Positioning the OUR 2002s in Your Room
For Center Channel Use
The C/LIR 2002, when used singly for center channel use, can be placed horizon-
tally or vertically above or below the TV. When used as center channel pairs, the
C/LIR 2002s should be placed on either side of the TV, or above and below it.
For Main
Left
and Right
Use
The C/LIR 2002 is a
hi~h
quality, full-range speaker system which, in addition to
its use as a center channel
In
home theater systems, can also be used as a left and right
main speaker in all home theater systems as well as conventional two channel audio
systems. When the C/LIR 2002 is used as a left and right main speaker, it may be
positioned either vertically or horizontally.
Installing the Logo
Because the C/L/R 2002 can be used either vertically or horizontally, the logo is sup-
plied separately. Holes are provided for installation when the speaker is used horizontal-
ly. These are located under the grill cloth at the center of the lower edge at the front of
the speaker approximately 11/16" up from the edge and 1 1/2" apart. Locate the logo
over these two holes and gently tap it in through the grill cloth. .
Installing the Feet/Angling Device
The C/LIR 2002 is supplied with brass inserts designed to go into the bottom of the
speaker to hold adjustable feet which hold the speaker above the surface it is placed on
as well as give you the option of angling the speaker up or down to point directly at the
listeners. Install three of these inserts in the bottom of the speakers. There are predrilled
holes on the bottom of the speaker under the grill cloth (when the speaker is positioned
horizontally). Simply locate the holes. Two holes are approximately 2" back from the
front and 12" apart. You also have a choice for the rear hole depending on the depth of the
surface you will place the speaker on. One is located farther back than the other. Select
one of these holes. Gently tap the inserts in through the grill cloth and screw the feet in.
Technical Assistance
It is our pleasure to offer assistance if you have any questions regarding your
C/L/R 2002s or their set-up. Please contact your nearest Defmitive Technology dealer
or contact us directly at 410-363-7148.
Service
Service and warranty work on your Definitive loudspeakers will normally be per-
formed by your local Definitive Technology dealer. If, however, you wish to return the
speaker to us, please contact us first, describing the problem and requesting authorization
as well as the locations of the nearest factory service center. Please note that the address
given
in this booklet is the address of our offices only. Under no circumstances should
loudspeakers be shipped to our offices or returned without contacting us first and
obtaining return authorization.
Definitive
Technolo~y
Offices
11433 Cronridge Dnve
Owings Mills, Maryland 21117
Phone: 410-363-7148
