- Page 1 OPERATOR’S MANUAL VENTILATOR 6300A NewTech Medical Limited 8400 Normandale Lake Boulevard, Suite 920, Bloomington 55437, Minnesota, U.S.A Tel: 1-952-837-2688 Fax: 1-952-400-8947 http://www.newtech-medical.com E-mail: info@newtech-medical.com...
-
Page 2: Table Of Contents
CONTENTS GENERAL ............................1 Main Technical Specification .......................1 Operational environment requirements..................2 Volume and weight ........................2 Storage ............................2 Symbols............................2 SYSTEM OPERATION PRINCIPLE....................3 System-Block-diagram ........................3 Basic Operation Principle ......................4 The rear panel ..........................7 INSTALLATION AND CHECK......................8 Ventilator Component........................8 Ventilator Installation ........................9 Check ............................9 OPERATION ............................. - Page 3 WARNINGS The following warnings must be read and understood before performing any of the procedures described in this section Under no circumstances should this medical device be operated in the presence of flammable anesthetics or other volatile materials due to a possible explosion hazard. Lipid spilled or dripped into the unit may cause damage to the unit or result in an electrical shock hazard.
- Page 4 IMPORTANCE You are welcome to purchase and utilize our equipment. The careful and comprehensive service to you is our commitment. Please read thoroughly and carefully the Operation Manual before putting the machine into operation and strictly follow all the procedures of operation. Our company guarantees the quality of the product.
-
Page 5: General
6300A Operator’s Manual 1 GENERAL 6300A microprocessor ventilator is pneumatic driven, electronic-controlled, pressure-limit and time- cycled multifunctional ventilator also with perfect multi-ventilating mode and monitoring system. Its panel configuration refers to the figure. Main Technical Specification 1.1.1 The performance of Airway System a) Safety pressure of the airway system: no more than 6kPa;... -
Page 6: Operational Environment Requirements
6300A Operator’s Manual Operational environment requirements +5 °C ~ +40°C a) Ambient temperature b) Relative humidity not more than 80% c) Atmospheric pressure 86kPa ~104kPa d) Requirements for Gas Source 0.3MPa ~0.5MPa, Oxygen e) Power supply ~220V, 50Hz f) Warming up... -
Page 7: System Operation Principle
6300A Operator’s Manual 2 SYSTEM OPERATION PRINCIPLE System-Block-diagram Figure 2-1 6300A Diagram - 3 - NewTech Medical Limited... -
Page 8: Basic Operation Principle
6300A Operator’s Manual Basic Operation Principle The high-pressure oxygen enters the pressure reduction valve I, and the output pressure from the pressure reduction valve I is stabilized at 0.25MPa (already adjusted before ex-factory). The output gas from the pressure reduction valve I enters the electromagnetic valve. In inspiring, the electromagnetic valve is open;... - Page 9 6300A Operator’s Manual The front panel Figure 2-2 2.2.1 Display screen See Fig. 4. Table1 Figure 2-3 Table 2-1 Display symbol’s implication Function TIDAL VOL Display the tidal volume value. Airway pressure display: Reflect the airway pressure AIRWAY PRESSURE change when patients respiration.
- Page 10 6300A Operator’s Manual 2.2.2 Parameter setting key Figure 2-4 Table 2-2 Parameter Function RATE Respiratory frequency setting key ranging from six to sixty bpm. Inspiration and respiratory ratio setting key, totally six positions: I: E 1:4, 1:3, 1:2, 1:1.5, 1:1, 2:1.
-
Page 11: The Rear Panel
6300A Operator’s Manual 2.2.4 Alarm Information Display Figure 2-6 Table 2-4 Symbol Function Oxygen Failure Supply Oxygen Failure Alarm Display. HI PRESS Airway High Pressure Alarm Display. LO PRESS Airway Low Pressure Alarm Display. Apnea Apnea Alarm Tidal Volume Tidal volume regulating knob. Regulate ranging :0, 80ml~1200ml 2min Eliminate alarm. -
Page 12: Installation And Check
6300A Operator’s Manual 3 INSTALLATION AND CHECK Ventilator Component Figure 3-1 1 Ventilator 2 Machine Arm 3 Power Cable For Ventilator 4 Check Valve 5 Oxygen Pipeline 6 Cart 7 Wheels 8 Bag 9 Water Trap 10 Lines For Measure Temperature... -
Page 13: Ventilator Installation
The fuse of the 6300A ventilator is at the power socket position of the rear panel. The fuse, with the value of 2A, can be replaced after the power cable is unplugged and the fuse box rear cover is opened with a small dash-line screwdriver. - Page 14 6300A Operator’s Manual 3.3.3 Switch on the ventilator’s power Set the ventilator standard state Upper pressure limit at 6kPa Lower pressure limit at 0.5kPa The respiratory frequency at 20bpm The ventilation mode as I: E as The tidal volume 700ml 3.3.4...
-
Page 15: Operation
6300A Operator’s Manual 4 OPERATION This chapter will mainly introduce the detailed operating method of 6300A ventilator. Parameters’ setting Table 4-1 Parameter key Operating method Turn the knob to change the tidal volume value. Increase by clockwise Tidal Volume and decrease by counter-clockwise. -
Page 16: Operation
6300A Operator’s Manual Operation Table 4-2 Parameter key Operating method Control ventilation: When pressing the key, the light at the left upper corner of the key flashes. At this mode, in case of the patients’ respiratory condition, ventilate for the patients according to the pre-adjusted ventilating parameters. -
Page 17: Operation Methods Of Various Ventilation Modes
6300A Operator’s Manual 5 Operation Methods of Various Ventilation Modes C: also called control respiration The characteristic is that patient cannot control releasing airflow, and all respiratory movement all must be carried out according to the conditions set by ventilator. -
Page 18: Simv: Synchronization Intermission Mandatory Ventilation
6300A Operator’s Manual SIMV: Synchronization Intermission Mandatory Ventilation This is a kind of method combined by patient independence breath and machine mandatory ventilation. The mandatory ventilation is touching off synchronous. It is used in the procedure from mandatory ventilation to independence breath before carrying down machine. -
Page 19: Spont
6300A Operator’s Manual SPONT In some hospitals, after patient have spontaneous respiration, select SPONT should be provided for the patient through facemask before offline so as to train the spontaneous respiration ability of the patient. As a routine, the methods for realizing persistent gas flow are as follows:... -
Page 20: Cleaning And Maintenance
6300A Operator’s Manual 6 CLEANING AND MAINTENANCE General principle Generally, the gas in the inspiration circuit (the part before the humidifier) is dry and clean, and flows to the patient with a certain velocity, so it is unsuitable for the bacteria to grow. While the gas... -
Page 21: Maintenance
6.2.1 Maintainability The 6300A ventilator is designed to place reliability at the principal position, and it is required that the mean time of break free (MTBF) of the whole machine be greater than 2000 hours. But human operates the machine; the operating life of the machine in a great extent is dependent on the human factors. - Page 22 6300A Operator’s Manual 6.2.5 Maintenance during operation and transportation The location of the machine at the operation place (such as operating room, ward, monitor room) should be appropriate, so that the doctor or nurse may not touch the machine during operation, therapy or nursing of the patient.
-
Page 23: Troubleshooting
6300A Operator’s Manual 7 TROUBLESHOOTING Table 7 Troubles Causes Methods Corrugated hose damaged or Replace or reinstall properly connector loose Sensor connector loose Reinstall Patients breathing system leaks Patients’ respiratory loop leaks Check as the above method Flow regulating switch closes... -
Page 24: Warranty
WARRANTY NewTech Medical Limited (NewTech) guarantees to the customers that NewTech VENTILATOR machines to be free from defects for a period of eighteen (18) months and accessories for a period of three (3) months. The warranty period starts at the date of purchase.
