Table of Contents
1.0 SPECIFICATIONS .....................................................................3
1.1 High Altitude Operation ..........................................................3
2.0 INSTALLATION REQUIREMENTS.............................................4
2.1 Location ................................................................................5
3.0 VENTING ..................................................................................6
Attaching Vent Piping to Boiler .....................................................6
3.1 Vent Pipe Material..................................................................7
3.2 Venting Configurations ...........................................................7
3.3 Venting Rules and Guidelines .................................................9
3.4 Venting Clearances.............................................................. 10
3.5 Determining Vent Lengths .................................................... 10
3.6 Outdoor Venting................................................................... 11
4.0 CONDENSATE DRAIN ............................................................ 12
5.0 INSTALLING GAS PIPING....................................................... 13
5.1 Installation........................................................................... 13
5.2 Testing and settings ............................................................. 13
6.0 BOILER PLUMBING................................................................ 15
6.1 Plumbing (Minimum Requirements)....................................... 16
6.2 Matrix Boiler Connections ..................................................... 17
6.3 Hydronic Heating Additions (Optional) ................................... 17
7.0 DOMESTIC HOT WATER SYSTEM.......................................... 23
7.1 Operation and Set-up ........................................................... 23
7.1.2 Matrix DHW with Storage................................................... 25
8.0 WIRING................................................................................... 26
8.1 Field Wiring to Matrix............................................................ 26
8.2 Matrix Factory Wiring Schematic ........................................... 27
9.0 CONTROL SETUP................................................................... 29
9.1 Controller Displays ............................................................... 29
9.2 Operation and Set-up ........................................................... 30
9.3 Outdoor Sensor Operation.................................................... 32
10.0 MATRIX BLOWER OPERATION ............................................ 33
10.1 Forced Air Heating ............................................................. 33
10.2 Duct Sizing ........................................................................ 34
11.0 HEAT RECOVERY VENTILATION ......................................... 35
11.1 Ventilation Needs ............................................................... 35
11.2 Types of Installation ........................................................... 36
11.3 Damper Box ...................................................................... 37
11.4 Condensate Drain .............................................................. 37
11.5 HRV Balancing .................................................................. 38
12.0 LIGHTING BOILER................................................................ 40
12.1 Initial Start-Up .................................................................... 40
12.2 Re-Lighting Unit ................................................................. 40
12.3 Turn Off Appliance ............................................................. 40
13.0 TROUBLE SHOOTING .......................................................... 41
14.0 SEQUENCE OF OPERATION ................................................ 45
15.0 INSTALLATION CHECKLIST................................................. 46
16.0 ANNUAL MAINTENANCE AND INSPECTION ........................ 47
16.1 Combustion Chamber Cleaning .......................................... 47
16.2 HRV/Air Handler Maintenance ............................................ 47
17.0 PARTS LIST.......................................................................... 48
18.0 WARRANTY.......................................................................... 49
Matrix
Matrix Boiler Only
VERSION DATE: 2-7-08
US Models
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Matrix M100
-
Page 1: Table Of Contents
7.1 Operation and Set-up ............23 7.1.2 Matrix DHW with Storage........... 25 8.0 WIRING................... 26 8.1 Field Wiring to Matrix............26 8.2 Matrix Factory Wiring Schematic ........... 27 9.0 CONTROL SETUP..............29 9.1 Controller Displays ............... 29 9.2 Operation and Set-up ............30 9.3 Outdoor Sensor Operation............ - Page 2 Matrix Installation and Operation Instructions WARNING THIS APPLIANCE INCORPORATES A CERTIFIED LOW PRESSURE BOILER, WHICH MUST OPPERATE WITH A SUSTAINED WATER PRESSURE. FAILURE TOMAINTAIN WATER PRESSURE WILL DAMAGE THE UNIT AND VOID THE WARRANTY. CAUTION IT IS THE RESPONSIBILITY OF THE HOMEOWNER TO KEEP THE VENT TERMINAL CLEAR OF SNOW AND ICE.
-
Page 3: Specifications
Elevation (ft) CAUTION AT ELEVATIONS GREATER THAN 2000 FEET, THE COMBUSTION OF THE MATRIX MUST BE CHECKED WITH A CALIBRATED COMBUSTION TESTER TO ENSURE SAFE AND RELIABLE OPERATION. CONSULT SECTION 5.20 FOR INSTRUCTIONS ON ADJUSTING THE INPUT TO PROVIDE PROPER OPERATION. -
Page 4: Installation Requirements
2.0 INSTALLATION REQUIREMENTS The installation of your NY Thermal Matrix gas furnace/boiler must conform to the requirements of your local authority, and the National Fuel Gas Code ANSI Z223.1 and or CAN/CGA B149 Installation Codes. Where required by the Authority, the installation must conform to the standard for “Controls and Safety Devices for Automatically Fired Boilers ANSI/ASME CSD-1. -
Page 5: Location
2.1 Location In all cases, the Matrix must be installed indoors, in a dry location, such that the gas components are protected from dripping or spraying water or rain, during operation and servicing. The boiler location ambient temperature is maintained to a minimum of 50°F. -
Page 6: Venting
Under no conditions, may this unit vent gases into a masonry chimney, unless it is vacant, and utilizes Matrix approved venting material as illustrated in the figures in this section. -
Page 7: Vent Pipe Material
Field supplied piping and fittings are required to complete the installation. Selection of the vent pipe material must be based upon the Local codes and regulations. The Matrix is certified to operate under all conditions using the following venting material:... - Page 8 Matrix Installation and Operation Instructions 3.2.2 Concentric Vent Termination (No longer approved for Canada) Figure 3.3 Concentric Vent Termination Apply Plate Here Support (Field installed) Inlet air Gas Vent Directly Below Keep Free of Obstructions Exhaust Exhaust Inlet air Must be 1”...
-
Page 9: Venting Rules And Guidelines
Matrix Installation and Operation Instructions IMPORTANT USE OF EXISTING CHIMNEY It is permissible to run vent pipe through an existing chimney as long as: 1. The chimney is not to be used by any other appliance. 2. Flue gases don’t enter the vacant chimney. -
Page 10: Venting Clearances
Matrix Installation and Operation Instructions 3.4 Venting Clearances These are code restrictions for the location of the Flue gas vent terminal. Compliance doesn’t insure a satisfactory installation; good common sense must also be applied. The vent terminal shall not terminate: 1. -
Page 11: Outdoor Venting
Matrix Installation and Operation Instructions 3.6 Outdoor Venting Figure 3.6 Outdoor Venting Vent piping outside the Building is permitted under the following conditions: Supports every 24” The maximum length outside the building is 20 feet. (Outdoor length must be included in the overall vent length calculation.) Exhaust All normal termination clearances are maintained. -
Page 12: Condensate Drain
Matrix Installation and Operation Instructions 4.0 CONDENSATE DRAIN This unit produces water as a product of combustion. Much of this water condenses on the heat exchanger and in the venting system. All exhaust piping must be on a slope back to the boiler ¼” per linear foot of vent. Steps must be taken to ensure that condensate does not collect in the venting system. -
Page 13: Installing Gas Piping
Gas line and regulator(s) must be able to support a line pressure at the gas valve of 4-9”w.c for Natural Gas and 9-12”w.c for LP while running at maximum rate. Matrix gas valves are equipped with two bleed ports to measure Line and Manifold pressure. - Page 14 Line Pressure CAUTION The Matrix is tested with Natural Gas having a heating value of 1020 BTU per cubic foot. For areas with lower heating values, a combustion test is required to obtain optimum operation. Using a calibrated flue gas analyzer, check the combustion and compare it with the acceptable requirements. The test should be performed at maximum fan speed (“Gas Input Value”).
-
Page 15: Boiler Plumbing
Matrix Installation and Operation Instructions 6.0 BOILER PLUMBING WARNING THIS APPLIANCE CONSISTS OF A “LOW-MASS” BOILER AND MUST HAVE ADEQUATE WATER FLOWING THROUGH IT WHENEVER THE BURNER IS ON. FAILURE TO DO THIS WILL DAMAGE THE UNIT AND VOID THE WARRANTY. -
Page 16: Plumbing (Minimum Requirements)
Low Water Cutoff: A certified LWCO is not provided in the package, however one is to be field installed in any application where the Matrix boiler is located above the radiation or where local authorities require it. Ensure that the water line of the “Low Water Cutoff” is at least 6”... -
Page 17: Matrix Boiler Connections
Preventer Expansion Tank IMPORTANT Expansion tank and air removal device for the internal functions of the Matrix are included and provide only enough capacity for these functions. Additional secondary systems require appropriately sized air removal and expansion capability. 6.3 Hydronic Heating Additions (Optional) ATTENTION 1. - Page 18 The Matrix has a Grundfos 15-42 built into the primary loop. Given the head loss of the primary loop, the flow rate is fixed at 5 gpm. When designing any secondary heating system it is important to allow for an increase boiler set point to ensure full capacity of the secondary system.
- Page 19 Matrix Installation and Operation Instructions 6.3.1(B) Multiple High Temperature Zones (Zone Valves) – Wiring w/ Zone Controller Matrix Terminal Strip System Circulator 24VAC Relay N/C Contact 6.3.1(C) Multiple High Temperature Zones (Zone Valves) – Wiring w/o Zone Controller Matrix 3-Wire Zone Valves...
- Page 20 Matrix Installation and Operation Instructions 6.3.2(A) Multiple High Temperature Zones (Zone Circulators) Zone #3 Zone #2 Zone #1 Check Valves Zone Circulators Separator Make Up Backflow Preventer Pressure Expansion Water Reducing Tank Valve 6.3.2(B) Multiple High Temperature Zones (Zone Circulators) – Wiring w/ Zone Controller...
- Page 21 Matrix Installation and Operation Instructions 6.3.3 Multiple Controlled-Temperature Zones (Tempering Valves) • Use wiring configuration in 6.3.2(B) Temp #3 Temp #2 Temp #1 Zone Circulators Tempering Valves Separator Make Up Backflow Preventer Pressure Expansion Water Reducing Tank Valve 6.3.4(A) Single Controlled-Temperature Zones (Injection System)
- Page 22 Matrix Installation and Operation Instructions 6.3.4(B) Single Controlled-Temperature Zones (Injection System) – Wiring Tekmar 356 tekmar Injection Circulator 3-Wire Zone Valves Matrix Terminal Strip System Circulator 24VAC Relay N/C Contact 24VAC Relay N/O Contact 6.3.5 Multiple Controlled-Temperature Zones (Injection System) Low Temp.
-
Page 23: Domestic Hot Water System
MANUAL, OPERATION MAY SUPPLY SCALDING HOT WATER TO THE OCCUPANTS. Flow Switch (Supplied): The Matrix comes with a domestic flow switch that must be field installed in the location shown. It is important the flow switch be installed in the cold water line before the cold-water branch to the Mixing Valve or in the mixed out line, thus the flow switch will have the total domestic hot water flow rate available to trigger it and initiate the hot water call. - Page 24 Procedure for Setting up Domestic Hot Water: If the Matrix is being installed in an application that uses municipal water, often the pressure is high enough to generate flow rates at the faucets that will exceed the appliances capacity to heat it. See the following table to determine what flow can be expected at various inlet and outlet water temperatures.
-
Page 25: Matrix Dhw With Storage
Matrix Installation and Operation Instructions 7.1.1 Matrix DHW without Storage Figure 7.1 DHW Piping The Matrix will provide domestic hot water Domestic continuously when flow is sensed by the flow- Water In (Cold) switch. This method is the most efficient means... -
Page 26: Wiring
Canadian Electrical Code CSA C22.1. All connections to the Matrix are made at the terminal board provided. This terminal board can be found on the left side of the appliance just above the plumbing connections. The following connections are available, and provide different functions according to which inputs are energized. -
Page 27: Matrix Factory Wiring Schematic
Matrix Installation and Operation Instructions 8.2 Matrix Factory Wiring Schematic 8.2.1 Boiler Control Wiring Consult diagram on unit for exact wire routing. - Page 28 Matrix Installation and Operation Instructions 8.2.2 Fan Control Wiring Consult diagram on unit for exact wire routing.
-
Page 29: Control Setup
The Matrix used two devices to control the functions required by the Matrix. The Matrix Boiler Control (red face) controls and ensures the safe operation of the boiler functions of the Matrix much the same as the Sentry 2100 does in the Trinity products. The Matrix Fan Control (blue face) controls all of the operation and safety functions related to air handling and hot water dispatching. -
Page 30: Operation And Set-Up
9.2 Operation and Set-up The Matrix employs a pneumatic modulation system. This modulation system increases or decreases the velocity of the combustion blower, to meet the demand for heating. The gas valve senses this change in blower pressure and introduces the required amount of gas to ensure correct combustion. - Page 31 9.2.2 Setting Matrix Fan Control Just as the Matrix Boiler Controller controls all of the operation and safety functions of the boiler, the Matrix Fan Controller, controls all of the operation and safety functions related to air handling and hot water dispatching. The fan controller controls the forced air modulation, ventilation, as well as priority of domestic hot water and secondary heating systems.
-
Page 32: Outdoor Sensor Operation
Matrix Installation and Operation Instructions 9.3 Outdoor Sensor Operation The outdoor sensor is connected to the terminal board on the left side of the matrix. The two terminals are labeled ‘OUTDOOR SENSOR’. Figure 9.1 Outdoor Sensor Connection When the Outdoor sensor is not used, or the outdoor temperature is below 0°F, the Matrix operates at a boiler water temperature equal to... -
Page 33: Matrix Blower Operation
79,000 1200 92,000 At stage 4 (Profile 1) the Matrix provides 675 cfm across the fan coil, which is receiving 128°F water from the boiler. The Example. coil then supplies plenum air at 113° F or ~30,000 BTU/hr. (1.08x675x(113-72)=30,000) On an initial thermostat call (24VAC @ W1), space heating begins by providing heat at stage 3 (~24,000 BTU/hr) (if hydronic heat is also calling (24VAC @ H) heating will begin at stage 1) and so long as the thermostat is not satisfied, incrementally increases to a maximum of stage 10 (~66,000 BTU/hr). -
Page 34: Duct Sizing
Call for Auxiliary Heat (24 VAC @ W2): When calling, furnace will provide heat at a stage 10 output rate. With a call for auxiliary heating the Matrix will function as a single stage, full fire appliance. This means the burner will come on with a thermostat call and go off when the call is satisfied. -
Page 35: Heat Recovery Ventilation
Matrix Installation and Operation Instructions 11.0 HEAT RECOVERY VENTILATION 11.1 Ventilation Needs With the evolution toward more energy efficient, tighter homes, air quality problems have increased. With less natural ventilation pollutants such as pet dander, humidity, tobacco smoke and wood ash now become trapped inside the home. -
Page 36: Types Of Installation
Matrix Installation and Operation Instructions 11.2 Types of Installation There are two basic methods of installing the ventilator in the Matrix: Exhaust at the source. Stale air is drawn from the kitchen and bathrooms External Ducting to be 6” insulated with Vapor Barrier... -
Page 37: Damper Box
HRV is off or in defrost mode. It is to be installed with the actuator on the top side and screw to the Matrix using the four screws provided. Damper Box with Collar Installed 11.4 Condensate Drain Condensation from defrost will collect in the ventilator and drain from the sloped drain pan. -
Page 38: Hrv Balancing
Zero the Magnehelic. Begin by selecting the heating profile required in the Matrix Fan Controller ‘HEA’ menu. Refer to the heating section of the manual for more explanation. The heating profile selected dictates the air handler blower speeds and is important to the proper functioning of the HRV. - Page 39 Matrix Installation and Operation Instructions Stale Fresh Figure 11.1 Sample Balancing Setup Exhaust Supply 6” Flow Measurement Station, Averaging Pitot Tube, or Pitot TransferTube Magnehelic (0-.25 inwg) or Digital Manometer Table 11.1 HRV Balancing Table Sample HRV Installed Installed Menu...
-
Page 40: Lighting Boiler
Matrix Installation and Operation Instructions 12.0 LIGHTING BOILER 12.1 Initial Start-Up Ensure that the boiler is wired in accordance with this manual. Ensure that the gas shut-off valve is turned on, and that the gas system has been fully tested for leaks. -
Page 41: Trouble Shooting
13.0 TROUBLE SHOOTING This section is intended to assist the service technician in detecting and correcting common errors. The Matrix Boiler and Fan Controls are equipped with an internal diagnostic system that verifies control operation. The following series of error codes has... - Page 42 Matrix Installation and Operation Instructions Symptom Detected Problem Solution Check wiring connections between HRV and Fan Controller. Communication Error with HRV Check door switch on HRV. Cycle power to appliance; contact NTI. If plenum is hot, check operation of blower fan; contact NTI.
- Page 43 Matrix Installation and Operation Instructions Symptom Detected Problem Solution If the Burner light on the Sentry is going out, go to “ Burner shutting off ”. Check condensate drain for blockage and check the inlet piping for ingested Indicates lack of a flame signal. In Boiler will snow or water (if the flame rod gets wet, it may need to be replaced).
- Page 44 Matrix Installation and Operation Instructions Figure 13.1 M a trix Thermistor Resistance Chart 1 Mohm Water Prob e (Low Temp.) 2.25 1.75 1.25 0.75 0.25 Water Tem pe rature ( Figure 13.2 M atrix Thermistor Resista nce Cha rt 1 Mohm Water Probe (Hi Temp.) Wate r Te mperature ( Figure 13.3 Outdoor 10K probe...
-
Page 45: Sequence Of Operation
Matrix Installation and Operation Instructions 14.0 SEQUENCE OF OPERATION Figure 14.1 Matrix Boiler Control Sequence Of Operation 120v Power Displays version Boiler in Applied b1.0 standby mode Furnace Control Furnace Control Awaiting Input closes T-C circuit. closes A-C circuit. From Furnace Control... -
Page 46: Installation Checklist
Matrix Installation and Operation Instructions 15.0 INSTALLATION CHECKLIST Installation Connect all plumbing, and ensure that there are no system leaks. Connect, secure, and glue all vent piping. Install all gas piping as per this manual, and local codes. Pressure test, to detect any gas leaks. -
Page 47: Annual Maintenance And Inspection
May be required more frequently in beginning, especially if new Once every three months. construction. The Matrix HRV module is relatively maintenance free but does require routine cleaning. Table 14 describes the necessary maintenance. Table 16.1 HRV Maintenance Items Vacuum surfaces, let soak in warm water for three hours, spray... -
Page 48: Parts List
Matrix Installation and Operation Instructions 17.0 PARTS LIST Replacement parts are available from your stocking wholesaler. Homeowners must contact their local Installer or Wholesaler. Installers or Wholesalers may contact NY Thermal Inc. for assistance at 506-432-1130. P.N. Description 82657 Premix burner, 135.8... -
Page 49: Warranty
Matrix Installation and Operation Instructions 18.0 WARRANTY CAUTION A LICENSED AND TRAINED HEATING TECHNICIAN MUST INSTALL THIS BOILER OTHERWISE THE WARRANTY IS VOID. What is Covered. We the manufacturer, warrant that any parts or components of each new boiler will be supplied free of defects in material or workmanship. This warranty replaces any other warranty implied or expressed.
