MBS-GPS-SS2-5HZ Novatel
SuperStar II PC/104 GPS Module
User's Manual
MICROBEE SYSTEMS CORPORATION
21723 North Meadowview Court
Colbert, WA 99005
Tech. Support: 256–426–2431
www.microbee-systems.com
support@microbee-systems.com
CAGE Code 3DPE9
COPYRIGHT 2005 MicroBee Systems Corporation.
All rights reserved.
However, any part of this document may be reproduced, provided that MicroBee Systems
Corporation is cited as the source. The contents of this manual and the specifications herein may
change without notice.
TRADEMARKS:
Windows® is a registered trademark of Microsoft Corporation.
ROM-DOS is a trademark of Datalight.
QNX is a trademark of QNX Software Systems, Ltd
1
Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MBS-GPS-SS2-5HZ and is the answer not in the manual?

Questions and answers

Summary of Contents for Microbee Systems MBS-GPS-SS2-5HZ

  • Page 1 COPYRIGHT 2005 MicroBee Systems Corporation. All rights reserved. However, any part of this document may be reproduced, provided that MicroBee Systems Corporation is cited as the source. The contents of this manual and the specifications herein may change without notice.
  • Page 2 It is a Condition of Sale that the user of MicroBee Systems products in life support applications assumes the risk of such use and indemnifies MicroBee Systems against all damage.

  • Page 3: Technical Support

    IO libraries. We will help you all we can. If you have a question about the MBS-GPS-SS2-5HZ card and cannot find the answer in this manual, call Technical Support. They will be ready to give you the assistance you need.

  • Page 4: Operating Precautions

    Also interrupts 10, 11, 14 and 15 are accessed thru this connector. The MBS-GPS-SS2-5HZ, being an 8 BIT interface, does not require a 16 bit ISA card be prior to the radio unless operation requires IRQ 10, 11, 12, 14 or 15.

  • Page 5: Installation

    INSTALLATION Before installing the MBS-GPS-SS2-5HZ GPS Module, refer to Figure 1 for the location of various connectors and jumpers. Interrupt Select Jumpers, JP3 & JP 4: JP3 is used to select the IRQ Level for the DATA port. IRQ's 3, 4, 5, 6, 7, 9, 10, 11, 12, 14 and 15 are supported.
  • Page 6 EXT GPS/Data port, J7. To allow user software identification of the type of GPS/ Module connected/installed on the MBS-GPS-SS2-5HZ JP5 and JP6 are available for use as identification bits. ID bits are read by polling the DCD, DSR and CTS bits of the Differential Port.
  • Page 7 INT or EXT GPS (depending upon GPS source selection), or the AUX 1PPS source. The 1PP is primarily used for synchronization of MicroBee Systems PC/104 FreeWave data radio products in Masterless TDMA mode and Push To Talk (PTT) mode. In addition the 1PP is very useful for timetag and system synchronization uses.
  • Page 8 J6.3: TTL level 1PPS output. It is identical to J6.1 except it is TTL level. J6.4: BAT IN is a optional input for an EXT battery to backup warm fix information on the Novatel SS2. The Novatel SS2 has a charge storage device to maintain this information for up to 1 week. Longer storage requires a battery.
  • Page 9 Figure 1, Jumper Layout Rev A...

  • Page 10: Limitations On Warranty

    WARRANTY MicroBee Systems Corporation (MicroBee), warrants that it’s standard hardware products will be free from defects in materials and workmanship under normal use and service a period of one year from date of purchase. MicroBee’s obligation under this warranty shall not begin until Buyer returns the defective product, freight prepaid to MicroBee’s facility or another specified location.

  • Page 11: Governing Law

    This agreement is made in, governed by and shall be construed in accordance with the laws of the States of Alabama and Washington. The information in this manual is provided for reference only. MicroBee Systems does not assume any liability arising out of the application or use of the information or products described in this manual.
