UDA-8705A Analog Utility Distribution Amplifier User Manual Part Number: UDA-8705A-OM Version: 1.1... - Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as a commitment by Sierra Video. Sierra Video assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
-
Page 3: Important Safety Instructions
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personnel injury and to prevent product damage. Products may require specific equipment, and /or installation procedures be carried out to satisfy certain regulatory compliance requirements. - Page 4 Operation of this equipment in a residential area is likely to cause harmful interference in which case users will be required to correct the interference at their own expense. Changes or modifications to this equipment not expressly approved by Sierra Video. could void the user’s authority to operate this equipment.
- Page 5 Environmental Information The equipment that you purchased required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Sierra Videoencourages you to use the appropriate take-back systems.
-
Page 7: Table Of Contents
Service Information In This Chapter ........................6-1 Troubleshooting Checklist ..................6-1 Power LED Conditions ..................... 6-2 Bootload Button ....................... 6-2 Warranty and Repair Policy..................6-2 Ordering Information UDA-8705A and Related Products ..................7-1 Contents • i UDA-8705A User Manual (Rev. 1.1) - Page 8 • Contents UDA-8705A User Manual (Rev. 1.1)
-
Page 9: Introduction
A Word of Thanks Congratulations on choosing the openGear UDA-8705A Analog Utility Distribution Amplifier. The UDA-8705A is part of a full line of Digital Products within the openGear Terminal Equipment family of products, backed by Sierra Video's experience in engineering and design expertise. -
Page 10: Functional Block Diagrams
Functional Block Diagrams This section includes functional block diagrams to illustrate the UDA-8705A functions including the looping feature. Figure 1. Simplified Block Diagram of UDA-8705A Functions Figure 2. Simplified Block Diagram of UDA-8705A with Looping Function 1-2 • Introduction UDA-8705A User Manual (Rev. 1.1) -
Page 11: Features
Features The following features make the UDA-8705A the best solution for general analog distribution: • 8 analog video outputs • DC Coupled • Wide adjustable gain range of ±3dB • Low distortion • Excellent isolation between outputs • Power to each card is individually fused •... - Page 12 1-4 • Introduction UDA-8705A User Manual (Rev. 1.1)
-
Page 13: Installation And Setup
Unpacking Unpack each UDA-8705A you received from the shipping container, and check the contents against the packing list to ensure that all items are included. If any items are missing or damaged, contact your openGear sales representative or Sierra Videodirectly. -
Page 14: Rear Module Installation (Optional)
8705) are required. Installing the Rear Module If you received a Rear Module with your UDA-8705A, you will need to install the module in your DFR-8300 series frame before you can install the UDA-8705A in the frame, or connect cables to the slot you have chosen for the UDA-8705A. -
Page 15: Board Installation
In the DFR-8310 series frames, the UDA-8705A occupies one slot and provides eight analog outputs. The input of the UDA-8705A can be terminated on the card depending on the rear module used. It is not necessary to terminate unused outputs. - Page 16 R2-8705 Rear Modules R2L-8705 Rear Modules Connections for the DFR-8320 Series Frames In the DFR-8320 series frames, the UDA-8705A may be used with the following Rear Modules: • R2-8705 Full Rear Module — Each card occupies two slots and provides eight outputs.
-
Page 17: User Controls
User Controls In This Chapter This chapter includes the following sections: • Jumper Locations • LEDs • Button Controls User Controls • 3-1 UDA-8705A User Manual (Rev. 1.1) -
Page 18: Jumper Locations
RV2 — Gain Adjustment The rotation of RV2 adjusts the Gain level of the UDA-8705A and provides a gain range of +/- 3dB. LEDs The following sections describe the UDA-8705A LEDs. Refer to Figure 8 for LED locations. -
Page 19: Button Controls
PWR (Power) LED The PWR LED indicates the overall operating status of the UDA-8705A. This LED displays the following conditions: • Green — The card is operating normally. • Flashing Green — The card requires a software upgrade. • Red — The card is not operational. Refer to the chapter, “Service Information” for details on this condition. - Page 20 3-4 • User Controls UDA-8705A User Manual (Rev. 1.1)
-
Page 21: Control And Monitoring
Control and Monitoring In This Chapter This section provides a detailed explanation on using remote control functions with your UDA-8705A. The following topics are discussed: • DashBoard Control System • SNMP Monitoring and Control DashBoard Control System The DashBoard Control System™ enables you to monitor and control openGear frames and controller cards from a computer. -
Page 22: Status Menus
720p 50 Signal Format 1080i 50 1080p 25 Indicates a video signal is Unknown Video present but is an unknown format Indicates an audio or other AES/Other analog signal is detected 4-2 • Control and Monitoring UDA-8705A User Manual (Rev. 1.1) -
Page 23: Snmp Monitoring And Control
UDA-8705A using Simple Network Management Protocol (SNMP), which is compatible with many third-party monitoring and control tools. Refer to your UDA-8705A Management Information Base (MIB) file for a breakdown of SNMP controls on this card. - Page 24 4-4 • Control and Monitoring UDA-8705A User Manual (Rev. 1.1)
-
Page 25: Specifications
Specifications In This Chapter This chapter includes the Technical Specifications for the UDA-8705A. Specifications • 5-1 UDA-8705A User Manual (Rev. 1.1) - Page 26 Field Rate Window Tile <0.1% Bandwidth -3dB @ 56MHz Typical Power Total Power Draw <1.5W *Looping only available with the R1L-8705 or R2L-8705 Rear Modules. Specifications are subject to change without notice 5-2 • Specifications UDA-8705A User Manual (Rev. 1.1)
-
Page 27: Service Information
Routine maintenance to this openGear product is not required. In the event of problems with your UDA-8705A, the following basic troubleshooting checklist may help identify the source of the problem. If the card still does not appear to be working properly after checking all possible causes, please contact your openGear products distributor, or the Technical Support department at the numbers listed under the “Contact Us”... -
Page 28: Power Led Conditions
Rear Module type and connections, or call Sierra Video Technical Support. Bootload Button In the unlikely event of a complete card failure, you may be instructed by a Sierra Video Technical Support specialist to perform a complete software reload on the UDA-8705A. Contact Sierra Video Technical Support for the latest software load for your card. - Page 29 In case any one or more of the provisions set forth herein shall be held to be invalid, illegal, or unenforceable in any respect, the validity, legality, and enforceability of the remaining provisions contained herein shall not in any way be affected or impaired thereby. Service Information • 6-3 UDA-8705A User Manual (Rev. 1.1)
- Page 30 UDA-8705A. If required, a temporary replacement module will be made available at a nominal charge. Any shipping costs incurred will be the responsibility of you, the customer. All products shipped to you from Sierra Video will be shipped collect.
- Page 31 Service Information • 6-5 UDA-8705A User Manual (Rev. 1.1)
-
Page 33: Ordering Information
Ordering Information UDA-8705A and Related Products Your UDA-8705A Analog Utility Distribution Amplifier is a part of the openGear family of products. Sierra Video offers a full line of openGear terminal equipment including distribution, conversion, monitoring, synchronizers, encoders, decoders, keyers, switchers, as well as analog audio and video products. - Page 35 After-hours Emergency 530-888-3195 530-478-1105 General Information Service @sierravideo.com E-MAIL Technical Support techsupport@sierravideo.com 104B New Mohawk Rd Sierra Video Nevada City, CA 95959 POSTAL SERVICE Sierra Video PO Box 2462 Grass Valley, CA 95945 Incorporated Visit Us Please visit us at our website for: •...
