NOTICE OF INTENDED INSTALLATION AND USE
THE CAR SHOW MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH
IS NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE
THE INSTALLER OF THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS
IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION
OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO
CAR SHOW DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THAT MAY
CarShow
Multi-Media Navigation System Installation Guide
VEHICLE IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.
WORKING PROPERLY PRIOR TO DELIVERY OF THE VEHICLE.
VIOLATE STATE AND/OR FEDERAL LAW.
RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION AND/OR USE.
Do not proceed until process has been completed
Process must be carefully observed in order to reduce
CAUTION
the risk of damage to the accessory or vehicle
Process must be carefully observed in order to ensure a
Specific tools and equipment recommended for this
Observe safe practices, this process can be dangerous
TESTING and TROUBLESHOOTING
Content specific testing and troubleshooting points
STOP
Damage to the vehicle may occur
CAUTION
CRITICAL
quality installation
TOOLS and EQUIPMENT
process
SAFETY RISK
and there is a risk of personal injury
Copyright 2013 All Rights Reserved
Rev A
Advertisement
Related Manuals for Car Show Honda CS-CRV12 CRV
Summary of Contents for Car Show Honda CS-CRV12 CRV
- Page 1 OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO VIOLATE STATE AND/OR FEDERAL LAW. CAR SHOW DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION AND/OR USE.
-
Page 2: Preparing For The Installation
CarShow Installation Guide – Honda CRV PREPARING FOR THE INSTALLATION STEP Before you start, please read these critical steps below BEFORE YOU START THE INSTALLATION, READ THIS GUIDE! CHECK THE BATTERY Test the battery voltage to make sure it’s fully charged This only takes seconds and can save hours of troubleshooting later. - Page 3 CarShow Installation Guide – Honda CRV REMOVE THE FACTORY RADIO STEP You will need to remove multiple interior trim components prior to removing the factory radio. The following steps will help guide you through this process. Use panel pry tool to remove left hand side vent CAUTION assembly Use panel pry tool to remove right hand side vent...
- Page 4 CarShow Installation Guide – Honda CRV Carefully use panel pry tool to remove radio CAUTION Carefully unplug hazard switch assembly at top of radio CAUTION Carefully pull out factory radio. CAUTION Be sure to unplug all harnesses. Remove 2 phillips screws to remove hazard switch assembly from OEM radio.
-
Page 5: Electronic Control Unit
CarShow Installation Guide – Honda CRV CarShow System Assembly Instructions STEP This step will walk you through how to attach/connect vehicle-specific faceplate to Electronic Control Unit (ECU) Vehicle-specific face plate (shown at right) will need to be attached to ECU. This step will walk you through this simple process. -
Page 6: Mounting Screws
CarShow Installation Guide – Honda CRV Make sure alignment tabs are properly inserted into tabs from faceplate Faceplate/ECU Alignment Verify faceplate bracket screw holes are aligned to ECU mounting screw holes. Make sure 28-pin connector is tucked completely inside faceplate cavity as shown at right Mounting Screws Verify faceplate bracket screw holes are aligned to ECU mounting screw holes. - Page 7 CarShow Installation Guide – Honda CRV Re-install 2 phillips screws that were removed in Step 2 to mount OEM hazard switch to CarShow unit. Be sure to mount included mounting brackets to CarShow unit LOCATING REMOTE COMPONENTS STEP You will need to mount the GPS and Optional Satellite Radio Antennas on the exterior of the vehicle. And mount the iPod Interface Connector in the vehicle.
- Page 8 CarShow Installation Guide – Honda CRV Retaining OEM BT Steering Wheel Controls STEP ONLY This step is used on vehicles equipped with OEM Bluetooth. If your vehicle is not equipped with OEM BT skip to step 6. This step will walk you through how to retain the OEM BT Steering Wheel Controls. It is provided ONLY so BT SWC are retained.
- Page 9 CarShow Installation Guide – Honda CRV INSTALL THE CARSHOW NAVIGATION SYSTEM STEP You will need to prepare the CarShow Navigation System for installation in the vehicle. Connect the Power and GPS Harnesses The GPS Harness must be properly seated into connector. Also be sure steering wheel control connector is securely connected.
- Page 10 CarShow Installation Guide – Honda CRV ENABLE INSTALLER SETTINGS STEP You will need to select certain Installer setting based on any Optional Equipment that you may have installed Launch the Installer Setting Screen From any screen with the Menu Button, follow these steps to display the Installer Setting Screen: 1) From any Screen, select “Menu”...
- Page 11 CarShow Installation Guide – Honda CRV Select SATELLITE RADIO as the Source Troubleshooting 1) Confirm the antenna has unobstructed view of the sky 2) Confirm the antenna is located on the outside of the vehicle Select iPod as the Source Confirm iPod is communicating and playback is OK Troubleshooting 1) Confirm the harnesses are properly engaged...
- Page 12 CarShow Installation Guide – Honda CRV Select Reverse Camera Confirm the backup camera screen shows in reverse Troubleshooting 1) Confirm “Reverse Trigger” is set to ON in the Installer Settings 2) Confirm the Reverse Trigger wire is attached properly 3) Confirm the Camera is receiving 12VDC as required Verify CANBus Operation Verify Steering wheel control, Illumination and dimming functions operate properly...
- Page 13 CarShow Installation Guide – Honda CRV Harness Diagram Back Of CarShow Unit CarShow Copyright 2013 All Rights Reserved Installation Guide CS-CRV12-3 Page 13...
- Page 14 CarShow Installation Guide – Honda CRV CarShow Copyright 2013 All Rights Reserved Installation Guide CS-CRV12-3 Page 14...
