Liquid Crystal Projector USER'S MANUAL USER'S MANUAL Thank you for purchasing this liquid crystal projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference. -
Page 15: Features
FEATURES FEATURES This liquid crystal projector is used to project various computer signals as well as NTSC / PAL / SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. Outstanding Brightness The UHB lamp and high-efficiency optical system assure a high level of brightness. -
Page 16: Part Names
Part Names Zoom Knob Focus Ring Remote Control Sensor Power Switch Lens AC Inlet Slide Lens Door (to the Power Cord) Foot Adjuster Ventilation Openings Front / Left / View (Intake) Control Panel (Refer to P.8 "OPERATIONS") LAMP Indicator RESET Button TEMP Indicator KEYSTONE Button POWER Indicator... -
Page 17: Loading The Battery
Part Names (continued) VIDEO Button STANDBY/ON VIDEO STANDBY/ON Button RGB Button KEYSTONE Button MENU SELECT Button KEYSTONE Button MENU Button SELECT POSITION Button Button MENU RESET POSITION Button RESET Button MENU Button MAGNIFY Button VOLUME Button MAGNIFY FREEZE VOLUME MAGNIFY Button VOLUME Button... -
Page 18: Installation
INSTALLATION INSTALLATION Installation of the Projector and Screen Refer to the drawing and table below for determining the screen size and projection distance. Screen The projection distances shown in the table below are for full size (800 x 600 dots). a: Distance from the projector to the screen. -
Page 19: Cabling
Cabling Refer to the table below for connecting each terminal of the projector to a device. Table 2. Cabling Function Terminal Cable Accessory RGB cable or optional RGB Analog RGB input cable with D-sub 15-pin shrink jack and inch thread screws RS-232C communication CONTROL Optional RS-232C cable... -
Page 20: Power Connection
Power Connection Use the correct power cord depending on the power outlet to be used. Connect the AC inlet of the projector to the power outlet firmly by the power cord. CAUTION • Be carful in handling the power Power outlet cord according to instructions of the accompanying manual "SAFETY INSTRUCTIONS"... -
Page 21: Operations
OPERATIONS OPERATIONS STANDBY/ON Button POWER Indicator STANDBY/ STANDBY/ON VIDEO ON Button KEYSTONE MENU SELECT Zoom knob MENU RESET POSITION Focus ring MAGNIFY FREEZE VOLUME Power Switch Slide Lens door Power ON 1. Check that the power cord is connected correctly. 2. -
Page 22: Basic Operation
Basic Operation The basic operations shown in Table 3 is performed from the supplied remote controller or the projector control panel. Items indicated by (*) may be used from the control panel. Table 3 . Basic Operation Item Description Select Input Signal ( : Press the INPUT button. - Page 23 Items indicated by (*) may be used from the control panel. Table 3. Basic Operation (continued) Item Description Volume Adjustment : Press the VOLUME button. VOLUME ↔ reduces the volume increases the volume Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the MUTE MUTE mode.
-
Page 24: Setup Menu
Setup Menu The following adjustments and settings are possible when SETUP is selected at the top of the menu. Part of the Setup menu differs between RGB input and video input. Select an item with the buttons, and start operation. Use the Single menu to reduce menu size (see Table 3, MENU SELECT). SETUP INPUT IMAGE... -
Page 25: Input Menu
Input Menu SETUP INPUT IMAGE OPT. The following functions are available when INPUT is selected on the AUTO EXECUTE menu. Select an item with the buttons, and start operation. CANCEL VIDEO HDTV Table 5. Input Menu Item Description Operation Start/Stop: Press the button. -
Page 26: Image Menu
Image Menu SETUP INPUT IMAGE OPT. The following adjustments and settings are available when IMAGE is BLANK MIRROR selected on the menu. Select an item with the buttons, and START UP GAMMA COLOR TEMP start operation. Table 6. Image Menu Item Description Select Blank Screen Color: Select color with the... -
Page 27: Options Menu
Options Menu SETUP INPUT IMAGE OPT. The following adjustments and settings are available when OPT. is VOLUME MENU COLOR selected on the menu. Select an item with the buttons, and LANGUAGE AUTO OFF start operation. SYNC ON G WHISPER Table 7. Options Menu Item Description ↔... -
Page 28: No Signal Menu
No Signal Menu VOLUME BLANK The same adjustments and settings are available with the Image and MIRROR START UP Options menus when the MENU button is pressed during display of the MENU COLOR LANGUAGE “NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE AUTO OFF SYNC ON G ON ***”... -
Page 29: Maintenance
MAINTENANCE MAINTENANCE Lamp HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE Contact your dealer before replacing the lamp. For the optional lamp, see the item “Optional Parts” of the Table 12. Before replacing the lamp, switch power OFF, remove the power cord from the power outlet, and wait approximately 45 minutes until the lamp has cooled. -
Page 30: Replacing The Lamp
Replacing the Lamp 1. Switch the projector OFF, remove the power cord from the power outlet, and wait at least 45 minutes for the unit to cool. 2. Prepare a new lamp. 3. Check that the projector has cooled sufficiently, and gently turn it upside down. -
Page 31: Air Filter
Air Filter Maintenance The air filter should be cleaned as described below at intervals of approximately 100 hours. 1. Switch the projector power supply OFF, and remove the power cord from the power outlet. 2. Clean the air filter with a vacuum cleaner. CAUTION •... -
Page 32: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING OSD Message The messages as described below may appear on the screen at power ON. Take the appropriate measures when such messages appears. Table 9. OSD Messages Message Contents The lamp will reach the end of its life in 300 hours. CHANGE THE LAMP Power is switched OFF automatically when the lamp AFTER REPLACING LAMP,... -
Page 33: Indicators Message
Indicators Message The POWER indicator, LAMP indicator, and TEMP indicator are lit and blank as follows. Take the appropriate measures. Table 10. Indicators Message POWER LAMP TEMP Contents indicator indicator indicator Lights Turns off Turns off The Standby mode has been set. orange Blinks Turns off Turns off... -
Page 34: Symptom
Symptom Before requesting repair, check in accordance with the following chart. If the situation cannot be corrected, then contact your dealer. Table 11. Symptom Symptom Possible cause Remedy Page The main power switch is not Turn on the main power switch. turned on. -
Page 35: Specifications
SPECIFICATIONS SPECIFICATIONS Table 12. Specifications Item Specification Product name Liquid crystal projector Panel size 1.8 cm (0.7 type) Liquid crystal Drive system TFT active matrix panel Pixels 480,000 pixels (800 horizontal x 600 vertical) Lens Zoom lens F=2.0 ~ 2.3 f=18 ~ 21 mm Lamp 150 W UHB Speaker... -
Page 36: Warranty And After-Service
WARRANTY AND AFTER-SERVICE WARRANTY AND AFTER-SERVICE If a problem occurs with the equipment, first refer to the P.20 “TROUBLESHOOTING” section and run through the suggested checks. If this does not resolve the problem contact your dealer or service company. They will tell you what warranty condition is applied. ENGLISH-23... -
Page 38: Dimension Diagram
TECHNICAL TECHNICAL Dimension Diagram 52.5 Unit : mm 74.5 Signal Connector Pin Assignment 1. D-sub 15-pin Shrink Connector (RGB IN) Pin No Signal Pin No Signal Pin No Signal Video input Red RGB IN 1: SCL(DDC) Video input Green Ground RGB IN 2: - Video input Blue RGB OUT: -... -
Page 39: Example Of Computer Signal
Example of computer signal Resolution Display fH (kHz) fV (Hz) Rating Signal mode H × × V mode 720 × 400 37.9 85.0 VESA TEXT Zoom in 640 × 480 31.5 59.9 VESA VGA (60Hz) Zoom in 640 × 480 35.0 66.7 Mac13"mode... - Page 40 Initial set signals The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, refer to adjust the V.POSIT and H.POSIT of the menu. Back porch b Front porch d Back porch b Front porch d Display interval c...
- Page 41 Connection to the Mouse Control 1. PS/2, ADB or Serial Mouse (1) Turn off the projector and computer, and connect the two units with the appropriate cable. For PS/2 mouse control (for IBM and compatible), use the enclosed mouse cable. For others, consult your dealer.
- Page 42 ADB Mouse Projector Computer ( POWER ON ) CONTROL Terminal DATA Mouse jack D-sub 15-pin shrink jack Mini DIN 4-pin ! " # % & ' ! " # Serial Mouse Projector Computer CONTROL Terminal Mouse jack D-sub 15-pin shrink jack D-sub 9-pin SEL0...
-
Page 43: Communications Setting
RS-232C communication (1) Turn off the projector and computer power supplies and connect with the RS-232C cable. (2) Turn on the computer power supply and after the computer has started up, turn on the projector power supply. Projector Computer RS-232C jack D-sub 9-pin Control jack D-sub 15-pin shrink jack... - Page 44 Requesting projector status (Get command) (1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes) +‘00H’+‘00H’) from the computer to the projector. (2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer. Changing the projector settings (Set command) (1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) + setting code (2 bytes)) from the computer to the projector.
-
Page 45: Command Data Chart
Command data chart Command data Names Operation type Header Action Type Setting code BE EF 06 00 3B D3 01 00 00 30 00 00 Orange BE EF 06 00 AB D2 01 00 00 30 01 00 Green BE EF 06 00 5B D2 01 00... - Page 46 Command data chart Command data Names Operation type Header Action Type Setting code BE EF 06 00 7C D2 02 00 07 30 00 00 Magnify Increment BE EF 06 00 1A D2 04 00 07 30 00 00 Decrement BE EF 06 00 CB D3...
- Page 47 Command data chart Command data Names Operation type Header Action Type Setting code Normal BE EF 06 00 46 D3 01 00 02 20 00 00 Mute Mute BE EF 06 00 D6 D2 01 00 02 20 01 00 BE EF 06 00 75 D3...
- Page 48 Command data chart Command data Names Operation type Header Action Type Setting code BE EF 06 00 F1 72 02 00 01 22 00 00 Sharpness Increment BE EF 06 00 97 72 04 00 01 22 00 00 Decrement BE EF 06 00 46 73...
-
Page 49: Regulatory Notices
REGULATORY NOTICES REGULATORY NOTICES FCC Statement Warning WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 50 LEGAL INFORMATION FIVE-YEAR LIMITED WARRANTY This Dukane LCD projector is warranted to the original purchaser for a period of five (5) years from the original purchase date - in normal use and service - against defects in material and workmanship. DUKANE CORPORATION EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
