User's Manual for ZKSD3 Series PTZ Dome IP Camera
Version: V1.8
Date: July 2014
About This Manual
This document mainly introduces the functional features, installation process and
access methods of ZKSD3 series IPC.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZKSD3 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKT ZKSD3 Series

  • Page 1 User's Manual for ZKSD3 Series PTZ Dome IP Camera Version: V1.8 Date: July 2014 About This Manual This document mainly introduces the functional features, installation process and access methods of ZKSD3 series IPC.
  • Page 2 Important Claim Important Claim Firstly, thank you for purchasing this terminal, before use, please read this manual carefully to avoid the unnecessary damage! The company reminds you that the proper user will improve the use affect and authentication speed. No written consent by our company, any unit or individual isn’t allowed to excerpt, copy the content of this manual in part or in full, also spread in any form.
  • Page 3: Table Of Contents

    User's Manual for ZKSD3 Series PTZ Dome IP Camera Contents 1 Overview ..............................1 1.1 Product Description ........................1 1.2 Product Features ..........................1 1.3 Technical Parameters ........................2 1.4 Product Appearance ........................3 1.5 Connecting Terminal ........................4 1.6 Basic Procedure ..........................6 2 Installation and Network Configuration ....................
  • Page 4: Overview

    1 Overview 1.1 Product Description The ZKSD3 series products are high-speed dome IP cameras with CCD sensors, which are integrated with multiple new technologies in mechanical, electronic and casting fields; they are high-performance integrative cameras with built-in zoom lens and high-end surveillance products combining the platform and digital decoder design, which represent new generation technologies.
  • Page 5: Technical Parameters

    User's Manual for ZKSD3 Series PTZ Dome IP Camera  360º continuous rotation in horizontal direction, -3º ~90º continuous rotation in vertical direction, surveillance without blind zone  Maximum speed of horizontal preset point is up to 250º /s; maximum speed of vertical preset point is up to 100º...
  • Page 6: Product Appearance

    1 Overview 10Base-T/100Base-TX Ethernet interface Network Interface Wi-Fi 802.11b/g wireless (optional) TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, Supported Network Protocols DDNS, NTP, UPNP and RTSP, P2P, etc. Horizontal Speed 0.1º ~250º /s Vertical Speed 0.1º ~100º /s Horizontal Speed: 100º...
  • Page 7: Connecting Terminal

    User's Manual for ZKSD3 Series PTZ Dome IP Camera 1.5 Connecting Terminal Power Interface: Used for connecting the power adapter. The voltage of series products is 24V AC and the current is not lower than 2A. Other power is not allowed, in order to avoid damage of the cameras.
  • Page 8 1 Overview alarm input terminals alarm (IN,GND) switch input device power supply of alarm input device Schematic Diagram of Alarm Input (Normally Opened) Connection alarm input terminals alarm (IN,GND) switch input device power supply of alarm input device Schematic Diagram of Alarm Input (Normally Closed) Connection ...
  • Page 9: Basic Procedure

    User's Manual for ZKSD3 Series PTZ Dome IP Camera Audio Input Interface: connect to external audio acquisition (e.g. MIC) for sound acquisition. Audio Output Interface: connect to audio player (e.g. active speaker) for sound broadcasting. Analog Video Output Interface: special for SD camera and engineering commissioning. After being installed and connected, this interface can be used locally to connect with the image display device and adjust the camera angle to the appropriate monitoring area according to the scene in the video.
  • Page 10: Installation And Network Configuration

    2 Install and Network Configuration 2 Installation and Network Configuration 2.1 Hardware Installation  Installation Notices Read through the guide for installation prior to installation. Check whether any component is missing against the packing list, if yes, please contact your supplier. Wire during power off.
  • Page 11 User's Manual for ZKSD3 Series PTZ Dome IP Camera Uncovered cable should be less than 5mm Mount the relay equipment in the middle to avoid signal attenuation when the straight communication distance from the camera to the incoming equipment exceeds 80m.
  • Page 12 2 Install and Network Configuration correct wiring wrong wiring  Installation Diagram Wall Mounted Mode:  Stick the installation template onto the wall, and drill holes according to the markings on the template.  Fix the bracket in wall by 4 screws. steel M8 expansion bolt ...
  • Page 13: Network Connection

    User's Manual for ZKSD3 Series PTZ Dome IP Camera Paper template for pendant mounting Pendant mounting 2.2 Network Connection The device can be connected to network in two ways. The first way is to connect to the network by means of Ethernet cable, and the second way is to connect to wireless network (optional).
  • Page 14: Accessing Device

    3 Accessing Device 3 Accessing device There are 4 methods can be used to access the device: WEB Browser, RTSP Media Player, Mobile Device and Video Surveillance Software (ZKiVision client software). 3.1 Using WEB Browser 1. Start the browser. Enter the dynamic domain name or IP address (for example, http://192.168.1.88) in the address bar, and press Enter.
  • Page 15 User's Manual for ZKSD3 Series PTZ Dome IP Camera 3. Click Watch the Video to enter the preview interface where you can start video surveillance.  Note: If you use a browser to access the camera for the first time, you need to download the ActiveX. (To download the ActiveX, click Install the Software (initial use), and follow instructions displayed on the ActiveX download window to download and install the software.) For details about how to use a browser for video surveillance, see the Web...
  • Page 16: Using Rtsp Media Player

    3 Accessing Device 3.2 Using RTSP Media Player 1. Download and install an RTSP-enabled player, such as the VLC media player. 2. Start the player and choose Media > Open Network Stream. A URL input interface is displayed. 3. Enter the network URL by using the format "rtsp://<IP address>:<RTSP Port>/<Stream code>". For the network ULR shown in the following figure, "192.168.1.88"...
  • Page 17: Using Mobile Devices

    User's Manual for ZKSD3 Series PTZ Dome IP Camera 5. After RTSP authentication is passed, the player plays the real-time videos collected by the camera.  Note: (1) The RTSP Port of the camera is "554" by default. To change the default RSTP Port, see the section "Network Setup"...
  • Page 18 3 Accessing Device mobile phones in real time by connecting their mobile phones to the front-end surveillance devices via a mobile wireless network. (Tips: In an LAN, you can use any set of digits or letters to replace a UID; however, in a WAN, you must enter a correct UID provided by your service provider.) The following takes adding a device via an IP address as an example to illustrate how to access a device by using the ZKiVision (mobile phone) monitoring software:...
  • Page 19: Using Video Surveillance Software

    User's Manual for ZKSD3 Series PTZ Dome IP Camera  Note: (1) The operating system of the mobile device must be Android or iOS. (2) Viewing videos will use data. For details about charges, consult your network service provider. (3) Open the mobile phone monitoring software, and add a P2P-capable device by using a UID for remote view and monitoring.
  • Page 20 3 Accessing Device...
  • Page 21: Extended Functions

    User's Manual for ZKSD3 Series PTZ Dome IP Camera 4 Extended Functions The mini PTZ dome IP camera supports a maximum of 255 presets, among which presets 90 to 130 and preset 255 are used for special functions. 95 (invoke preset 95): Enter the high speed dome menu...
  • Page 22 3 Accessing Device...
