Summary of Contents for LaView USA 4-CH DVR
-
Page 1: Quick Start Guide
Quick Start Guide 4/8/16-CH DVR... -
Page 2: Install Hard Drive
4/8/16-CH DVR Quick Start Guide Install Hard Drive Notice: 1. Support one or two SATA hard disk drives. Please use manufacturer recommended hard disk drives for DVR. 2. Please disconnect the power before connecting to other devices. Do NOT hot plug in/out. -
Page 3: Rear Panel Instruction
4/8/16-CH DVR Quick Start Guide Index Name Function Sign DVR Logo Optional Indicators Power On, H D D / Network /Alarm/Recording Active Directional controls: Up/Down can jump up or down. Activates the digital input box to increase or decrease a number. Directional Left/Right: Switches screens keys... - Page 4 4/8/16-CH DVR Quick Start Guide Analog video signal （BNC） input jacks Video input Analog video/audio signal （BNC） output jacks Video/Audio Output Audio input Audio (RCA) input jacks VGA output port RJ45 network cable connector USB Ports USB 2.0 Ports for mouse & external device RS-485 Port A/B RS-485 port for P/T/Z (Pan/Tilt/Zoom) Connection Power input...
- Page 5 4/8/16-CH DVR Quick Start Guide Index Name Description Video input Composite video signal（CVBS）input interface. Audio input Audio input interface. HDMI HDMI output interface. VGA output interface. Video/Audio Composite video/audio signal（CVBS）output interface. output I/O Ports Alarm input/output, RS-485 interface. USB/Network USB2.0 and RJ-45 interface. Power input DC 12V.
-
Page 6: Startup And Shutdown
4/8/16-CH DVR Quick Start Guide Startup & Shutdown 3.1 Startup Step1: Connect to cameras and monitor. Step2: Connect to a power source. Step3: The device will boot and a power indicator will turn on Step4: A live view window will appear 3.2 Shutdown You can shut down the device by using the IR remote controller and mouse. -
Page 7: Login
4/8/16-CH DVR Quick Start Guide Login When the DVR successfully loads, you can login to the DVR. Press the Menu button. The Login dialogue box will appear where you will enter the username: admin and the password: 123456 Main menu setup Right click the mouse, or press Enter button on the front panel to enter into the Main Menu. -
Page 8: Recording Setup
4/8/16-CH DVR Quick Start Guide Recording Setup There are four kinds of record modes. You will need to install and format the HDD, and set all the record parameters before recording. Manual Recording A user can press REC button on the front panel after quitting system setup. Press the button again to stop recording. - Page 9 4/8/16-CH DVR Quick Start Guide 【Copy】: Copy one of channel’s configurations to another. 【Set】: Pop up the setting interface for one of the listed weekdays. Record Type: Set the recording time segments. There are up to six configurable time segments which can be selected for recording during each 24-hour period.
- Page 10 4/8/16-CH DVR Quick Start Guide 6.3 Motion Based Recording Motion detection based recording: when motion is detected, the camera will automatically trigger to begin recording Step1: Enter into Menu Record -> Record Plan tab. The setup steps for schedule for motion based recording are similar to normal schedule setup. You can refer to 6.2 Schedule recording for details.
- Page 11 4/8/16-CH DVR Quick Start Guide Step3: Click “Process” to set Period/ recording channel/PTZ activation etc. Click “Apply‟ a n d “O K ‟ to save settings. Step4: In the live view mode, right click the mouse, select “Record,” and it will bring you into Record Control interface. Select “Schedule” to start recording and select “Stop”...
- Page 12 4/8/16-CH DVR Quick Start Guide Playback In live view mode, right click the mouse button, select “Search,” click to enter into playback interface as shown below...
- Page 13 4/8/16-CH DVR Quick Start Guide Index Type Description Calendar Click a specific date to call up the recording. The list is upgraded automatically. Time Select recording search start and end time. Playback control: stop/play, pause, fast, slow, previous/next frame when in pause Play mode.
-
Page 14: Back Up
4/8/16-CH DVR Quick Start Guide Back up This unit supports backup by USB flash，DVD writer and USB HDD. Connect an external USB device to one of the USB ports to back up recordings from the DVR’s internal hard disk. Step1：Enter into Menu -> Storage -> Backup tab. Step2: Click “Detect”... -
Page 15: Remote Surveillance
4/8/16-CH DVR Quick Start Guide 9. Remote Surveillance In order to view the DVR from a network it must be connected to a LAN/WAN or internet. The network setup should be done accordingly. 9.1 Access DVR on LAN Step1: Please enter into Menu -> Configuration -> Network -> Base as shown below. - Page 16 4/8/16-CH DVR Quick Start Guide 9.2 Access DVR on WAN 1. Connect the DVR to internet through router or virtual server Step1: Please enter into Menu Configuration Network Base as shown above. Step2: Input IP address, Subnet, Gateway. If using DHCP, please enable DHCP in both the DVR and the router.
-
Page 17: Access Dvr By Uid (P2P)
4/8/16-CH DVR Quick Start Guide 9.3 Access DVR by UID (P2P) 1. Connect the DVR to internet Step1: Please enter into Menu -> Configuration -> Network -> Base as shown above. Step2: Input IP address, Subnet, Gateway. If using DHCP, please enable DHCP in both the DVR and the router. - Page 18 4/8/16-CH DVR Quick Start Guide P2P Web Operation Step1: Open IE browser, enter the P2P address (The IP address of the server PC, eg: http://www.vssweb.net), and log in. Step2: IE will download ActiveX automatically. Note: *If ActiveX cannot be downloaded，IE security level is high，please check and set the security settings.
