- Page 1 QRS MUSIC TECHNOLOGIES, INC. PMII Installa on Manual (51074) QRS PNOma on Manual Revision: July, 2013 QRS Music Technologies, Inc. 269 Quaker Drive Seneca, PA 16346 (814) 676‐6683 www.qrsmusic.com...
-
Page 2: Table Of Contents
Installing the Steinway Sostenuto Assembly [Special Order Part # 70897] 26‐27 Moun ng and Connec ng the Electronic Components Electronic Components ‐ Descrip on 28‐29 Power Supply / Driver Board PMII Processor / Pin‐Light Extension (PLx) / Wi‐Fi Device / Powered Speaker Component Loca on ‐ Grand and Upright 30 Mount & Connect: Power Supply / Processor / Wi‐Fi / Speaker / PNOscan II(Record) 31 Mount & Connect the PLx 32 Mount the Key Solenoid Rail / Mount & Connect the Driver Boards ... -
Page 3: Introduc On
July 2013 Introduc on QRS is pleased that you have chosen the QRS PNOma on II™ Retrofit Kit, the superb retrofit kit for automa ng acous c pianos. This product brings a level of excellence in reproducing live performances on the piano. It is made possible by many remarkable technical innova ons. However, in spite of its high level of sophis ca on, this retrofit kit is easy to install and service. Before beginning the installa on, take me to read “Make Certain the Kit Fits,” to ensure that the piano will indeed accept the kit. This kit will NOT fit into a spinet piano. Familiarize your‐ self with the parts in the kit before proceeding and then let the instruc ons guide you. ... -
Page 4: Parts List
79232 1 Wi‐Fi Device w/Power Adapter and Ethernet Cable 82797 1 Owners Pack Out 70388 4 AAA Ba eries 73398 1 PMII Big Bu on Remote 71009 1 Split Loom Tubing 71010 3 Clamp, R Cable (7/8” Black) 70253 1 Owners Warranty Registra on Card 60205 ... - Page 5 Parts List Upright Kit ‐ Item #815022 [Without Record Op on] Item #2 Item #3 Item #4 QTY Descrip on 76040 1 QRS Amplified Speaker 81502 1 PMII Kit ‐ Upright 80124 8012406 1 PMII PLP x Pin Light Extension (PLx) 50128 2 Cable: 1/8” Male to 1/8” Male ‐ 6.5’ ...
-
Page 6: Make Certain That The Kit Will Fit
July 2013 Introduc on Make Certain that the Kit will Fit! All kits play 80 notes, excluding the first and last 4 keys of the standard piano keyboard. The following ques ons should be asked before beginning an installa on: 1. Is it a grand or upright piano? The kit will not fit into a spinet piano. 2. Is the keybed made of wood or a wood‐veneered laminate? ... -
Page 7: Piano Ac On Regula On
July 2013 Introduc on Piano Ac on Regula on This discussion is not intended to be a complete course on grand ac on regula on, but rather may prove helpful in restoring the ac on to proper performance. Proper alignment of ac on parts, and key easing are all very important steps in the regula on procedure. The following procedure assumes that this preliminary work has been checked and performed as necessary. Before removing the ac on from the ac on cavity, evaluate ac on regula on. If the ac on is not well regulated, proper perfor‐ mance of the system cannot be expected. During the installa on process of the PNOma on II Player System, it is quite possible that ac on regula on will be directly affected. A por on of the keyframe and back rail cloth will be removed so that the note solenoid plungers can contact the keytails. This opera on may cause the keytails to be lower than their original posi on. The result of lower key tails is an increase in both key height, and hammer strike distance. Restoring the strike distance to specifica ons by turning out the capstan screws is not the proper remedy. Always re‐work the back rail height so that the key height is at its original posi on. ‐ Are the keys level? ‐ Do the hammers let off 1/8 in the bass, tapering to 1/16 in the high treble? ‐ Is the drop 1/16 below the point of let‐off? ... -
Page 8: Installa On Procedure
5. Special upright driver board moun ng brackets are required for moun ng the driver boards to the solenoid rail. These brackets are 3” long and will allow the driver board and chassis to hang below the solenoid rail when completed. 6. SPECIAL NOTE**** If the driver boards are mounted upside down, you can reverse the playing order of the notes by selec ng “Invert Keybed” in the “Playback Parameters” sec on of PMII. 7. The power supply and the processor board are mounted inside the cabinet of the piano in any place convenient to the installer. Make sure the electrical cables do not interfere with any of the mechanical levers within the piano. 8. It is necessary to cut a 1” hole directly through the soundboard of the piano towards the bo om of the piano at the end where the power supply is mounted. This will allow the main power plug to easily be plugged into a wall outlet. This hole will not affect the sound of the piano in any way. ... - Page 9 July 2013 Installa on Procedure ...Upright Piano Installa on ‐ Recommenda ons Twin Speakers for Upright Installa on # 76047 Mount two brackets. One on each side of each speaker . Use two screws per bracket. Attach brackets to piano.
-
Page 10: Preparing The Key Solenoid Rail
July 2013 Installa on Procedure Preparing the Key Solenoid Rail In this chapter, we determine the throw of the key solenoid plunger in rela on to the piano ac on’s key‐tail travel. We also walk through the process of key solenoid alignment with respect to the piano ac ons keytails. When this chapter’s ... -
Page 11: Key Solenoid Plunger Throw
July 2013 Installa on Procedure ...Key Solenoid Plunger Throw Plunger Tip-Felt Plunger Stem Key Solenoid Solenoid Cap Plunger Body Used to adjust Plunger Throw Step 3. Hold the plunger in its "ON‐HOLD" posi on. This On‐Hold posi on is where the TOP of the Plunger Body is flush with the top of the solenoid. ... -
Page 12: Key Solenoid Rail Assembly - Solenoid To Key Alignment
July 2013 Installa on Procedure Key Solenoid Rail Assembly ‐ Solenoid to Key Alignment With the piano ac on on your workbench and the fronts of the keys facing away from you. Place the solenoid rail on the workbench in front of the keytails and put the plungers inside the solenoids. Turn the solenoid rail assembly on its side, so that the plungers are now parallel to the workbench surface and the felt plunger ps are touching the back ends of the piano keys. The first plunger should start all the way to the le side of the rail. Secure the rail and ac on with the two clamps so they will not move during the alignment process. Mark which side is bass and treble. Make sure all the solenoid plates are free moving. If they are not, use an 11/32” nut driver to loosen them. The spacing between sec ons has been held in check by the introduc on of solenoid assembly pairs adjacent to the breaks. Because not all sec ons on a piano will have an even number of notes played in them, those which have an odd number will require a modified solenoid assembly to provide the addi onal note required, and this modified note will be placed adjacent to a sec on break or at either end. Count the number of keys to be played in each sec on. If there is an even number, align the solenoids with plungers already on the rail with the centers of their respec ve key tails. If the number of keys to be played is odd, simply re‐ move one of the solenoids from the double moun ng bracket and con nue to the alignment of the next sec on. If necessary, cut away the unused por on of the rail ends with a hack saw and file off all burrs with a metal file. Be ... -
Page 13: Modifying The Keyframe - Grand [Perform A Pnoscan Ii Record Installa On Here]
July 2013 Installa on Procedure Modifying the Keyframe ‐ Grand... If you are installing a QRS PNOscan II record system you should incorporate it’s installa on while modifying the pi‐ ano ac on. The PNOscan II has it’s own installa on manual. ... - Page 14 July 2013 Installa on Procedure ...Modifying the Keyframe ‐ Grand... The key frame must now be cut. Remove all keys. With a jig saw, follow the pencil line and cut away the frame in each sec on between the breaks. With the palm sander, clean up all the rough edges. The ac on is now ready to be used to locate the posi ons of the slots through the piano's keybed. Place the keyframe into the grand piano case and secure it with the right and le cheek blocks. With a short, sharp pencil, reach into the keyboard compartment and mark the notched rear most limits of the keyframe, including the right and le extremes of each notch. These lines will be used to iden fy the exact loca ons of the keybed slots on the underside of the keybed, so be certain to make well‐defined pencil lines. ...
- Page 15 July 2013 Installa on Procedure ...Modifying the Keyframe ‐ Grand 1-3/4” to 2” slot 1/4” Treb Bass Lyre Back edge of the keyframe drawn on the top of the keybed. Ends of the sot. Lines transferred from the top of the keybed.
-
Page 16: Cu Ng The Keybed Slot
July 2013 Installa on Procedure Cu ng the Keybed Slot... Tools needed for this chapter include a circular saw (sabre saw with a sufficiently long blade/ router may be used), a power drill with a sharp 1‐3/4" Forstner bit (or wood boring bit), various screwdrivers, a frame square, a pencil, a tape measure, and paint that matches the underside of the piano. At this point the piano is on its legs, the ac on is outside of the piano case and has been modified to allow the key tails to protrude over the rear of the key frame by 1‐1/4". Felts are a ached to the undersides of each key tail, and the original trapwork is s ll in place. Next, have an assistant press the sustain pedal. While he depresses it, measure the distance the pedal lyre li rod moves and write it ... - Page 17 July 2013 Installa on Procedure ...Cu ng the Keybed Slot Taking into account any varia ons in the contour of the front of the piano and using the frame square aligned with the mark just made on the front underside of the keybed, measure and mark the depth measurement on the underside of the keybed. Next, measure 1/4" toward the front of the piano scribing a straight line between the bass and treble notes. Then measure 1‐3/4" toward the rear of the piano from the newly scribed line. Whenever possible we recom‐ mend keeping in the breaks. Each slot should be at least 1‐3/4" wide (2” Maximum). The longitudinal center of each slot must correspond to the center line of the felt padded key tails, which is 1/2" in from the end of each key. Verify the marks just made. Drill a small exploratory hole within each slot and compare the posi on of the slot with the ...
-
Page 18: Installing The So -Shi Lever
July 2013 Installa on Procedure Installing the So ‐Shi Lever The So Shi (una corda) pedal mechanism usually includes a long, cast‐iron bell crank lever whose short arm pro‐ trudes though the keybed to engage a groove cut in the bo om of the keyframe somewhere beneath the treble sec‐ on. The shi pedal in this configura on does not have to pass through the solenoid rail and, therefore, may o en be le untouched. However, on some pianos you may have to move the so shi toward the front of the piano to accom‐ modate for the width of the rail. For the pianos that need modifica on, brackets have been included in the kit for easy readjustment. It is a good idea to leave one of the original wooden blocks a aching the so shi lever to the key bed, and only use one of the brackets supplied. -
Page 19: Installing The Sustain Pedal Trapwork
July 2013 Installa on Procedure Installing the Sustain Pedal Trapwork... General Recommenda ons When you are at the point where you are ready to start removing the original trapwork system from the piano we rec‐ ommend that you trace around the trap components before you actually remove them. This is just a good reference should you have ques ons about leverage, stroke or placement a er you have removed everything. You should also trace around anything else you will be removing such as the piano legs. It is normally a good idea to install the new trap components (except for the Sostenuto) a er you install the solenoid rail because there is only one correct place the rail can be installed, where as the trap components are somewhat flexi‐ ble in their placement. The first is deciding if you need to mill any areas of the keybed besides the rail slot itself. The most likely places that would require special milling would be to mill a recess for the Sostenuto actuator assembly so it can be mounted above the solenoid rail. Another case would be to mill a pocket in the keybed to accommodate the up most posi on of the so shi lever such as on a Steinway. You might be milling a slot perpendicular to the solenoid slot to fit a bridge support if you can’t leave one when you cut the main slot. Depending on the situa on you may need to drill a new hole for the sustain dowel. It is important to realize these possibili es before you cut the slot. You don’t want to cut the slot, clean up the mess and install the solenoid rail just to find out you need to cut more material to accommodate a piece of the trap hardware! Once you have the slot laid out on the bo om of the keybed (we recommend using a soap stone or med p grease pencil), it will be much easier to conceptualize how you will configure the trap system. With the lines drawn exactly where the slot will be cut, you will be able to tell what obstacles will need to be moves, modified or worked around. ... - Page 20 July 2013 Installa on Procedure ...Installing the Sustain Pedal Trapwork 1 Draw a Straight line between the sustain hole in the keybed, lyre sustain push rod and the Pedal Solenoid. 2 Place the trapwork on the keybed so that it follows that line 3 Fasten the trapwork to the keybed with the 4, 3 1/2” screws provided. 4 Screw the locking nylon nuts onto the #8 Damper Tray Push Rod so that it supports the damper tray. Screw the 2 #8 nuts with a washer on the other end. 5 Insert the #8 Damper Tray Push rod onto the Damper Tray. 6 Align the #8 Damper Tray Push Rod with the predrilled hole in the Trapwork Straight Bar. Put the Nylon Collar in that hole. 7 Place felt or leather on the Adjustable Lyre Rod Lever where the sustain push rod makes contact with the Adjustable Lyre Rod Lever. 8 Adjust the Lyre Rod Lever un l it reaches over the lyres sustain push rod. 9 Adjust the 2 #8 Nuts so that the dampers fall to a full rest on the strings 10 Tighten the nuts a er all the lost mo on is out. 11 Notch the Solenoid Rail cover where the Trapwork Straight Bar enters 12 Adjust the Pedal so that there is 1/4” li on the damper tray 1 ...
-
Page 21: Installing The Sustain Pedal Solenoid - Grand
July 2013 Installa on Procedure Installing the Sustain Pedal Solenoid ‐ Grand... You can now turn your a en on to the installa on of the sustain pedal solenoid assembly. This procedure is not required when sustain pedal is not installed. Because there is a certain amount of varia on in the architecture of grand pianos, you will probably have to custom‐tailor the following direc ons to suit the mechanical dimensions of the par cular instrument you are working on. The key elements to focus on here include the sustain pedal lyre rod's upward projec on onto the keybed immediately above it, the loca on of the large hole through which the original sustain pedal pitman dowel projected to reach its corresponding hole in the wooden or aluminum damper tray (which li s all of the piano's dampers simultaneously), and the rearmost OUTSIDE ver cal wall of the keyboard compartment, called "the belly rail." The proper installa on of the sustain pedal solenoid assembly takes into account the dimensional rela onships of these three elements. In addi on to providing for both the manual and automa c opera on of the piano's dampers, you want to give the sustain pedal solenoid as much mechanical advantage as possible in order to minimize the power required to ac vate it. Despite the excellent design of the sustain pedal solenoid assembly, its long term opera on depends upon your skill in loca ng the various leverage‐points which enable it to func on both manually and auto‐... -
Page 22: Installing The Sustain Pedal Solenoid - Upright
July 2013 Installa on Procedure ...Installing the Sustain Pedal Solenoid ‐ Grand Installing the Sustain Pedal Solenoid ‐ Upright Ver cal Pedal Solenoid Li er Included Pedal Solenoid. QRS Part # 51045 ... - Page 23 July 2013 Installa on Procedure Install the Universal Sostenuto Assembly... Not used Iden fy the piano’s Sostenuto type. Push ‐ The Sostenuto is engaged when the actuator rises toward the strings. Pull ‐ The Sostenuto is engaged when the actuator descends away from the strings. Steinway ‐ Part of the assembly is built into the ac on. You will need to order the Steinway Sostenuto Assembly from QRS. Part # 70897 These instruc ons explain a Pull Type Sostenuto installa on. Remove the exis ng actuator a ached to the Sostenuto blade. Drill a hole in the new actuator for the staple. ...
-
Page 24: Installing The Universal Sostenuto Assembly
July 2013 Installa on Procedure ...Installing the Universal Sostenuto Assembly... Install the push lever which consists of the Push Block, the Main Sha , the Sha Bearings and the Swing Arm. Determine placement of the push lever by first installing the pedal lyre on the piano. Place the push lever so that the end of the lyre’s Sostenuto rod is on the outer edge of the push block when the pedal is not depressed. Make sure that there is clearance as the push block travels through its arc as the pedal is depressed. The push block posi‐ on is adjustable by loosening the set‐screw. There are several indents in the sha for posi oning. Also note the posi on of the sha bearing and bushing has been placed as close to the bend in the sha as possible to prevent the bushing from working its way out during opera on. Only this sha bearing should be fastened in place at this me. It is OK for the sha bearings to slightly overhang the slot. The assembly may need inset into the keybed to accommodate the key solenoid rail and rail cover. ... - Page 25 July 2013 Installa on Procedure ...Installing the Universal Sostenuto Assembly A ach the small return spring to the thread‐rod so it pulls up on the actuator. You’ll have to find a conven‐ ient place above the actuator to a ach the other end of the spring. Adjust the Sostenuto by loosening the locking screw on the swing arm to allow the main sha to spin freely without ac va ng the Sostenuto. Swing the main sha so that the brass insert on top of the push block is centered on the spring with the pedal in the rest posi on. Rotate the swing arm so that the piano’s Sostenu‐ to tab li er bar is about 1/16” away from damper Sostenuto tabs. Tighten the swing arm locking screw. Push the Sostenuto pedal on the lyre and inspect the opera on of the mechanism. When the pedal is depressed the tab li er bar should be nearly parallel with the key bed. Install the solenoid rail so that it goes over the Sostenuto sha . ...
-
Page 26: Installing The Steinway Sostenuto Assembly [Special Order Part # 70897]
July 2013 Installa on Procedure Installing the Steinway Sostenuto Assembly (Order 70897)... - Page 27 July 2013 Installa on Procedure ...Installing the Steinway Sostenuto Assembly (Order 70897) Route out the Sostenuto actuator pocket, centered on the original dowel hole, 2” x 2”. The depth is dependent on the key bed thickness but, the monkey must be able to slid over the actuator guide. Actuator Guide ...
-
Page 28: Moun Ng And Connec Ng The Electronic Components
July 2013 Moun ng & Connec ng the Electronic Components Electronic Components ‐ Descrip on... Power Supply Descrip on 1 ON/OFF Main Power Switch The UNSW OUT socket is “hot” when switch is ON 2 FUSE: 7amp 250 volt 3 Processor ‐ Ribbon Power Cable to PMII 4 AC INPUT ‐ From home’s AC Outlet 5 SUST PEDAL ‐ To Sustain Pedal Solenoid 6 Moun ng Bracket Can be also be mounted to the short side of the chassis 1 2 3 10 11 7 ... - Page 29 July 2013 Moun ng & Connec ng the Electronic Components ...Electronic Components ‐ Descrip on PMII Processor Descrip on The new PNOma on II processor replaces both the tradi onal QRS processor and the QRS user controller. The en re QRS Music library can be put on an SD memory card and inserted into the PMII unit. Control of the system is best achieved when connected via a standard wireless access point and an iPad or Android device. PNOma on II Processor with the SD Card Music Library, Moun ng brackets and screws Pin‐Light Extension (PLx) Descrip on The PLx box is used to extend two of the USB ports and two of the audio ports from the PMII processor to an easily accessible loca on under the keybed. This box is also used to show the status of the system. Pin‐Light Port Extender [PLx] [Six Lights; IR Sensor; Stereo & USB Ports; Microphone; Reset Bu on] ...
- Page 30 Component Loca on ‐ Grand At this point the piano is s ll on its side. The op onal sustain pedal solenoid is in place. All the trapwork modifica‐ ons have been completed and a clear passage has been made for installa on of the solenoid rail. The following is the SUGGESTED method of moun ng the electronics. Keep in mind every piano will be unique, and may require some parts mounted differently. PMII Processor & Wi‐Fi Device Pedal Solenoid Power Supply Driver Boards Speaker PLx Box Component Loca on ‐ Upright 5 Driver Boards Pedal Solenoid Power Supply Wi-Fi PMII Processor Extension Cord Speakers...
-
Page 31: Mount & Connect: Power Supply / Processor / Wi-Fi / Speaker / Pnoscan Ii(Record)
Having located the sustain pedal solenoid assembly, you can now locate the Power Supply chassis on the side of an adjacent wooden beam beneath the piano's soundboard. You should a empt to locate the Power Supply chassis as close to the belly‐rail as possible so as to avoid exceeding the length of the related cables. The moun ng can be placed on either the wide or narrow side of the power supply. Mount and Connect the PMII Processor and the Op onal PNOscan (Record) Moun ng the new PNOma on II processor to the piano and connect these cables. ‐ ... -
Page 32: Mount & Connect The Plx
July 2013 Moun ng & Connec ng the Electronic Components Mount the PLx (Pin Light Extension) The Pin‐Light Extension serves several functions: Six lights will display valuable information about your system. The built‐in IR Sensor will allow you to use your existing QRS Remote to control PMII. USB A‐ USB Mini B & 1/8” stereo jacks extend the ports from PMII to an accessible position on the piano. The button is for Play / Stop / Standby and Reset. Mount the PLx unit under the keybed at the treble side of the piano. IR Sensor for QRS remote control access Connect one end of the 6‐pin lat ribbon cable to the PMII’s “ALT” port. The black side of the cable faces the word “ALT” Connect the other end of the 6‐pin lat ribbon cable to the PLx connector. Connect so the black side faces the ceiling. Connect the USB A Male cable to one of the USB Host sockets on the PMII. PMII Updates & Music Source Connect the other end of the cable, USB 5‐Pin Mini B, to back of the PLx. Connect the USB B Male cable to the “USB Client” port o the PMII. Computer Connect the other end of this cable, USB A Male, to the back of the PLx. Connect one end of a 1/8” audio cable to the PMII’s Audio #1 socket. Audio #1 Connect the other end to the last 1/8” socket of the PLx. PMII External Source Line Input [AUX] port. AUX Line In Connect to home stereo system. Mixes Synth Piano with Audio. -
Page 33: Mount The Key Solenoid Rail / Mount & Connect The Driver Boards
July 2013 Moun ng & Connec ng the Electronic Components Mount the Key Solenoid Rail At this point, the rail has solenoid assembly pairs corresponding to ac ve keys at either end of each ac on sec on and the rail has been previously cut to length. The piano is standing on its side; all of the electronics, moun ng hardware and trapwork are in place and func‐ oning. Since the piano is res ng on its le side, you can install the key solenoid rail easily by res ng the bass‐most (that is, the lowest) por on of the rail on the lowest end of the lowest ... -
Page 34: Adjustment Procedures
July 2013 Adjustment Procedures Lost Mo on Adjustment: Plunger‐Tip to Keytail Height Don’t confuse Lost Mo on with the Plunger Throw adjustment! The Lost Mo on is the space between the ps of the plungers and the bo oms of the keytails. Raise or lower the Key Solenoid Rail Assembly so that the plunger ps are as close as possible to the keytails with‐ out touching. Lost Motion Adjust the solenoid rail assembly Felt‐Tip Plungers Solenoids Fully encased solenoids with a unique metal alloy inner sleeve specially designed for PNOmation. Built to hold tolerances of commercial applications and environments. Te lon Impregnated Plungers Won’t Corrode / Non‐Sticking / Self‐Lubricating Plunger Throw Adjustment Don’t lubricate, just wipe with a dry cloth. -
Page 35: Verify Opera On
July 2013 Adjustment Procedures Verify Opera on Connect to Power and Turn ON to Standby Mode Plug the AC power cord into a wall outlet. Flip the power supply switch to the “ON” posi on. PNOma on II will take several minutes to turn on the Low Voltage. During this power‐on/boot sequence PMII is loading the opera ng system and indexing the music on the SD card. You may remove the SD card for faster boot me during ini al setup and service. Note: Once removed, the SD card must be re‐inserted before flipping ON the power supply switch. The system has booted and is in standby when PLx lights stop scanning and the Power light is yellow. Establish a Wireless Connec on and Power ON Wirelessly connect your iTouch, iPad, Wireless Computer or Android Phone to the piano’s Wi‐Fi Adapter. [Se ngs / Wi‐Fi / click on the QRSPNO ### device] Open your Safari, Google Chrome or Android internet browser. In the address box type: QRSPNO , h p://qrspno/qrs or h p://192.168.1.1/qrs and refresh your browser. Press the Power ON bu on The “Power”, “System” and “Network” lights should be green. Power System Network Mode MIDI... -
Page 36: Key Adjust
July 2013 Adjustment Procedures Key Adjust The key adjustment sets the minimum force for each key. There is no “save” bu on. Your changes are automa cally saved to memory. Press “System Setup” Press “Test Files” then “Test‐Up_Down Runs” for a warm‐up before adjus ng key levels. Stop Stop the Test File. Press “Key Adjust” and then the “START” bu on. Piano key #5 should begin to repeat. [Key #1 for 88 note systems] You must set the Legato AND Staccato Force levels for each key. Set the Legato adjustment first. Previous Key / Key Number / Next Key Key “Force”: Legato & Staccato. Adjust so key plays as so ly as possible. “Extend”: Sets the Force value “displayed” to all notes upscale. Clicking “More” or “Less” increases or decreases the force for ALL Keys. Global Entering a number in the force box sets the Key Force value entered to ALL Keys. ... -
Page 37: Pedal Adjust
July 2013 Adjustment Procedures Pedal Adjust This procedure is not necessary on systems that do not have a sustain pedal solenoid, usually uprights . Press “Pedal Adjust” and then slide the “Start/Stop Test” bu on to the right to start the adjustment. The sustain pedal solenoid and the sustain dampers should start to cycle ON and OFF. Turn OFF the “Thump Reduc on” by sliding the bu on to the le . Press the “‐” bu ons to set the “Ini al Drive” and “Hold” values to zero. Watch the sustain dampers and press the Ini al Drive’s “+” bu on un l the dampers move off the strings. Then, press the Hold “+” bu on un l the dampers li up and hold off of the strings. Turn ON the “Thump Reduc on” by sliding the bu on to the right. Thump reduc on will pulse the pedal solenoid as it’s release to break it’s fall and reduce noise. Adjust the release up and down un l the solenoid drops quietly. ... -
Page 38: Pnoscan Adjust [Pnoscan Ii Must Be Installed]
July 2013 Adjustment Procedures PNOscan Adjust If PNOma on II is connected to the QRS PNOscan II record system, as shown at the bo om of page 5, then the PNOscan Adjust op on will appear on the System Setup page. The following adjustments are necessary a er ini al installa on or when the system isn’t recording properly. Select the PNOscan Adjust op on from the Home Screen’s System Setup page. Press the Calibrate bu on. The PNOscan Adjustment Started box will appear. At this point the previous calibra on has been cleared. To calibrate the PNOscan key sensors you’re going to play each key, in sequence, star ng at the bass end of the keyboard. Watch the MIDI light on the PLx box and press the first bass‐end key. The light will flicker red indica ng that the key is set. Release the key and proceed up the keyboard. MIDI Move to the next key when the PLx light flashes. Press OK when finished. ... -
Page 39: Install Rail Cover, Lyre Braces And Dress Cables
July 2013 Adjustment Procedures Install the Rail Covers Install the two key solenoid rail covers using “L” brackets A ach the Lyre and Braces Locate the points on the keybed where the original braces were seated. Because the cover might be in the path of the braces to these two points, bend each brace in a gentle arc such that when the braces are placed into their seats on the lyre, their opposite ends come up just under their original moun ng posi ons. Measure the distance from the keybed to the brace bracket. Fill the distance with a block of the appropriate thick‐ ness, painted the color of the piano's keybed finish. A ach the blocks to the underside of the keybed with wood screws. A ach the lyre braces to the blocks. Dress the Cables Secure the cables using wire‐ es and clamps. Installa on is Complete At this point the installa on is completed. Play the instrument for several hours to break‐in the solenoids. ... -
Page 40: User Guide - Introduc On
July 2013 User Guide ‐ Introduc on Power ON to the PMII User Interface The lights on the PLx box should be ON but not scanning from right to le . If the PLx lights are off, see the “Verify Opera on” sec on of this manual on page 8. Wirelessly connect your iTouch, iPad, Wireless Computer or Android Phone to the piano’s Wi‐Fi Adapter. [Se ngs / Wi‐Fi / click on the QRSPNO ### device] Open your Safari, Google Chrome or Android internet browser. In the address box type: QRSPNO or h p://192.168.1.1/qrs and refresh your browser. The browser will load the PMII interface and index the music. Then the Power Op on box will appear. Press “Power ON” Welcome to QRSPNO Playback Settings Pause Selected Song... -
Page 41: Play Piano
July 2013 User Guide ‐ Introduc on Play Piano Home Page Select a song from any of these loca ons. Playback Settings Stop Play Pause Go back to Home Page Standby Music Groups QRS Music on SD Card Song Title Color Music from your USB drive Solo Music that you’ve recorded Blue Concert... -
Page 42: Wi-Fi Setup
July 2013 Wi‐Fi Setup Configura ons for PNOma on II Please update PMII to the latest Driver version before switching modes. Connect to PMII and click on the QRSPWR icon at upper right of display to see the current version.. Download the current Driver from the QRS website. h p://qrsmusic.com/support_pmii.asp Copy update to a USB memory drive and plug drive into USB port on piano. The update is automa c and will take about 5 minutes to complete. Both PMII AND the Wi‐Fi device must be programmed to switch modes. There is no connec on to the Internet. The user wirelessly connects to the TP‐Link (SSID = QRSPNO) and PM II delivers control on Google Chrome, or Safari, at the IP Address of 192.168.1.1. PM II and the users Wi‐Fi device communicate only with each other. Stand Alone #3 Light = Green ... -
Page 43: How To Change Modes: Stand Alone & Network
Select and connect to QRSPNO. Select the Safari browser. Enter the following address: 192.168.0.254 and press “Go” Set a sta c IP address if you can’t connect to the TP‐Link. See [Select “Sta c”] in the “TP‐Link Reset” instruc ons. Enter “admin” as the User Name and Password. Press the “Log In” bu on. Click “Quick Setup” Click “Next” Select “Bridge Mode” Click “Next” Click the “Survey” bu on. Click “Connect” for the SSID of the network you wish to join. Change the SSID to “QRSPNO Network” Under “Security Op ons” choose the type of security (WEP or WPA) Enter your network password in the “PassWord” box Click “Next” If prompted, change the channel se ng displayed. Press “OK” and then do so and click “Next” Select “Disable Security” (Unless you want to secure the network) Click “Next” Click “Reboot” Click “OK” to confirm. Connect to your home network PLx light # 3 should be YELLOW. Lighted bu on on the PMII processor should be FLASHING. The TP‐Link is now linked to your home network and ready for “Network Mode” on the PMII. If you did not hear the IP address press SHIFT and then INFO on the QRS remote control. You may have to reboot PMII by unplugging from AC power and reconnec ng. Open Safari enter the IP address heard from the speaker. ... - Page 44 Enter “admin” as the User Name and Password. Press the “Log In” bu on. Click “Quick Setup” Click “Next” Select “Router Mode” Click “Next” Change the SSID to QRSPNO Set Channel to “Auto” Under “Security Op ons:” select “Disable Security” Click “Next” Under “WAN Connec on Type” select “Dynamic IP” Click “Next” Under “MAC Clone” select “No” Click “Next” Click “Reboot” Click “OK” Restar ng Wait for the TP‐Link configura on to finish and restart. Close browser when 100% complete. On the QRS PNOma on II remote control: Press the following bu ons in sequence… SHIFT FUNC 9 9 0 The third light should be green. Press SHIFT INFO to confirm the 192.168.1.1 address. Lighted bu on #3 on the PMII processor should be SOLID green. The device is now ready for “Stand‐Alone Mode” on the PMII. Select Se ngs and then Wi‐Fi on your iPad, iPhone or iTouch. Select and connect to “QRSPNO”. Open Safari and enter 192.168.1.1 ...
- Page 45 Press the “Log In” bu on. You may be asked for the TP‐Link’s password. It’s located on the back of the TP‐Link. Click “Quick Setup” Click “Next” Select “Router: Router Mode” Click “Next” Change the SSID to QRSPNO Under “Security Op ons:” select “Disable Security” Click “Next” Under “WAN Connec on Type” select “Dynamic IP” Click “Next” Under “MAC Clone” select “No” Click “Next” Click “Reboot” Click “OK” to confirm. The TP‐Link will configure and restart. Go to Se ngs / Wi‐Fi and connect to the QRSPNO. Open Safari and navigate to 192.168.0.254 If necessary, enter “admin” as the ID and Password You may have to enter “Sta c:” again. See above. Under “Advanced Se ngs” click DHCP Under DHCP Server” select “Enable” Press “Save” and “OK”. On the QRS PNOma on II remote control: Press the following bu ons in sequence… SHIFT FUNC 9 9 0 The third light should be green. Press SHIFT INFO to confirm the 192.168.1.1 address. Go to Se ngs / Wi‐Fi and verify your connected to QRSPNO Open your Safari browser and enter the 192.168.1.1 address to connect to PMII. ...
-
Page 46: Other Kits
702821 4 PMM Parts Fuse: Power Supply Rev 2 [75210] 70083F 4 PMM Parts Plunger 4.5” [Felt Tip] 70083R 4 PMM Parts Plunger 4.5” [Rubber Tip] 75210 1 PMM Parts Power Supply Rev 2 73398 1 PMM Parts Remote, PMII Big Bu on 70071 2 PMM Parts Solenoid ‐ Key, Black 70070 2 PMM Parts Solenoid ‐ Key, White 70130 1 PMM Parts Solenoid Assembly, Pedal 70743 1 PMM Parts Sostenuto Assembly, Universal 76040 1 PMM Parts ... -
Page 47: Pmii Upgrade Kit (81525) & Pmii Midi Upgrade Kit (81529)
PMII Upgrade Kit ‐ See above 8152905 PMII Upgrade Kit to PMII MIDI Upgrade Kit Conversion 70166 2 Adapter: MIDI Barrel Connector 990026 Cable: Speaker [1/8” stereo plug to two RCA] 815250 Power Adapter [Power supply for PMII] 1 200711 2 Cable: 6’ MIDI 6 73398 PMII Big Bu on Remote 70388 ... -
Page 48: Qrs Remote Control
QRS Remote Control Music Source Demo Future Option Power ON/OFF Music Source MIDI IN Music Source P LIST Future Option AUD UP / DN Audio Volume - Offset MSTR UP / DN Master Volume - Adjusts Piano and Audio Levels PNO UP / DN Piano Volume - Offset Numbers 0-9... -
Page 49: Troubleshoo Ng
Troubleshoo ng Problem Possible Cause Remedy Unit will not turn on Power cord is not plugged into live Plug line cord into wall outlet socket Wall outlet is not live Some wall outlets ate controlled by a wall switch Power switch on Power Supply is off Turn the main power switch on. This is located on the power supply Blown external power supply fuse Replace the 7amp 250 volt Fast‐Blow fuse Blown internal power supply fuse Replace the 5mm 250 volt Slow‐Blow 5amp fuse No music. Mute is on Located in volume controls Solenoid misalignment Loosen the 11/32” solenoid moun ng plate nut and align the pusher p with the center of the key tail Key stays depressed Bent Solenoid Plunger Push Rod Replace solenoid plunger Magic Pedal Mode Plug in Pedal Solenoid Pedal Thumping Modula on Level Adjust the “Thump Reduc on” se ng. System Setup/Pedal Adjust ...
