Sling Shot is the latest technology in fast, small electric boating. Blow by the competition! You'll be
impressed with Sling Shot's speed and handling, even in rough water. Run it in the pool, it turns on a
dime! Run it at the lake, you'll be tearing it up, jumping the wake, and blowing larger, slower boats out
of the water! Look inside and you'll find a traditional, reliable R/C power and radio control system with
electronic speed control, servo and 380 size motor. Get ready to Sling Shot past the competition!
Includes 27Mhz FM Transmitter and 900mAH NiMH Battery
The MBP Sling Shot RTR is distributed exclusively by
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2004, Global Hobby Distributors
IMPORTANT
Before beginning assembly, please read and understand the warnings listed on the next page. Failure to do
so could lead to bodily harm and/or injury. The MBP Sling Shot RTR is not intended for those under 12 years of age, unless
closely supervised by an adult.
OPERATING INSTRUCTIONS
Global Hobby Distributors
Version V1.0 October 2004
SPECIFICATIONS AND FEATURES:
Length: 14 Inches (360mm)
Beam: 5 Inches (130mm)
Weight: 14.7 Ounces (420gr)
Completely Built and Ready-to-Run
2 Channel FM Proportional Radio Control System
Proportional Motor Control
380 Size "Black-Can" Electric Motor
6 Cell 900mAH NiMH Battery
110V AC Battery Charger
Easy-Access Rubber Hatch Cover
Kit Product #'s 151161, 151162 & 151163
1
Advertisement
Table of Contents
Summary of Contents for mbp Sling shot
- Page 1 Before beginning assembly, please read and understand the warnings listed on the next page. Failure to do so could lead to bodily harm and/or injury. The MBP Sling Shot RTR is not intended for those under 12 years of age, unless closely supervised by an adult.
- Page 2 We urge you to come check out our website at http://globalservices.globalhobby.com. There you will find public message boards frequented by other MBP product owners and the MBP support staff. This is a great place to learn about new MBP products, get help and suggestions for your current MBP products or just simply hang out and chat with people that share your same interests.
-
Page 3: Parts Identification
If you're missing a part, please contact us immediately, using the Customer Service Information listed on page # 2. RECOMMENDED ITEMS This section lists the items you will need to run and maintain your Sling Shot RTR. As you can see, there's not much to it! 8 Pack Trinity AA Alkaline batteries for the transmitter Part # 837801 Prather Lubricating Oil Part # 521047 ®... - Page 4 Main Hull: The main body of the boat. The hull is molded from lightweight, high-strength plastic. Electric Motor: Provides power to the boat. The Sling Shot RTR features a powerful "Black Can" 380-size motor to reach high speeds. Antenna: Receives the signals from the transmitter. Never cut the antenna shorter or you'll loose control of the boat after a very short distance.
-
Page 5: Step 2: Installing The Transmitter Batteries
ASSEMBLING YOUR SLING SHOT RTR STEP 1: INSTALLING THE TRANSMITTER ANTENNA Push the telescoping transmitter antenna down into the molded hole in the top of the transmitter. Thread the antenna (clockwise) into place and tighten it gently until it stops. -
Page 6: Checking The Controls
Carefully pull the molded rubber hatch cover off of the top of the boat and set it aside for now. Double-check that the boat's on/off switch is in the "OFF" position. BATTERY INSTALLATION TIP ® The battery is held in place using Velcro strips that are preinstalled into the bottom of the hull and onto the bottom of the battery. - Page 7 STEP 2: TURNING ON THE RADIO CONTROL SYSTEM Turn on the transmitter by moving the on/off switch into the "ON" position. Both LEDs should glow brightly. IMPORTANT Always turn on the transmitter before turning on the boat. This will prevent unwanted radio signals from interfering with the radio control system. If the green LED does not glow brightly or if ONLY the red LED is glowing, replace the transmitter batteries with new, fresh ones.
-
Page 8: Charging The Nimh Battery
While looking from the front of the boat (with the boat upside down), push the right/left turn lever to the left. The back edge of the rudder should pivot to the left. This will make the boat turn left. With the trim lever and the right/left turn lever both centered, verify that the rudder is centered. -
Page 9: Care And Maintenance
If the controls don't operate normally, don't drive the boat. Refer to the troubleshooting guide on page # 10. STEP 2: DRIVING THE SLING SHOT RTR After you've checked the controls and are satisfied that the range check has been completed successfully, set the boat in the water pointing away from shore. -
Page 10: Troubleshooting Guide
A) Replace propeller REPLACEMENT PARTS LIST MBP stocks the most popular replacement parts for your Sling Shot RTR. Listed below are the replacement parts that are available along with their respective part numbers for easy ordering convenience. We suggest ordering directly from your local MBP or Global dealer. If your local dealer does... - Page 11 If you enjoyed the fun and excitement of your MBP Sling Shot RTR, check out these other fun and exciting MBP Boats, the Offshore Flyer, Seamaster and Air Buggy. All three are Ready-to-Run and feature high-quality components and are designed for fast, exciting fun.
-
Page 12: Our Guarantee
IMPORTANT WARRANTY SERVICE INFORMATION Before returning your Sling Shot RTR for warranty consideration, the status of the unit must be within the guarantee as stated above. Do not return your Sling Shot RTR to the place of purchase. They are not authorized or equipped to perform warranty work on MBP products.
