     INSTALLATION AND CONNECTION ..............14     ALARM SIGNALS OF PCH-205 .................19     TRANSPORTATION AND STORAGE ..............20     RECYCLING ........................21     WARRANTY ........................22    ...
  • Page 3 Unicont SPb Ltd Technical Documentation PCH-205 This Operating Manual applies to the PCH-205 Power Supply/Automatic Battery Charger. This Manual is intended to assist in the familiarization with the design, operating principles and procedures established for the convection heater during its intended use or maintenance.
  • Page 4: General Data

    Technical Documentation PCH-205 1. General data A power Supply/Automatic Battery Charger PCH-205 (hereinafter referred to as — PS, device) is designed to provide devices of the shipboard equipment with constant voltage 24 V. Also, the device operates as a charging device (hereinafter referred to as — CHD) and carries out automatic charging of storage batteries connected to it (hereinafter referred to as —...
  • Page 5 Unicont SPb Ltd Technical Documentation PCH-205 Figure 1. Base Configuration PCH-205 Figure 2. Configuration PCH-205 with Integrated Control Figure 3. Configuration PCH-205 with Remote Control Page 5...
  • Page 6: Specifications

    Unicont SPb Ltd Technical Documentation PCH-205 3. Specifications Table 2. Electrical Specifications Parameter Integrated Power Supply Unit Integrated Charging Device 220 V (180 V ... 264 V), 50/60 Hz, Supply Voltage optionally: 110 V (90 V – 132 V), 50/60 Hz 9–30 V (is selected by the operator),...
  • Page 7: Safety Engineering Instructions

    Unicont SPb Ltd Technical Documentation PCH-205 Integrated Parameter Integrated Power Supply Unit Charging Device Performance 85 % Overall Dimensions 370 mm × 350 mm × 140mm Operating -20 °C …+55 °C Temperature: Storage Temperature -60 °C …+70 °C Weight 9.65 kg...
  • Page 8: Operation Principle

    Unicont SPb Ltd Technical Documentation PCH-205 5. Operation principle The device consists of two main modules: a power supply unit and charging device. The modules are autonomous from each other and connected with a switching unit (relay) between each other.
  • Page 9: Controls And Indicators

    Unicont SPb Ltd Technical Documentation PCH-205 6. Controls and indicators The content of controls and indicators depends on the device configuration: - for configuration of the devices of base and with remote control, a basic set of controls and indicators is used (see para. 6.1);...
  • Page 10 Unicont SPb Ltd Technical Documentation PCH-205 6.2 Extended Set of Controls and Indicators The device configuration with integrated control provides the following controls and indicators: control buttons, three LEDs indicating the device state and operation mode, two digital LED indicators (see Figure 6).
  • Page 11 Unicont SPb Ltd Technical Documentation PCH-205 Table 5. Purpose of LED Indicators LED Indicator Purpose Flashes during primary charging phase of SB, i. e., when CHD is in current Charging regulation mode (see the diagram of voltage and current charging curves, (yellow) Figure 4).
  • Page 12 Unicont SPb Ltd Technical Documentation PCH-205 6.2.2. Setting of PS Configuration with Integrated control Charging Current Setting Charging current is set by the user with an integrated keyboard of the device. To set the required current value, carry out the following actions: - press button “SELECT”...
  • Page 13 Unicont SPb Ltd Technical Documentation PCH-205 Note! If the PS is used without a temperature sensor, after setting the recommended charging voltage in the CHD, the battery temperature shall be controlled within the first day and in case of obvious overheat of SB the set voltage and current shall be reduced until optimal thermal conditions are selected.
  • Page 14: Installation And Connection

    Unicont SPb Ltd Technical Documentation PCH-205 7. Installation and connection The PS is installed in the following sequence: 1. Select and prepare the place for installation to provide free connection of cables. The device is recommended to be mounted on the vertical bulkhead.
  • Page 15 3. Deliver cables of connected devices to the PS. When selecting, use the cable with an appropriate core section (see Cable Core Section Table, Table 7 and Figure 9). Table 7. Types of Cables and Section of the Cores Connected to the Terminals of PCH-205 Core...
  • Page 16 Unicont SPb Ltd Technical Documentation PCH-205 IMPORTANT! Before connecting the power supply cable to the PS, make sure that it is not energized. Total load for all terminals shall not exceed 40 А Figure 9. Connection Diagram of External Devices to PS 10.
  • Page 17 Unicont SPb Ltd Technical Documentation PCH-205 If alarm system actuates, it is necessary to found out and eliminate the cause of its actuation (see para. 8). 7.1 Connection of auxiliary devices to CHD: The following devices can be connected to the charging device (see Figure 9):...
  • Page 18 Unicont SPb Ltd Technical Documentation PCH-205 7.1.2. Control panel of storage batteries BCP-136 The control panel of storage batteries BCP-136 (see Figure 11) is connected to the PS when remote setting and control of device is required. Except for the main function of current value indication and device control, BCP-136 backups audio and light alarm in alarm situations (see para.
  • Page 19: Alarm Signals Of Pch-205

    Unicont SPb Ltd Technical Documentation PCH-205 8. Alarm signals of PCH-205 In the PS, the provision is made for alarm devices with light, audio and relay notification about emergency situations in PS operation (see table “Alarm About Emergency Situations”, Table 8).
  • Page 20: Transportation And Storage

    Unicont SPb Ltd Technical Documentation PCH-205 9. Transportation and Storage The divice shall be stored in heated space at air temperature of +5 ºС to +35 ºС (maximum values of -60 ºС to +70 ºС), at relative humidity of air not exceeding 95 % at temperature of +25 °C and content of dust, oil, moisture and aggressive admixtures in the air not...
  • Page 21: Recycling

    Unicont SPb Ltd Technical Documentation PCH-205 10. Recycling Do not recycle the packing of a new product, its parts with defects identified during its operation as well as the overage product as common household waste since they contain materials and raw materials suitable for their recovery.
  • Page 22: Warranty

    Technical Documentation PCH-205 11. Warranty The manufacturer guarantees the unit PCH-205 complies with this manual provided that the operation, transportation and storage conditions are adhered to during the warranty period. The unit’s warranty period expires 24 months from the date of its shipping from the manufacturer’s storehouse.
  • Page 23: Date Of Packing

    Unicont SPb Ltd Technical Documentation PCH-205 12. DATE OF PACKING Power Supply/Automatic Battery Charger PCH-205 № name of article designation serial number Packed Unicont SPb Ltd, Russia. Manufacturer according to the requirements of the current technical documentation. post signature clarification of signature year, month, day 13.
