Congratulations! And thank you for choosing this car audio amplifier! To maximize the performance of this amplifier and your car audio system install, we recommend that you acquaint yourself thoroughly with all capabilities and features of the amplifier model you have chosen. Please read this manual carefully, before attempting the installation of this amplifier.
DESIGN FEATURES 4 CAR AUDIO AMPLIFIER : This amplifier allows the crossover controlled amplification of satellite speaker systems, kickwoofer or subwoofer systems 4 FULL-MOSFET CIRCUITRY : This amplifier line features a full MOS-FET circuitry layout, implementing MOS-FET's for power supply, to guarantee excellent sonic performance and very high power output 4 LOAD STABILITY : This amplifier line up features models that work stable and reliable into very low impedance loads.
CONNECTIONS & CONTROLS FRONT PANEL 1. RCA INPUTS 1/2-CH Low-level stereo RCA signal input for connection with head-unit.. 2.INPUT LEVEL CONTROL Input level control for amplifier section-allowing to match the output voltage of the head-unit's RCA line-outs to the amplifier input section. AMPLIFIER ACTIVE X-OVER SWITCH a) FULL: Allows for full range pass through.
Page 5
CONNECTIONS & CONTROLS REAR PANEL 6.POWER LED Green"Operation" LED, signaling correct operation of the amplifier. 7.PROTECTION LED Red "Protection" LED, signaling faulty speaker connections or general malfunction of the amplifier. 8."GND" POWER INPUT TERMINAL Terminal to connect the amplifier to the negative or ground pole of the car battery. 9."REM"...
AMPLIFIER MOUNTING Attention! For your own safety, disconnect the positive battery terminal (+12v) or remove the main fuse in the positive power cable near the car battery, before you start any wiring work! Before you proceed to install this amplifier, it is recommended to map out the complete audio system and the respective wiring required.
WIRING CONNECTIONS CAUTION: AS A PRECAUTION, IT IS ADVISABLE TO DISCONNECT THE VEHICLE'S BATTERY BEFORE MAKING CONNECTION TO THE +12 VOLT SUPPLY WIRING. 33/20/10mm² depending from the model(thicker if planning for additional amplifier) wire is recommended for both the power and ground wires. 12 Gauge, for the remote turn-on wire.
WIRING DIAGRAM 2 CHANNEL LINE INPUT LEVEL HIGH PASS FILTER x 10 FULL H.P.F 50Hz 500Hz (500Hz) (5kHz) 2 CHANNEL CLASS AB AMPLIFIER GND REM B+ CAR STEREO HEAD UNIT AUTO - ANTENNA LEAD CROSSOVER ADJUSTMENTS INPUT LEVEL ADJUSTMENT To reach a maximum in dynamic response from each individual head-unit/amplifier/ speaker combination, it is important to set the respective input level controls "GAIN"...
TROUBLE SHOOTING THE SYSTEM We have put together this trouble-shooting guide if you experience problems after installing the amplifier. Please keep in mind that the majority of problems incurred are caused by improper installation and not the equipment itself. In addition, there are many components in the system that could cause various signal problems such as inducted electrical noise and engine noise.
Page 11
SPECIFICATION AMPLIFIER 65X2 4OHM @ 0.08% THD STEREO RMS 100X2 2OHM @ 0.08% THD STEREO RMS 190X1 4OHM @ 0.08% THD MONO RMS EFFICIENCY 50Hz-5KHz HIGH PASS FILTER(VARIABLE) 10Hz-30kHz FREQUENCY RESPONSE (-1dB) >103dB SIGNAL TO NOISE RATIO (`A' WTD) 200mV - 6V INPUT SENSITIVITY 10k Ohms INPUT IMPEDANCE...
