Technical Specifications
Output power
(14.4v)
Output power
(Two TL-1023 amplifiers bridged)
Frequency response
Subsonic Filter Frequency Range
Low Pass Filter Frequency Range
Bass Boost Frequency Range
Input Impedance
Input sensitivity
Signal/Noise Ratio (A. Wtg)
1 Watt Reff.
Damping Factor (100 Hz @ 4 ohm)
Efficiency
Idle Current
Max Peak Current
Minimum Subwoofer impedance
Power supply
Dimensions:
(length x width x height)
Features
•
Class D monoblock subwoofer amplifier
•
Huge power output
•
Subsonic and Lowpass filters
•
Adjustable bass boost
•
N-Channel Circuit for high efficiency
•
Excessive heat, Reverse polarity, Short circuit and Input overload protection
•
Heavy-duty power supply
•
Heavy-duty aluminium heatsink
•
"Bass Kompressor" circuitry provides extra low-frequency enhancement
•
Easy bridging of two TL-1023 amplifiers
All content © Copyright TheLoudest.com 2008
OWNER'S MANUAL
1 x 3000 Watt Max
@ 1 ohm
1 x 1000 Watt RMS
@ 1 ohm
1x 500 Watt RMS
@ 2 ohm (THD+N < 2%)
1 x 300 Watt RMS
@ 4 ohm (THD+N < 1%)
Not possible
@ 1 ohm
1 x 2000 Watt RMS
@ 2 ohm
1 x 1000 Watt RMS
@ 4 ohm
10 Hz ~ 200 Hz
20 ~ 50 Hz (Adjustable)
40 ~ 180 Hz (Adjustable)
30 ~ 80 Hz (Adjustable 0-12 dB)
67 Kohm
0.2 V ~ 5 V
>100 dB
>120
82%
0.8 A
80 A
Using one TL-1023:
1 ohm
Using two TL-1023s:
2 ohm
DC 12V
58 x 210 x 277 mm
HIGH PERFORMANCE
CLASS D MONOBLOCK
SUBWOOFER AMPLIFIER
3,000 Watts Max @ 1 ohm
1,000 Watts RMS @ 1 ohm
OWNER'S
MANUAL
SAFETY GUIDELINES | TECHNICAL SPECIFICATIONS
FEATURES | INSTALLATION AND OPERATION INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TheLoudest.com Competition pro TL-1023
Summary of Contents for TheLoudest.com Competition pro TL-1023
-
Page 1: Technical Specifications
• Heavy-duty power supply • Heavy-duty aluminium heatsink • “Bass Kompressor” circuitry provides extra low-frequency enhancement • Easy bridging of two TL-1023 amplifiers SAFETY GUIDELINES | TECHNICAL SPECIFICATIONS FEATURES | INSTALLATION AND OPERATION INSTRUCTIONS All content © Copyright TheLoudest.com 2008... -
Page 2: Table Of Contents
OWNER’S MANUAL Contents Introduction Congratulations on your purchase of the Competition Pro TL-1023 subwoofer amplifier. After huge amounts of careful and detailed research, design, development and testing, TheLoudest.com are able to present a revolutionary range of premium car audio products. -
Page 3: Control Panel Functions
OWNER’S MANUAL OWNER’S MANUAL 6. Low Pass Filter (LPF) control – This knob controls the highest frequency range that is sent to the Control Panel Functions subwoofer(s). The range is adjustable, from 40 to 180 Hz with a third order slope of 18 dB per octave. The value that this should be set to changes depending on the subwoofer(s), enclosure and vehicle used. -
Page 4: Installation
Split charging relay. As mentioned above. Split charging relays usually used for boats or caravans are recommended. TheLoudest.com accepts no liability for any damage resulting to vehicle components when installing or operating the amplifier. It is the sole responsibility of the user to follow these instructions carefully and upgrade any vehicle components as required. -
Page 5: Bridging
OWNER’S MANUAL OWNER’S MANUAL Connect the remote gain controller to the amplifier. This is optional and not essential. The needs to be protected from damage. Failure to protect it from damage could lead to a plug will slot straight in to the “Remote” socket on the amplifier. The cable needs to be vehicle fire. -
Page 6: Safety
TheLoudest.com accepts no liability for hearing disorders, nausea or other side effects Source unit is not capable of Replace/upgrade source unit caused by this equipment.
