Samsung N64D Service Manual

Chassis: n64d
Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE
TFT-LCD TV
LN40B550K1
Refer to the service manual in the GSPN (see the rear cover) for the more information.
LCD-TV
Chassis
: N64D
Model
: LN40B550K1H
LN52B550K1H
Manual
1. Precautions
5. Exploded View & Part List

Contents

Advertisement

Table of Contents
loading

Related Manuals for Samsung N64D

Summary of Contents for Samsung N64D

  • Page 1: Service Manual

    LCD-TV Chassis : N64D Model : LN40B550K1H LN52B550K1H SERVICE Manual TFT-LCD TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Exploded View & Part List 6. Wiring Diagram LN40B550K1 Refer to the service manual in the GSPN (see the rear cover) for the more information.

  • Page 2: Table Of Contents

    Contents 1. Precautions ......................1-1 1-1. Safety Precautions ......................1-1 1-2. Servicing Precautions ..................... 1-2 1-3. Electrostatically Sensitive Devices (ESD) Precautions ..........1-2 1-4. Installation Precautions ....................1-3 2. Product specifications .................... 2-1 2-1. Feature & Specifications ....................2-1 2-2. Specification Comparison to Old Models ................ 2-5 2-3.
  • Page 3 GSPN (Global Service Partner Network) Area Web Site North America http://service.samsungportal.com Latin America http://latin.samsungportal.com http://cis.samsungportal.com Europe http://europe.samsungportal.com China http://china.samsungportal.com Asia http://asia.samsungportal.com Mideast & Africa http://mea.samsungportal.com © 2009 Samsung Electronics Co.,Ltd. This Service Manual is a property of Samsung Electronics Co.,Ltd. All rights reserved. Any unauthorized use of Manual can be punished under applicable Printed in Korea International and/or domestic law. P/N: BN82-00656A-00...

  • Page 4: Disassembly And Reassembly

    3. Disassembly and Reassembly 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LN40B550K1 LCD TV. WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components. 3-1. Disassembly and Reassembly Cautions: 1.
  • Page 5 3. Disassembly and Reassembly Description Picture Description Screws 4. Remove the 4 screws of the main board. 5. Remove the 5 screws of the IP board. (40”) Remove the 7 screws of the IP board. (52”) (40”) (52”)
  • Page 6 3. Disassembly and Reassembly Description Picture Description Screws 6. Remove the 2 screws of the sub SMPS. 7. Remove the left and right speaker. 8. Remove the 6 screws of bottom bracket stand link. 9. Remove 2 screws.
  • Page 7 3. Disassembly and Reassembly Description Picture Description Screws 10. Remove the top 2 bracket screws and brackets. 11. Lift up the bracket stand link.(panel’s BKLT) 12. Lift up the panel. Reassembly procedures are in the reverse order of disassembly procedures. ※...

  • Page 8: Ln40B550K1H Exploded View

    5. Exploded View & Part List 5. Exploded View & Part List 5-1. LN40B550K1H Exploded View...

  • Page 9: Ln40B550K1H Parts List

    5. Exploded View & Part List 5-1-1. LN40B550K1H Parts List Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark T0003 BN96-09668N ASSY COVER P-FRONT;LB550 40,UO(HOTEL),PC M0215 BN07-00661A LCD-PANEL;V400H1-L05 M0215 BN81-02390A A/S-T CON V400H1-L05;V400H1-L05 M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 S.N.A M0115 BN61-04918A BRACKET-STAND LINK;40, B610,SECC,T1.6 S.N.A...

  • Page 10: Ln52B550K1H Exploded View

    5. Exploded View & Part List 5-2. LN52B550K1H Exploded View...

  • Page 11: Ln52B550K1H Parts List

    5. Exploded View & Part List 5-2-1. LN52B550K1H Parts List Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark T0003 BN96-09670J ASSY COVER P-FRONT;LB550 52,UO(HOTEL),PC M0215 BN07-00678B LCD-PANEL;LTF520HB07 T0101 BN61-04817A BRACKET-WALL;46, B610,SECC,T1.6 S.N.A M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 S.N.A M0115 BN61-04788A BRACKET-STAND LINK;46, B610,SECC,T2.0 S.N.A...

  • Page 12: Ln40B550K1H Parts List

    5. Exploded View & Part List 5-3. LN40B550K1H Parts List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark LN40B550K1HXZA LN40B550K1H,N64D/40BK1-G5K,40,LCD-TV,UNI M0001 BN90-01959N ASSY COVER FRONT;LB550 40 S.N.A T0175 BN96-09463C ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:60 T0003 BN96-09668N ASSY COVER P-FRONT;LB550 40,UO(HOTEL),PC ...3...
  • Page 13 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.002 S.N.A ...3 T0920 BN61-05118A GUIDE-STAND;40,LB550,PC+GF(20%) V0,BLK S.N.A ...3 BN61-05185A HOLDER-SWIVEL RING TOP;40,ACETAL,NATURAL S.N.A ...3 BN63-05231A COVER-STAND,SUB;40,LB550,ABS+PMMA,HB,BK2 S.N.A ...3 BN63-05571A COVER-STAND GLASS;37,40 B550,GLASS,T8.0, S.N.A ...3...
  • Page 14 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 D916 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D919 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D923 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D951_5 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D952_5 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D101 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 S.N.A ..4...
  • Page 15 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 IC104 0801-002378 IC-CMOS LOGIC;74VHC04,INVERTER,SOP,14P,8 S.N.A ..4 IC106 1001-001567 IC-VIDEO SWITCH;TMDS361,TQFP,64P,9x9mm,3 ..4 IC803 1006-001266 IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P, ..4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm ..4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm ..4 IC112...
  • Page 16 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 D921 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D922 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D925 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D950_5 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 HD804 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 HD805 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 HD806...
  • Page 17 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R608 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R610 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R612 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R735 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R812 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 18 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R917 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R921 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R922 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R937 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R954_5 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 19 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 HR801 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 S.N.A ..4 HR805 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 S.N.A ..4 R652 2007-000159 R-CHIP;56Kohm,5%,1/16W,TP,1005 S.N.A ..4 HR166 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 S.N.A ..4 HR167 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 20 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R378 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R379 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R380 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R383 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R386 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 21 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R149 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R401 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R473 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R605 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R950 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 22 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R416 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 ..4 R619 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 ..4 R620 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 ..4 R327 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, S.N.A ..4 R330 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, S.N.A ..4 R453 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32...
  • Page 23 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C443 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 C444 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 HC441 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 HC442 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 C741 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 ..4 C742 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 ..4 C743...
  • Page 24 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C733 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 S.N.A ..4 C734 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 S.N.A ..4 C817 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 ..4 C1029 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 S.N.A ..4 C1030 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 S.N.A ..4 C1031...
  • Page 25 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C139 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C144 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C147 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C148 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C149 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4...
  • Page 26 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C458 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C459 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C460 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C461 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C462 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4...
  • Page 27 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C628 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C629 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C630 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C631 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C633 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4...
  • Page 28 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C528 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C561 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C562 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C563 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C565 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C567 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C568...
  • Page 29 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568...
  • Page 30 ...3 BN96-10788A ASSY ACCESSORY-PREVENT;32,LB650,nylon66 S.N.A ...3 T0059 BN68-02178A MANUAL FLYER-CARD;COMM,SAMSUNG,eng/spa/c S.N.A ...3 BN68-02226C MANUAL FLYER-QSG;B550,SAMSUNG,ENG/SPA,US S.N.A ...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,10 L S.N.A M0113 BN92-04300H ASSY P/MATERIAL;LB550 40 (UO) S.N.A T0524 6902-001043 BAG PE;HDPE/NITRON,T0.015/T0.5,W1200,L80 S.N.A T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g S.N.A T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M,...

  • Page 31: Ln52B550K1H Parts List

    5. Exploded View & Part List 5-4. LN52B550K1H Parts List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark LN52B550K1H,N64D/52BK1-G5K,52,LCD-TV,UNI M0001 BN90-01961P ASSY COVER FRONT;LB550 52 S.N.A T0175 BN96-09463D ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:70 T0003 BN96-09670J ASSY COVER P-FRONT;LB550 52,UO(HOTEL),PC ...3...
  • Page 32 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...3 T0920 BN61-05120A GUIDE-STAND;46,LB550,PC+GF(20%) V0,BLK S.N.A ...3 BN63-05232A COVER-STAND,SUB;46,LB550,ABS+PMMA,HB,BK2 S.N.A ...3 BN63-05636A COVER-STAND GLASS;52 B550,GLASS,T8.0,BLK S.N.A ...3 M0126 BN73-00215A RUBBER-FOOT;40LB650,RUBBER,15*25,60,4.0, S.N.A ...3 CCM1 BN63-04755D COVER-SHEET;PE,T0.05,W520mm,200M,600FE,C 0.83...
  • Page 33 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 D913 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D914 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D915 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D916 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D919 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D923 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO ..4 D951_5...
  • Page 34 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0..4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 ..4 IC104 0801-002378 IC-CMOS LOGIC;74VHC04,INVERTER,SOP,14P,8 S.N.A ..4 IC106 1001-001567 IC-VIDEO SWITCH;TMDS361,TQFP,64P,9x9mm,3 ..4 IC803 1006-001266...
  • Page 35 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 D908 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D910 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D911 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D921 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D922 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D925 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP ..4 D950_5...
  • Page 36 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R508 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R601 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R607 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R608 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4 R610 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 37 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R874 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R876 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R910 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R917 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4 R921 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 38 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R923 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 S.N.A ..4 R924 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 S.N.A ..4 R959_5 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 S.N.A ..4 HR801 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 S.N.A ..4 HR805 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 39 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R375 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R376 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R377 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R378 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4 R379 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 S.N.A ..4...
  • Page 40 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R606 2007-000755 R-CHIP;330Kohm,1%,1/10W,TP,1608 ..4 R124 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R148 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R149 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R401 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 S.N.A ..4 R473...
  • Page 41 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 R949 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 S.N.A ..4 R115 2007-008593 R-CHIP;750ohm,1%,1/16W,TP,1005 ..4 ZR000 2007-008720 R-CHIP;4.7ohm,1%,1/4W,TP,3216 S.N.A ..4 R416 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 ..4 R619 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 ..4 R620 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32...
  • Page 42 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C179 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 ..4 C180 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 ..4 C119 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 C443 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 C444 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 HC441 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 ..4 HC442...
  • Page 43 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C735 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 S.N.A ..4 C736 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,1608 S.N.A ..4 C438 2203-001724 C-CER,CHIP;4700nF,+80-20%,16V,Y5V,TP,321 S.N.A ..4 C733 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 S.N.A ..4 C734 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 S.N.A ..4...
  • Page 44 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C127 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C134 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C138 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C139 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4 C144 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 S.N.A ..4...
  • Page 45 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C440 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C456 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C457 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C458 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C459 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4...
  • Page 46 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C622 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C624 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C626 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C628 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4 C629 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 S.N.A ..4...
  • Page 47 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 C464 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C509 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C526 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C528 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C561 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C562 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 ..4 C563...
  • Page 48 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..4 T0568 3301-001236 BEAD-SMD;60ohm,1608 S.N.A ..4 T0568 3301-001236 BEAD-SMD;60ohm,1608 S.N.A ..4 T0568 3301-001236 BEAD-SMD;60ohm,1608 S.N.A ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz ..4 T0568 3301-001404...
  • Page 49 TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, S.N.A T0527 6902-000621 BAG SHEET;HDPE/NITRON,T0.015/T1,W1000,L2 S.N.A M0019 BN92-04995A ASSY LABEL;LA40B550K1HXXT S.N.A M0045 BN92-05032E ASSY ACCESSORY;LN52B550K1HXZA S.N.A BN68-01402E MANUAL FLYER-STAND GUIDE;32”,SAMSUNG,Eng S.N.A M0045 BN96-09871A ASSY ACCESSORY;LN52B550K1HXZA ...3 T0268 3903-000144 CBF-POWER CORD;DT,US,BP3/Y,U(IEC C13-RA) ...3 T0524 6902-000018 BAG PE;LDPE,T0.1,W280,L400,CLEAR,8,2,20. S.N.A ...3 AA68-03242L MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun...
  • Page 50 5. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...3 BN68-02226C MANUAL FLYER-QSG;B550,SAMSUNG,ENG/SPA,US S.N.A ...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,10 L S.N.A 5-43...

  • Page 51: Safety Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing, and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify any circuitry. 1-1-2. Servicing the LCD TV When servicing the LCD TV, Disconnect the AC line cord from the AC outlet.

  • Page 52: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions WARNING: An electrolytic capacitor installed with the wrong polarity might explode. Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 53: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than two people are required for carrying the product. 2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. 3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 54: Product Specifications

    2. Product specifications 2. Product specifications 2-1. Feature & Specifications Model LN40B550K1H Feature Digital-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0(Media Play), D-SUB � Brightness : 500cd/m � Contrast Ratio : 70000:1 � Response time : 6.5ms � Specifications Item Description LCD Panel 40inch HD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic)
  • Page 55 2. Product specifications Model LN52B550K1H Feature Digital-TV, RF, 4-HDMI, 2-Component, 2-A/V, 1-USB2.0(Media Play), D-SUB � Brightness : 500cd/m � Contrast Ratio : 70000:1 � Response time : 6.5ms � Specifications Item Description LCD Panel 52inch HD 60Hz Scanning Frequency Horizontal : 60 kHz ~ 73 kHz (Automatic) Vertical : 40 Hz ~ 75 Hz (Automatic) Display Colors 16.7 million colors...
  • Page 56 2. Product specifications CHANNEL FREQUENCY TABLE OUTPUT FREQUENCY : ANALOG fv:45.75MHz, fs:41.25MHz DIGITAL Fc:44MHz TUNING STEP SIZE : FIRST PLL 250KHz SECOND PLL 62.5KHz OSD CH NO CH NO CH NO CH NO Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC 72.
  • Page 57 2. Product specifications OSD CH NO CH NO CH NO CH NO Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC 499.25 ULTRA 498.00 499.25 505.25 ULTRA 504.00 505.25 511.25 ULTRA 510.00 511.25 517.25 ULTRA 516.00 517.25 523.25 ULTRA 522.00 523.25 529.25...

  • Page 58: Specification Comparison To Old Models

    2. Product specifications 2-2. Specification Comparison to Old Models Model LN40B550K1H LN40A650A1H Design Display Type LCD TV LCD TV Built-in Tuner Resolution 1920 x 1080 1920 x 1080 LCD Panel TFT LCD Panel 60Hz TFT LCD Panel 60Hz Screen Size 40”/ 52”...

  • Page 59: Accessories

    2. Product specifications 2-3. Accessories Product Description Code. No Remark Remote Control & Batteries BN59-00899A (AAA x 2) Power Cord 3903-000144 Screw 6002-001294 (for the stand - M4, M16) Cover-Bottom BN63-05327A Owner’s Instructions BN68-01569B Cleaning Cloth BN63-01798A OCC : BN39-00865B NXTV : BN39-01011B Data cable nStreams : BN39-01110A...

  • Page 60: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting Check the various cable connections first. • Check to see if there is a burnt or damaged cable. • Check to see if there is a disconnected or loose cable connection. • Check to see if the cables are connected according to the connection diagram. IP Board SUB SMPS Main Board...
  • Page 61 4. Troubleshooting 4-1-1. No Power Symptom The unit is dead. No led’s on the front cover light up. Check the following: Check the internal cable connection status inside the unit. Major checkpoints Check the fuses of each part. Check the output voltage of SMPS. 40”...
  • Page 62 4. Troubleshooting 1.9V B12V B13V B3.3V...

  • Page 63: No Video (Analog Pc Signal)

    4. Troubleshooting 4-1-2. No Video (Analog PC signal) Symptom No video with PC source. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set in the Lamp(Backlight) on, no video ‘Stand-by mode’...
  • Page 64 4. Troubleshooting Pin #34,35 Pin #16,17 TP67 TP69 TP71 TP70 TP72...
  • Page 65 4. Troubleshooting WAVEFORMS PC input (V-sink , H-sink , R/G/B ) LVDS output...
  • Page 66 4. Troubleshooting 4-1-3. No video (HDMI - Digital signal) Symptom No video with HDMI input. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set Lamp(Backlight) on, no video in the ‘Stand-by mode’.
  • Page 67 4. Troubleshooting Pin#7 Pin#12 Pin #34,35 Pin #16,17...
  • Page 68 4. Troubleshooting WAVEFORMS HDMI input (RX_Data, RX_Clk) LVDS output...
  • Page 69 4. Troubleshooting 4-1-4. No Video (Tuner_CVBS) Symptom No video with a tuner source. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set Lamp(Backlight) on, no video in the ‘Stand-by mode’.
  • Page 70 4. Troubleshooting Pin #17 Pin #16 Pin #8 Pin #4 Pin #2 4-11...
  • Page 71 4. Troubleshooting WAVEFORMS CVBS OUT (Grey Bar) LVDS output 4-12...
  • Page 72 4. Troubleshooting 4-1-5. No Video (Tuner DTV) Symptom No video on Tuner input. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set Lamp(Backlight) on, no video in the ‘Stand-by mode’.
  • Page 73 4. Troubleshooting Pin #34,35 Pin #16,17 Pin #4 Pin #2 4-14...
  • Page 74 4. Troubleshooting WAVEFORMS LVDS output 4-15...
  • Page 75 4. Troubleshooting 4-1-6. No Video (Video CVBS) Symptom No video with CVBS. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set Lamp(Backlight) on, no video in the ‘Stand-by mode’.
  • Page 76 4. Troubleshooting Pin #34,35 Pin #16,17 V3CVBS COMY 4-17...
  • Page 77 4. Troubleshooting WAVEFORMS CVBS OUT (Grey Bar) LVDS output 4-18...
  • Page 78 4. Troubleshooting 4-1-7. No Video (Component) Symptom No video on component input. Check your source on the TV. Major Check your source content. checkpoints Check all connections. 40” 52” Power indicator LED is off. Check a set Lamp(Backlight) on, no video in the ‘Stand-by mode’.
  • Page 79 4. Troubleshooting Pin #34,35 Pin #16,17 COMY COMPB COMPC 4-20...
  • Page 80 4. Troubleshooting WAVEFORMS Compnent_Y (Gray scale) / Pb / Pr (Color bar) LVDS output 4-21...

  • Page 81: No Sound

    4. Troubleshooting 4-1-8. No Sound Symptom No audio. Check your audio level setting. Check your internal mute setting. Major checkpoints Check your source content. Check all connections. 40” 52” Check the source and Input the sound source properly. check the connection of sound cable (Comp/PC/DVI to HDMI)? Does the sound data appear at Check CN707,CN805,CN704,CN904...
  • Page 82 4. Troubleshooting R416 B3.3V B12V TP_915 V2SR TP_916 V2SL TP_L-,L+,R-,R+ COMSL COMSR 4-23...
  • Page 83 4. Troubleshooting WAVEFORMS I2C Data Speaker out 4-24...

  • Page 84: Alignments And Adjustments

    4. Troubleshooting 4-2. Alignments and Adjustments 4-2-1. General Alignment Instuction Usually, a color LCD-TV needs only slight adjustment upon installation. Use the specified test equipment or its equivalent. Correct impedance matching is essential. Avoid overload. Excessive signal from a sweep generator might overload the front-end of the TV.

  • Page 85: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1 How to Access Service Mode Using the Customer Remote Turn the power off and set to stand-by mode Press the remote buttons in this order; MUTE-1-8-2-POWER ON to turn the set on. The set turns on and enters service mode. This may take approximately 20 seconds. If you fail to enter service mode, repeat steps 1 and 2 above, press the Power button to exit and store data in memory.

  • Page 86: Factory Data

    40D6AF0C / 46A6AF0C / 46L6AF0C / 46D6AF0C / 52A6AF0C / 52L6AF0C / NONE Model LB450/LB457 TUNER ALPS ALPS/Xugang/SECCustom Region SAMSUNG SAMSUNG / Etron Light Effect On / Off Exhibition On / Off Mode ADC/WB Factory Name ADC Tarhet ADC RESULT...
  • Page 87 4. Troubleshooting Mode ADC RESULT Factory Name Range HDMI / DTV / AV / RF Component HDMI-PC 1st_AV_Gain 0 ~ 255 1st_AV_Offset 0 ~ 255 1st_Comp_Gain 0 ~ 255 1st_Comp_Gain_Cb 0 ~ 255 1st_Comp_Gain_Cr 0 ~ 255 1st_Comp_Offset 0 ~ 255 1st_Comp_Offset_Cb 0 ~ 255 1st_Comp_Offset_Cr...
  • Page 88 4. Troubleshooting Factory Name Control EDID Sub Option PDP Option Hotel Option Shop Option Sound Config Option Test Pattern Factory Name Data Range EDID EDID ON/OFF On / Off EDID WRITE ALL Success Success / Failure EDID WRITE PC Success Success / Failure EDID WRITE DVI Success...
  • Page 89 4. Troubleshooting Factory Name Data Range Sub Option Mute Time(VIDEO) 0 ~ 10 ready Failure Success / Failure Hotplug On / Off Hotplugcontrol On / Off Spread Spectrum Auto Power On / Off Arab On / Off NT Conversion On / Off Mirror On / Off HDMI EQ1...
  • Page 90 4. Troubleshooting Spread Spectrum Factory Name Data Range Spread Spectrum On / Off Period 40K / 50K / 60K Amplitude 0 / 0.5 / 1 / 1.5 / 2 DDR Spread 2% Spread Off / 1% Spread / 2% Spread Factory Name Data Range...
  • Page 91 4. Troubleshooting Shop Option Factory Name Data Range Shop Mode On / Off USB DEMO ON (SEC) USB DEMO OFF (SEC) Sound Factory Name Data Range Saturation Mute M Prescale A2K Prescale BTSC Mono Prescale BTSC Stereo Prescale SAP Prescale CH1 BW CH2 BW Num of Check...
  • Page 92 4. Troubleshooting Factory Name Advanced WB Movie EPA Standard ADJUST YC_Delay SHARPNESS PQ Others Color Space EEPROM RESET Factory Name Data Range Movie WB Movie On / Off Color Mode Dynamic / Standard / Movie Color Tone Cool / Normal / Warm1 / Warm2 Msub Brigh 0 ~ 255 Msub Contr...
  • Page 93 4. Troubleshooting EPA Standard Factory Name Data Range Std Contr 0 ~ 100 Std Bright 0 ~ 100 Std Sharp 0 ~ 100 Std Color 0 ~ 100 Std Tint 0 ~ 100 Std Backlight 0 ~ 10 Factory Name Data Range ADJUST...
  • Page 94 4. Troubleshooting SHARPNESS Data Factory Data Range component HDMI Name CVBS (720p) (720p) (720p) H1 Gain H2 Gain H3 Gain H4 Gain V1 Gain V2 Gain H overshoot V overshoot H undershoot V undershoot Coring TH2 Coring TH1 SHARPNESS Data Range Comp/HDMI/ PC / HDMI...
  • Page 95 4. Troubleshooting PQ Others Factory Name Data Range 7.5 IRE NTSC On / Off 7.5 IRE 0 ~ 60 Comp SD COMP HD Comp SD COMP HD Color HDMI SD HDMI HD HDMI SD HDMI HD HDMI Range Space Factory DTV SD DTV HD DTV SD...

  • Page 96: Hotel Interactive Mode

    Hotel Mode - On : Hotel TV Stand-alone or Interactive - Off : Retail TV Select the SI Vendor SI Vendor SAMSUNG SAMSUNG/OCC/MTI/NSTREAMS/DAW/Magilink/NXTV/Enseo Power On Chanel TV will switch on to this particular Channel Power on Band Channel search STD and AIR (for NTSC model) Power on source Select the Input source when TV is turned on initially.
  • Page 97 4. Troubleshooting interactive hotel ITEM Description initial Value Selection of the way to update clock data - Auto: Use clock data from server Local Time Manual - Manual: manual clock setting (without updating from TTX data) - TTX: manual clock setting (with updating from TTX data) Time Format 12 Hour Select time exprression method(12H/24H)

  • Page 98: Stand Alone Hotel Mode

    4. Troubleshooting 4-5. Stand Alone Hotel Mode 4-5-1. Entering Stand Alone Hotel Mode Under power on condition, MUTE + 1 + 1 + 9 + ENTER 4-5-2. Stand Alone Hotel Mode Data interactive hotel ITEM Description initial Value Hotel mode on/off Hotel Mode - On : Hotel TV Stand-alone or Interactive - Off : Retail TV...
  • Page 99 4. Troubleshooting interactive hotel ITEM Description initial Value Time Format 12 Hour Select time exprression method(12H/24H) PMOLED Test To test PMOLED itself (brightness and pixel) PMOLED Normal PMOLED brightness selection Dimming PMOLED StandBy PMOLED STY-BY brightness selection Dimming The interactive or stand alone Hotel TV options in the OSD when Clone Htl Menu Standalone pressing the Hotel key on the clone remote control.

  • Page 100: White Balance - Calibration

    4. Troubleshooting 4-6. White Balance - Calibration 4-6-1 White Balance -Calibration 1. Calibration AV Calibration Comp Calibration PC Calibration HDMI Calibration 4-6-2 Service Adjustment - You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration ...
  • Page 101 4. Troubleshooting Method of Color Calibration (AV)  1) Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port 2) Press the Source key to switch to “AV1” mode 3) Enter Service mode 4) Select the “Calibration” menu 5) Select the “AV Calibration”...

  • Page 102: White Ratio (Balance) Adjustment

    4. Troubleshooting 4-6-3 White Balance - Adjustment (low light) (hight light) Sub Bright Sub Contrast 3. W/B R offset R gain G offset G gain B offset B gain (W/B adjustment Condition refer next page) 4-7. White Ratio (Balance) Adjustment You can adjust the white ratio in factory mode (1:Calibration, 3:White-Balance).

  • Page 103: Servicing Information

    4-8. Servicing Information 4-8-1 USB Download Method Samsung may offer upgrades for TV’s firmware in the future. Please contact the Samsung call center at 1-800- SAMSUNG (726-7864) to receive information about downloading upgrades and using a USB drive. Upgrades will be possible by connecting a USB drive to the USB port located on your TV.
  • Page 104 Hotel Plug & Play is a function that automatically performs the Hotel mode selection, Country Setup, Clock Setup and Picture mode Setup once, when power is first turned ON, after a Service Reset is executed. - Samsung IR Signal Format - Initial ID code which is transmitted is fixed as 0.
  • Page 105 4. Troubleshooting Hotel Plug & Play OSD - Initial Highlight: Hotel Plug & Play. - Display time: 10 seconds. - If Exit key is selected or OSD display time out of 10 seconds occurs, Standalone hotel mode is set by default and “Standalone mode is set”...
  • Page 106 Interactive : When TV is powered-up initially it sends command to identify SBB/STB, if identified TV switches to ONLINE mode and full control is through SBB/STB. In ONLINE TV stops receiving IR(Samsung remote) commands and acts according to interface protocol.
  • Page 107 4. Troubleshooting Connecting the TV with STB (SBB) Connect the [DATA] jack of the TV to the [ETH MODEM] jack of the STB(SBB) with the Data cable. - Use data communication. Connect the [Class 2 Wiring 12V DC/1.5A] jack of the TV to the [DC-POWER] jack of the STB (SBB) with the DC cable.
  • Page 108 4. Troubleshooting SI Vendor Calibration BN39-00865B NXTV BN39-01011B nStreams BN39-01110A LodgeNet BN39-01011C MPEG4 BN39-00865B 4-49...
  • Page 109 4. Troubleshooting Connecting the Bathroom Speakers You can connect the Bathroom Speakers in one of the following 2 methods. Connecting through the Variable Output (available without an external amplifier) Connect the VARIABLE AUDIO [R-AUDIO-L] port of the TV to the Bathroom Wall Speakers of the hotel. Connect the [VOL-CTRL] jack of the TV to the Volume Control Box Switch port of the Bathroom Wall of the hotel.
  • Page 110 4. Troubleshooting Installing the Volume Control - If you configure the Volume Control Box as shown by the figure, you can control the volume of bathroom speakers. - The jack that is connected from the Volume Control Box to the TV is a normal Phone jack. - Volume Control Box switch consists of Tact switch.
  • Page 111 4. Troubleshooting Connect through the Fixed Output (available without an external amplifier) Connect the AUDIO OUT port of the TV and the Audio In port of the audio amplifier with a stereo cable. 4-52...
  • Page 112 Connect the [HDMI] port of the TV and the HDMI port of the RJP. Connect the EX-LINK port of the TV and the RS/232 port of the RJP. - The RJP (Remote Jack Pack) compatible with this Samsung TV is TeleAdapt TA-7610. 4-53...
  • Page 113 4. Troubleshooting RJP(Remote Jack Pack) RJP stands for Remote Jack Pack. The RJP is a hardware module that has different Audio Video inputs (A/V, S-Video, Audio, PC and HDMI) and corresponding outputs. The corresponding output sources are connected from RJP to TV. The RJP communicates with the TV via RS232.

  • Page 114: Wiring Diagram

    6. Wiring Diagram 6. Wiring Diagram 6-1. Wiring Diagram 6-1-1. Wiring Diagram 40”...
  • Page 115 6. Wiring Diagram 6-1-2. Wiring Diagram 52”...
  • Page 116 6. Wiring Diagram FCN402 (LVDS Connector) CN904(HDMI1 input) CN1(PC Sound input) EVEN[0]- HDMI1_RX2+ 12 PC_SR_IN HDMI1_RX2- PC_SL_IN HDMI1_RX1+ 15 PC_SL_IN ODD[3]+ PC_SL_IN ODD[3]- HDMI1_RX1- PC_SR_IN LVDS opt HDMI1_RX0+ 18 PC_SR_IN SDA_Panel ODDCLK+ W/P(T_Con) ODDCLK- HDMI1_RX0- CN102(Speaker) HDMI1_RXCLK+ SDA_Panel ODD[2]+ SCL_Panel ODD[2]- ODD[1]+ CN902(HDMI2 input)
  • Page 117 6. Wiring Diagram CN802(HDMI4 input) CN903(PC D-Sub input) CN702 (Function/IR Connector) HDMI4_RX2+ 12 PC_RED KEY_1 KEY_2 PC_GREEN HDMI4_RX2- PC_BLUE HDMI4_RX1+ 15 LED_INDICATOR BUZZER LED_Control HDMI4_RX1- CN105 (SBB Power supply) HDMI4_RX0+ 18 HDMI4_RX0- PC_5V HDMI4_RXCLK+ PC_IDENT EMU_SDA PC_H_SYNC PC_V_SYNC EMU_SCL...

  • Page 118: Cables

    6. Wiring Diagram 6-2. Cables Main IP (30P) Main - TCON IP - BalanceBD (7P) 40”BN39-01099V (800mm) 40”BN96-10075A (350mm) 52”BN39-00830B (200mm)) Code 52”BN39-01099U (700mm) 52”BN96-10074A (450mm) Photo IP - BalanceBD(L) (2P) IP - BalanceBD(R) (2P) IP-SUB SMPS (3P) 52”BN39-01021D (1200mm) 52”BN39-01024A (350mm) 40”BN39-00618M(250mm) Code...
  • Page 119 6. Wiring Diagram Memo...

This manual is also suitable for:
