Vista X/S3 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PLEASE READ
This manual is provided as a free service
by Projector.com.
We are in no way responsible for the
contents of the manual. We do not guarantee
its accuracy and we do not make any claim
of copyright. The copyright remains the
property of their respective owners.
ABOUT PROJECTOR.COM
Projector.com (http://www.projector.com) is
your review and buying guide resource for
DLP and LCD video projectors.
Visit the site to read the latest projector
news and reviews, read and comment on
projector specifications, download user
manuals and much more.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X/S3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vista X/S3

  • Page 1 PLEASE READ This manual is provided as a free service by Projector.com. We are in no way responsible for the contents of the manual. We do not guarantee its accuracy and we do not make any claim of copyright. The copyright remains the property of their respective owners.

  • Page 2: Table Of Contents

    Keypad Reference ................... B-1 Menu Tree......................C-1 Serial Communication Cables ................D-1 Throw Distance....................E-1 Optional Input Modules ................... F-1 NOTE: Due to continuing research, all information in this manual is subject to change without notice 54-017115-13P Software Version 2.1 (10/02) Roadster/Vista User's Manual...

  • Page 3: Introduction

    ◊ Brightness (ANSI lumens, ±10%): • Vista X3/S3 = 3000 • Roadster X4/S4 = 4000 (note: X4/S4 discontinued) • Vista X5/S5 = 5000, Roadster X6/S6 = 6000 (note: Vista S5 discontinued) • Roadster X9/S9 = 8500 ◊ Contrast Ratio • Vista X3/X5, Roadster X4/X6 = 300:1 ANSI, 500:1 full on/off •...

  • Page 4: Components

    = Standard MODELS and AVAILABILITY: The Roadster line and the Vista line both offer models differing in light output and/or image resolution. All combinations are documented in this manual, however the following models are no longer manufactured: Roadster X4 / S4 Vista S5 Whether the projector is under warranty or the warranty has expired, Christie’s...

  • Page 5: Installation & Setup

    AC. Use the line cord provided with the projector (see Section 5). Model AC Power Required X/S3 and X/S4 100-240 VAC, 50-60 Hz, max. 11.5 amps @ 100V X/S5 and X/S6 200-240 VAC, 50-60 Hz, max. 8.5 amps @ 200V X9/S9 200-240 VAC, 50-60 Hz, max.
  • Page 6 Section 3. Adjust Image (MOTORIZED MODELS) NOTE: Motorized lens controls are standard on Roadster models only. With the input image displayed, press Lens on any keypad. Figure 2.1. Motorized Lens Adjustments Roadster/Vista User’s Manual...

  • Page 7: Installation Considerations

    Christie Hoisting/Stacking Kit specially designed for the projector, as well as appropriate nylon webbed safety straps and rigging equipment. Never hoist a projector by its feet, handles or any other component (Figure 2.3). IMPORTANT It is recommended that you remove the lens before hoisting a projector. Roadster/Vista User’s Manual...
  • Page 8 Securely wrap hoisting cabling and safety straps around the whole projector. Attach to the proper Christie ceiling mount only–never suspend or “fly” this model. NOTE: Vista models cannot use the Christie Hoisting/Stacking Kit for hoisting into place. Stacking See Figure 2.4. A maximum of 2...
  • Page 9 Hoist with cabling and straps as described in Hoisting, above–make sure to use at least one safety strap on each projector in the stack. See Figure 2.5. WARNING Use Christie Hoisting/Stacking hardware only. Figure 2.5. Hoisting a Stack, Minimum Configuration (SHOWN INVERTED) Roadster/Vista User’s Manual...

  • Page 10: Installation Type

    Because of the low gain, flat screens are most effective when ambient lighting is reduced, although this difference may be negligible given the high brightness output from this projector. Figure 2.6. Audience Coverage with Flat Screen Roadster/Vista User’s Manual...

  • Page 11: Rear Screen Installations

    NOTE: With a few exceptions, sources with less than 1280 x 1024 resolution have a 4:3 aspect ratio. The normal aspect ratio for 1280 x 1024 sources is 5:4. Roadster/Vista User’s Manual...
  • Page 12 If you do have windows, make sure that window coverings are opaque and overlapping — some window coverings are designed to provide up to 100 percent blockage of outside light. Ideally, the material should have a matte finish. Roadster/Vista User’s Manual...
  • Page 13 • Keep the projector away from devices which radiate electromagnetic energy such as motors and transformers. Common sources of these are slide projectors, speakers, power amplifiers, elevators, etc. Roadster/Vista User’s Manual...

  • Page 14: Projector Position And Mounting

    NOTE: If your projector is tilted in relation to the screen, as is sometimes the case for large venues or elevated installations, throw distance still represents the smallest measurement between the screen and front feet. 2-10 Roadster/Vista User’s Manual...
  • Page 15 100% 4-7:1 130% 100% ✻ 4-7:1 114% 100% ✻ NOTE: VistaGRAPHX lens. Threaded lens adapter required. Motorized ZOOM feature is not available for VistaGRAPHX lenses. The 0.8:1 lens is not recommended for use in “S” models. 2-11 Roadster/Vista User’s Manual...
  • Page 16 INSTALLATION AND SETUP Figure 2.13. Maximum Vertical Offsets Continued… 2-12 Roadster/Vista User’s Manual...
  • Page 17 The maximum horizontal offset for lenses that can be installed in this projector is shown in Figure 2.14. This value expresses the maximum percentage of the image that can be projected to one side of the lens center (roughly 77%, depending on the lens). 2-13 Roadster/Vista User’s Manual...

  • Page 18: Special Mounting

    Figure 2.15. Horizontal and Vertical Tilt Ranges You must use the proper ceiling mount fixture or stacking kit for your projector. For more information, contact your dealer. 2-14 Roadster/Vista User’s Manual...

  • Page 19: Source Connections

    (audio is standard on Vista only). NOTES: 1) Audio connectors are standard on Vista models only. 2) For all connections to the projector, use only high-quality shielded cables. Figure 2.16. Rear Connector Panel 2-15 Roadster/Vista User’s Manual...
  • Page 20 Figure 2.17. Connecting RGB Input AUDIO for INPUT 1 To control audio levels in an audio/visual (STANDARD ON VISTA ONLY): “IN 1” system, connect pre-amplified (line level) audio inputs to the left and right channel audio inputs located near the top left corner of the rear input panel. Then “OUT”...
  • Page 21 INPUT 2 . Use the appropriate digital interface installed at AUDIO for INPUT 1 To control audio levels in an audio/visual (STANDARD ON VISTA ONLY): “IN 1” system, connect pre-amplified (line level) audio inputs to the left and right channel audio inputs located near the top left corner of the rear input panel. Then “OUT”...
  • Page 22 RCA phono jack at –do not use both as inputs. See Figure 2.19. AUDIO for INPUT 1 To control audio levels in an audio/visual (STANDARD ON VISTA ONLY): “IN 3” system, connect pre-amplified (line level) audio inputs to the left and right channel audio inputs located near the top left corner of the rear input panel.
  • Page 23 2.20. Figure 2.20. Connecting S-Video AUDIO for INPUT 1 To control audio levels in an audio/visual (STANDARD ON VISTA ONLY): “IN 4” system, connect pre-amplified (line level) audio inputs to the left and right channel audio inputs located near the top left corner of the rear input panel. Then “OUT”...
  • Page 24 BNC or the phono plug as input or output depends on the type of cable you have on hand and what type of connectors are on each end. If desired, connect one audio signal to any projector as usual (audio is standard on Vista models only). VIDEO TERMINATION: In Image Settings / Video Options control, make sure “Video...
  • Page 25 4-pin mini DIN or the 2 adjacent BNCs as input or output depends on the type of cable you have on hand and what type of connectors are on each end. If desired, connect one audio signal to any projector as usual (audio is standard on Vista models only).
  • Page 26 NOTES: 1) Audio ports on optional interfaces are non-functional. Use the IN 2 projector’s audio connectors labeled (standard on Vista only). 2) Optional digital interfaces cannot be used in a Marquee Case/Power Supply or Switcher. 3) INPUT 1 Connect analog HDTV signals directly to or to any “RBG”...
  • Page 27 #3 on switcher #1. Note that slots used in this manner on switcher #1 are no longer recognized as inputs to the projector–if you select a slot location that is connected to another switcher’s RGB output, the projector will display the “no input signal” error message. 2-23 Roadster/Vista User’s Manual...

  • Page 28: Power Connection

    To make small corrections to the projector's level, rotate each leg as necessary to raise or lower. For angled installations, see “Special Mounting” under 2.3, Projector Position and Mounting earlier in this section. 2-24 Roadster/Vista User’s Manual...

  • Page 29: Zoom, Focus & Lens Offset

    ENABLING ILS In the Lens Control menu, enable the “Intelligent Lens System” option (highlight it and press Enter ). This will add the 4 lens positions—focus, zoom, 2-25 Roadster/Vista User’s Manual...
  • Page 30 (1003, 1005, etc.) rather than switching to an even setting (1002, 1004, etc.). This technique will prevent the lens from reversing and settling in the backlash zone. 2-26 Roadster/Vista User’s Manual...

  • Page 31: Serial Port Connections

    (see Figure 2.27). Then set the projector baud rate to match that of the computer (changing the baud rate is described in 3.7, Configuring System Parameters. NOTE: Refer to Appendix D for complete cable wiring details. 2-27 Roadster/Vista User’s Manual...
  • Page 32 —these 6-pin XLR connector ports are located near the upper right corner of the projector's rear control panel (see Figure RS-422 2.28). Use an port only if your equipment has RS-422 capability—always first consult the documentation supplied with your equipment. 2-28 Roadster/Vista User’s Manual...
  • Page 33 RS-232 interface, first set them all to the same baud rate needed, then chain the RS-232 OUT projectors together by connecting the connector of the first projector RS-232 IN (already connected to the computer/controller) to the connector of the next projector in the chain. 2-29 Roadster/Vista User’s Manual...
  • Page 34 RS-422 PORT 2 projectors together by connecting the connector of the first projector RS-422 PORT 1 (already connected to the computer/controller) to the connector of the next projector in the chain. Figure 2.30. Adding Another Projector via RS-422 2-30 Roadster/Vista User’s Manual...
  • Page 35 NOTES: 1) To avoid damage, connect only properly wired serial communication cables. See Appendix D for details. 2) It is recommended that each RS-232 communication cable be no more than 25 feet in length. Use high quality cables. 2-31 Roadster/Vista User’s Manual...
  • Page 36 Then connect projectors together using both RS-232 and RS-422 ports as shown. Make sure the “Split Network” option is enabled in the Communications menu. Now, if either controller fails, you can simply switch to the other controller and communicate via the other standard. 2-32 Roadster/Vista User’s Manual...
  • Page 37 For complete information on how to assign projector numbers, see 3.7, Configuring System Parameters. NOTE: To loop a single incoming video source through to another projector or display device on a network, see Video Loop Through in 2.4, Source Connections. 2-33 Roadster/Vista User’s Manual...

  • Page 38: Keypad Protocols And Conversion

    The standard IR remote keypad or the optional wired remote can be set to one of two Protocol different protocols — “A” or “B”. To hard-wire a protocol to “A” or “B” in either — IR OR WIRED KEYPAD — remote, follow Steps 1 through 5: 2-34 Roadster/Vista User’s Manual...
  • Page 39 2 as shown. For the wired remote, make sure that the jumper is set between pins 2 and 3 as shown. Step 5 Replace battery compartment cover. Plug into projector (wired keypad only) and test. 2-35 Roadster/Vista User’s Manual...
  • Page 40 Use the projector's built-in keypad to access the Communications menu. Under “Front IR” or “Back IR” or "Wired Keypad", select the protocol that matches the new protocol of the keypad at hand. The projector should now respond properly. 2-36 Roadster/Vista User’s Manual...
  • Page 41 Unplug the keypad from the projector. • Open the keypad back and unplug the keypad cable. • Wait 1-2 minutes. • Install batteries (see Section 4). • Set keypad protocol as desired, using “IR” jumper settings. • Replace battery compartment cover. 2-37 Roadster/Vista User’s Manual...

  • Page 43: Operation

    99 different channels possible. Projector components and functions are illustrated below. Refer back to the chart on page 1-2 to determine what is available on each of the various models. Figure 3.1. Basic Projector Components Roadster/Vista User’s Manual...
  • Page 44 NOTE: Lamp replacement requires a qualified service technician. FILTER SIDE PANEL - Louvered grille for air intake. Remove to replace air filter. AUDIO IN/OUT (Vista) – For connecting pre-amplified (line level) audio. Standard on Vista models only. Roadster/Vista User’s Manual...
  • Page 45 See Section 5. Never unplug while the fans are running. Model AC Power Specifications X/S3 and X/S4 100-240 VAC, 50-60 Hz, max. 11.5 amps @ 100V X/S5 and X/S6 200-240 VAC, 50-60 Hz, max. 8.5 amps @ 200V X9/S9 200-240 VAC, 50-60 Hz, max.

  • Page 46: Using The Keypad

    The keypad appears in three locations: Using the • Keypad Built-in to the rear of the projector • Infrared (IR) Remote for tetherless control up to 100 feet away • Wired Remote (optional) tethered to the rear of the projector Roadster/Vista User’s Manual...
  • Page 47 (IR) transmitter. Use the IR remote keypad the same way you would use a remote keypad supplied with a TV or VCR. When making key presses, point the keypad either toward the screen or toward the front or rear of the Roadster/Vista User’s Manual...
  • Page 48 Never unplug the projector during this time, or as a shut down, as it can lead to premature lamp failure. 2) Avoid turning a projector back on until it has been off for a few minutes—hot re-strikes of the lamp may reduce lamp life. Roadster/Vista User’s Manual...
  • Page 49 Display Channel List option is selected in the Menu Preferences menu. You can choose to use a scrollable list of channels when you press Chan , or you may prefer to enter the desired channel number “blind”, i.e., without on-screen feedback. See Menu Preferences later in this section. Roadster/Vista User’s Manual...
  • Page 50 (in this case Power* ). Then immediately (within 2 seconds) press either as desired. The specific toggle will occur. Toggle keys are labeled with an asterisk on the keypad. They are listed below: Roadster/Vista User’s Manual...
  • Page 51 Adjusting the Image (Image Settings subsection). Volume Press to control the audio level (if connected). Use until you reach the desired volume. NOTE: Audio control is standard on Vista models only. In other models, the does nothing. Roadster/Vista User’s Manual...
  • Page 52 NOTES: 1) Requires a motorized lens. In non-motorized projectors, adjust the lens manually for proper focus, zoom and offsets as described on page 2-2. 2) For full details regarding motorized lens functions, refer to 2.8, Zoom, Focus and Lens Offset. 3-10 Roadster/Vista User’s Manual...
  • Page 53 Adjust the image clarity. If focus is not uniform throughout the image, bore sight is likely poor. Contact your dealer for service. ZOOM: Enlarge or shrink the image (note: requires a Roadster/Vista zoom lens). HORIZONTAL OFFSET: Shift the lens and image left or right. Note that slidebar values will not reach extremes of 0 or 9999.
  • Page 54 (useful if you are unsure of the present status). In either case, a small message appears on screen to signify mute status. NOTE: After early October 2000, audio control is standard on Vista models only. In models without audio, Mute* temporarily turns the current menu on/off.
  • Page 55 (which is "A or B") for one of the keypads. See section 2.10, Keypad Protocols and Conversion for complete instructions. 3-13 Roadster/Vista User’s Manual...

  • Page 56: Navigating The Menus

    From presentation level, press Help to access general Help Topics. Scroll as necessary within a topic. Press Exit to return to your presentation. At the bottom of some menus, a line of hint text also appears. 3-14 Roadster/Vista User’s Manual...
  • Page 57 (for continuous adjustment, hold down the desired arrow key). Or press Enter activate a slidebar text box for specific number entry via the keypad, then press Enter to save (or press Exit to cancel). 3-15 Roadster/Vista User’s Manual...
  • Page 58 Pull-down lists – To see a pull-down list of options available for a given parameter labeled with a ▼ , you can: • Highlight it and press Enter • Or enter the menu option number. 3-16 Roadster/Vista User’s Manual...
  • Page 59 ADD OR DELETE A CHARACTER OR SPACE: To insert a space at the cursor location, press Func . To delete a highlighted character (or space), press Func 3-17 Roadster/Vista User’s Manual...

  • Page 60: Using Inputs And Channels

    — is a quick and seamless way to display from one of the four inputs connected at the rear of the projector. Or, if your projector has a SWITCHER switcher connected to it at the port, press the general Input key and enter 3-18 Roadster/Vista User’s Manual...
  • Page 61 Input1 Input2 Input3 Input4 ), the existing channels in the projector are searched for matching input and signal parameters. If no match to the incoming input signal is found in the currently defined channels, a new 3-19 Roadster/Vista User’s Manual...
  • Page 62 See Editing a Channel Setup for details. 3-20 Roadster/Vista User’s Manual...
  • Page 63 Exit to cancel and return to the previous menu. Copying channels is a quick method for creating numerous channels, each of which can then be edited and adjusted for a variety of presentations in the future. 3-21 Roadster/Vista User’s Manual...
  • Page 64 CHANNEL EDIT — STEP 2 To edit parameters shown in the Channel Setup menu, select the relevant channel and press Enter . The Channel Edit menu will appear similar to the sample shown in Figure 3.13. 3-22 Roadster/Vista User’s Manual...
  • Page 65 Select this option to see or change Channel Edit settings for the previous channel in the Channel Setup list. • NEXT CHANNEL: Select this option to see or change Channel Edit settings for the next channel in the Channel Setup list. 3-23 Roadster/Vista User’s Manual...

  • Page 66: Adjusting The Image

    What an “Auto Setup” Does OPTIMIZES: SETS TO DEFAULT: Pixel Tracking Contrast & Brightness Pixel Phase Auto Input Level (off) Size Blanking Vertical Stretch Detail (if video source) Position Filter Input Levels Luma Delay (if analog source) 3-24 Roadster/Vista User’s Manual...
  • Page 67 A graphic image will resize to fill the screen, regardless of its original aspect ratio. For example, 1024 x 768 becomes 1280 x 1024 in “S” models. 3-25 Roadster/Vista User’s Manual...
  • Page 68 See right. NOTE: SXGA resolution shown. • Select “FULL WIDTH” to fill the display from left-to- right. Depending on the source, this may create top and bottom borders. 3-26 Roadster/Vista User’s Manual...

  • Page 69: Vertical Stretch

    Proper pixel tracking ensures that the image quality–whether good or poor– is consistent across the screen, that aspect ratio is correct, and that pixel phase can be optimized (below). 3-27 Roadster/Vista User’s Manual...
  • Page 70 5. Return Pixel Tracking to its correct setting from Step 1. 6. Readjust Phase. NOTE: “Filter” affects only the current signal. H-Position SHORT CUT: Press Position and adjust the top slidebar.) This option moves image right or left. 3-28 Roadster/Vista User’s Manual...
  • Page 71 NOTES: 1) Keystone is enabled for a source only if Size is 1000 and Size Vertical Stretch is 1,000,000. 2) Keystone adjustment is not available in “S” models. 3) Avoid using Keystone with Blanking. 3-29 Roadster/Vista User’s Manual...
  • Page 72 Start low and increase so that whites remain bright but are not distorted or tinted, and that light areas do not become white (i.e., are “crushed”). For best results, keep close to 50. 3-30 Roadster/Vista User’s Manual...

  • Page 73: Color Space

    (video). These signals can include: • RGB signals in NTSC, PAL, SECAM frequency ranges • Scan-doubled sync-on-green • Scan-quadrupled sync-on-green For these signals, change the Color Space to RGB, which will define a new channel for future use. 3-31 Roadster/Vista User’s Manual...
  • Page 74 Different curves can improve performance for certain kinds of source input and applications. Generally the best gamma curve is one that produces maximum contrast, brightness and color performance for the current signal and ambient lighting conditions. 3-32 Roadster/Vista User’s Manual...
  • Page 75 Color Setup menu as usual, regardless of your source or channel. Use of the Color Temperature Setup menu is described below. NOTE: For best results, use an internal grayscale test pattern when working with color temperature. Figure 3.17. Color Temperature Setup Menu 3-33 Roadster/Vista User’s Manual...
  • Page 76 This function can be particularly useful as a starting point for a new “User” color, or for accessing an unaltered factory default. It is disabled for all color temperatures except “User”. See Figure 3.18. Figure 3.18. “Copy From” 3-34 Roadster/Vista User’s Manual...

  • Page 77: Video Options

    (i.e., with dark gray appearing black) nor excessively elevated (i.e., with black appearing dark gray). By default, the projector automatically determines the correct setting according to the type of incoming video signal: 3-35 Roadster/Vista User’s Manual...

  • Page 78: Input Levels

    50 and that color temperature is properly set up on an internal grayscale test pattern. 3) There must be at least one white pixel present in the image for proper “Auto Input Level” function. Leave this control off. 3-36 Roadster/Vista User’s Manual...
  • Page 79 Alternatively, do not use “Auto”—reduce blacklevels manually instead. Judge by eye and change one or more of the six levels as necessary to obtain proper blacks and whites. You may want to see 3-37 Roadster/Vista User’s Manual...
  • Page 80 Adjustments are related, so you may have to go back and forth until both bands are just optimized. Repeat Steps 2-5 with the other two remaining primary colors. When each primary color shows one optimized black band and white band, the input levels 3-38 Roadster/Vista User’s Manual...
  • Page 81 Motion Filter setting is automatically determined according to the type of incoming source signal. However, if your source is noisy and/or inconsistent you may wish to “force” a setting to ensure stable processing for this source—if desired, override 3-39 Roadster/Vista User’s Manual...
  • Page 82 You can override this by selecting a value from 1-10, with “1” applying no filtering and “10” applying maximum filtering. High filtering levels will soften the image slightly, particularly evident along horizontal edges. 3-40 Roadster/Vista User’s Manual...

  • Page 83: Configuring System Parameters

    Channel Setup menu. This option also enables on-screen feedback when using the Input key. If you prefer to hide the channel list and input dialog box while switching channels and sources during a presentation, do not enter a checkmark. 3-41 Roadster/Vista User’s Manual...
  • Page 84 Use the options in the Color and Uniformity submenu to define color temperature, primary color hues and/or to achieve consistent brightness throughout all display areas. This submenu is typically used in multiple- projector applications that require precise matching 3-42 Roadster/Vista User’s Manual...

  • Page 85: Diagnostics And Calibration

    OPERATION between adjacent displays—for Roadster/Vista models, only Color Temp Setup is available. COLOR TEMP SETUP — See Image Settings. This function is offered in multiple menu locations for convenient access. Auto Power Up Enter a check mark to enable the projector to automatically power up after losing power due to a power failure or due to unplugging the projector during operation.
  • Page 86 NOTE: 1) The baud rate setting does not affect the switcher port, which is always 9600 baud. 2) See Serial Port Connections and Appendix D for more information about cable connections between devices. 3) On early models, the 2 highest baud rates are unavailable for downloading projector MAIN software. 3-44 Roadster/Vista User’s Manual...
  • Page 87 Instead, if you want to quickly change to the other protocol, you may find it more convenient to use one of the other keypads (the built-in keypad or the IR remote) to execute the protocol change for the wired keypad. The projector will now recognize 3-45 Roadster/Vista User’s Manual...

  • Page 88: Broadcast Key

    RS-232 to RS-422 anywhere in the network. Likewise, if you have two serial links connected between any two projectors, failure to use the Split Network checkbox can also cause a communication error. 3-46 Roadster/Vista User’s Manual...

  • Page 89: Working With The Lamp

    Enter a checkmark if you want to enable a warning message upon power-up that the lamp has reached the specified lamp limit and should be replaced. Delete the checkmark if you do not want to see this warning—instead, when your 3-47 Roadster/Vista User’s Manual...
  • Page 90 75A. During the first few hundred hours of life, the lamp arc gradually changes and voltage automatically increases until the lamp is utilizing the full 1700W. This self-adjusting behavior results in less “lamp drop-off” over time---images are brighter for a larger percentage of overall lamp life. 3-48 Roadster/Vista User’s Manual...
  • Page 91 Precise behavior with newly-installed lamps in X9/S9 is described in footnote 1 on the previous page. Because a new lamp in X9/S9 can emit maximum brightness without initially requiring maximum power, adjusting Power or Intensity slidebars beyond this point produces no additional light output. This is normal for these models. 3-49 Roadster/Vista User’s Manual...

  • Page 92: Projector Status

    (such as a rental period), and for your projector model name and serial number. In addition, the Status menu identifies the current channel, switcher, slot and frequencies. to see additional Status information. 3-50 Roadster/Vista User’s Manual...

  • Page 93: Using Multiple Projectors

    “Broadcast Keys” option unchecked and their keypads disabled (do this in the Configuration / Communications menu). The "Broadcast Keys" projector will then relay keypad commands to the other projectors. If using a wired remote, make 3-51 Roadster/Vista User’s Manual...
  • Page 94 PROJECTOR ROW AND PROJECTOR COLUMN – For each projector, use these two slidebars to define the projector’s unique row-and-column location within the videowall. Any videowall begins with the top left corner display as Row 1, Column 1. See Figure 3.30. 3-52 Roadster/Vista User’s Manual...
  • Page 95 HDTV signals. See right. NOTE FOR LARGE ARRAYS: 1) In large arrays having 3 or 4 rows, the center row(s) will automatically fill. 2) Screens with very little or no image will be blanked (cropped). 3-53 Roadster/Vista User’s Manual...

  • Page 96: Error Conditions

    “RS-232” option instead. To receive both notifications, select “All”. To disable error messages (except for invalid user entries), select “Off”. NOTE: Error messages also always appear at the rear LCD next to the keypad. 3-54 Roadster/Vista User’s Manual...
  • Page 97 A system warning message indicates that a system malfunction has been detected (see Status LED Codes, below). A system warning message replaces any input signal message and disappears when the input signal status changes. While the projector 3-55 Roadster/Vista User’s Manual...
  • Page 98 For example, a pattern of “yellow- yellow-red-red-red” is “Code 23”, meaning the lamp ballast (power supply) is overheated. These codes are listed in Table 3.3. 3-56 Roadster/Vista User’s Manual...
  • Page 99 Unable to program the video decoder (VDM) OPTIONAL INTERFACE MODULE Unable to program the option card If you encounter a system error, try resetting the projector by powering it off and on again (cooling if necessary). Contact dealer/factory if error persists. 3-57 Roadster/Vista User’s Manual...

  • Page 101: Maintenance

    Christie-approved ceiling mount fixture. A projector and cart combination should be used with care. Sudden stops, excessive force, and uneven surfaces may cause the projector and cart combination to overturn. Roadster/Vista User’s Manual...
  • Page 102 Before unplugging the power cord, make sure the internal lamp cooling fans have shut off. The fans automatically shut off when the projector has adequately cooled down. Slots and openings in the projector provide ventilation. To ensure Roadster/Vista User’s Manual...

  • Page 103: Cleaning

    The optional IR Remote Keypad uses four AA size, 1.5V batteries (preferably Replacing alkaline). To install new batteries, open the battery compartment at the back side of Keypad the keypad by pulling on the raised portion of the cover as shown (Figure 4.1). Batteries Roadster/Vista User’s Manual...

  • Page 104: Replacing The Lamp And Filter

    NOTE: Always wait a minute or two when replacing batteries so that the internal electronics discharge and can recognize the change. NOTE: For this procedure you will need the appropriate “Roadster / Vista / Mirage Replacing the Lamp and Filter Replacement Kit” manufactured by Christie.
  • Page 105 See Figure 4.3. Loosen the 2 screws fastening the lamp door shut. • Lift the door fully open (it will stay up on most models). Not shown: Air deflector on underside of X9/S9 lamp door. Do not remove. Figure 4.3. Open the lamp door Roadster/Vista User’s Manual...
  • Page 106 The lamp should now be fully free– refer to the recycling/disposal instructions provided with the new lamp. Figure 4.5. Detach lamp from terminal block (TOP VIEW) IMPORTANT Detach the lamp from the terminal block only. Do not disconnect cables. Roadster/Vista User’s Manual...
  • Page 107 Then push and turn each T-bolt 90° to lock. See Figure 4.7. Figure 4.7. Using the T-bolts (INVERT ILLUSTRATION FOR X9/S9 • Replace the side-mount air deflector if you had to remove it (X9/S9 only). Roadster/Vista User’s Manual...
  • Page 108 • Lower the panel slightly to clear two pins at the bottom edge of the projector. • Pull the panel off to expose the filter near the front corner. Figure 4.8. Remove the right side panel Roadster/Vista User’s Manual...

  • Page 109: Replacing The Lens

    For motorized zoom lenses, you may also need a remote keypad and flashlight. 2) “Top” or “bottom” references assume a non-inverted projector, as illustrated. 3) If you are installing a Vista lens, GRAPHX first make sure its “Vista...
  • Page 110 See below. Using both hands, rotate the lens barrel counterclockwise until the screw heads align with the larger end of their slots on the lens flange. PULL LENS OUT: Carefully pull the lens assembly straight out of the projector and set aside. 4-10 Roadster/Vista User’s Manual...
  • Page 111 See Figure 4.14. NOTE: For a motorized zoom lens, the rotation will skew the access holes away from the lens mount screws. Screws will still be accessible, however. 4-11 Roadster/Vista User’s Manual...

  • Page 112: 4.6 Troubleshooting

    IR signals. Ensure the keypad is directed at either the front or rear of the projector, or at the screen. Also make sure that these paths are not blocked. Try the built-in keypad. 4-12 Roadster/Vista User’s Manual...
  • Page 113 2. The projector probably became overheated (there is likely an error code flashing and a message in the LCD status window). Allow to cool and make sure that nothing blocks projector vents. Do not operate in environments warmer than 35°C (95°F). 4-13 Roadster/Vista User’s Manual...
  • Page 114 Motorized ZOOM does not work, or is limited… CAUSE / REMEDY: 1. Remote lens functions are standard with Roadster models only. 2. Motorized zoom function is not available for Vista zoom lenses 2.5-4:1 GRAPHX or 4-7:1, neither of which have a zoom gear, or fixed (non-zoom) lenses.
  • Page 115 4. The screen size may be too large. As screen size increases, magnification increases, reducing brightness and clarity. See lens specifications in Section 5. 5. The source input signal may be of low quality. Try another source. 4-15 Roadster/Vista User’s Manual...
  • Page 116 NOTE: If your projector has a motorized lens mount and cannot power-up due to an expired lamp or power supply problem, the motorized functions must be disabled and then vertical offset adjusted manually. Contact your dealer or the manufacturer. 4-16 Roadster/Vista User’s Manual...

  • Page 117: Specifications

    S e c t i o n 5 Specifications NOTES: 1) Due to continuing research, specifications are subject to change without notice. 2) Specifications Specifications apply to all models unless otherwise noted. 3) Roadster X4/ S4 and Vista S5 All Roadster are no longer manufactured. All Vista...
  • Page 118 • Bi-level or tri-level composite Polarity ** Positive or negative Not applicable for sync-on-green Audio (NOTE: STANDARD ON VISTA MODELS ONLY) Number & type of inputs 4 pairs of phono plug Nominal input and output level 1.0 V DC offset ±...
  • Page 119 450-700 watts Adjustment range for X5/S5 and X6/S6 800-1200 watts Adjustment range for X9/S9 1200-1700 watts Operating angle any vertical angle, ±15° horizontal Warm up period to full brightness 5 minutes Rated life 1000 hours to half intensity Roadster/Vista User’s Manual...

  • Page 120: Operating Environment

    Temperature -25°C to 55°C (-22°F to 120°F) Humidity (non-condensing) 0% to 95% Standard Components IR (infrared) Remote Keypad — includes batteries High current AC line cord User’s Manual 9/64” hex socket ball driver 4 Eyebolts (Roadster only) Roadster/Vista User’s Manual...
  • Page 121 (NOTE: v1.2 or higher TWC required for CoRE v1.4 or higher) IR Remote Sensor Alternate Throw Lenses (see page 5-1) Roadster Hoisting/Stacking Kit Universal Ceiling Mount (includes Roadster / Vista adapter) CoRE Librarian for downloading new software Threaded lens adapter/flange for installing Vista lenses GRAPHX...

  • Page 123: Glossary

    Backlash Zone The extra travel distance required for accurate lens mount positions in a Roadster, Vista or Mirage projector having a motorized lens mount. Bandwidth The frequency range of the projector's video amplifier.
  • Page 124 (also known as field rate) is one half of vertical frequency. Foot-candle The intensity of visible light per square foot. Foot-lambert The luminance (brightness) which results from one foot-candle of illumination falling on a perfectly diffuse surface. Roadster/Vista User’s Manual...
  • Page 125 When light from a projector is incident on a screen, the light reflects from the screen such that the angle of reflection equals the angle of incidence. The Line of Best Viewing is along the line of reflection. Roadster/Vista User’s Manual...
  • Page 126 Resolution (lens) The maximum number of alternate white and black horizontal lines that can be distinguished on a screen when a photographic target is placed between the lens and a light source and illuminated by that source. Roadster/Vista User’s Manual...
  • Page 127 This term refers to the part of the video signal that is used to stabilize the picture. Sync can occur in three forms: "Composite sync": the horizontal and vertical components are together on one cable. "Sync-on-green": the sync is part of the green video. Roadster/Vista User’s Manual...
  • Page 128 A high-end analog component video signal. Sometimes called YUV, Component, or Y, R-Y, B-Y, the YPbPr signal by-passes the video decoder in this projector. See YPbPr. Zoom The adjustment of image size by means of a zoom lens. Roadster/Vista User’s Manual...

  • Page 129: Keypad Reference

    A p p e n d i x B Keypad Reference Figure B-1. Keypad Roadster/Vista User’s Manual...

  • Page 131: Menu Tree

    A p p e n d i x C Menu Tree Roadster/Vista User’s Manual...
  • Page 132 MENU TREE Roadster/Vista User’s Manual...

  • Page 133: Serial Communication Cables

    A p p e n d i x D Serial Communication Cables Vista When connecting a Roadster and/or projector to a computer, another projector, or a Marquee Signal Switcher, use the appropriate serial communication shielded cabling as illustrated. Roadster/Vista User’s Manual...
  • Page 134 SERIAL COMMUNICATION CABLES Roadster/Vista User’s Manual...
  • Page 135 SERIAL COMMUNICATION CABLES Roadster/Vista User’s Manual...
  • Page 136 SERIAL COMMUNICATION CABLES Roadster/Vista User’s Manual...

  • Page 137: Throw Distance

    Min: 3.93 x screen width (↔ ft.) + .66 10-40 (VistaGRAPHX) Max: 6.85 x screen width (↔ ft.) + .51 NOTES: 1) Make sure to use HORIZONTAL screen size in all formulas. 2) The 0.8:1 lens is not recommended for use in “S” models. Roadster/Vista User’s Manual...
  • Page 138 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 139 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 140 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 141 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 142 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 143 THROW DISTANCE Roadster/Vista User’s Manual...
  • Page 144 THROW DISTANCE Roadster/Vista User’s Manual...

  • Page 145: Optional Input Modules

    RGB500 Input Module The RGB500 Input Module may be installed in this projector, a Marquee Signal 38-804606-xx Switcher, or a Marquee Case/Power Supply. The module receives analog RGB input signals from computers or other RGB source devices. Roadster/Vista User’s Manual...
  • Page 146 BNC connectors for RGB signal inputs NOTE: The audio connectors are not functional. Connect audio to the projector’s audio port, if available (standard on Vista models only). RGB400BA Input Module The RGB400 Buffered Amplifier Input Module may be installed in this projector, in a 38-804610-xx Marquee Signal Switcher or in a Marquee Case/Power Supply.
  • Page 147 Connect audio to the projector’s audio port, if available (standard on Vista models only). 3) For use with this projector, do not connect both composite video and S-video signals to the Composite / S-Video Input Module– connect one or the other, even when plugged into a switcher.
  • Page 148 20-bit 4:2:2 component signal (10 bits each for Y and CbCr) ◊ SMPTE 292M compatible ◊ Two data rates: 1.485 Gb/sec or 1.485/1.001 Gb/sec. ◊ SERIAL IN SERIAL OUT provides both a and a BNC connector ◊ includes 4 status LEDs Roadster/Vista User’s Manual...
  • Page 149 LEDs for signal and error IN 2 NOTE: Connect audio to the projector’s audio port, if available (standard on Vista models only).. Marquee The Marquee Case/Power Supply enables you to use an analog input module as a Case/Power Supply stand-alone interface.
  • Page 151 Display Channel List, 3-41 Channel Edit Menu, 3-22 Display Error Messages, 3-42 Channel Key, 3-7, 3-19 Display Slidebars, 3-42 Channel Selection, 3-20 DVI / DFP Input Module, 3-30 Channel Setup Menu, 3-20 And Enter Key, 3-21 INDEX-1 Roadster/Vista User’s Manual...
  • Page 152 Troubleshooting, 4-14 Mode, 3-48 Image Adjustments, 3-24 Recording Serial Number, 3-50 Image Orientation, 2-24, 3-41 Specifications, 5-3 Image Settings, 3-30 Lamp Counter, 4-4 InMenu Checkbox, 3-23 Lamp History, 3-50 Input Lamp Hours, 3-47 Connection, 2-1, 2-15 INDEX-2 Roadster/Vista User’s Manual...
  • Page 153 Resetting, 3-4, 3-56 Menu Preferences Menu, 3-41 Service, 4-3 Menu System, Navigation, 3-24 Ventilation, 2-9, 4-2 Minimum Delay, 3-39 Protocols, 2-34, 3-45 Motion Filter, 3-39 Changing, 2-34 Motorized Lens Functions, 2-25, 3-10 Changing in Projector, 3-45 INDEX-3 Roadster/Vista User’s Manual...
  • Page 154 YPbPr, 3-31 Status LEDs, 3-3 Connecting, 2-17 Status Menu, 3-50 S-Video Connecting, 2-19 Extra, 2-22 Zoom, 2-2, 2-25, 3-2 Loop Through, 2-21 Troubleshooting for Motorized, 4-14 Switcher, 3-23, 3-44 Switcher Connection, 2-23 Sync Def. and types, 5 INDEX-4 Roadster/Vista User’s Manual...
  • Page 155 PLEASE READ This manual is provided as a free service by Projector.com. We are in no way responsible for the contents of the manual. We do not guarantee its accuracy and we do not make any claim of copyright. The copyright remains the property of their respective owners.
